Starlyf CORDLESS VAC User manual

International patents pending. All imitations will be prosecuted. STARLYF CORDLESS VAC®sis a registered EU/CTM trade mark.

2
13
8
2
4
a
b
d
c
e
fg
9
67
5
10
Fig.1
Fig.2 Fig.3

3

4
Thank you for purchasing STARLYF CORDLESS VAC®, the
cordless vacuum cleaner that removes dust and dirt in minutes.
Before using the product for the rst time, please read all these
instructions to ensure you use the product correctly.
WARNINGS
- Do not use the unit if the product charger
cable is damaged or defective.
- To avoid the risk of electrocution, do not
immerse the battery in water or any other
liquid. Do not charge the battery if it is wet
or shows signs of corrosion.
- The charger should be used only with
STARLYF CORDLESS VAC®; no other
charger should be used. Do not use the
charger outdoors or immerse it in water.
- For best results, do not charge the battery
at temperatures below 5ºC or above 40ºC.
- We recommend using the product with
rubber gloves and goggles for protection
from any splashes coming off the rotating
brush.
- Before you begin working on large areas,
use STARLYF CORDLESS VAC® on a small
part of the surface to be cleaned that is the
least visible. For best results, follow the
directions in this manual.
- This product is not completely water
resistant. If water gets inside the device,
be sure to dry it as soon as possible. Any
moisture left on the product could damage
it.
- If you are not going to use the product for
a long time, remove the battery to prevent
battery leaks that may keep the device from
working properly.
- Remove the battery and unplug the power
cable from the mains before performing
any cleaning or maintenance tasks on the
device.
- Keep out of reach of children.
- This product is designed for household
use.
- Do not use this device for purposes other
than those described in this manual.
- Do not tamper with the device in any way.
The device should be handled or repaired
only by an authorized professional.
- This device may be used by children
aged 8 and over, by people with reduced
physical, sensory or mental abilities, and by
people lacking in experience and knowledge
if they are appropriately supervised or given
suitable instructions on the safe use of the
device and understand the dangers its use
entails.
- Do not use STARLYF CORDLESS VAC® in
direct contact with the body of automotive
vehicles, as it could damage the paint job.
- Children should not be allowed to play
with the device.
Children shouldnot cleanordo maintenance
on the device without supervision.
This device must be used only with the
supplied battery.
WARNING: To charge the battery, use only
the charger supplied with the device.
WARNING (BATTERY):
- DO NOT TRY TO OPEN, REPAIR
OR DISMANTLE THE BATTERY.
- DO NOT SHORT-CIRCUIT THE BATTERY
- THE BATTERY MAY EXPLODE IF DIS-
POSED OF IN FIRE.
- THE BATTERY SHOULD BE CHARGED
ONLY WITH THE SUPPLIED CHARGER.
- THERE IS A RISK OF EXPLOSION IF THE
BATTERY IS REPLACED WITH THE WRONG
TYPE.
- DISPOSE OF OR RECYCLE SPENT BAT-
TERIES ACCORDING TO THE INSTRUC-
TIONS.
The set includes:
Main Components: Fig. 1
1.Motor
2. Dust lter
3.Lithium rechargeable battery
4.0.8 L dustbin
5.Fixed connector opening
6.LED pilot light
7.ON/OFF button
8.Air outlet
9.Filter cover
10.Dustbin base tab
11.Charger
Accessories Fig. 2
a)Aluminium extension wand to help with cleaning
b) Standard oor attachment for general cleaning
c)Crevice tool
d)Round dusting brush
e)Upholstery tool
f) Crevice tool with moving brush
g)Multi-angle rotating tool
ENGLISH

5
STARLYF CORDLESS VAC®ASSEMBLY INSTRUCTIONS:
STARLYF CORDLESS VAC®consists of the main unit, which
holds the motor (1), lter (2), lithium rechargeable battery (3) and
dustbin (4). These parts can be disassembled to clean the lter
and the dustbin. See the CLEANING INSTRUCTIONS section.
The main unit has a xed connector opening (5) where the
accessories you plan to use can be attached.
ATTACHING AN ACCESSORY TO THE MAIN UNIT OR THE
ALUMINIUM EXTENSION WAND
- THE STARLYF CORDLESS VAC® and the aluminium
extension wand are designed to attach to the accessories
included in the main set. Use the combination that best suits
your needs Fig. 4.
STARLYF CORDLESS VAC®CHARGING INSTRUCTIONS:
• To install the battery, insert the tab into the slot of the vacuum
cleaner, as shown in Fig. 3. Reverse these steps in order to re-
move it.
• While the battery is installed in the main unit, insert the charger
plug into the port next to the connection button for the lithium
rechargeable battery and plug the other end into the mains.
• Do not charge the battery for more than 12 hours. Overcharg-
ing can reduce the charge duration. Do not let the battery die
before recharging it.
• The LED pilot light (6) will blink while the device is charging.
As the battery charges, the lights will start turning green. The
light will stay green and will stop blinking when the device is fully
charged.
• The device will be completely charged in 4 to 4½ hours and
will run for approximately 20 minutes, depending on individual
use.
• Unplug the charger from the device and the cable from the
mains.
INSTRUCTIONS FOR USE:
Once the battery has been properly charged, you can start using
the vacuum.
Connect the accessory you plan to use to the vacuum’s xed
connector opening (5) until you hear a click.
The STARLYF CORDLESS VAC®motor has two speeds. The
rst is strong suction power and is activated by pressing the ON/
OFF button once. The second speed is even stronger suction
power and is activated by pressing the ON/OFF button a second
time. (7)
To stop the unit, press the ON/OFF button a third time. The
sequence is S1-S2-OFF.
DUSTBIN MAXIMUM FILL LEVEL
- Do not let the dirt exceed the level of the dust lter (2), as this
may reduce the suction power Fig. 8.
EMPTYING THE DUSTBIN
- Empty the dustbin when it is full or when you notice a
considerable drop in the product’s suction power.
- Press the tab on the base and empty the dustbin into the
rubbish Fig. 5.
CHANGING THE FILTER
- Change the lter when you notice a considerable reduction in
the product’s suction power.
- Remove the lter cover (9) and press the PUSH button Fig 6.
- Check the lter status regularly. To take out the lter, remove
the cover by turning the dustbin from left to right. Reverse these
steps to reinstall the lter Fig. 7.
CLEANING INSTRUCTIONS:
- Do not clean STARLYF CORDLESS VAC®with chemical
products such as volatile liquids or solvents. Do not immerse it
in water. Use a damp cloth and a non-abrasive cleaning product
or mild soap. Allow to air dry.
- To clean the dustbin (4), press the tab on the base (10) and
empty the dustbin into the rubbish. Rinse the dustbin and let it
air dry.
- For enhanced maintenance, after each use, remove the l-
ter cover (9) and press the PUSH button. The lter (2) in the
main unit can be removed by turning the cover. It should then be
washed in water and allowed to air dry.
TECHNICAL SPECIFICATIONS
Adaptor:
• Input power: 100-240 V - 50/60 Hz – 24,0 W
• Output power: 26,0 V 500 mA 13,0 W
* Appendix1
Device:
• Input power: 22.2 V
• Suction power: 23.9 W
• Power consumption: 140 W
Battery:
· Voltage: 22.2 V
· Material: Li-ion
· 2000 mAh
DISPOSAL OF MATERIALS
A symbol of a crossed-out wheeled bin means you
should nd out about and follow local regulations
about disposing of this kind of product.
Do not dispose of this product as you would other household
waste.
Dispose of this device in accordance with the corresponding
local regulations.
Electrical and electronic devices contain hazardous substances
that can have harmful effects on the environment and/or human
health and should be recycled properly.
The battery must be removed before disposing of
the product. To do so, unplug the device from the
mains. Open the battery compartment cover with a
screwdriver and remove the battery. The battery must
be disposed of safely.
HOW TO REMOVE THE BATTERY FROM THE DEVICE
- Warning: it is important for the battery to be completely
discharged before it is removed from the device.
- Warning: the device must be disconnected from the mains
while the battery is being removed.
To remove the battery, see the section STARLYF CORDLESS
VAC®CHARGING INSTRUCTIONS
The instruction manual is available from http://www.industex.
com
Quality Warranty:
This product is covered by a warranty against manufacturing
defects subject to the time periods stipulated by the legislation in
force in each country.
This warranty does not cover damages resulting from
inadequate use, negligent commercial use, abnormal wear and
tear, accidents or improper handling.
Australia & New Zealand only
This product has the benet of certain Consumer Guarantees.
These are prescribed by the Australian Consumer Law & the
