Star Trac Inspiration Strength IP-B7506 User manual

MULTI-ADJUSTABLE BENCH
IP-B7506
OWNERS MANUAL

Table of Contents
Safety and warning information Pages 3-4
Warranty information Pages 5-6
Installation instructions Pages 7-9
Preventive maintenance Page 10
Warning Labels & Stickers Page 11
Page 2
Copyright 2010. Star Trac by Core Industries, Inc. All rights reserved, including those to reproduce this
book or parts thereof in any form without first obtaining written permission from Star Trac.
Every effort has been made to keep this information current; however, periodically, changes are made to
the information herein, and these changes will be incorporated into new editions of this publication. All
product names and logos are trademarks of their respective owners. Printed in the USA.

Inspiration safety and warning information
• It is the sole responsibility of the purchaser of Star Trac Inspiration Strength™ products to read the
owner’s manual, warning labels and instruct all individuals, whether they are the end user or
supervising personnel on proper usage of the equipment.
• It is recommended that all users of Star Trac Inspiration Strength™ exercise equipment be informed
of the following information prior to its use.
• Star Trac recommends that all commercial fitness equipment be used in a supervised area. It is
recommended that the equipment be located in an access controlled area. Control is the
responsibility of the facility owner. The extent of control is at the discretion of the owner.
Proper Usage
• Do not use any equipment in any way other than designed or intended by the manufacturer. It is
imperative that benches, racks and machines as well as any other Star Trac equipment are used
properly to avoid injury.
• Keep hands and feet clear at all times from moving parts to avoid injury.
• Read all machine warnings and seek the instruction of a qualified fitness professional prior to using
any Star Trac strength product.
• SECURING EQUIPMENT: All equipment MUST be secured (bolted and tightened) to a solid, level
surface to stabilize and eliminate rocking or tipping over. This must be performed by a licensed
contractor and meet Star Trac’s installation instruction requirements. The exception to this
requirement is portable Inspiration benches (benches that feature wheels for transport). These
portable benches can be bolted down but are not required to be secured to the floor.
Page 3
portable benches can be bolted down but are not required to be secured to the floor.
Check for damaged parts
• DO NOT use any equipment that is damaged and or has worn or broken parts. Use only replacement
parts supplied by Star Trac.
• MAINTAIN LABELS AND NAMEPLATES: Do not remove labels for any reason. They contain
important information. If unreadable or missing, contact Star Trac for a replacement.
• MAINTAIN ALL EQUIPMENT: Preventative maintenance is the key to smooth operating equipment
as well as keeping the product in safe operating condition. Failure to conduct preventative
maintenance by the owner may cause the product to operate in an unsafe manner. Equipment
needs to be inspected and maintained at regular intervals per the preventative maintenance
schedule provided in this manual.
• Ensure that any person(s) making adjustments or performing maintenance or repair of any kind is
qualified to do so. Star Trac will provide service and maintenance training at our corporate facility
upon request or in the field if proper arrangements are made.

Inspiration safety and warning information
Specific operating warnings
• Use only replacement components supplied by Star Trac Substitutes are forbidden and will void all
warranties.
• Do not allow users to wear loose fitting clothing while using equipment. It is also recommended to
have user’s secure long hair back and up to avoid contact with moving parts.
• Never attempt to release jammed components or parts.
• When adjusting any seat, knee stabilization pad, range of motion limiter, foothold pad or any other
type of adjuster, make certain that the adjusting pin is fully engaged in the hole to avoid injury.
• It is the purchaser’s sole responsibility to properly instruct its end users and supervising personnel as
to the proper operating procedures of all Star Trac equipment.
• Keep children away from selectorized strength equipment. Parent or others supervising children
must provide close supervision of children if the equipment is used in the presence of children.
• This equipment is not designed to be used by Children – injury may occur.
• UNDERSTANDING EACH AND EVERY WARNING TO THE FULLEST IS IMPORTANT. IF ANY OF
THESE WARNINGS ARE UNCLEAR, ASK FOR CLARIFICATION FROM STAR TRAC
PERSONNEL.
•
Injuries may result if exercising improperly or excessively. It is recommended that all individuals
Page 4
•
Injuries may result if exercising improperly or excessively. It is recommended that all individuals
consult a physician prior to commencing an exercise program. If at any time during exercise you feel
faint, dizzy or experience pain, stop and consult your physician.
• Do not exceed maximum the user weight of – 350 lbs.
• A complete set of artwork samples of Inspiration Strength™ user, caution and safety warnings can
be found in section 3 of this manual for review.

Warranty Coverage
Star Trac commercial exercise equipment (.Product.) is warranted to be free of all defects in material and
workmanship.
Star Trac warrants all structural frameworks for a period of 10 years. This limited warranty on structural
frame does not include coatings. The following moving parts are warranted for 5 years; rotary bearings and
structural moving parts. All unlisted parts handles and accessories are warranted for 1 year. Upholstery is
warranted for 6 months.
All warranty periods begin at the time of initial purchase from Star Trac.
Who is covered
The original purchaser or any person receiving the Product as a gift from the original purchaser.
Who pays for transportation and insurance for service
If the Product or any covered part must be returned to a service facility for repairs, Star Trac, will pay all
transportation and insurance charges for the first year. You are responsible for transportation and
insurance charges during the second and third years (if applicable).
What Star Trac will do to correct covered defects
We will ship to you any new or rebuilt replacement part or component, or, at our option, replace the
Product. Such replacement parts are warranted for the remaining portion of the original warranty period.
What is not covered
Any failures or damage caused by unauthorized service, misuse, accident, negligence, improper assembly
or installation, debris resulting from any construction activities in the Product’s environment, rust or
corrosion as a result of the Product’s location, alterations or modifications without our written authorization
or by failure on your part to use, operate and maintain the Product as set out in your Manual (.Manual.).
Page 5
All terms of this warranty are void if this product is moved beyond the continental borders of the United
States of America (excluding Alaska, Hawaii, and Canada) and are then subject to the terms provided by
that country’s local authorized Star Trac representative.
Owners Manual
It is very important that you read and review this manual before operating the Product. Remember to
perform the periodic maintenance requirements specified in the Manual to assure proper operation and
your continued satisfaction.
How to get parts and service
Contact Star Trac Customer Support Services Monday through Friday from 8:00 a.m. to 6:00 p.m. Pacific
Standard Time, and tell them your name, address and the serial number of your Product. They will tell you
how to get a replacement part, or, if necessary, arrange for service where your Product is located or advise
you on how and where to ship the Product for service.
Visit us on line at http://www.startrac.com/us-en/Support
Customer Services Hot Line: 1 800 503 1221
Fax: [phone]
[email protected]
International Customer Services: [phone]
Fax: [phone]
[email protected] or [e-mail]

Exclusive warranties
THIS LIMITED WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES OF ANY KIND EITHER
EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, AND ALL OTHER OBLIGATIONS
OR LIABILITIES ON OUR PART.
We neither assume nor authorize any person to assure for us any other obligation or liability concerning the
sale of this Product. Under no circumstances shall we be liable under this warranty, or otherwise, of any
damage to any person or property, including any lost profits or lost savings, for any special, indirect,
secondary, incidental or consequential damages of any nature arising out of the use of or inability to use
this Product. Some states do not allow the exclusion or limitation of implied warranties or of liability for
incidental or consequential damages, so the above limitations or exclusions may not apply to you.
Changes in warranty that are not authorized
No one is authorized to change, modify or extend the terms of this limited warranty.
Effects of state laws
This warranty gives you specific legal rights and you may have other rights, which vary, from state to state.
Our commitment to you
Our Products are designed, manufactured and verified to the highest industry standards.
We want you completely satisfied with our products and will do everything possible under the terms of this
warranty to meet and exceed your expectations.
Page 6

INSTALLATION INSTRUCTIONS
1• TORQUE WRENCH • • • • • • • • • • • • • • • • • • •• • • • • • • • • • • • • •• • • •
• • •
2• 13MM OPEN-END WRENCH • • • • • • • • • • • • • • • • • • •• • • • • • •
• •
1• 6MM HEX KEY SOCKET • • • • • • • • • • • • • • • • • • •• • • • • • • • • • • •
• •
REQUIRED TOOLS:
GENERAL NOTES:
• Unless otherwise noted Loctite 242/243 or equivalent thread locker must be used on all threaded fasteners. (Do not
use thread locker when a Nyloc nut is used.)
• All Star Trac Strength equipment MUST be secured to the floor using either 10mm or 3/8in. (grade 5 minimum) bolts.
To accommodate this there are mounting holes located on every foot.
• This Installation Instructions Manual must be used in conjunction with the equipment’s Owner’s Manual. The Owner’s
manual describes equipment setup and instructs members on how to use it correctly and safely.
THREAD LOCKER APPLICATION: Clean all threads and holes, apply no more than 3-4 drops per bolt.
Thru Holes Blind Holes
Page 7
Should any component not be present or if you have any operational questions, please refer to your owner’s manual or on
the web @ www.startrac.com . Specifically refer to your Inspiration serial number and model number labeled on your
equipment.
PACKAGING REMOVAL:
Carefully remove all packaging materials that wrap the equipment. DO NOT USE A KNIFE OR BOX
CUTTER AS YOU MAY DAMAGE THE EQUIPMENT. At this time remove any sub-components
from the box and set aside for later assembly.
Metric Steel Bolts Torque Specifications
Bolt Size Thread Pitch Torque, N-m (lbs-ft)
6mm 1.25 10-13.5 (8-10)
8mm 1.25 25.5-28.5 (19-21)
10mm 1.75 55.5-58 (45-48)
12mm 1.25 61-65 (45-48)
• Torque all hardware to values as specified above, unless noted otherwise.
• See Page 9 of this manual for fastener sizing information; for reference only.
• Note: All torque values are in N-m unless otherwise stated.

2. Locate the bottom bracket and align with
the holes in the rear support foot.
BENCH ASSEMBLY:
1. Place the Multi-Adjustable Bench upside
down and install the rear support foot as
shown. Note: The wheels need to face
outward.
Bottom
Bracket
Support
foot
3. Using four (M8,75mm,Socket Head Bolts)
eight (M8,Flat Washer) and four
(M8,Nylock,nuts) install as shown.
4. Using an M6 hex key and 13mm wrench
tighten the four M8 bolts using a criss-cross
sequence.
Page 8
MACHINE CLEARANCE AND SPACING
For the safe operation Star Trac recommends that a clearance of 48 inches (122cm) be maintained
between and behind equipment.
Before using this product, it is essential to read the ENTIRE operations manual and ALL
installation Instructions. The Owner’s manual describes equipment setup and instructs
members on how to use it correctly and safely.
Health related injuries may result from incorrect or excessive use of exercise
equipment. Star Trac strongly recommends you to encourage you and your members to
discuss their health program or fitness regimen with a health care professional,
especially if you or they have not exercised for several years, are over 35, or have
known health conditions.
WARNING!

HARDWARE GUIDE
Page 9

Preventative Maintenance & Cleaning
Cleaning
• Keeping your Inspiration units clean is an important component of preventative maintenance and the
overall aesthetics of your product. While your clients will appreciate clean equipment free of sweat, dirt
and other contaminants proper care and cleaning will extend the life of your product and reduce
premature aging and wear.
Page 10
• Upholstery should be cleaned daily with a mild soap and water mix or an approved antibacterial
cleaner.
• Hand grips should be cleaned daily with a mild soap and water mix or an approved antibacterial
cleaner.
• Main frame should be cleaned weekly with mild soap and water mix dampened cloth or an approved
antibacterial cleaner to remove all dust and accumulated contaminants.
• Caution should be taken to not leave excess moisture after cleaning.
• Note – do not use cleaners that contain solvents, alcohol or abrasives.
Inspection
• Visual inspection of your Inspiration units will insure a safe environment for your clients and alert you to
any issues that may require maintenance prior to equipment failure. Proper, timely visual inspection is
a critical component to the long term care of your product.
• Fasteners, hardware and attachments should be checked monthly for looseness. Tighten as required
using appropriate tools.
• Handgrips should be checked for wear or damage monthly and replaced as needed.
• Upholstery should be inspected for wear or damage monthly and replaced as needed.
• Main frame should be inspected every six months for signs of unusual wear, corrosion or structural
integrity issues.

Warning labels and communication stickers
The following pages show example of the Inspiration Strength™ warning labels and communication
stickers placed on the equipment as part of the manufacturing process. It is critical that owners maintain
the integrity and placement of these stickers. If you find any stickers missing or damaged each sample
indicated includes its corresponding part number so that replacements may be ordered.
Page 11

Page 12

Page 13

Part No. 620-8051, Rev A., 26 OCT 10
WORLD HEADQUARTERS
14410 Myford Road, Irvine, California 92606 USA
Tel [phone] Corp [phone] Fax [phone]
www.startrac.com
EUROPE HEADQUARTERS
Unit 4, The Gateway Centre, Coronation Road
Cressex Business Park, High Wycombe, Bucks HP12 3SU United Kingdom
Tel [phone] Fax [phone]
www.startrac.com/europe
ASIA HEADQUARTERS
No. 39A Jalan Pemimpin, Halcyon Building #01-02, Singapore 577183
Tel [phone] Fax [phone]
