StarMax 5124CF User manual

®
C US
LISTED
®
® ®® ®
ELECTRIC COUNTER
CHAR-BROILER
MODEL
5124CF & 5136CF
Installation and
Operation
Instructions
2M-Z16003 Rev. B 03/21
5124CF

2
These symbols are intended to alert the user to the presence of
important operating and maintenance instructions in the manual
accompanying the appliance.
RETAIN THIS MANUAL FOR FUTURE REFERENCE
NOTICE
Using any part other than genuine Star factory supplied parts relieves the
manufacturer of all liability.
notice. Such revisions do not entitle the buyer to corresponding changes,
improvements, additions or replacements for previously purchased
equipment.
Due to periodic changes in designs, methods, procedures, policies and
without notice. While Star International Holdings Inc., Company exercises
good faith efforts to provide information that is accurate, we are not
responsible for errors or omissions in information provided or conclusions
provided, the user assumes all risks in connection with such use.
MAINTENANCE AND REPAIRS
Contact your local authorized service agent for service or required maintenance.
Please record the model number, serial number, voltage and purchase date in the area below and have it
ready when you call to ensure a faster service.
SAFETY SYMBOL
Model No.
Serial No.
Voltage
Purchase Date
Business 8:00 am to 4:30 p.m. Central Standard Time
Hours:
Telephone:
Website:
1-800-264-7827
www.star-mfg.com
Service Help Desk
Authorized Service Agent Listing
Reference the listing provided with the unit
or
for an updated listing go to:
Website: www.star-mfg.com
Mailing Address: Star Manufacturing International Inc.
265 Hobson Street
Smithville, TN 37166
U.S.A

2M-Z16003: Star-Max Electric Charbroiler
Specications
Model Voltage kW Amps
1PH
Amps 3Ph Innite
Controls
Cooking
Surface
Dimensions Weight
x y z Width Depth Height Installed Shipped
5124CF 208V 6.6 31.8 21.8 21.8 13.8 2396 sq in
(2555 sq cm)
24”
(61cm) 25 5/8”
(65 cm)
14 1/4”
(36 cm)
98 lb
(45 kg)
145 lb
(66 kg)
240V 27.5 18.8 18.8 11.9
5136CF 208V 9.9 47.6 27.6 27.6 27.6 3594 sq in
(3832 sq cm)
36”
(91cm)
175 lb
(80 kg)
215 lb
(98 kg)
240V 41.3 23.9 23.9 23.9
GENERAL INSTALLATION INSTRUCTIONS
This equipment is designed and sold for commercial use only by personnel trained and experienced in
its operation and is not sold for consumer use in and around the home nor for use directly by the general
public in food service locations.
Before using your new equipment, read and understand all the instructions & labels associated with the
unit prior to putting it into operation. Make sure all people associated with its use understand the units
operation & safety before they use the unit.
All shipping containers should be checked for freight damage both visible and concealed. This unit has
been tested and carefully packaged to insure delivery of your unit in perfect condition. If equipment is
received in damaged condition, either apparent or concealed, a claim must be made with the delivering
carrier.
Concealed damage or loss - if damage or loss is not apparent until after equipment is unpacked, a
request for inspection of concealed damage must be made with carrier within 15 days. Be certain to
retain all contents plus external and internal packaging materials for inspection. The carrier will make an
inspection and will supply necessary claim forms.
These Electric Char-broilers are equipped for the voltage and wattage indicated on the
nameplate mounted on the front panel. These units are designed to operate on alternating
current (AC) only. DO NOT CONNECT TO DIRECT CURRENT (DC).

2M-Z16003: Star-Max Electric Charbroiler
INSTALLATION
The installation of this appliance should conform to the national electric code and local electric codes
and ordinances and the local electric company rules and regulations.
For your protection, we recommend that a qualied electrician install this appliance. The electrician
should be familiar with electrical installations and local electrical requirements. The external wiring
should be in conduit or an approved type of exible cable suitable for operation at 90° C and sized to
carry the load. Use copper wire only. The supply circuit should be properly fused and equipped with
a means of disconnecting as required by local electrical code. The body of the appliance should be
grounded (Do not ground to a gas supply pipe).
1. Locate the unit: Do not install the unit
closer than 12 inches from a side wall
and/or closer than 9 inches from a rear
wall.
2. Level the char-broiler by adjusting the
feet, which have provision for 1 inch of
adjustment. This adjustment also allows
a perfect alignment to be achieved with
other Star-Max™ units.
3. The pigtail leads can be accessed by
removing the cover plate from the back of
the broiler.
4. Fill the water pan on the broiler prior
to use. Water should be ush with the
bottom of the splash ba󰀪es. Make sure
water is present in the pan at all times.
Note: The pan is easily removable for
cleaning.
CARE MUST BE TAKEN WHEN OPENING PAN TO PREVENT SPILLING.
5. The charbroiler is equipped with modular grates that are readily removable for cleaning.
Each heated section is controlled by a separate heat control switch.
6. Seasoning - Set the heat control switch to the low position and preheat for about 15 to 20
minutes. Using a cloth, spread a thin lm of cooking oil over the top of the grate surface.
Allow the lm to remain on the grate for about 5 minutes. Wipe the surface clean and apply
another lm of cooking oil. Wipe the surface clean again. The broiler is now ready for use.
The oil may tend to smoke - this is normal.
7. Approximate grilling temperatures range from 350° F (with no product on the grill) on low
setting to 570° F on high.
CLEANING
1. Clean with a clean soft cloth daily. Any discoloration can be removed with a non-abrasive
cleaner.
2. Remove the water pan and cooking grates. Wash them in a sink.
3. To clean heating element, rst remove the grates. Swing the element housing to a vertical
position and lock it in place with the support located in the center. Clean the elements with a
sti󰀨 wire brush or equivalent.
4. Heat ba󰀪es are located directly below the heating elements and are removable for cleaning in
a sink.
CAUTION
Water Pan / Drip Tray
Fill with water before operating
to prevent flare-ups and
catches grease.
IL1442

2M-Z16003: Star-Max Electric Charbroiler
LIMITED EQUIPMENT WARRANTY
Star Manufacturing [as well as its subsidiaries] warrants to the original purchaser
of new Star products to be free from defects in material or workmanship, under
normal and proper use and maintenance service as specified by Star and upon
proper installation and start-up in accordance with the instructions supplied with
each Star unit. Star’s obligation under this warranty is limited to a period of one [1]
year from the date of original installation, or eighteen [18] months from original
invoice date, whichever occurs first. Defects that occur as a result of normal use,
within the time period and limitations defined in this warranty, will at Star’s
discretion have the parts replaced or repaired by Star or a Star-authorized service
agency.
THIS WARRANTY IS SUBJECT TO ALL LISTED CONDITIONS
Repairs performed under this warranty are to be performed by a Star authorized
service agency. Star will not be responsible for charges incurred or service
performed by non-authorized repair agencies. In all cases, the nearest Star-
authorized service agency must be used. Star will be responsible for normal labor
charges incurred in the repair or replacement of a warrantied product within 50
miles (80.5 km) of an authorized service agency. Time and expense charges for
anything beyond that distance will be the responsibility of the owner. All labor will
need to be performed during regular service hours. Any overtime premium will be
charged to the owner. For all shipments outside the U.S.A. and Canada, please see
the International Warranty for specific details. It is the responsibility of the owner
to inspect and report any shipping damage claims, hidden or otherwise, promptly
following delivery. No mileage or travel charges will be honored on any equipment
that is deemed portable. In general, equipment with a cord and plug weighing less
than 50 lb. (22.7 kg) is considered portable and should be taken or shipped to the
closest authorized service agency, transportation prepaid.
CONTACT
Should you require any assistance regarding the operation or maintenance of any
Star Manufacturing; phone, email or fax our service department. In all
correspondence provide the model number and serial number of the unit needing
service; include the voltage or gas type.
Normal Business Hours: 8:00 a.m. to 4:30 p.m. Central
Telephone: [phone] Tech Service Option 2
Email: [e-mail]
www.Star-Mfg.com
January 29, 2021
WARRANTY EXCLUSIONS
THE FOLLOWING WILL NOT BE COVERED UNDER WARRANTY.
Star’s sole obligation under this warranty is limited to either repair or
replacement parts, subject to the additional limitations detailed below. This
warranty neither assumes nor authorizes any person to assume obligations
other than those expressly covered by this warranty.
• Any product which has not been used, maintained, or installed in
accordance with the directions published in the appropriate installation sheet
and/or owner’s manual, including incorrect gas or electrical connection. Star
is not liable for any unit which has been mishandled, abused, misapplied,
subjected to harsh chemicals, modified by unauthorized personnel, damaged
by flood, fire, or other acts of nature [or God], or which have an altered or
missing serial number.
• Installation, labor, and job checkouts, calibration of heat controls, air and
gas burner/bypass/pilot adjustments, gas or electrical system checks, voltage
and phase conversions, cleaning of equipment, or seasoning of griddle
surface.
• Replacement of fuses or resetting of circuit breakers, safety controls, or
reset buttons.
• Replacement of broken or damaged glass components, quartz heating
elements, and light bulbs.
• Labor charges for all removable and consumable parts in gas charbroilers
and hotplates, including but not limited to burners, grates, and radiants.
• Any labor charges incurred by delays, waiting time, or operating restrictions
that hinder a service technician’s ability to perform service.
• Replacement of parts that fail or are damaged due to normal wear or labor
for replacement of parts that can be replaced during a daily cleaning routine,
such as but not limited to silicone belts, PTFE non-stick sheets, control labels,
knobs, bulbs, fuses, quartz heating elements, baskets, racks, and grease
drawers.
• Any economic loss of business or profits.
• Non-OEM parts. Use of non-OEM parts without Star’s approval will void the
warranty.
• Units exceeding one [1] year from original installation date, or more than
eighteen [18] months from original purchase date, whichever comes first.
ADDITIONAL WARRANTIES
• Specific/chain-specific equipment may have additional and/or extended
warranties.
PRODUCTS
PARTS
LABOR
Star Ultra Max
Ⓡ
fryers, griddles,
charbroilers and hotplates 2 years 2 years
Star Max
Ⓡ
fryers, griddles,
charbroilers and hotplates 2 years 2 years
Staltek™roller grill coatings 5 years
Cast iron grates, burners
and burner shields 1 year
Original Star, Toastmaster or Holman
parts sold to repair equipment 90 days
The foregoing warranty is in lieu of any, and all other warranes expressed
or implied and constutes the enre warranty.

2M-Z16003: Star-Max Electric Charbroiler

2M-Z16003: Star-Max Electric Charbroiler

2M-Z16003: Star-Max Electric Charbroiler
STAR MANUFACTURING INTERNATIONAL, INC.
MODEL - 5124CF
CERTAIN INSTANCES MAY NOT BE AVAILABLE
ILLUSTRATIVE PURPOSES ONLY AND IN
SOME ITEMS ARE INCLUDED FOR
SK2591 Rev. A 03/2021
5
4
3
2
1
11
10
9
87
6
13
14
15
16
17
18
37
12
19
22
21
23
24
25
2627
28
29
30
31 32
34
35
36
38
39
40
33
20
42
41
Nameplate
43
44

2M-Z16003: Star-Max Electric Charbroiler
PARTS LIST March 24, 2021, Rev. B
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE 1
INCLUDE MODEL AND SERIAL NUMBER OF 2
Some items are included for illustrative purposes only and in certain instances may not be available.
Star Manufacturing International, Inc.
Model; 5124CF & 5136CF Electric Counter Char-Broiler
Fig No Part No Qty Description Application
1 2I-7370 2 GASKET
2 2F-Z6858 2 SUPPORT WITH BUSHING
3H1-Y3115 2ELEMENT STRAP 5124CF
H1-Y3266 5136CF
4H1-Z6115 1ELEMENT HOUSING 5124CF
H1-Z6116 5136CF
5H1-Z6117 1ELEMENT HOUSING COVER 5124CF
H1-Z6118 5136CF
6 2F-Y3107 4TOP GRATE 5124CF
6 5136CF
7 2A-5401 2 COTTER PIN
8 2C-1811 2 WASHER
9 2P-7969 1 SPRING
10 H1-Z6122 1 PROP ROD BRACKET
11 2A-Z6121 1 PROP ROD
12 H1-Z6119 2ELEMENT CLAMP 5124CF
H1-Z6120 5136CF
13 H1-512400 1TOP ASSEMBLY 5124CF
H1-513600 5136CF
14 2K-Z6183 3BUSHING 5124CF
5 5136CF
15 G3-Y7788 1 BOX COVER
16 2C-Y2344 1 GROUND LUG
17 2E-Y7327 1 ELECTRICAL BOX
18 H1-Z6054 1REAR PANEL 5124CF
H1-Z6056 5136CF
19 H1-Z6059 1REAR ENCLOSURE 5124CF
H1-Z6060 5136CF
20 G3-624303 1 SIDE LINER ASSEMBLY RIGHT
21 G3-Z5945 2 SIDE PANEL
22 H1-Z6123 2 FOOT SUPPORT
23 H1-Z6045 1FRONT HOUSING 5124CF
H1-Z6046 5136CF
24 G3-Z6036 2 DRAWER SLIDE
25 2A-Z5942 4 FOOT
26 H3-Z6482 1 GREASE DRAWER 5124CF
H3-Z6483 5136CF
27 2J-6403 2/3 INFINITE CONTROL 5124CF / 5136CF
29 2M-Z15452 2/3 LABEL ELECT INF LG 5124CF / 5136CF
30 G3-624330 2/3 KNOB ASSY LG E-F KEYT 5124CF / 5136CF
31 2M-Z15804 1 STAR-MAX LOGO ALL
32 2J-Y6690 2/3 PILOT LIGHT 5124CF / 5136CF
33 G3-Z5911 1FRONT PANEL 5124CF
G3-Z5921 5136CF

2M-Z16003: Star-Max Electric Charbroiler
PARTS LIST March 24, 2021, Rev. B
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE 2
INCLUDE MODEL AND SERIAL NUMBER OF 2
Some items are included for illustrative purposes only and in certain instances may not be available.
Star Manufacturing International, Inc.
Model; 5124CF & 5136CF Electric Counter Char-Broiler
Fig No Part No Qty Description Application
34 2C-8477 3 TINNERMAN CLIPS ALL
35 H3-612400 1LINER ASSEMBLY 5124CF
H3-613600 5136CF
36 G3-624302 1 SIDE LINER ASSEMBLY LEFT
37 H1-Z6173 1 BAFFLE FRAME REAR 5124CF
H1-Z6085 5136CF
38 H1-Z6082 1LINER COVER 5124CF
H1-Z6083 5136CF
39 H1-Z6084 1BAFFLE FRAME FRONT 5124CF
H1-Z6533 5136CF
40 H1-Z6086 9 BAFFLE 5124CF
H1-Z6086 15 5136CF
41 2N-Y3085 2/3 HEATING ELEMENT 240V 5124CF / 5136CF
2N-Y3086 HEATING ELEMENT 208V 5124CF / 5136CF
42 2N-Y3083 2/3 HEATING ELEMENT BENT 240V 5124CF / 5136CF
2N-Y3084 HEATING ELEMENT BENT 208V 5124CF / 5136CF
43 2C-9704 12 #10-24 HEX HEAD NUT 1" LONG 5124CF / 5136CF
44 2C-08-07-0207 12 #10-24 HEX NUT W/ LOCK WASHER 5124CF / 5136CF
NA 2E-Z6113 1WIRE KIT, 24” ELEC CHAR 5124CF
NA 2E-Z6114 WIRE KIT, 36” ELEC CHAR 5136CF

2M-Z16003: Star-Max Electric Charbroiler

STAR MANUFACTURING INTERNATIONAL INC.
Star - Holman - Lang - Wells - Toastmaster
265 HOBSON ST. SMITHVILLE, TN 37166
[phone]
www.star-mfg.com
