Staray ST-1013 Mounting instructions

1
230W BEAM LIGHT
USE MANUAL

2
PLEASE READ THIS CAREFULLY BEFORE USE
WARNINGS :please read these instructions carefully before installation
1. Inspect the device carefully before installtion in case of loose during transportation.
2. Don’t put the product on the shakable or moist place.
3 .Please keep the voltage stable, otherwise it will will destroy the parts easily.
4. Check the voltage before turning on lamp. While power off, it needs 15minutes to cool
before reconnecting the power.
5. Please keep the lamp dry and cool, .avoid working at 40or above to guarantee its
lifespan.
6 .Disconnect the power before installation or removing and ask professional technician to
repair in case of malfunction.(Check fuse tube first).
Skill parameters
Voltage:AC100V-240V 50/60HZ
Light source: Philips MSD 230W
Power consumpton:350W
Channel:16CHs
Color:14 colors & white
Gobo:17 gobos & white
Strobe:0-10 tomes/second
X axis:540 degrees
Y axis:270 degrees
Display:LCD or digital for choice
Protection:IP20 over heat protction
Prism: 8-facet prism
Package size:46*42*55cm
N.W:16KG G.W:18KG
16 Channels Control Illustration
CHANNEL CHANNEL MODE
16 20
1 COLOUR WHEEL COLOUR WHEEL
2 STOP/STROBE STOP/STROBE
3 DIMMER DIMMER
4 STATIC GOBO CHANGE STATIC GOBO CHANGE
5 PRISM INSERTION PRISM INSERTION
6 PRISM ROTATION PRISM ROTATION
7 EFFECTS MOVEMENT
(UNUSED) EFFECTS MOVEMENT (UNUSED)

3
8 FROST FROST
9 FOCUS FOCUS
10 PAN PAN
11 PAN FINE PAN FINE
12 TILT TILT
13 TILT FINE TILT FINE
14 FUNCTION (UNUSED) FUNCTION (UNUSED)
15 RESET RESET
16 LAMP CONTROL LAMP CONTROL
17 PAN-TILT TIME
18 COLOUR TIME
19 DIMMER-PRISM-FROST TIME
20 GOBO TIME
COLOUR WHEEL - channel 1
BIT EFFECT
255 FAST ROTATION
…… ……
150 SLOW ROTATION
145 BLUE + WHITE
140 BLUE
135 CTB 8000 + BLUE
130 CTB 8000
125 CTO 190 + CTB 8000
120 CTO 190
115 CTO 260 + CTO 190
110 CTO 260
105 CYAN + CTO 260
100 CYAN
95 MAGENTA + CYAN
90 MAGENTA
85 YELLOW + MAGENTA
80 YELLOW
75 PINK + YELLOW

4
70 PINK
65 LAVENDER + PINK
60 LAVENDER
55 LIGHT GREEN + LAVENDER
50 LIGHT GREEN
45 GREEN + LIGHT GREEN
40 GREEN
35 AQUAMARINE + GREEN
30 AQUAMARINE
25 ORANGE + AQUAMARINE
20 ORANGE
15 RED + ORANGE
10 RED
5 WHITE + RED
0 WHITE
STOP/STOBE - channel 2
BIT EFFECT
252-255 OPEN
239-251 RANDOM FAST STROBE
226-238 RANDOM MEDIUM STROBE
213-225 RANDOM SLOW STROBE
208-212 OPEN
207 FAST PULSATION
…… ……
108 SLOW PULSATION
104-107 OPEN
103 FAST STROBE
…… ……
4 SLOW STROBE
0-3 CLOSED
DIMMER - channel 3
BIT EFFECT
255 100%
…… ……
0 0%
STATIC GOBO CHANGE - channel 4

5
BIT EFFECT
255 GOBO 17 SHAKE, FAST SPEED
…… ……
251 GOBO 17 SHAKE, SLOW SPEED
250 GOBO 16 SHAKE, FAST SPEED
…… ……
246 GOBO 16 SHAKE, SLOW SPEED
…… ……
180 GOBO 2 SHAKE, FAST SPEED
…… ……
176 GOBO 2 SHAKE, SLOW SPEED
175 GOBO 1 SHAKE, FAST SPEED
…… ……
171 GOBO 1 SHAKE, SLOW SPEED
170 FAST ROTATION
…… ……
135 SLOW ROTATION
130-134 STOP
129 SLOW ROTATION
…… ……
90 FAST ROTATION
85 GOBO 17
80 GOBO 16
75 GOBO 15
70 GOBO 14
65 GOBO 13
60 GOBO 12
55 GOBO 11
50 GOBO 10
45 GOBO 9

6
40 GOBO 8
35 GOBO 7
30 GOBO 6
25 GOBO 5
20 GOBO 4
15 GOBO 3
10 GOBO 2
5 GOBO 1
0 WHITE
PRISM INSERTION - channel 5
BIT EFFECT
128-255 PRISM INSERTED
0-127 PRISM EXCLUDED
PRISM ROTATION - channel 6
BIT EFFECT
255 FAST ROTATION
…… ……
193 SLOW ROTATION
191-192 STOP
190 SLOW ROTATION
…… ……
128 FAST ROTATION
0-127 POSITION
EFFECTS MOVEMENT - channel 7 (NOUSED)
FROST - channel 8
BIT EFFECT
128-255 FROST INSERTED
0-127 FROST EXCLUDED
FOCUS - channel 9
BIT EFFECT
255 100%
…… ……
0 0%
PAN - channel 10
PAN FINE - channel 11
TILT - channel 12

7
TILT FINE - channel 13
FUNCTION - channel 14 (NOUSED)
RESET - channel 15
BIT EFFECT
128-255 COMPLETE RESET
77-127 PAN/TILT RESET
26-76 EFFECTS RESET
0-25 UNUSED RANGE
LAMP CONTROL- channel 16
BIT EFFECT
101-255 LAMP ON
10-100 LAMP OFF
0-9 UNUSED RANGE
TIMING CHANNELS
Timing Channel Channel function
17 Pan-Tilt time Pan-Tilt-(Pan fine-Tilt fine)
18 Colour time Colour wheel
19 Beam time Dimmer-Prism -Frost
20 Gobo time Static Gobo
CERTIFICATE OF WARRANTY
Service & Warranty REGISTRATION
Name: Tel:
Add:
Model: Serial No:
PurchaseNo:
InvoiceNO: Date:
Thevendorkeepsthiscard
Signature by customer
