Supplied Accessories
Check that you have the following components
in your converter pack ;
(1) 1 x Instruction Manual
(2) 1 x Transmitter or Repeater or Receiver
(3) 1 x AC Adaptor : 12VDC, @300mA
Safeguards and Precautions
A. Keep this unit away from fire, extremely hot areas, water or moisture of any Kind.
B. Do not place this unit on any support that is not firm, level and strong.
C. Do not service the unit yourself. Opening the unit's housing will void the warranty.
D. Servicing must be by Shinybow or by an authorized technician.
C. Illegal duplication of copyrighted material is strictly prohibited by Federal Laws.
Introduction
Before you make any connections
Make sure all Video devices to be connected to the CAT5 Transmitter/Repeater/Receiver are
functioning according to their respective operation manuals before connecting them. Always
connect the digital Audio devices to the CAT5 Tx/Rx one at a time and make sure each works
just as it did before it was connected.
Congratulatio ns on your purchase of one th e most innovativ e CAT5 Transmitte r/R epeate r
/Receiv er product on th e market Today. The SB-6135 is a transmitte r its driv in g Dig ita l PCM
or Composite Video and Stereo Audio signals over long lin es by category cable to SB-6135R
CAT5 receiv er. high perfo rmance fo r Dig ita l Audio (PCM) or Composite Video with Ste reo
Audio driving with a ADCs digita l signal. Sig nals AV with a maxim um exte nsion of 1000ft
betw een transmitte r and receiver. And use category 5 cable. The termin ato rs are Rj45
(Category 5) jack and Dig ita l or composite video RCA jack.
Specifications :
Driving Signals
Digital Audio (PCM)
Cable for CAT5,5e
SB-6135 (Tx), SB-6135R (Rx)
Model Number
Tx, Rx Input/output
Transmitter & Receiver
Digi tal Aud io(PC M) or Composi te Vide o / Stereo Aud io (AR /AL)
Type of Signals
Power Consumed
SB-6135(@100mA), SB-6135R(@100mA)
Power Source
DC 12 Volts, SB-6135(@300mA), SB-6135R(@300mA)
Size (L,W,H)
2.75 in x 2.60 in x 1 in (70x66x26mm)
Net We ight (Unit only)
0.4 lbs. (0.24kg) Approx.
In/Out Terminal
Rj45 Jack, HD-15 and Ear phone Jack fem al e connect ors.
Video Bandwidth
Tx : 400 Mhz, 13dB full powe r, Rx : 270MH z 1090V/ us@G= +1
Tx slew rate
2000 V/us
Audio Frequency response
20Hz to 20KHz, +/-1db
Tx: 68dB SF DR@5 Mh z 200 load. Rx: 1 Vp-p@5 MHzW
Low di stor tion
Composite video
Stereo Audio (AR/AL)
1 M differentialW
Rx High input imp edance
1000 feet
1000 feet
1000 feet
Distance
Video Ma ximu m input levels
3.1 Vp -p(line level)
1.45 Vp-p
Audio Maximum input levels
Safeguards and Precautions
A. Keep this unit away from fire, extremely hot areas, water or moisture of any Kind.
B. Do not place this unit on any support that is not firm, level and strong.
C. Do not service the unit yourself. Opening the unit's housing will void the warranty.
D. Servicing must be by Shinybow or by an authorized technician.
C. Illegal duplication of copyrighted material is strictly prohibited by Federal Laws.
Typical Hookup and Operation
APPLICATIONS:
TX : Video line driver, Digital line driver, Low power differential
ADC driver, Signal-ended input to differential output driver
RX : High speed differential line receivers, Differential-to-sigle-
ended converters, High speed instrumentation amps, level shifting.
Front :
Inpu t : 1x Digi tal Audi o (PCM) or Compos ite
1x Stereo Audi o (AR/AL)
Rear :
Output : CAT5 (Tx) Transmitter
Power output : DC12V, @300mA
Front :
Input : CAT5 (Rx) Receiver
Power Input : DC 12V, @300mA
Rear :
Output : 1x Digital Audi o (PCM) or Composi te
1x Ster eo Audi o(AR/AL)
SB-61 35R
RECEIVER
SB-61 35
TRANSMITTER
2002/9 5/E C
RoHS
Transm itter and Recei ver si gnal s :
Digital Audi o (PC M) or Composi te Video, St er eo Audi o( AR/AL)
Front V iew Rear View
Front View Rear View
Installing
1000 feet
SB-6135
TRANSMITTER
RECEIVER
SB-6135R
SB-6135R
SB-6235R
SB-6330R
SB-6345R
Audio out
Cat5 ou t
Dig ita l
(Video)
AL
AR
AL
AR
A/V Player
Vid eo
(D igita l)
HDTV
