Starr Instruments GMX-01 User manual

Starr Instruments
63 Waterview Close
DANDENONG SOUTH
VICTORIA 3175, AUSTRALIA
PH: 03 8787-3636
ABN: 33 998 859 720
GMX-01
Gloss Meter
User Manual
Please read this manual carefully before using and reserve it for reference.

Starr Instruments
63 Waterview Close
DANDENONG SOUTH
VICTORIA 3175, AUSTRALIA
PH: 03 8787-3636
ABN: 33 998 859 720
I. Product Introduction
The GMX-01 is a hand-held gloss meter that tests the surface gloss of paint,
coating, ink, plastic, paper, ceramic, stone and metal just to name a few. The
GMX-01 provides accurate and repeatable tests whilst being extremely easy to use.
In addition to its normal model, the QC mode can be used to undergo quality
assurance checks. It is also equipped with a powerful PC software. The USB stick
provided can be plugged into a computer and used to generate reports.
II. Parameters
Measuring
Angle
60°
Measuring
Aperture
9mm * 15mm
Minimum Test
Material Size
20mm * 10mm
Measuring
Range
0 - 200GU
Resolution
0.1GU
Repeatability
0 - 100GU: ±0.2GU
100 - 1000GU: ±0.2%
Zero Error
0.1GU
Indication Error
0 - 100GU: ±1.5GU
100 - 1000GU: ±1.5%
Weight
240g
Power Supply
Rechargeable Lithium Battery 3.7V@650mAh
Display
240 × 128 Dot Matrix
Language
Simplified Chinese, English
Charge Port
USB(Type-C)
Data Transmission
USB
Working Temperature
10~45℃,0~85%RH (no condensation)
Storage Temperature
-10~60℃,0~85%RH (no condensation)

Starr Instruments
63 Waterview Close
DANDENONG SOUTH
VICTORIA 3175, AUSTRALIA
PH: 03 8787-3636
ABN: 33 998 859 720
III. Features
1. Real time and instantaneous measurements.
2. Detect samples quickly with QC judging function.
3. The environmental temperature compensation function guarantees long-term
calibration stability.
4. USB Stick provides PC operating software, which has various functions and the
ability to generate test reports
5. Designed with an emphasis on ergonomics, sleek style and comfortable feel.
6. Built-in rechargeable lithium battery, with ultra-low power consumption, means it
can work continuously for more than 32 hours.
IV. Operation
1. Turn on/off
Turn On: When off, a short press of the power button turns on the instrument.
Turn Off: When on, a long press of the power button turns off the instrument. The
instrument will also automatically power off with no operation for 30 minutes.
2. Parameter Setting
When off, a long press of the button for 3s, enters the parameter setting mode:
Language
A short press of the button will switch between the two options of English or
Chinese, whilst a long press for 3s will select the option and enter the mode
selection.
Mode Selection
A short press of the button will switch between the two options of Normal or QC,
whilst a long press for 3s will select the option, exit the setting and enter the
calibration interface.

Starr Instruments
63 Waterview Close
DANDENONG SOUTH
VICTORIA 3175, AUSTRALIA
PH: 03 8787-3636
ABN: 33 998 859 720
3. Calibration
If the meter gets powered on in the calibration holder, it will enter the calibration
interface. The user can perform the calibration operation according to the prompts,
the instrument will enter measurement interface after the calibration. If it is not
powered on in the calibration holder, it will skip the calibration and enter the
measurement interface directly.
If it prompts that the calibration failed, the reasons may include:
If the standard is not clean, please clean the standard with special lens cloth before
placing the meter into the calibration holder.
If the meter is not properly clicked to the calibration holder, please re-place into
calibration holder.
If the light source cannot work normally due to attenuation, the device should be
returned for repair.
4. Measurement
(1) Normal Mode
If the instrument is set to normal mode, remove the calibration holder after
calibration. Place the measuring port on the surface of the object to measure, the
instrument will display the measured value instantly. A short press of the button and
the lower left corner of the interface displays the "HOLD" symbol, meanwhile the
measurement data is held on the display. To measure again, press the button to
cancel the "HOLD" state and return to the "Measuring" state.

Starr Instruments
63 Waterview Close
DANDENONG SOUTH
VICTORIA 3175, AUSTRALIA
PH: 03 8787-3636
ABN: 33 998 859 720
(2) QC Mode
If the instrument is set to QC mode, remove the calibration holder after calibration.
Then place the measuring port of the instrument on the surface of the object to
measure. A short press of the button will measure and then the instrument will judge
whether the measured value is qualified. The upper and lower limits can be set
through the PC software.
V. PC Software
By connecting the instrument to the PC software via a USB cable, it can perform
functions such as online measurement, change of calibration values, parameter
settings, test report generation and printing.

Starr Instruments
63 Waterview Close
DANDENONG SOUTH
VICTORIA 3175, AUSTRALIA
PH: 03 8787-3636
ABN: 33 998 859 720
VI. Precautions
1. The temperature compensation function guarantees long-term calibration stability, it
is recommended to calibrate once a week. If the environmental temperature
changes significantly, please recalibrate it.
2. The measuring port of the instrument shall be attached to the surface of the object
to avoid leakage of external light.
3. Please save the calibration holder in a clean place after the meter is removed, to
prevent the standard from contamination.
4. Do not insert any object into the instrument for any reason, as it will damage it and
influence the measuring accuracy as well as operation safety.
5. The instrument and calibration standard should be cleaned before storage and
usage. As the surface of the standard is very precise, make sure there are no fine
particles on the lens cloth to avoid damage of the standard.
6. If you have multiple meters, put the meter on the calibration holder in
correspondence to its the serial number.
7. It is recommended that each meter should be calibrated at least once a year.
VII. Packing List
No.
Description
Quantity
Unit
1
Gloss Meter
1
Set
2
USB Data Cable
1
pc
3
USB Disk (software)
1
pc
4
Special Lens Cloth
1
pc
5
User Manual
1
pc
6
Certificate / Warranty Card
1
pc
This Gloss Meter conforms to the following standards: ISO2813, ISO7668, ASTM D523,
ASTM D2457, DIN 67530, GB/T9754, GB/T13891, GB/T7706, GB/T8807. All indexes
meet the requirements of JJG 696-2015 Verification Regulation of “Specular Gloss
Meters and Gloss Plates” as the first-class working meters.
