STATESMAN FUSION 50ETW User manual

USER / INSTALLER
INSTRUCTION BOOKLET
Please read instructions before using the appliance
MODEL: FUSION 50ETW
Serial No.
Affix Serial No. Label above

2
CONTENTS
Introduction……………………..Page 3
Service………………………….Page 3
Safety (General)……………….Page 4 & 5
Using the Oven………………...Page 5
Using the Grill………………….Page 5
Using the Hotplate…………….Page 6
Installation……………………...Page 7 & 8
User Safety Rules……………..Page 8 & 9
Cleaning………………………..Page 9
Technical Specification……….Page 10
CE Declaration of Conformity
This cooking appliance has been designed to be used only for cooking. Any other use
(such as heating a room) is improper and dangerous.
This cooking hob has been designed, constructed, and marketed in compliance with:
- Safety requirements of the “LVD” Directive 2006/95/EC;
- Safety requirements of the “EMC” Directive 89/336/EC;
-Requirements of the Directive 93/68/EC.

3
INTRODUCTION
Thank you for choosing a STATESMAN appliance.
IMPORTANT: Before using your appliance, please read this manual carefully to assist
safe and successful operation.
INSTALLATION (SEE PAGE 7/8)
- This cooker must be installed by qualified personnel, according to the manufacturers
instructions and to the relevant British Standards.
- This cooker is heavy; take care when moving it.
- Remove all packaging before using the cooker.
- Ensure that the electrical supply complies with type stated on the rating plate.
- Do not attempt to modify the cooker in any way as this may be dangerous and will
invalidate the warranty.
SERVICE
Should you have any difficulty using your cooker, and you have checked the possible
causes with the help of information provided, you may contact our CUSTOMER
SERVICES DEPARTMENT: 0844 84 85 861
Please have ready the following details:
- Model No.
- Serial No.
- Date of purchase
- Name, address and postcode
- Contact telephone number
- Accurate description of fault
- Where purchased
Spare parts information can be obtained by calling the SPARE PARTS
DEPARTMENT: 0844 84 85 862

4
SAFETY
- It is important to read this manual and take all safety measures recommended.
- This appliance has been designed for domestic, non-professional use.
- Check for any damage once unpacked. If there are any defects or damage, do not
use the appliance. Report the defect/damage to your supplier or Statesman Service.
Remove and dispose of all packaging immediately to prevent any risk of harm to
children.
- This appliance must be installed and commissioned by a qualified person as
Statesman will not take any responsibility for damage caused by incorrect installation.
- Before installing this appliance, make sure that the electricity supply is compatible with
the specification on the rating plate and the packaging.
- The supply cable must never be changed by the customer. If it becomes damaged,
contact a qualified person to replace it.
- Switch the power supply off before changing the oven lamp.
- Always switch the power supply off before any cleaning or maintenance is carried out.
- After use, some parts of this appliance may remain hot for a long time. Take care to
avoid touching parts until the appliance has cooled.
- Keep flammable materials away from the appliance.
- Ensure that no cables of other electrical appliances come into contact with this
appliance, especially hot parts.
- Turn any control knobs to the “off” position when not being used.
- Keep children away from this appliance.
- Take care to avoid touching the heating elements inside the oven as these become
extremely hot when in use.
- When using the grill, the oven door should be kept open.
- Never use steam cleaners for cleaning the appliance.

5
SAFETY CONT….
IF A REPAIR IS REQUIRED, ONLY GENUINE PARTS SHOULD BE USED AND
ANY WORK MUST BE CARRIED OUT BY A STATESMAN ENGINEER.
- The installer of this appliance should read the installation instructions and should be a
suitably qualified person.
USING THE OVEN
OPERATION
When you first operate your oven the installation material around your oven will emit an
odour. This is harmless and will soon fade.
To operate oven:
Turn thermostat knob to desired temperature setting. For preheated recipes, preheat
the oven for 15 minutes.
When the required temperature is reached the oven/grill indicator light will no longer be
illuminated.
USING THE GRILL
To operate the grill:
Turn the grill control knob to the required setting. The indicator light will show,
indicating that the grill is on. The clip-on grill pan handle should be used when handling
the grill pan.
The grill door must be open when grilling.

6
USING THE HOTPLATE
Turn the corresponding control knob for hotplate clockwise; the indicator light will
illuminate showing that the hotplate is on. When cooking is finished turn the control
knob to the “0” position. There may be some discolouration of hotplate trims initially
which is normal and not detrimental to its use in any way.
The control knob for each hotplate has these heat settings:
Knob
position
0
1 & 2
3 & 4
5 & 6
Function
Off
Low heat
simmering
Cooking
and boiling
Rapid
cooking
and boiling
145mm plate
1000W
250 W
750 W
1000 W
185mm plate
1500W
750 W
1250 W
1500 W
185mm plate
2000W
1000 W
1500 W
2000 W
Do not leave the hotplates on without a pan in place as this could cause overheating.

7
INSTALLATION
IMPORTANT –Installation of this cooker must be carried out by qualified personnel.
This cooker must be earthed.
CLEARANCES
This cooker may be fitted flush to the base units, please leave a small gap of
approximately 2mm for cleaning etc.
No over hang or cooker hood can be closer than a minimum of 650mm above hotplate.
The cooker must have a horizontal clearance above the hotplate of 90mm each side
and a minimum of 400mm above the hotplate.
ELECTRICAL CONNECTION
- This appliances must be earthed.
- The power supply must be 220-240v for single phase or 380-415v for three phase.
- This appliance requires a 32amp circuit breaker and double pole switch with minimum
contact separation of 3mm.
- The power supply cooker switch must be close to the appliance with no extension
cable being used.
- The power supply cable must not come into contact with any hot/sharp parts of the
back of the appliance. This is to avoid damage to the cable which could result in a
short circuit.
- Do not install the appliance with a damaged cable.
- Incorrect installation will invalidate the guarantee.
Cont…

8
ELECTRICAL CONNECTION CONT….
SINGLE PHASE –NORMAL THREE PHASE
USER SAFETY RULES
- This appliance has been manufactured according to all regulations for electrical
appliances. Any maintenance or repair work must be carried out by a qualified and
authorised engineer. This is for your safety and to avoid the guarantee being
invalidated.
- When in use, the outer surfaces of the appliance will become hot as well as the interior
surfaces of the oven and grill. The heat is retained for a certain time after use and
care must be taken not to touch these parts of the appliance until it has cooled down.
Keep children away until it has cooled down.
-Never leave the cooker whilst cooking with solid or liquid oils and fats. If neglected
and overlooked they can easily catch fire. Never use water to extinguish burning oil.
Apply a cover to the pan and turn off the cooker power supply switch.
- Please be aware of the risk of leaving the oven door open. Any downwards
pressure could tilt the cooker forward and tip any pans being used from the hotplate.
Excess weight or pressure on the open door may also result in damage
which will not be covered by the guarantee.
CONT…

9
USER SAFETY RULES CONT….
- Switch the power supply switch (cooker switch) off at the wall when not in use.
- Always protect the appliance from the effects of damp or wet weather conditions.
CLEANING
IMPORTANT –Before any maintenance or cleaning can be carried out, you must
DISCONNECT the cooker from the electricity supply.
THE HOB TOP
The hob is best cleaned whilst it is still warm, as spillage can be removed more easily
than if it is left to cool.
Regularly wipe over the hob top using a soft cloth well wrung out in warm water to which
a little washing up liquid has been added. Avoid the use of the following:
- Household detergent and bleaches
- Impregnated pads unsuitable for non-stick saucepans
- Steel wool pads
- Bath/sink stain removers.
THE FACIA
Before cleaning the facia ensure that the facia surface is cool.
For best results use a soft dampened cloth. If marks should remain use a very mild
detergent using a light rubbing action being particularly careful around graphics.
THE OVEN AND GRILL
The oven should be kept clean at all times. A build up of fats or other foodstuffs could
result in a fire.
The oven and grill cavities have a smooth enamel finish and can be scrubbed with a soft
cloth soaked in warm soapy water. However, from time to time they may require a more
thorough clean using an oven cleaner. Ensure that the oven cleaner used is suitable for
smooth enamel.

10
TECHNICAL DATA
SPECIFICATION FOR HOTPLATE, OVEN & GRILL
Rating
145mm Hotplate
1000 W
145mm Rapid
Hotplate
1000 W
180mm Hotplate
1500 W
180mm Rapid
Hotplate
2500 W
Grill Element
1400 W
Oven Top Element
1000 W
Oven Bottom Element
1000 W
