StarTech.com HDMI2VGA User manual

HDMI® to VGA Video Converter with Audio
HDMI2VGA
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l’utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l’uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
Packaging Contents
• 1 x HDMI to VGA converter
• 1 x DE-15 VGA to Component RCA cable adapter
• 1 x Universal Power Adapter
• 1 x Installation Guide
System Requirements
• HDMI enabled video/source
• VGA or YPbPr component enabled display device
• Stereo audio speakers with 3.5mm mini-jack (optional)
• Available electrical outlet
Installation
1. Make sure all devices are powered o before installing the
HDMI2VGA converter.
2. Connect the HDMI video/audio source to the HDMI2VGA
converter using a standard male/male HDMI cable.
3. If connecting the HDMI2VGA to a VGA display device, use a
standard male/male VGA cable. Set the “Output” selector switch
to RGB mode.
4. If connecting the HDMI2VGA to a component video (YPbPr)
display device, use the included VGA to RCA component cable
adapter. Set the “Output” selector switch to YPbPr mode.
OPTIONAL: If the HDMI source is also transmitting audio, stereo
speakers/headphones may be connected to the 3.5mm mini-jack
connector.
5. Connect the power adapter from a power outlet to the
HDMI2VGA converter. The LED next to the power connector
should light up solid.
6. Power on the display device.
7. Power on the HDMI video/audio source.
8. The HDMI2VGA converter will automatically convert the
incoming video signal to the congured output signal. The video
resolution, refresh/scan rate, etc. will remain the same as the
original.
Rear View
Front View
Output selector
switch
DE-15 VGA
connector (output)
3.5mm mini-jack
Audio (output)
HDMI conector
(input)
Power LED
Power Connector
*actual product may vary from photos
Instruction Manual
Manual Revision: 01/26/2012
For the most up-to-date information, please visit: www.startech.com

FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment o and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver
is connected.
Consult the dealer or an experienced radio/TV technician for help.
Use of Trademarks, Registered Trademarks, and other Protected Names & Symbols
This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of
third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an
endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual
applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body
of this document, StarTech.com hereby acknowledges that all trademarks, registered trademarks, service marks, and
other protected names and/or symbols contained in this manual and related documents are the property of their
respective holders.
Technical Support
StarTech.com’s lifetime technical support is an integral part of our commitment to provide industry-leading solutions.
If you ever need help with your product, visit www.startech.com/support and access our comprehensive selection of
online tools, documentation, and downloads.
Warranty Information
This product is backed by a two year warranty.
In addition, StarTech.com warrants its products against defects in materials and workmanship for the periods noted,
following the initial date of purchase. During this period, the products may be returned for repair, or replacement with
equivalent products at our discretion. The warranty covers parts and labor costs only. StarTech.com does not warrant
its products from defects or damages arising from misuse, abuse, alteration, or normal wear and tear.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees
or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise),
loss of prots, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the
actual price paid for the product. Some states do not allow the exclusion or limitation of incidental or consequential
damages. If such laws apply, the limitations or exclusions contained in this statement may not apply to you.
Specications
Video Signal RGBHV, YPbPr
Audio Signal PCM
Connectors
1 x HDMI
1 x DE-15 VGA female
1 x 3.5mm mini-jack
1 x DC power
LEDs 1 x Power
Maximum Video Resolution 1920x1200@60Hz
1080p@50/60Hz
Power Adapter 5VDC, 2.6A, center positive
Operating Temperature 0°C ~ 40°C (32°F ~ 104°F)
Storage Temperature 0°C ~ 60°C (32°F ~ 140°F)
Humidity 0 ~ 60% RH
Dimensions (WxHxD) 76.0mm x 30.0mm x 92.0mm
Weight 172g
