Cortex LP-1 User manual

NOTE: This manual may be subject to updates or changes. Up to date manuals are available through our website at www.lifespanfitness.com.au
Product may vary slightly from the item pictured due to model upgrades
Read all instructions carefully before using this product. Retain this owner’s manual for future
reference.
LP-1 LEG PRESS
OWNER’S MANUAL

2
LP-1 Leg Press
TABLE OF CONTENTS
1. IMPORTANT SAFETY INSTRUCTIONS 3
2. PARTS LIST 4
3. ASSEMBLY INSTRUCTIONS 5
4. EXPLODED DIAGRAM 9
5. WARRANTY 10

3
LP-1 Leg Press
1. IMPORTANT SAFETY INSTRUCTIONS
WARNING - Read all instructions before using this machine.
Install the product on a flat level surface
Place your unit on a solid, level surface when in use
Never allow children on or near the machine.
Keep hands away from all moving parts.
Never drop or insert any object into any openings.
Care must be taken when lifting or moving the equipment so as not to injure your back. Always use
proper lifting techniques and/or seek assistance if necessary.
Keep children and pets away from the machine at all times. DO NOT leave children unattended in the
same room with the machine.
Only 1 person at a time should use the machine.
If the user experiences dizziness, nausea, chest pain, or any other abnormal symptoms, STOP the
workout at once. CONSULT A PHYSICIAN IMMEDIATELY
Do not use the machine near water or outdoors.
Keep hands away from all moving parts.
Always wear appropriate workout clothing when exercising. DO NOT wear robes or other clothing that
could become caught in the machine. Running or aerobic shoes are also required when using the
machine.
Use the machine only for its intended use as described in this manual. DO NOT use attachments not
recommended by the manufacturer.
Do not place any sharp objects around the machine.
Disabled person should not use the machine without a qualified person or physician in attendance.
Never operate the machine if the machine is not functioning properly.
A spotter is recommended during exercise.

4
LP-1 Leg Press
2. PARTS LIST
PART NO
DESCRIPTION
Q’TY
01
MAIN UPRIGHT FRAME
2
02
FRONT BOTTOM CONNECT TUBE
1
03
REAR BOTTOM CONNECT TUBE
1
04
BACK CUSHION TUBE
2
05
FRONT CROSS TUBE
1
06
HEAD CUSHION TUBE
1
07
TOP CONNECT TUBE
1
08
SLIDE TUBE
2
09
FOOT PLATE
1
10
OP TUBE
3
11
BACK CUSHION
1
12
HEAD CUSHION
1
13
FOOT CAP
5
14
SMALL BUFFER
3
15
BIG BUFFER
3
16
PIN
2
17
HEX BOLT M10*80MM
14
18
HEX BOLT M10*25MM
2
19
HEX BOLT M8*45MM
4
20
HEX BOLT M8*20MM
2
21
BOLT M8*10
3
22
WASHER φ10
36
23
WASHER φ8
6
24
NYLON LOCK NUT M10MM
22

5
LP-1 Leg Press
3. ASSEMBLY INSTRUCTIONS
STEP 1
1. Attach foot cap (13) to main upright frame (01).
2. Attach front bottom connect tube (02) and rear bottom connect tube (03) to main upright
frame (01) using hex bolt M10*80mm (17), washer φ10 (22) and nylon lock nut M10mm
(24).
3. Attach back cushion tube (04) to front bottom connect tube (02) and rear bottom connect
tube (03) using hex bolt M10*80mm (17), washer φ10 (22) and nylon lock nut M10mm (24).

6
LP-1 Leg Press
STEP 2
1. Attach foot cap (13) to front cross tube (05).
2. Attach front cross tube (05) to front bottom connect tube (02) using hex bolt M10*80mm
(17), washer φ10 (22) and nylon lock nut M10mm (24).
3. Attach head cushion tube (06) to front cross tube (05) using washer φ10 (22) and nylon
lock nut M10mm (24).

7
LP-1 Leg Press
STEP 3
1. Attach back cushion (11) to back cushion tube (04) using hex bolt M8*45mm (19) and washer
φ8 (23).
2. Attach head cushion (12) to head cushion tube (06) using hex bolt M8*20mm (20) and washer
φ8 (23).

8
LP-1 Leg Press
STEP 4
1. Attach slide tube (08) to main upright frame (01) using hex bolt M10*25mm (18) and pin (16).
2. Attach top connect tube (07) to slide tube (08) using washer φ10 (22) and nylon lock nut M10mm
(24).
3. Attach foot plate (09) to top connect tube (07) using washer φ10 (22) and nylon lock nut M10mm
(24).
4. Attach small buffer (14) to top connect tube (07).
5. Attach OP tube (10) to top connect tube (07) using bolt M8*10mm (21).
6. Attach big buffer (15) to OP tube (10).

9
LP-1 Leg Press
4. EXPLODED DIAGRAM

10
LP-1 Leg Press
5. WARRANTY
AUSTRALIAN CONSUMER LAW
Many of our products come with a guarantee or warranty from the manufacturer. In addition, they come with
guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or
refund for a major failure and compensation for any other reasonably foreseeable loss or damage.
You are entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure. Full details of your consumer rights may be found at www.consumerlaw.gov.au
Please visit our website to view our full warranty terms and conditions:
http://www.lifespanfitness.com.au/warranty-repairs
Warranty and Support:
Please email us at [e-mail] for all warranty or support issues.
For all warranty or support related enquiries an email must be sent to lodge a support case in our system.
Head Office and Customer Service:
Global Fitness and Leisure Pty Ltd
17 Fordson Rd
Campbellfield
VIC, 3061
Australia
PH: 03 9357 2166
