StarTech.com USBBT1EDR4 System manual

Mini USB Bluetooth® 4.0 Adapter - 50m (165ft) Class 1 EDR Wireless Dongle
StarTech ID: USBBT1EDR4
The USBBT1EDR4 USB to Class 1 Mini Bluetooth® Dongle lets you add Bluetooth wireless capabilities to a laptop
or desktop computer through USB, with support for transfer distances of up to 50m (165ft).
Compliant with Bluetooth 4.0 LE +EDR , the USB Bluetooth adapter offers data transfer rates up to 3 Mbps and low
power consumption. This Bluetooth Smart Ready transceiver is an effective way to connect to a rapidly growing list
of the Bluetooth Smart peripherals on the market, including the latest Apple® and AndroidThursday, September 19,
2013 10:33:55 AMrade; smartphones and tablets. Bluetooth v4.0 also integrates added security for all transfers
using 128-bit AES encryption.
A conveniently portable device, this ultra-compact adapter is unobtrusive when connected to your laptop, so you
won't have to remove it each time you store your laptop in a carrying case or bag. The adapter is also backward
compatible with previous Bluetooth standards (v3.0, 2.0, 1.2 and 1.1) to ensure connectivity with all of your Bluetooth
devices.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
Applications
Connect Bluetooth peripherals such as keyboard/mouse or smart phones to your computer system
Reduce cable clutter by using wireless Bluetooth devices (such as keyboard/mouse) instead of traditional
wired devices
Connect peripherals wirelessly to a computer in a remote/secure location
Connect peripherals in an industrial setting where the computer can be kept away from the work areas

Features
Bluetooth® 4.0 LE compliant Bluetooth Smart Ready transceiver
Class 1 device with 50m (165ft) effective range
Support for Enhanced Data Rate (EDR) with data transfer rates up to 3 Mbps
Low power consumption
Ultra-compact form factor
Backward compatible with Bluetooth v3.0, 2.0, 1.2 and 1.1 devices
Power / Linking / Standby LED indicator
Technical Specifications
Warranty 2 Years
Bus Type USB 2.0
Chipset ID CSR - CSR8510A06
Industry Standards Bluetooth v4.0, v3.0, EDR
Connector Type(s) 1 - Bluetooth Class 1.0
Connector Type(s) 1 - USB A (4 pin) Male
Frequency 2.402-2.48GHz ISM Band
Max Distance 50 m / 165 ft
Maximum Data Transfer Rate 3 Mbps
Modulation GFSK,p/4 DQPSK, 8DPSK
OS Compatibility Windows® 8 (32/64bit), 7 (32/64), Vista(32/64), XP(32/64), 2000
Windows® Server 2008 R2, 2003(32/64)
Mac OS 10.x, 9.x
Color Black
Enclosure Type Plastic
Product Height 0.2 in [5.5 mm]
Product Length 0.9 in [21.9 mm]
Product Weight 0.1 oz [3 g]
Product Width 0.6 in [14.4 mm]
LED Indicators 1 - Power / Standby / Link
Power Adapter Included USB-Powered
Humidity 0~75% RH
Operating Temperature -10°C to 50°C (14°F to 122°F)
Storage Temperature -20°C to 70°C (-4°F to 158°F)
System and Cable Requirements Available USB port
Shipping (Package) Weight 2.6 oz [75 g]
Shipping (Package) Weight 3.5 oz [100 g]
Included in Package 1 - USB Bluetooth Adapter
Included in Package 1 - Driver DVD
Included in Package 1 - Instruction Manual
