Staray ST-1033 User manual

Technical:
Voltage: AC110-220V, 50-60HZ
Power: 100W
Channel: 8CH
Light power: 9pcs*10W R,G,B,W 4IN1 led
Material: plastic
Control mode: DMX512, sound, auto, master-slave
LED Stage Light Equipment User Manual
LED DIGITAL PAR LIGHT
■9pcs RGBW４in1
Please Read Over This Manual before Operating the Light Fixture

Diagram Instruction
A：Function Selection Key
B：Plus Key
C：Minus Key
D：Confirm Save Key
OOOO
A B C D
DMX-512 Function Instruction 8 Channels-modify CH7 allows device synchronization）
Device Feature Setting
DISPLAY Function Instruction
D001 all numbers DMX512 mode, master-slave
synchronization mode B，C Key to modify the address code value
（001-512）
HOST or SLAV signal condition
setting, B.C Key
modify setting
HOST Host running when signal output
SLAV No signal out put；master-slave
synchronization mode set as” SLAV”
EO。01 each
group setting as
the actual total
Follow strobe mode total units
setting
（follow strobe mode parameters
requires）
B，C key to modify to total units of the follow
strobe devices（01-32 units）The
equipment involved in follow strobe
Each group is set according to the actual
gross (total number of units must all be set to
the same value)
E-。01 each group
setting as the
actual place
Follow strobe mode total number
setting
（follow strobe mode
parameters requires）
B，C key to modify to numbers of the follow
strobe devices （NO.01-32）values do not
repeat, can not exceed the total maximum
number of units Valley Equipment
EE．00 Follow strobe mode: There are
23 kinds of effects can choose
(please set the total number of
units and number)
B，C Key to modify the effect of follow strobe
（0-22）0-8：choose 1 from 9 colors；
9-21：choose 1 from 13 effects 22：
recycle effects
T．0-255 Follow strobe speed setting B，C Key to modify the speed of follow
strobe
A．0-255 4 colors hopping mode
B，C Key to modify the change speed of LED
（from slow to fast）
C．0-255 full color hopping mode
J．0-255 full color gradient mode
L．0-255 variable pulse mode
N．0-255 hopping, gradient, variable pulse
modes combination
P．0-255 gradient strobe mode
（built fixed fast strobe）
1S . 0-20 Sound mode 1: voice strobe B，C Key to modify Sound Sensitivity（0-
20）
2S．0-20 Sound mode 2：Voice hopping
R．0-255 Color selection mode：red dimming
setting
B，C Key to modify colors selection（0-255）
（No strobe）
G．0-255 Color selection mode：green dimming
setting
B．0-255 Color selection mode：blue dimming
setting
W. 0-255 Color selection mode：white dimming
setting
F．0-255 Strobe model B，C Key to modify the speed of colors
selection and strobe
8.8.8.8.
Cha
nnel Value Function Instruction
CH1 0--255 Total dimming
CH2 0--255 （RED）dimming
CH3 0--255 （GREEN）dimming
CH4 0--255 （BLUE）dimming
CH5 0--255 （White）dimming
CH6 0 No strobe
1-255 Strobe speed from low to fast
CH7
0 macro
function off CH1-CH6 channel color selection modes on（CH6 strobe setting）
1-255
macro
function
effectively;
CH1-CH6
Function
off
1—29 ：4 colors hopping mode
30—59 : full color hopping mode
60—89 ：full color gradient mode
90—119: variable pulse mode
120-149: hopping, gradient,
variable pulse modes combination
150-179 :gradient strobe mode
（built fast strobe）
180—--199 save disabled
246—250 sound mode—
hopping sound control
251--255 sound mode—
strobe sound control
200-245 follow strobe
mode:23 different selections
（please set the total
numbers of the units and
numbers ）
200-229 choose 1 colors
from 9
230-243 choose 1 colors
from 13
244-245 recycle effect
CH8 0-255 Macro LED speed from low to fast
