Staray ST-1033N User manual

Technical Reference:
Voltage: AC110-220V 50-60HZ
Power: 80w
Light source: 9 PCS*3W 3IN1；1PCS*30W 3IN1
Channel: 6CH
Control mode: auto, sound, master-slave, DMX512
Material: Plastic
LED Stage Lighting Operating Manual
9+1 Digit PAR Light RGB
RGB 3IN1 PAR
Please Read Over This Manual before Operating the Light Fixture

Thank you so much to choose this product; it is adopting the most advanced
lamps, which is called LED lamps. It conquers a lot of disadvantages such as
power wasting, short using life, high temperature, etc. It has advantages of
power saving, long life (it can reach 60,000.00 hours in general circs), high
brightness, fresh colors…It is the best stage illuminating and various effect
decorative products.
Security:
1. Make sure the user voltage cannot higher or lower than the regulate
value of the user manual.
2. Please take more attention while installing the fixtures. Avoid touching
exposed AC cord, or will cause deadly accident.
3. When installing the fixtures, make sure the fixtures are not exposed in
extremely hot, humid or dusty environment. Make sure the distance
between the fixture and the lighted object is not less than 0.5 meter.
Make sure there is no combustible or explosive object around 0.5
meters.
4. Please operate the light fixture after becoming very familiar with the
functions. In most cases, the light fixture will be broken by incorrect
operation. It won’t allow laypeople to operate this light. Don’t shake or
anything rudely to the light fixture, or it will cause problems.
DMX512 Control：
6Channel Model
Channel Channel data Function instruction
CH1 0-255 Master dimming
CH2 0-255 Red dimming
CH3 0-255 Green dimming
CH4 0-255 Blue dimming
CH5 1-255 Strobe control
CH6 1-255 Master function + sound control
D001 D512
AuxxAu01
Digital Par User Manual
Au02
Au03
RED
GREEN
BLUE
Au04
Au05
Au06
RED+GREEN
GREEN+BLUE
RED+BLUE
Au07
Au08
Au09
RED+GREEN+BLUE
RED+BLUE
Au01- Au07
Au10
So01
So02
Gradual change
Sound control leaping change
Sound control, strobe
St00 St00 Auto motor no strobe
St01 St16
SP00 SP16
R000 r255 RED bri
g
htness settin
g
G000 G255 GREEN brightness setting
B000 B255 BLUE brightness setting
DMX model
Auto motor strobe, speed from slow to fast
Auto motorAu08 Au09 Au10 speed from fast to slow
