StarLeaf Pronto 210 User manual

Before installing Pronto 210, read the safety and compliance information at:
support.starleaf.com/safety
All the components and cables you need for this installation are included in the box
Pronto Cable USB
Hub 20
HDMI EthernetUSB-A USB-A
Network Power supply
Room screen
Keypad
How to install Pronto 210
1. Screw both antennas into Hub 20. If you want to place
Hub 20 behind a room screen, make sure that there is
enough space
2. Connect the network, room screen, and keypad to
Hub 20. Connect Pronto Cable USB to enable wired
sharing for your meeting room
3. Connect the power supply to Hub 20. It may take a
few minutes to initialize
4. Enter the QuickConnect code using the keypad. To
generate the QC code, admins must add Hub 20 to
their StarLeaf Portal
5. When provisioning is complete, your room screen will
display the idle instructions screen until content is
presented
Antenna Antenna
How to generate a QuickConnect code
1. Go to the Room Systems page on your Admin portal
and click Add room system
2. Complete all required fields and ensure you select
StarLeaf Hub 20 in the Hardware endpoint section
3. Click Apply. The QC code appears in the Hardware
endpoint section
StarLeaf Pronto 210 Installation Guide
For more help with any StarLeaf product, go to: support.starleaf.com Copyright © StarLeaf March 2020

Hub 20
HDMI*USB-A
Network Power supply
Keypad
Antenna Antenna
Touch 2045 controller
GT Mini 3330
1. Screw both antennas into Hub 20. If you want to place
Hub 20 behind a room screen, make sure that there is
enough space
2. Connect the network, room screen, and keypad to
Hub 20.
3. Connect Hub 20 to the Computer In DVI-I port of
your room system’s codec using the HDMI cable and
DVI-I adaptor provided
4. Connect the power supply to Hub 20. It may take a
few minutes to initialize
5. Enter the QuickConnect code using the keypad. To
generate the QC code, Admins must add Hub 20 to
their StarLeaf portal
6. When provisioning is complete, the room screen will
turn to the idle screen until content is presented
How to install (with GT Mini 3330)
Ethernet
*Use the DVI-I adapter to connect the HDMI cable to the codec
How to generate a QuickConnect code
1. Go to the Room Systems page on your Admin portal
and click Add room system
2. Complete all required fields and ensure you select
StarLeaf Hub 20 in the Hardware endpoint section
3. Click Apply. The QC code appears in the Hardware
endpoint section
The following installation shows how to add wireless sharing to a
StarLeaf room system which has GT Mini 3330 and Touch 2045
already installed
StarLeaf Pronto 210 Installation Guide
For more help with installing wireless sharing into any room system go to: support.starleaf.com 480-00360-01
