Stealth BBUX6 Series User manual

4
User Manual BBUX6 Series
USA
Extreme Power Building Booster
Cellular
Signal Booster
RX/TX
MULTI BAND 60-72dB
60-72dB 6 BAND
GSM,HSPA,CDMA,LTE, LTE A
Band 12,17
Band 13
Band 5
Band 4
Band 2,25
700MHz Upper
850MHz
1700/2100MHz
2G, 3G, 3G+, 4G, 4G+
1900MHz ext
700MHz Lower
6 BAND
Stealth X6 4G LTE
60 -72dB
Extreme Power Building Boosters
X660 X665 X672
MULTI BAND
stealth
tech
®
model shown: BBUX660
Smoothtalker.com 1-877-726-3444
Building
[e-mail] Tel: [phone]
In 2001 SmoothTalker produced the rst digital mobile cellular signal booster
in North America with FCC and ICAN approval. We continue to lead with the
most powerful and intelligent boosters in the world.
Our dynamic adaptive proprietary algorithms make them very network friendly.
We call it STEALTH TECH technology.
Contact information for Booster registration:
Some providers have set up web-sites for booster registration. If you don’t see
your provider on this list, please contact your provider for information on how
to register your booster.
AT&T: https://securec45.securewebsession.com/attsignalbooster.com/
Verizon: http://www.verizonwireless.com/solutions-and-services/accessories/
register-signal-booster/
T-mobile: https://www.signalboosterregistration.com/
Sprint: https://www.sprint.com/legal/fcc_boosters.html
Us Cellular: http://www.uscellular.com/uscellular/support/fcc-booster-registration.jsp
This is a CONSUMER device.
BEFORE USE, you MUST REGISTER THIS DEVICE with your wireless provider and
have your provider’s consent.
WARNING. E911 location information may not be provided or may be inaccurate
for calls served by using this device.
The antenna for the device has a 10 meter above ground maximum antenna height limitation when the
device is used with a handset that covers the 1710-1755 MHz band. Violation of this rule could be subject
to potential FCC enforcement action for noncompliance.
This device may be operated ONLY in a xed location for in-building use.
Operational description:
To comply with FCC NPS (Network Protection Standard) requirements: NPS and other compliance/
safeguard features for AGC and anti-oscillation have been implemented. NPS and other compliance/
safeguard features are defaulted to be “On”(in operation). NPS and other compliance/safeguard features
can not be eld recongured, disabled or removed. This booster is not user programmable, does not need
ne tuning or adjustment, does not require professional installation. Most wireless providers consent to
the use of signal boosters. Some providers may not consent to the use of this device on their network.
If you are unsure, contact your provider.
3
If you need help pls contact [e-mail] and we will help
you determine your cell tower location and get you setup.
1) Installation:
Connect the inside antenna and the outside antenna as shown in Fig. 1, Pg. 4.
2) Outside antenna:
a) Place outside antenna outside of the house in the area that has the best signal.
b) If outside location is unavailable, place the outdoor antenna on a window with
the best signal.
3) Inside Antenna: Connect the inside antenna as shown in Fig. 1, Pg. 4.
4) Separation: Increase the distance of the outside and inside antenna as much as
possible to maximize coverage and avoid gain reduction. A vertical distance
of at least 20 feet or a horizontal distance of at least 50 feet between the Outside
Antenna to the Inside Antenna should be maintained.
5) Power: Connect the power supply to the booster and turn it on.
6) Coverage: Use your cell phone to determine if coverage is OK. If coverage is not
adequate, please look at the Green and Orange lights to determine if the
booster has automatically turned down its gain per LED Gain Chart on Pg. 6.
If so pls try to separate or move antennas as per explantion on Pg. 5/6.
Important: Use only the power supply included with the booster. Connecting any other power supply at any
time will result in damage to the booster and will void the warranty. Do not turn on the power switch until
ALL cables have been screwed or plugged into the booster or you can cause damage to the booster.
Optional Dual Inside Antenna Installation (Fig. 2)
(Additional parts required which are not included in Booster kit
See page 2 for list of approved equipment )
1) Choose a splitter model for your needs. For 2 interior antennas use a 2 way
splitter and for 3 interior antennas use a 3 way splitter etc…
2) Mount the interior antennas in the areas which need cellular coverage
3) Evenly distribute the antennas throughout the oors and areas to cover
4) Turn on Booster unit and check signal strength improvement as needed
Typical Installation (Fig. 1 )
(All parts are included in Booster kit.)
Optional Dual Inside Antenna Installation (Fig. 2 )
(Additional parts required which are not included in Booster kit.)
Fig. 1
Fig. 2
Smoothtalker.com 1-877-726-3444
Made in
North
America
stealth
tech
®
Automatic power
control protects the
Cellular Network
FCC
Approved

Band 12, 17 700MHz Lower
Band Frequency
Band 13 700MHz Upper
Band 5 850MHz
Band 4 1700/2100MHz
Band 2, 25 1900MHz ext
RX High Power Attenuation
Oscillation Attenuation
Orange LED
Green LED
Hp Att
Osc Att
Understanding the LED Indicators
The LED lights on the booster face plate indicate the operating gain state
of the booster.
The Green and Orange lights indicate the gain status in each operating band
When Both Green and Orange LED's are“SOLID ON” it means that the booster
is operating normally with full gain (No Automatic Gain Reduction)
When one or both of the LEDS are ashing (Per the chart on Pg. 6)
it indicates that the gain has been automatically reduced due to either:
A) High RX outside signal level (close to cell tower)
B) Loop Oscillation, caused when the inside antenna is located too close to the
outside antenna.
[e-mail] Tel: [phone]
LED Lights Explanation and Troubleshooting
Each ash indicates 3dB of gain reduction also known as gain attenuation.
For example: three ashes equals 9dB of attenuation.
Green LED indicates loop oscillation status. When ashing it means reduction of
gain. To improve you need to spread the distance between the inside and outside
antennas. If you spread them far enough away, the Green LED
will become SOLID ON.
Orange LED indicates RX (outside signal) status.
There are 5 Orange LED lights: 700 Mhz Lower, 700 Mhz Upper, 850 Mhz,
1700/2100 Mhz,1900 Mhz ext. LED ON state indicates that the RX (Receive Signal)
function of the band is functioning normally.
LED OFF state indicates that the band is shut down.
When Orange LED is ashing it indicates reduced gain also known as attenuation
of gain. You cannot prevent this condition. It means that the outside signal is very
strong and the booster has reduced it's gain in order to protect the closest cell
tower. If the cell tower which is close is the one you are using, then you can ignore
the gain reduction and you will still get enough signal strength to cover your area.
In this case this is the normal operating process.
If the close cell tower is not the one you are using, then you can try to relocate
your outside antenna away from this cell tower and face it or point it to the cell
tower you are using in order to get more gain.
If you need help pls contact [e-mail] and we will help
you determine your cell tower location and get you setup.
Power supply 120V AC/DC
Gain
65
60
1.0
1.0
0.2
0.2
Operating temp
-22 F + 185 F
Dimensions Weight 1.2 lbs
L 5.0 x W 4.75 x H 1.25 (inch)
Model
72
1.0
0.2
BBUX672
BBUX665
BBUX660
SPECIFICATIONS Stealth X6 4G LTE 2G, 3G, 3G+, 4G, 4G+, GSM, HSPA, CDMA, LTE, LTE A
Frequencies MHz
700 upper 700 lower 850 1700/2100 1900
Max Power TX: Watts
Max Power RX: Watts
1
ContentsContents
To comply with FCC rules, this booster must only be operated with cables, antennas
and coupling devices that have been approved for use with this equipment.
NOTE:
Only one of the outside antennas is included in this kit. All kits include necessary brackets and co-axial cables for assembly.
It is normal for the booster to be quite warm while the phone is in use state. All parts shown are not included in all kits.
Please check your model number for more details at smoothtalker.com
6
2
5
LED Lights Status Explanation
ON ON
ON
SLOW FLASHING
SOLID ONSOLID ON
SOLID ON
SOLID ONSLOW FLASHING
FAST FLASHING
OFF
ON/
ORANGE LED
High Power
GREEN LED
Oscilation
Attenuation (Att)
Orange Solid ON = Full Gain & Green Solid ON = Full Gain
Orange Solid ON & Green Slow Flashing = Oscillation Att
Orange O & Green Fast Flashing = Oscillation Shutdown
Orange Slow Flashing & Green Solid ON = RX High Power Att
Each ash indicates up to 3dB of gain reduction also known as gain attenuation.
For example: three ashes equals 9dB of attenuation.
No Flashing = Full Gain
Each Flash = up to 3dB of gain reduction
Each Flash = up to 3dB of gain reduction
Fast Flashing = booster shutdown (pls troubleshoot)
For specications of any of the Smoothalker FCC approved part numbers
listed below visit smoothtalker.com
FCC requirements prohibit the use of unauthorized Antennas, Cables,
and/or Coupling devices.
You MUST operate this device with approved antennas and cables as specied by
the manufacturer. Antennas MUST be installed at least 8 inches from any person.
You MUST cease operating this device immediately if requested by the FCC or a
licensed wireless service provider.
Approved Equipment List
ANTENNA CABLES
ACX100X, ACX900X
CBXmaXfe10,20,30,40,50,60
CBNmaNfe10,20,30,40,50,60
CBGmaGfe 10,20,30,40,50,60,70,80,90,100
CBL4maL4fe 10,20,30,40,50,60,70,80,90,100
SPLITTERS
ADCSPN2
ADCSPN3
ADCSPN4
ADCSPG2
ADCSPG3
ADCSPG4
ANTENNAS
SEM2THL, 11THL, 14THL, 26THL series
SRP1X , SRP1XL
SRBL series
SEMD1 series
SEMDA2 series
SEMO series
SEMDP1 series
SEMDY series
SEMDYD series
Power supply
Cellular Booster Inside antenna
Optional outside antennas
SEMDA2 SEMDP1
SEMOGL
