Panasonic NR-BE647ASAE User manual
Operating Instructions /
• Thank you very much for purchasing "Panasonic" Refrigerator.
• Before operating this unit, please read these instructions completely.
• Before using this product, please pay particular attention to the "Safety precautions" for a safe use.
• Please keep operating instructions surely, and read them when you need.
Model No
NR-BE647ASQA
NR-BE647ASAE
NR-BE647ASAS
NR-BE647ASSA
NR-BE647AWSA
:
Refrigerator-Freezer /
The smart way of using the refrigerator leads to energy saving.
SPECIAL FEATURE /
• INVERTER
According to changes in the inside temperature, the motors run at
different speed. At normal temperature, the motors run at a lower
speed. (Energy saving & lower noise).
When powerful cooling is required, the motors run at a higher speed.
• About ECONAVI
ECONAVI records the usage pattern in different times such as how often and how long
the doors are opened and detects the level of lighting around the fridge. The fridge would
automatically turn to the ECONAVI mode to adjust the operation rate to save energy.
◎When the ECONAVI mode is on, the indicator light would be on; when the mode is
off, the indicator light would be off.
◎
brightness due to energy saving. The light would turn off when the ECONAVI mode is
off.
Notice: To enter the ECONAVI mode, you need to set the Freezer temperature setting at
the Med temperature.
ECONAVI
ECONAVI
ECONAVI
ECONAVI◎
◎
.ECONAVI
ECONAVI
Med
QUICK
DEODORIZER
FREEZER
CONTROL
QUICK
FREEZING
–3–
CONTENTS /
PAGE /
SAFETY PRECAUTIONS
Please be sure to follow
4
PREPARATION
10
WHEN USING…..
..…
11
PARTS IDENTIFICATION
12
FOOD KEEPING TIPS
13
HOW TO USE THE REFRIGERATOR COMPARTMENT
13
HOW TO INSPECT AND OPERATE THE CONTROL PANEL
15
HOW TO USE THE FREEZER COMPARTMENT
16
HOW TO MAKE ICE CUBES
18
DEFROSTING
19
HOW TO TAKE CARE OF YOUR REFRIGERATOR
20
HOW TO REMOVE AND ATTACH INDIVIDUAL COMPONENTS
21
IN THESE CASES
22
IS THIS A FAILURE
23
SPECIFICATIONS
26
How to use
When necessary
Preparation and
checks
–4–
The following explanations are provided for the items you should know to prevent personal injuries and property damages related to the users and other
people.
SAFETY PRECAUTIONS /
Please be sure to follow
▓Do not install the product where water splashes are possible.
Deteriorating electrical insulation may lead to an electrical shock and fire.
▓Do not block the ventilation port of the refrigerator or spaces around it.
Leaked refrigerant may cause a fire and result in an explosion.
▓Provide a grounding connection or install a ground-fault interrupter when the product is installed in a moist or watery
location.
Ground leakage by a product malfunction may cause an electrical shock.
• Be sure to contact your distributor when installing a ground connection or ground-fault interrupter.
•
When installing.... /....
▓The following expressions are used to distinguish the degree of danger or damage caused when the product is used incorrectly by disregarding the
instructions provided in this manual.
▓
▓The following symbols and explanations are provided to explain the types of act complied by the user. (Shown below are the examples of
pictograms used)
▓
This expression presumes possibility of death or serious injury.
This pictogram indicates a "Mandatory" item to be performed.
This expression presumes possibility of personal injury or material
damage.
This pictogram indicates a "Prohibited" type of act.
WARNING /
WARNING CAUTION
–5–
For power plugs and cords....
When using....
/
▓Do not splash water or liquid detergents on the back of the refrigerator or into the mechanism room at the bottom of the
back side of refrigerator. Splashed water would possibly permeate into electrical parts and cause an accidental fire or other
dangers.
▓When you detect burning smell, remove the power plug to stop operation.
Be careful in order to avoid an electric shock or a fire.
▓Do not connect many plugs to a single outlet by exceeding the rated current or to an outlet other than 220 V a.c. ~ 240 V a.c.
Too many plugs in a single outlet may generate abnormal heat and possible fire.
240 220
▓Do not plug or unplug with wet hands. Electric shock is possible.
▓Insert the power plug fully into the outlet.
Incomplete insertion may cause electrical shock and/or fire from overheating.
• Do not use damaged power cords or loose receptacles.
•
▓Remove dust periodically from the power plug.
Dust accumulation on the power plug may cause an insulation failure with humidity and possible fire.
• Unplug the power cord and wipe with dry cloth.
•
▓Do not damage the power cord or power plug.
Do not damage the cord, modify, bring close to a heating device, bend, twist, pull, place a heavy item on, pinch with the refrigerator
or bundle the cord.
Use of a damaged cord or plug leads to an electrical shock, short-circuit or fire.
• Consult with your distributor if you need to repair the power cord or plug.
•
▓Supply cord and plug.
If the supplied cord or plug of the appliance is damaged, it must be replaced by the manufacturer of its service agent or similarly
qualified person in order to avoid a hazard.
WARNING /
–6–
▓This appliance is not intended to be used by people (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning the use
of the appliance by a person responsible for their safety.
▓Children should be supervised to ensure that they do not play with the appliance.
▓When leakage of flammable gas (propane gas, city gas) is detected, do not touch the refrigerator and open the window for
ventilation.
Power plug connection/disconnection operations may cause sparks, which leads to fire, explosion, or burn.
▓Flammable gas is used for insulation in this refrigerator.
When you throw away this unit, please discard it by proper method.
.
▓Removal of the back cover is prohibited except by service personnel.
May cause injury, burn, or electrical shock.
▓Always unplug the power cord when cleaning the refrigerator .
May cause electrical shocks and/or injury.
.
▓Do not place a water container over the refrigerator.
Spilled water may damage insulation of electrical components and cause electricity leakage, fire or electrical shocks.
.
▓Do not store flammable items in the refrigerator.
Benzine, ether, LP gas, paint thinner, adhesive etc may catch fire.
•Tightly cap the alcoholic beverage bottles.
.
•
▓Do not hang on the door or ride on the drawer compartment.
Injury is likely by a fallen refrigerator or body parts being pinched.
▓Do not damage the cooling circuit (piping) in the refrigerator body.
.
▓Do not apply water on the body or interior.
Electrical insulation deteriorates and may cause shocks or fire.
▓Absolutely, do not disassemble, repair or modify the refrigerator.
An unexpected fire or movement may cause injuries.
• Consult with your distributor when you need a disassembly/repair.
•
When using....
WARNING /
–7–
▓Do not place objects that are prone to fall on top of the refrigerator.
The vibration caused by the operation of the refrigerator may cause the object to fall.
.
▓Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.
▓Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the
manufacturer.
▓Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type
recommended by the manufacturer.
▓This appliance is intended to be used in household and similar applications such as
•staff kitchen areas in shops, offices and other working environments;
•farm houses and by clients in hotels, motels and other residential type environments;
•bed and breakfast type environments;
•catering and similar non-retail applications.
•
•
•
•
▓Do not store chemicals or scientific specimen.
Home-use refrigerator can not store those requiring a strict control.
▓The insulation blowing gas and refrigerant is flammable. When disposing of the appliance, do so only at an authorized waste
disposal centre. Do not expose to flame.
▓
▓WARNING: When positioning the appliance, ensure the supply cord is not trapped or damaged.
▓
▓WARNING: Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance.
▓
▓Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.
▓
–8–
▓Do not attempt to dismantle, repair or tamper the refrigerator, otherwise an electrocution, fire or explosion
accident may occur.
▓Since a flammable refrigerant is used, be sure to open the window for ventilation if the Cooling Loop (piping)
is faulted and then contact the Panasonic Service Station; otherwise an electrocution, fire or explosion
accident may occur.
▓The refrigerator should be placed in a well ventilated location.
▓Do not attempt to use mechanical tool or other tool to speed up the defrosting process.
▓Do not damage the refrigerant loop. (Remark: This warning is applicable only for the tools that can be used
by the user to touch the Refrigerant Loop.)
▓Except for the suggested tools, do not use other tools in the Food Refrigerating Compartment.
▓Before moving the Refrigerator, be sure to remove the power plug and then connect the power after
relocating to the designed location securely.
▓If the Refrigerator is damaged, be sure to contact Panasonic manufacturer or the personnel of Panasonic
Service Station to avoid hazard.
▓If the refrigerant circuit is damaged:
- Avoid opening flames and sources of ignition.
- Thoroughly ventilate the room in which the appliance is situated.
WARNING /
–9–
If you are discarding the refrigerator, remove the door completely as a safe way against small children being trapped inside.
Do not insert your hand into the bottom of the refrigerator.
Inserting your hand during cleaning in the bottom may cause injury by the sheet metal edge.
.
Do not slide your hand on the rail and metal edges during interior cleaning.
You may injure yourself.
When opening the bottom drawer, do not place your feet too close to the refrigerator.
The drawn compartment may hit your feet top.
.
Install the glass shelves securely.
The glass shelf when dropped may break or cause injuries.
Do not use the wheels on the bottom when placed on easy-to-mar floor.
The bottom wheels may damage the floor.
Do not transport refrigerators in a horizontal position.
Laying a refrigerator horizontally may damage the piping.
.
Do not place any protruding item out of the shelf area.
Bottles may drop and cause injuries.
When opening a door or other person touching the refrigerator, make sure the moving door not pinch anyone's finger.
The moving door may hit fingers and cause injuries
Do not eat any smelling or color-changed food.
Rotten food may cause illness.
The compressor and the copper pipeline are high-temperature parts. Do not get in touch with them, or you may get burnt.
Please, when carrying the appliance, do it with horizontal movements, never tilt or lay the refrigerator.
CAUTION /
–10 –
PREPARATION /
Suitable location for the refrigerator
Install at a location not affected by heat or direct
sunshine.
For minimizing deterioration of cooling power and avoiding wasted
electricity.
Secure heat dissipation spaces
Do not place items over the refrigerator. Secure a space of 2 cm on
the both sides and 10 cm or over the refrigerator. The back surface
may be fitted to the wall.
(Leave a space when vibration noise occures)
The refrigerator dissipates heat around it for cooling the food inside.
2
10
Install at a low-humidity, keep ventilation
openings in the appliance enclosure or in the
built-in structure, clear of obstruction.
For suppressing rust generation and avoiding wasted electricity.
more than 10cm
10
more than 2 cm
2
more than 2 cm
2
HOW TO INSTALL /
Turn the adjustable leg to firmly fit on the floor to
prevent vibration or noise. When the floor is covered
with carpet, tatami or vinyl, place a solid board under
the refrigerator to avoid color change by heat.
To prevent the refrigerator from tumbling down due to
an earthquake or shaking of the refrigerator, a nylon
cord or robust string may be tied to the refrigerator on
the lugs on the top of the back side of the refrigerator
and hung to a hook on the wall.
Proper installation will help you get the most use out of your refrigerator.
–11–
To ensure the refrigerator structure not being affected by an uneven ground, please adjust the level carefully with the fol-
lowing steps.
Step 1:
Ensure the rear feet (left and right) are standing firmly. In
case of unevenness, please shim the suspending portion
until it is firmly supported.
:1
Step 3:
Adjust the left front foot to just contacting the ground.
* Excessively lifting the height of the left front foot
may result in skewed body and slanted door of the
refrigerator.
:3
Step 2:
Adjust the right front foot so that
the refrigerator slants backward
slightly, leaving the roller about
0.5cm above the ground.
(Method: Insert a flat screwdriver
into the gap of the adjustable foot
and turn clockwise, this will move
the adjustable foot downward.)
:2
0.5
WHEN USING…..
Clean the interior with damp soft cloth.
• The interior plastic parts may smell in
the beginning but the odor gradually
goes away when the interior gets cold.
•
The interior does not get cold
immediately after turning the power on.
• The exterior surface of the refrigerator
gets hot in the beginning of use or when
the ambient temperature is high as in
summer, but it is not abnormal.
•
•It requires approximately 12 hours in a normal condition until the interior gets cold.
• It may take more than one day until reaching the set temperature in hot season.
• Refrain from opening the doors until it gets fully cold.
12 •
•
•
Wait more than ten minutes to re-start the refrigerator after you stop it once.
CAUTION /
–12–
PARTS IDENTIFICATION /
ⒶFREEZER COMPARTMENT /
qIce Tray /
wIce Box /
eTray /
rFreezer door shelf /
ⒷREFRIGERATOR COMPARTMENT /
tChilled case /
yRefrigerator Temperature Control Dial /
uLED Cover /
iTempered Glass Shelf /
oVegetable case /
!0 Egg Tray /
!1 Egg Shelf /
!2 Door Switch /
!3 Small item case /
!4 Free Rack /
!5 Bottle Stopper /
!6 Bottle shelf /
ⒸOTHER /
!7 Adjustable Leg /
Ⓐ
Ⓑ
Regarding replacement of the LED light
• If the LED light does not work, please contact service
center to check what the problem is.
Do not remove and replace LED light by yourself.
–13 –
FOOD KEEPING TIPS / مﺎﻌﻄﻟا ﻆﻔﺤﻟ ﺢﺋﺎﺼﻧ
▓Smart ideas for storage.
• Leave spaces among foods to help air circulation. Blocking the air flow will cause warm
temperature in the refrigerator compartment.
• Cool hot dishes to room temperature before placing them in your refrigerator.
• Cover juicy foods with tight lids, plastic film or foil.
• Do not keep the door open any longer than necessary, particularly in hot, humid weather.
• Do not put carbonated liquids (fizzy drink, etc.) in the freezer compartment as they may
burst.
• Do not give children loipops direct from the freezer compartment. They may burn their
lips by "freezer burn" due to low temperature.
.ﻦﯾﺰﺨﺘﻠﻟ ﺔﯿﻛذ رﺎﻜﻓأ
•
•
•
•
•
HOW TO USE THE REFRIGERATOR COMPARTMENT
ﺔﺟﻼﺜﻟا ةﺮﯿﺠﺣ ماﺪﺨﺘﺳا ﺔﯿﻔﯿﻛ
• For temporary storage of immediately used items.
• For storing drinks.
[Food examples]
• Beer cans
• Juice / milk / pudding
• Tofu / raw eggs
• Jelly
• Vegetables in sealed tray
Request & Notice:
• Temperatures in the Fine Chilled case can be
very low. It is not suitable for storing puddings,
bean curd or tropical fruits.
:تﺎﻈﺣﻼﻣو ﺢﺋﺎﺼﻧ
Egg Tray / ﺾﯿﺒﻟا فر
Chilled Case / ةدﺮﺒﻣ ﺔﺒﻠﻋ
Vegetable Case تاوﺮﻀﺨﻟا جرد
• For 10 eggs. (2 PCS)
10 •
• An useful, provided for storing food to be kept fresh, in lower temperature not
freeze and eat fresh food soon after you purchase.
•
• Please put vegetable and fruit into Vegetable Case.
•
Vegetables or fruits placed at the Glass Shelf PC, especially those near the vent
port, are prone to freeze. Avoid doing this as far as you can.
•
ﮫﯿﺒﻨﺗ
CAUTION /
ﮫﯿﺒﻨﺗ
CAUTION /
–14–
Request & Notice:
Food may be frozen in the following conditions.
•
either "MED" or "MIN"
•
When placing watery food (tofu etc.) and eggs near the cold air
The thermostat, specially designed for this refrigerator, functions to maintain the optimum inside condition for food
storage at the "MED" dial setting, regardless of ambient temperature variations. Besides, in order to meet your individual
requirements, the refrigerator temperature as you desire can be obtained by adjusting the temperature control dials. Lower
temperature can be obtained by turning the dial clockwise on controls.
Temperature control of the refrigerator compartment
ﺔﺟﻼﺜﻟا ةﺮﯿﺠﺣ ةراﺮﺣ ﺔﺟرد ﻲﻓ ﻢﻜﺤﺘﻟا
About Ag Bio Filter sterilization apparatus
Ag ﺔﯿﺟﻮﻟﻮﯿﺒﻟا ﺮﺗﻼﻔﻟا ﻢﯿﻘﻌﺗ ةاَدأ لﻮﺣ
This machine with Ag Bio Filter sterilization apparatus, through the freezer powerful fan circulation device, can reduce the number of
bacteria inside the refrigerator, to keep the air clean.
Ag
:تﺎﻈﺣﻼﻣو ﺢﺋﺎﺼﻧ
•
•
–15 –
HOW TO INSPECT AND OPERATE THE CONTROL PANEL
ﺎﮭﻠﯿﻐﺸﺗو ﻢﻜﺤﺘﻟا ﺔﺣﻮﻟ ﺺﺤﻓ ﺔﯿﻔﯿﻛ
Setting: Max / Med / Min
Freezer Temperature
Setting: ON / OFF
ON
OFF
Quick Freezing
Quick Freezing Indicator Light
Ambient Brightness Sensor
Freezer Temperature Indicator
Light
ECONAVI Indicator Light
ECONAVI
※Functional Keys
Descriptions
ﺔﯿﻔﯿظﻮﻟا ﺢﯿﺗﺎﻔﻤﻟا ﻒﺻو ※
–16 –
HOW TO USE THE FREEZER COMPARTMENT
رﺰﯾﺮﻔﻟا ةﺮﯿﺠﺣ ماﺪﺨﺘﺳا ﺔﯿﻔﯿﻛ
FREEZER COMPARTMENT / رﺰﯾﺮﻔﻟا ةﺮﯿﺠﺣ
• For storing frozen foods.
• For storing frozen desserts.
• For storing dried foods Frozen storage is suited for
tealeaves, coffee or seaweed that deteriorate with
moisture.
•
•
[Food examples]
• Frozen foods
• Lollipops – Ice cream
• Sherbet
• Tealeaves
• Seaweed, etc.
Do not place the food over capacity.
The unseated top case causes incomplete closure of the drawer
and malfunctions such as frosting in the compartment or failure
in freezing.
(Use caution for these items)
• Long items
• Tall items in bags.
• Excessive quantity of items in plastic bags.
•Tall items in boxes.
.ﺔﺣﻮﻤﺴﻤﻟا ﻆﻔﺤﻟا ﺔﻗﺎط ﻦﻣ ﺮﺜﻛأ مﺎﻌط ﺔﯿﻤﻛ ﻊﺿو مﺪﻋ ﻰﻠﻋ صﺮﺣا
•
•
•
•
How to make frozen foods (QUICK FREEZING)
(ﻊﯾﺮﺴﻟا ﺪﯿﻤﺠﺘﻟا) ﺔﻤﻌطﻷا ﺪﯿﻤﺠﺗ ﺔﻘﯾﺮط
Press the "QUICK FREEZING" button.
(Blue light turns on)
• The freezing ends in the longest 150 minutes. (The blue light turns on)
• Press the "QUICK FREEZING" button again for stopping the operation. (The blue light turns off)
“ﻊﯾﺮﺴﻟا ﺪﯿﻤﺠﺘﻟا” رز ﻰﻠﻋ ﻂﻐﺿا
(قرزﻷا نﻮﻠﻟﺎﺑ حﺎﺒﺼﻣ ءﻲﻀﯾ)
150
Request & Notice:
defrosting process.
Automatic rapid freezing will start after defrosting.
:تﺎﻈﺣﻼﻣو ﺢﺋﺎﺼﻧ
–17–
Tips for good freezing / ﺪﯿﺟ ﺪﯿﻤﺠﺗ ﻰﻠﻋ لﻮﺼﺤﻠﻟ ةﺪﯿﻔﻣ ﺢﺋﺎﺼﻧ
Thin and small
Cutting in thin and small pieces
and storing in small packages is
convenient when using.
Fully seal the food
For preventing drying during
storage and transfer of odors.
Cool down the food fi rst.
Storing cooked foods while still warm would adversely affect
other items.
ﻻوأ مﺎﻌﻄﻟا دﺮّﺑ
Do not refreeze
Use up the entire quantity once thawed. Refreezing substantially
deteriorates taste and nutrition and also unhygienic.
ﺪﯿﻤﺠﺘﻟا ةدﺎﻋإ ﺐﻨﺠﺗ
MIN Indicates a higher temperature between -17ºC ~ -20ºC
-20-17
MAX Indicates a lower temperature between -21°C ~ -23°C
-23-21
Temperature control of the freezer / رﺰﯾﺮﻔﻟا ةراﺮﺣ ﺔﺟرد ﻲﻓ ﻢﻜﺤﺘﻟا
• The temperature for freezer compartment can be
set in Nine steps,more detailed than as "MIN" and
"MED"and"MAX" as show in the table.
1. Set"MIN" with the "FREEZER CONTROL" button.
2. Press the "FREEZER CONTROL" button (for 10
Seconds).
3. Set by pressing the "FREEZER CONTROL"button.
To reset the setting,repeat steps 1,2 and 3.
لوﺪﺠﻟا ﺢﺿﻮﯾو ،تﺎﺟرد ﻊﺴﺗ ﻰﻠﻋ رﺰﯾﺮﻔﻟا ةراﺮﺣ ﺔﺟرد ﻂﺒﺿ ﻦﻜﻤﯾ •
ﺪﺤﻟا”و “ﻂﺳﻮﺘﻤﻟا ﺪﺤﻟا”و “ﻰﻧدﻷا ﺪﺤﻟا” تاداﺪﻋﻹا ﻦﻣ ﺮﺜﻛأ ﻞﯿﺻﺎﻔﺗ
.“ﻰﺼﻗﻷا
1
102
3
.321
Remark:
When operating the refrigerator for the first time, after connecting the plug, adjust the temperature to center position of each control and leave
it for 24 hours for an effective cooling operation. After that, adjust the temperature as you prefer. If you want to save the energy, do not adjust
the temperature lower than the actual operating condition.
:ﺔﻈﺣﻼﻣ
24
Cooling Level
LED display at "FREEZER CONTROL"
botton
MIN / MED / MAX /
Minimum /
Middle /
Maximum /
●
●○
●●
○●
●
● ○
● ●
○ ●
●●●
●Lighting / ○Blinking /
ةﺮﯿﻐﺻو ﺔﻘﯿﻗر ﻊﻄﻗ
ﺔﻤﻜﺤﻣ تﺎﻔﻠﻐﻣ ﻲﻓ ﺔﻤﻌطﻷا ﻆﻔﺣا
قﻼﻏﻹا
–18–
HOW TO MAKE ICE CUBES / ﺞﻠﺜﻟا تﺎﺒﻌﻜﻣ ﻞﻤﻋ ﺔﯿﻔﯿﻛ
NOTE
If you put wet ice cubes in the ice server, they may stick to one another.
ﺔﻈﺣﻼﻣ
Ҝቢ
Water level line
Pour water into the ice tray to the water
level line and put it in the ice tray rail.
Twist the ice tray and let the ice drop as
illustrated.
–19–
When the refrigerator is handled in a slanted position, ensure the defrosted water is drained out, so that no water will spill out when moved.
DEFROSTING / ﺞﻠﺜﻟا ﺔﺑاذإ
You never have to defrost the compartment since your refrigerator is designed to defrost itself completely and automatically.
Defrost water flows to the collector pan where it is forcibly evaporated into the air.
11. Turn the drainage cap counterclockwise to remove it.
1
22. Use a sharp tool with forward rotation to open up the draining hole. (Only required for the
first-time, the defrosted water will drain out immediately after opening up.)
2
33. Let the water drain from the part marked with arrows. Collect the water with a container so it
does not wet the floor.
3
44. After draining, remember to re-install the cover. (Turn clockwise)
4
※How to drain the defrosted water. / .
Draining device /
–20–
HOW TO TAKE CARE OF YOUR REFRIGERATOR
ﺔﺟﻼﺜﻟﺎﺑ ءﺎﻨﺘﻋﻻا ﺔﯿﻔﯿﻛ
Since the function of the refrigerator is to store food, regular cleaning is advised. /
.
How to take care of your
Refrigerator
ﺔﺟﻼﺜﻟﺎﺑ ءﺎﻨﺘﻋﻻا ﺔﯿﻔﯿﻛ
Wipe with cloth soaked with lukewarm water.
When a surface spot does not come off, use a neutral kitchen cleaning product and then wipe off with
the cloth soaked with lukewarm water and tightly wringed.
.ﺮﺗﺎﻓ ءﺎﻤﺑ ﺔﻠّﻠﺒﻣ شﺎﻤﻗ ﺔﻌﻄﻘﺑ ﺔﺟﻼﺜﻟا ﺢﺴﻣا
Operation panel / ﻞﯿﻐﺸﺘﻟا ﺔﺣﻮﻟ • Wipe off with soft dry cloth.
※If press any keys which change setting while wiping operation panel,
please reset setting.
•
※
Door surface / بﺎﺒﻟا ﺢﻄﺳ • Wipe off with damped soft cloth.
※This product is high gross metal, please avoid cleaning it with rough
face of cleaning cloth and contact with sharp object to prevent
surface damage. (such as metal, magnet, etc.)
※
Inspection after caring
ﻒﯿﻈﻨﺘﻟا ﺪﻌﺑ ﺺﺤﻔﻟا
Use a dry or tweaked-dry cloth to clean, preventing water or impurities from residing in the refrigerator, so as
to prolong the service lifespan of steel sheets of the refrigerator.
1. Are there any damages on the power cord?
2. Is the power plug hot?
3. Is the power plug securely inserted into the outlet ?
In case of any doubt, please contact your dealer immediately.
Panasonic Service Station.
1
2
3
▓Do not insert your hand underneath the refrigerator.
▓Do not rub rails or metal edges strongly.
Injuries are likely.
.ﺔﺟﻼﺜﻟا ﻞﻔﺳأ ﻚﯾﺪﯾ ﻊﺿو ﺐﻨﺠﺗ ▓
.ةﻮﻘﺑ ﺔﯿﻧﺪﻌﻤﻟا فاﻮﺤﻟا وأ ﻞﺻﺎﻔﻟا ﻚَﻟَد ﺐﻨﺠﺗ ▓
.حوﺮﺠﺑ ﺔﺑﺎﺻﻹا ﻞﻤﺘﺤﻤﻟا ﻦﻣ نﻮﻜﯾ ﺚﯿﺣ
▓Make sure to unplug the power cord before starting.
▓Do not handle the power plug with wet hands.
May cause injuries or electrical shocks.
▓Do not splash water on the exterior or interior surface.
May cause a fire or electrical shocks.
▓Periodically remove the dust on the power plug.
Dust accumulation on the power plug leads to insulation failure by moisture
and may cause a fire.
• Unplug the power cord and wipe with dry cloth
.ﺔﺟﻼﺜﻟا ﻒﯿﻈﻨﺗ ءﺪﺑ ﻞﺒﻗ ﺔﻗﺎﻄﻟا رﺪﺼﻣ ﻦﻣ ﺲﺑﺎﻘﻟا عﺰﻧ ﻰﻠﻋ صﺮﺣا ▓
.ﺔﻠﺘﺒﻣ ٍﺪﯾﺄﺑ ﺔﻗﺎﻄﻟا ﺲﺑﺎﻗ ﺲﻤﻟ ﺐﻨﺠﺗ ▓
.ﻲﻠﺧاﺪﻟا وأ ﻲﺟرﺎﺨﻟا ﺔﺟﻼﺜﻟا ﺢﻄﺳ ﻰﻠﻋ ءﺎﻤﻟا شر ﺐﻨﺠﺗ ▓
.ﻢﻈﺘﻨﻣ ﻞﻜﺸﺑ ﻲﺋﺎﺑﺮﮭﻜﻟا ﺲﺒﻘﻤﻟا ﻦﻋ رﺎﺒﻐﻟا ﺔﻟازإ ﻰﻠﻋ صﺮﺣا ▓
Cleaning fluids shown as alkaline or acids in the
property column of kitchen cleaning agent.
• Plastic parts may break with the agent.
Tooth paste, powder soap, petroleum, boiling water,
scrubber, acids, benzine, paint thinner, alcohol etc.
• Deteriorates the surface, coating or plastic parts.
When using a chemical wiper, comply with the
cautions given with the product.
Do not use the following items.
.ﺔﯿﻟﺎﺘﻟا ﺮﺻﺎﻨﻌﻟا ماﺪﺨﺘﺳا ﺐﻨﺠﺗ
ﮫﯿﺒﻨﺗ
CAUTION /
ﺮﯾﺬﺤﺗ
WARNING /
This manual suits for next models
5
Table of contents
Languages:
Other Panasonic Refrigerator manuals
Panasonic
Panasonic NR-F681GT-XA User manual
Panasonic
Panasonic NR-BW414MN User manual
Panasonic
Panasonic Inverter NR-BW415V User manual
Panasonic
Panasonic NR-BY608X User manual
Panasonic
Panasonic NR-BC572VSAE User manual
Panasonic
Panasonic NR-BV360AS User manual
Panasonic
Panasonic NR-BT223 SERIES User manual
Panasonic
Panasonic NR-AF162SNMY User manual
Panasonic
Panasonic NR-CW530H User manual
Panasonic
Panasonic NR-YW590Y User manual
Panasonic
Panasonic NR-F543XZ User manual
Panasonic
Panasonic NR-BY552 User manual
Panasonic
Panasonic NR-BY55BPS User manual
Panasonic
Panasonic NR-D700D User manual
Panasonic
Panasonic NR-TZ601B User manual
Panasonic
Panasonic NR-B29SG2 User manual
Panasonic
Panasonic NR-BN211GKMY User manual
Panasonic
Panasonic NR-BN31CX2 User manual
Panasonic
Panasonic NR-CW530J User manual
Panasonic
Panasonic NR-BN31AW1 User manual
Popular Refrigerator manuals by other brands
Samsung
Samsung RS7 Series user manual
Silver King
Silver King Monarch SKM49R Technical manual and replacement parts list
Stevens Lee Company
Stevens Lee Company Silver King SKRB48 Technical manual and replacement parts list
CDA
CDA FW224 Use and maintenance
Marvel
Marvel 6OBAR-SS-F datasheet
GE
GE CustomStyle GCL22QGT Dimensions and installation information
