starlight SL-7000 User manual

OPERATING MANUAL
Universal
Remote
Control
Model: SL-7000
All manuals and user guides at all-guides.com
all-guides.com

Thank you for purchasing the Star Light universal remote control.
This unit was desingned to fully complement your home entertainment
system. Any comments or questions about this product should be
directed to Universal Remote Control, Inc., New Rochelle, NY 10801.
You can also call our toll-free Customer Service Line at
1-800-901-0800 for any assistance.
Please read this instruction manual carefully.
The Star Light universal remote control has many advanced features
that can add enjoyment and convenience during its use. Keep these
instructions for future reference.
2
All manuals and user guides at all-guides.com

Table of Contents
Introduction ...............................................................
4
Battery Installation ...................................................
5
Programming the Remote
.........................................
6 7
A. Quick Set-Up
C. Standard Set-Up
Advanced Features
......................................................
8 12
A. Code Number Recall
B. Storing Multi-Commands/Favorite Channels to emory Buttons
C. Assigning Device Codes to other Device Buttons
D. Punch-Through TV Volume Control
E. Punch-Through VCR Control
Satellite key pad Information
.........................................
13
Hidden Buttons
..........................................................
13
Glossary .................................................................... 13
Warranty and Specifications
...........................................
14
Three Digit Code Lists .................................................. 15 30
A. TV Codes
B. VCR Codes
C. CATV Codes
D. SAT Codes
E. Audio Codes
F. Aux Codes
Satellite Functions by code
............................................. 31~44
Page
3
All manuals and user guides at all-guides.com

INTRODUCTION
The Star Light universal remote control can replace or consolidate up to six (6)
of your remote controls. It is already preprogrammed, so there is no need to
have your original remote. The Star Light universal remote works with virtually
all IR (Infrared) equipment, including : TV' s, VCR's, Cable Boxes, Satellite
Receivers, Compact Disc Players, A/V Receivers, Cassette Decks, and many other
audio /video components.
4
All manuals and user guides at all-guides.com

Battery Installation
The Star Light remote control is powered by four AAA batteries(included). Please
be sure to match the (+) and (-) on the batteries to the (+) and (-) marking inside
the battery compartment.
Battery Compartment Cover Removal
To remove the battery compartment, located on the rear of the remote, press down
and push forward toward the top of the remote control.
To close the battery compartment cover, slide the cover straight back until it clicks
into place.
Diagram for opening and closing of the battery cover is shown below.
Note :
When changing batteries, please replace the new batteries within ten minuites.
Otherwise, resetting of your codes may be required.
5
All manuals and user guides at all-guides.com

Programming the Remote
A. Quick Set-Up:
Step 1: Turn on the device (TV, VCR,CABLE BOX, SATELLITE RECEIVER,etc .)
you wish to operate.
Step 2: On the remote control, press the corresponding DEVICE button
(TV, VCR, CATV , SAT, etc.) and MUTE button simultaneously.
Note: SET will appear in the LCD.
Step 3: Point the remote control toward the device. Punch in the first three digit
code number assigned to your brand from the brand code lists located on
pp.(15 30).The device will turn off when the correct code has been selected.
Step 4: Once the device turns off, press the corresponding DEVICE button again
to store the code.
Note: LCD will flash PASS indicating that the code has been
stored.
Step 5: Test the remote control functions with the code that was just stored.
If any of the buttons do not perform as they should, please repeat from
Step 2 using the next three digit code number for your brand of equipment.
6
All manuals and user guides at all-guides.com
all-guides.com

Programming the Remote,( Continued )
7
C. Standard Set-Up:
Step 1: Turn on the device ( TV, VCR, Cable Box, Satellite Receiver, etc. ) that you
wish to operate.
Step 2: On the Star Light universal remote control, press the corresponding
DEVICE button (TV, VCR,CATV, SAT,Audio,or Aux) and the MUTE
button simultaneously.
Note: SET will appear in the LCD.
Step 3: Locate the three digit code number for your brand of equipment from the
code lists found on pp. (15 31). Example: TV codes-Sony 001,003,etc.
Note: If the brand list contains more than one code number,
select the first code listed.
Step 4: Point the remote control at the devise turned on in Step1and press in the
three digit code number selected in Step 3.
Note: SET # # # will appear in the LCD.
Your device will turn off when the correct code has been selected. If the
device fails to turn off, go back to Step 3 and select the next three digit
code for your equipment, and press in the code number.
Note: Repeat the above step until the device turns off. When
the device turns off proceed to Step 5.
Step 5: Press the DEVICE button (TV, VCR, CATV, SAT, Audio, Aux) on the
remote control to store the three digit code that turned off your equipment.
Note: PASS will flash in the LCD indicating that the code has
been stored.
Step 6: Test the remote control functions with the code just stored.
Example: Power, Channel Up, Volume Up, etc. If any of the buttons do not
perform as they should, please repeat from Step 2using the next three digit
code until the right code is found.
Step 7: To program other devices into the corresponding Device button of the
remote control, repeat the above steps with the respective devices and Device buttons.
All manuals and user guides at all-guides.com

Advanced Features
A. Three Digit Code Number Recall:
If you wish to find a code number that has been stored in your remote control,
please use the following steps:
Step 1:
On the remote control, press the DEVICE and MUTE buttons simultaneously.
Note: SET will appear in the LCD.
Step 2: Press the INPUT button. The LCD will flash the three digit code number
for five seconds before returning to its original sate.
B. Storing Multi-Commands/Favorite Channels to Memory Buttons
Memory buttons M1, M2, M3and M4can be set up to store up to six(6) commands
with one button push. Any functions, in any Device mode (except Channel up and
Channel down), can be stored in any one of the four memory buttons.
This will enable you, for example, to turn on the TV and Satellite receiver and select
a preassinged satellite channel with only one button push.
Method of setting up:
Step 1: Press the Device button (TV, VCR, CATV, SAT, AUX, AUDIO) and MUTE
button, simultaneously.
Note: SET will appear in the LCD.
Step 2:
Press one of the memory buttons(M1-M4) that you would like to designate
for multi-command or favorite channel operation.
Note: M (1-4)will appear in the LCD. The memory button
is now ready to be set up.
Step 3: Press up to six commands that you would like to store in the memory button.
Note: Each successive selection will appear as 1~6 in the LCD.
Step 4: Press the Channel(+) button to store your selection.
Note: SAVE will flash twice and the Device mode will appear in the LCD.
Please repeat the above steps for the remaining memory buttons.
8
All manuals and user guides at all-guides.com

Example:
Memory button M1in the SAT mode can be set up to do the following functions: to turn on
the Satellite receiver, select channel #18 on the satellite receiver, and then turn on the TV.
Step 1:Press the SAT and MUTE buttons, simultaneously.
Note: SET will appear in the LCD.
Step 2
: Press memory button M1.
Note: M 1will appear in the LCD.
Step 3
: Press the Power buttons (to turn on the satellite receiver).
Note: M 1 1 will appear in the LCD.
Press the # 1button (to select the first digit of channel # 18)
Note: M 1 2 will appear in the LCD.
Press the # 8 button (to select the second digit of channel # 18)
Note: M 1 3 will appear in the LCD.
Press the TV Device button (to select the TV Device mode).
Note: M 1 4 will appear in the LCD.
Press the Power button (to turn on the TV).
Note: M 1 5 will appear in the LCD.
Step 4
: Press the Channel (+)button to store the above commands.
Note: SAVE will flash and the current Device mode will appear.
Now, anytime the memory button M1is pressed while the remote control is in the
SAT mode, the commands to turn on the Satellite receiver, select the Satellite channel
#18 and turn on the TV, will be sent out by the remote control.
Memory buttons can be used in any combination you select.
Note: Any previously stored multi-commands on a memory button will be erased
when new multi-commands are stored to that same memory button.
9
All manuals and user guides at all-guides.com

C. Assigning Different Device Codes to other Device Buttons
This feature can be used to program the remote control for more than one TV, VCR,
Satellite Receiver, etc. The three digit code for any device can be stored in any of the
DEVICE buttons. For example: For two VCRs, the first VCR can be stored in the VCR
DEVICE button under normal set up procedures, and the second VCR can be
programmed into the unused CATV or any other DEVICE button.
Step 1: Turn on the device you wish to operate.
Step 2: On the remote control, press the DEVICE button you wish to assign this
device to, and the MUTE button simultaneously.
Note: SET will appear in the LCD.
Step 3: Press the DEVICE BUTTON that corresponds to the actual device you plan
to operate.
Note: SET will appear in the LCD.
Step 4: Select the three digit code number from the code list found on pp.
(15 30) for the device you will be operating
Step 5: Point the remote toward the device, and press in the three digit code
number.
Note: SET # # # will appear in the LCD.
Step 6: The device will turn off when the correct three digit code number has been
selected. Press the DEVICE button selected in Step 2. This will store the three
digit code into that DEVICE button.
Note: PASS will flash in the LCD.
Advanced Features (Continued )
10
All manuals and user guides at all-guides.com

Advanced Features
(
Continued
)
D. Punch Through TV Volume Control
After setting up the remote control to work with your respective TV, VCR, CATV, Satellite
equipment, etc., the remote control can also be set up so that theTV volume control will
supersede respective equipment volume control, even when the remote control is in a
different Device mode.
Step 1 : Press the DEVICE button (VCR, CATV, SAT, etc.)and MUTE button
simultaneously.
Note: SET will appear in the LCD
Step 2: Press the VOLUME (+) button.
Note: TV-O will appear in the LCD.
Example: To set up TV volume to replace the satellite receiver volume in the SATmode.
Step 1: Press the SAT and MUTE buttons, simultaneously.
Note: SET will appear in the LCD.
Step 2 : Press the VOLUME (+) button
Note: TV-O will appear in the LCD.
TV volume will now operate in the SAT mode.
To return to the original volume control setting.
Step 1 : Press the DEVICE button(VCR,CATV,SAT,etc.) and MUTE button, simultaneously.
Note: SET will appear in the LCD.
Step 2 : Press the VOLUME(+) button.
Note: TV-X will appear in the LCD.
The TV volume Punch Through for the selected device mode is
now deactivated.
11
All manuals and user guides at all-guides.com
all-guides.com

Advanced Features
(
Continued
)
E. Punch Through VCR Controls.
After setting up the remote control to work your respective TV, VCR, CATV, Satellite
equipment, etc, the remote control can also be set up so that the VCR control buttons
(PLAY, STOP, FAST FORWARD, REWIND, PAUSE, and RECORD) will operate (VCR
controls), even when the remote is in a different Device mode.
For example, you can control your VCR while in the CATV mode, eliminating the need to
switch between CATV and VCR modes to operate your VCR.
Step 1 : Press the DEVICE button (TV, CATV, SAT, etc.) and MUTE button, simultaneously.
Note: SET will appear in the LCD.
Step 2: Press the VOLUME ( ) button.
Note: VCR-O will appear in the LCD.
VCR
controls ( PLAY, STOP, FF, REW,PAUSE , and RECORD)
will now operate in the mode selected in Step 1.
To return to the original state.
Step 1: Press the DEVICE button ( TV, CATV, SAT, etc.) and MUTE button,
simultaneously.
Note: SET will appear in the LCD.
Step 2 : Press the VOLUME(-) button.
Note: VCR-X will appear in the LCD.
The VCR Punch Through for the selected mode is now deactivated.
12
All manuals and user guides at all-guides.com

Satellite key Pad Information
Many satellite receivers have a letter/ number assignment for satellite names and
numbers. Since these assignments differ from one satellite manufacturer to another,
we have listed the corresponding letter/ number designation by code on
pages(31~44) Please copy the letters assigned to your code onto the peel off label
we have included Place this label on the back of the remote control for future use.
Hidden Buttons
13
Device:
Audio and /or video equipment (Example: TV, VCR, Compact Disc, etc.) that is
being controlled by the remote control.
Device Buttons:
Blue buttons located at the top of the Star Light remote control labeled
TV, VCR, CATV, SAT, AUDIO, AUX.
Device Modes:
Operating modes displayed as TV, VCR, CABLE, AUDIO, AUX, or SAT in the LCD
indicating the device the remote control is ready to operate.
LCD:
Liquid crystal display screen at the top of the Star Light Remote. The LCD displays
the device mode in normal operation. The LCD is also used in Set Up to program
the Star Light Remote.
Three Digit Code:
Preprogrammed list of three digit numbers that corresponds to manufacturer's
equipment.
Glossary
Eight (8) additional buttons are located beneath the VIEW, -, +, AMT, M1, M2, M3 and
M4 buttons. They are NEXT, MESS, SET-UP, HELP, P.L, AUTO, T.I, and A/B buttons.
To acess these hidden buttons, please lift up the cover by releasing the latch alonmg
the top, right side of the remot.
All manuals and user guides at all-guides.com

Warranty
Specifications
The Star Light remote control comes with a one year warranty from date of purchase.
MODEL : SL-7000
BATTERY: Four 1,5 AAA Battery
DIMENSION: (H x W x D) 8.88" x 2.75" x 1.25"
WEIGHT: 6.6 oz. (with batteries)
14
All manuals and user guides at all-guides.com

Three Digit Code Lists
AKAI
112 143
A MARK
001 146
AMPRO 167 073
AMSTRAD 052
ANAM 043 054 056 080 104 108 112 115 118 121 131
AOC 001 004 112
BLAUPUNKT 088
CANDLE 001 002 003 004
CAPEHART 058
CETRONIC 043
CITIZEN 001 002 003 004 043 101 103 143
CLASSIC
CONCERTO
043
004
CONTEC 039 043 050 051
CORONADO 143
CRAIG 043 054
CROWN 043 143
CURTIS MATHES 001 101 116 143
CXC 043
DAEWOO 004 016 017 043 044 055 071 076 103 107 111
114 117 120 123 125 127 128 136 143
DAYTRON 116 143
DYNASTY 043
DYNATECH 062
ELECTROHOME
EMERSON
007 143
028 048 043 155 005 096 047 116 153 154 051
143 151 001 050
FISHER 077 057
FUNAI 028 043
FUTURETECH 043
GE 160 144 165 161 073 130 001 008 009 034 056
074 004 155 091
TV
15
Maker (Brand) Name Code Number (3 digit) List
All manuals and user guides at all-guides.com

Three Digit Code Lists
GOLDSTAR 102 106 110 112 113 116 119 122 127 137 143
HALL MARK 116
HITACHI 011 163 166 158 143 004 010 012 023 075 001
009 041
INFINITY 164
INKEL 129
JBL 164
JCPENNY 001 008 030 065 101 160 004 024 143 009 156
JENSEN 013
JVC 038 083 145 034
KEC 043
KENWOOD 001
KLOSS 002 059
KMC 143
KTV 043 001 143 154
LODGENET 072
LOGIK 072
LUXMAN
LXI
004
166 007 015 164 160 081 052
MAGNAVOX 164 059 001 003 060 061 063 064 160 004 143
127
MARANTZ 001 164 077
MATSUI 164
MEMOREX 007 072 116
METZ
MGA
MINERVA
088
001 004 028 042 049 077 116
088
MITSUBISHI 109 024 124 001 004 040 146 028 042
MTC 001 101 004 062
NAD 015 025
NEC 132 130 134 001 040 016 024 056 007 019
NIKEI 043
TV
16
Maker (Brand) Name Code Number (3 digit) List
All manuals and user guides at all-guides.com
all-guides.com

Three Digit Code Lists
ONKING 043
ONWA 043
OPTONICA 019 081
PANASONIC 034 080 092 056 164
PHILCO 001 003 024 056 059 060 063 064 164 004 143
043 127
PHILIPS 164 038 070 093 001 003 004 143 059 160
PIONEER 135 025 023 001 018 116 027
PORTLAND 004 143
PROSCAN 144
PROTON 004 131 143 058 171
QUASAR 034 092 056
RADIO SHACK 019 043 047 116 127 143
RCA 160 161 165 065 156 144 001 004 023 024 056
074 152
REALISTIC 007 019 043 047
RUNCO 168 169
SAMPO
SAMSUNG
001 058 116
050 089 101 105 113 116 127 133 137 143 160
SANYO 166 007 057 082 020 053 021 033 039
SCOTT 028 043 116 143 048
SEARS 015 030 004 007 028 057 143 094 160 116 082
101
SHARP
SIEMENS
170 081 019 028 029 014 004 022 143
088
SIGNATURE 072
SONY 070 147 126 085 139 041 079
SOUNDESIGN 028 003 043 116
SPECTRICON
SSS
112
004 043
TV
SUPRE MACY 002
17
Maker (Brand) Name Code Number (3 digit) List
All manuals and user guides at all-guides.com

Three Digit Code Lists
TANDY 081
TATUNG 056 062
TECHNICS 084
TECHWOOD 004
TEKNIKA 001 002 003 004 024 028 043 072 101 143 031
077 103
TELEFUNKEN 037 046 086 087
TELERENT 072
TMK 004 116
TOSHIBA 015 138 030 007 040 062 101 051
TOTEVISION 143
UNIVERSAL 008 009
VIDEO CONCEPTS 146
VIDTECH 004 116
WARDS 004 008 009 019 028 060 061 063 064 072 074
YAMAHA
116 143
001 004
YORK 116
YUPITERU 043
ZENITH 072 073 095 157
ZONDA 112
TV
18
SYLVANIA 001 003 059 060 063 064 164 044 160 116 127
140
Code Number (3 digit) List
Maker (Brand) Name
All manuals and user guides at all-guides.com

Three Digit Code Lists
AIWA 034
AKAI 146 043 046 124 125 142 016
AMPRO 072
ANAM 031 033 103
AUDIO DYNAMICS
BROKSONIC
012 023 039 043
035 037 129
CANON 028 031 033
CAPEHART 108
CRAIG 003 040 135
CURTIS MATHES 031 003 041
DAEWOO 005 007 010 064 065 108 110 111 112 116 117
119
DAYTRON 108
DBX 012 023 039 043
DYNATECH
ELECTROHOME
034 053
059
EMERSON 006 029 035 025 027 034 036 037 046 101 129
131 138 017 031
FISHER
FUNAI
003 008 009 010
034
GE 031 072 144 147 033 063 107 109
GO VIDEO 132 136
GOLDSTAR
HARMAN KARDON
012 013 020 101 106 114 123
HITACHI
INSTANTREPLAY
012 045
004 026 034 043 150 063 137 018
031 033
JCL 031 033
JCPENNY 012 013 015 066 040 033 101
JENSEN 043
JVC
KENWOOD
LLOYD
048 043 130 150 050 055 060 012 031 033
014 034 048 039
034
VCR
19
Maker (Brand) Name Code Number (3 digit) List
All manuals and user guides at all-guides.com

Three Digit Code Lists
LXI 034 101 013 014
MAGIN 040
MAGNAVOX 067 031 034 041 033 068
MARANTZ
MARTA
031 067 012 033 069
101
MATSUI 027 030
MEI 031 033
MEMOREX 101 003 010 014 031 034 053 072 139 134 033
MGA 045 046 059
MINOLTA
MITSUBISHI
013 020
059 061 151 046 051 142 013 020 045 049
MTC 034 040
MULTITECH 024 034
NEC
NORDMENDE
012 023 043 048 039
043
OPTONICA 053 054
PANASONIC 066 070 083 145 133 140 074
PENTAX
PHILCO
013 020 031 033 063
031 033 034 067
PHILIPS 031 067 034 101 054 033 071
PILOT 101
PIONEER 021 048 013
PORTLAND
PULSAR
108
072
QUARTZ 002 014
QUASAR 033 066 075 145
013 020 033 041 062 063 107 109 140 144 145
RCA
147
REALISTIC 003 008 010 014 031 033 034 040 053 054 101
VCR
RICO 058
RUNCO 148
SALORA 014
20
Maker (Brand) Name Code Number (3 digit) List
All manuals and user guides at all-guides.com
