Stealth FR-1501-17 User manual

User Manual
17" & 19" Flatrack Models
Models: FR-1501-17 & FR-1501-19
Features:
- 1280 x 1024 Resolution
- Saves Expensive Rack Space
- Folds down to 1U, 1.75" High
- Easily installs into 19" Rack Cabinets
17” & 19" Slim 1U LCD Monitor Rack Drawer
1-888-STEALTH - www.stealth.com Date: August 2, 2013

1-888-STEALTH - www.stealth.com
Legal Information
Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness
of the contents. The information in this document is subject to change without notice. We are not liable for any injury or
loss that results from the use of this equipment.
Safety Instructions
Please read all of these instructions carefully before you use the device. Save this manual for
future reference.
■Unplug equipment before cleaning. Don’t use liquid or spray detergent; use a moist cloth.
■Keep equipment away from excessive humidity and heat. Preferably, keep it in an air-conditioned environment with
temperatures not exceeding 40º Celsius (104º Fahrenheit).
■When installing, place the equipment on a sturdy, level surface to prevent it from accidentally falling and causing
damage to other equipment or injury to persons nearby.
■When the equipment is in an open position, do not cover, block or in any way obstruct the gap between it and the
power supply. Proper air convection is necessary to keep it from overheating.
■Arrange the equipment’s power cord in such a way that others won’t trip or fall over it.
■If you are using a power cord that didn’t ship with the equipment, ensure that it is rated for the voltage and current
labeled on the equipment’s electrical ratings label. The voltage rating on the cord should be higher than the one listed
on the equipment’s ratings label.
■Observe all precautions and warnings attached to the equipment.
■If you don’t intend on using the equipment for a long time, disconnect it from the power outlet to prevent being
damaged by transient over-voltage.
■Keep all liquids away from the equipment to minimize the risk of accidental spillage. Liquid spilled on to the power
supply or on other hardware may cause damage, fire or electrical shock.
■Only qualified service personnel should open the chassis. Opening it yourself could damage the equipment and
invalidate its warranty.
■If any part of the equipment becomes damaged or stops functioning, have it checked by qualified service personnel.
What the warranty does not cover
■Any product, on which the serial number has been defaced, modified or removed.
■Damage, deterioration or malfunction resulting from:
□Accident, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized product modification, or
failure to follow instructions supplied with the product.
□Repair or attempted repair by anyone not authorized by us.
□Any damage of the product due to shipment.
□Removal or installation of the product.
□Causes external to the product, such as electric power fluctuation or failure.
□Use of supplies or parts not meeting our specifications.
□Normal wear and tear.
□Any other causes which does not relate to a product defect.
■Removal, installation, and set-up service charges.

1-888-STEALTH - www.stealth.com
< Part. 3 > Options
3.1 HDMI, S-Video + BNC &Audio
3.2 17” / 19” Touchscreen : Resistive, Capacitive
3.3 48V, 24V or 12VDC power
P.8
P.9
P.10
< Part. 2 > Specif cations / OSD
2.1 Product Specifications
2.2 On-screen Display Operation ( OSD ) P.4 - 5
P.6 - 7
< Part. 1 > FR-1501-17 / FR-1501-19
1.1 Package Content
1.2 Structure Diagram & Dimension
1.3 Installation
Contents
P.1
P.1 - 2
P.3

1-888-STEALTH - www.stealth.com
■It is very important to mount the equipment in a suitable cabinet or on a stable surface.
■Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive
dust, dirt, heat, water, moisture and vibration.
The equipment comes with the standard parts shown in package content. Check and make sure they are
included and in good condition. If anything is missing, or damaged, contact the supplier immediately.
Unpacking
Before Installation
How To Clean Your LCD Monitor
Caution :
■To avoid the risk of electric shock, make sure your hands are dry before unplugging your monitor from or
plugging your monitor into an electrical outlet.
■When you clean your monitor, do not press down on the LCD screen. Pressing down on the screen can
scratch or damage your display. Pressure damage is not covered under warranty.
■Use only cleansers made specifically for cleaning monitors and monitor screens. Cleansers not made to
clean monitors and monitor screens can scratch the LCD display or strip off the finish.
■Do not spray any kind of liquid directly onto the screen or case of your monitor. Spraying liquids directly
onto the screen or case can cause damage which is not covered under warranty.
■Do not use paper towels or abrasive pads to clean your monitor. Using an abrasive pad or any wood based
paper product such as paper towels can scratch your LCD screen.
Cleaning Your Monitor
To clean your LCD safely, please follow these steps :
Disconnect the power cord.
Gently wipe the surface using a clean, dry microfiber cloth. Use as little pressure as possible.
1
2
Cleaning Tough Marks and Smudges
To remove tough marks and smudges, please follow these steps :
Disconnect the power cord.
Spray a small amount of non-abrasive cleanser on a microfiber cloth.
Gently wipe the surface. Use as little pressure as possible.
Wait until your monitor is completely dry before plugging it in and powering it up.
1
2
Caution : Do not spray or apply any liquids directly onto the monitor. Always apply the solution to your
microfiber cloth first, not directly on the parts you are cleaning.
3
4

1-888-STEALTH - www.stealth.com
1
2
4
LCD panel
Installation Slide
Audio speaker ( for HDMI or Audio option )
1
2
3
4
5
5
LCD OSD membrane
Carry handle to release the 2-pt lock
2-point lock
< 1.1 > Package Content
P.1
< Part 1 >
FR-1501-17 or FR-1501-19 unit X 1
- 6ft VGA cable X 1
- Power cord X 1
- M6 screw, cage nut & cup washer X 8
< 1.2 > Structure Diagram
The above package content is only for the pure model ( VGA and DVI-D only ).
It varies with options such as HDMI, AV, audio, touchscreen & DC power.
6
3
6

1-888-STEALTH - www.stealth.com
Weight based on standard model configuration. It varies with accessories & options
such as HDMI, AV, audio, touchscreen & DC power.
Model Product Dimension
(W x D x H)
Packing Dimension
(W x D x H)
Net
Weight
Gross
Weight
FR-1501-17 441.6 x 500 x 44 mm
17.4 x 18.1 x 1.73" 590 x 687 x 120 mm 23.2 x 27 x 4.7” 10.5 kg 23 lb 16.5 kg 36 lb
FR-1501-19 441.6 x 500 x 44 mm
17.4 x 19.7 x 1.73" 590 x 687 x 120 mm 23.2 x 27 x 4.7” 12.5 kg 28 lb 18.5 kg 41 lb
< 1.2 > Dimension
P.2
Front View
Side View UNIT : mm
1mm = 0.03937 inch
Top View

1-888-STEALTH - www.stealth.com
■Fix the display drawer into the rack.
Complete the installation
Step 3
■Insert the left and right rear mounting brackets into
the display drawer.
Step 1
< 1.3 > Installation - How to install Installation Slides
P.3
Step 2
■Measure the depth of the front and rear mounting rails.
■Align each rear mounting bracket to a suitable length.
M6 screw, cage nut & cup washer x 8 are provided.

1-888-STEALTH - www.stealth.com
Video
Connectivity
Digital HDMI HDMI 1.1, CEA-861-D
DVI DVI-D, TMDS single link
Analog VGA Analog 0.7Vp-p
Composite ( BNC ) NTSC & PAL
S-Video ( 4-pin ) NTSC & PAL
Plug & Play DVI / VGA VESA EDID structure 1.3
Synchronization VGA Separate, Composite & SOG
Audio
Connectivity
Audio Input Connector 3.5mm stereo jack
Impedance / Power level 30kΩ/ 750mV
Audio Output Connector 3.5mm stereo jack
Resistance / Power level 30kΩ/ 2.8V
Speaker Output Power 2 x 2W
*When the audio output is connected, speaker output is OFF
Power Power Supply Range Auto-sensing 100 to 240VAC,
50 / 60Hz
Power Consumption Screen display ON 25W or less
Power saving mode 4W or less
Power button OFF 1W or less
Regulatory
< 2.1 > Product Specifications
LCD
Panel
FR-1501-17 FR-1501-19
Manufacturer
Panel Size ( diagonal ) 17-inch TFT color LCD 19-inch TFT color LCD
Display pixel ( dots x lines ) 1280 x 1024 1280 x 1024
Brightness ( typ. ) 250 250
Contrast Ratio ( typ. ) 1000:1 1000:1
Color 16.7 M 16.7 M
ViewingAngle ( L/R/U/D ) 80/80/80/80 85/85/80/80
Response Time ( ms ) 5 5
Dot pitch ( mm ) 0.264 0.294
Display Area ( mm ) 337.92H x 270.33V 376.32H x 301.06V
Surface treatment Haze 25%, Hard-coating
Surface hardness 3H 3H
Backlight Type CCFL LED
MTBF ( hrs ) 50,000 30,000
P.4
< Part 2 >

1-888-STEALTH - www.stealth.com
Physical
Specif cation
FR-1501-17 FR-1501-19
Product ( W x D x H ) 441.6 x 500 x 44 mm 441.6 x 500 x 44 mm
17.4 x 19.7 x 1.73 inch 17.4 x 19.7 x 1.73 inch
Packing ( W x D x H ) 590 x 687 x 120 mm 590 x 687 x 120 mm
23.2 x 27 x 4.7 inch 23.2 x 27 x 4.7 inch
Net Weight 10.5 kgs / 23 lbs 12.5 kgs / 28 lbs
Gross Weight 16.5 kgs / 36 lbs 18.5 kgs / 41 lbs
Applicable
Format
DVI-D / VGA Input PC Signal 1280 x 1024 x 60 / 75Hz
1280 x 960 x 60Hz
1280 x 760 x 60 / 75Hz
1152 x 864 x 75Hz
1024 x 768 x 60 / 70 / 75Hz
848 x 480 x 60Hz
800 x 600 x 60 / 72 / 75Hz
720 x 400 x 70Hz
640 x 480 x 60 / 72 / 75Hz
640 x 400 x 70Hz
640 x 350 x 70Hz
P.5
Environmental
Conditions
Operating Temperature 0 to 50°C degree
Humidity 20~90%, non-condensing
Storage Temperature -5 to 60°C degree
Humidity 5~90%, non-condensing
Shock 10G acceleration (11ms duration)
Vibration 5~500Hz 1G RMS random

1-888-STEALTH - www.stealth.com
< 2.3 > On-screen Display Operation ( OSD )
Exit the OSD screen
Go back to the previous on-screen sub-menu or
main menu
Scroll through menu options and adjust
the displayed control
Display the OSD menu
Act as an Enter key to select screen setting options
Turn the monitor on or off
Membrane Switch Function
Remark : All LED touch buttons in WHITE light.
The LED of Power touch button will flash continuously when there is no signal input.
All the LED touch buttons will automatically turn off after 10 minutes of idle status ( except the Power ).
To Light up all membrane buttons, press any button for 1 - 2 seconds ( except for the Power ).
1
2
P.6

1-888-STEALTH - www.stealth.com
< 2.3 > On-screen Display Operation ( OSD )
P.7
OSD Conf guration Page
Image:
for the brightness, contrast, color temp, red, green, and blue
Geometry:
for the auto adjust, H position, V position, phase and clock
Video:
for the colour, tint, sharpness, noise reduction, DCDi and TV Setup
Audio:
for volume, bass, treble, balance, AVL and mute
Misc:
for the language, OSD position, graphic mode, ratio, reset and timer

1-888-STEALTH - www.stealth.com
Audio
Power VGA
DVI-DHDMI
S-Video BNC
in - in - out
PC Video
- AV
- Audio
( S-Video + Composite, BNC )
( 3.5mm audio jacks for audio in & out, and 2W + 2W speakers )
( 1 ) Either HDMI or DVI-D can be selected.
( 2 ) For the above options, casing depth will be extended from 500mm ( 19.7" ) to 570mm ( 22.4" )
- HDMI ( HDMI 1.1, CEA-861-D )
< 3.1 > Options :
< Part 3 >
P.8

1-888-STEALTH - www.stealth.com
Step 1. Run the bundled CD disc
Step 2. Double click the Setup.exe
Step 3. Follow the installation instruction to finish the setup
Step 4. After installation, run the TouchKit program & the “4 point calibration”
Please follow the below steps to setup the touch screen:-
Please do the initial calibration
after the first setup
Model 17’ 19” 17” 19”
TRB e-Resistive TCB e-Capacitive
Technology 5-Wire Resistive Capacitive
Touch Point Single Single
Method Stylus or Finger Finger
Activation Force ≤50g / Stylus=R0.8 ≤50g
Durability 35 million touches 300 million touches
Response Time 15 ms 20 ms
Optical Transmittance 80% ± 3% 93% ±2%
Surface Hardness 3H 9H
Haze 8% ± 3% 7%
Glass 1.4 ±0.2 mm 3.2 ±0.2 mm 2.8 mm ±10% 2.8 mm ±10%
Connector USB Type A USB Type A
Compatibility Windows 7 / XP / Vista, Linux Windows 7 / XP / Vista, Linux
17” / 19" USB Touchscreen Specification
■USB touchscreen package includes 1 x 6ft USB cable, quick reference guideline and CD disc
■For detailed information, please refer to the attached CD disc
■As the touchscreen unit is not made of toughened glass, please handle it carefully
P.9
< 3.2 > Options : Touchscreen & driver
For touchscreen option, casing depth will be extended from 500mm ( 19.7" ) to 570mm ( 22.4" )
***
Power VGA
DVI-D
USB Touchscreen

1-888-STEALTH - www.stealth.com
< 3.3 > Options : DC Power
Model 12V 24V 48V
Input rating
Input voltage: 12-Volt 24-Volt 48-Volt
Input range: 9 ~ 18V 18 ~ 36V 36 ~ 75V
Input current
- No load 50 mA 50 mA 50 mA
- Full load 4950 mA 2450 mA 1220 mA
Output rating
Output voltage: 12-Volt 12-Volt 12-Volt
Output current: 4.16A 4.16A 4.16A
Eff ciency 84% 85% 85%
P.10
VGA
DVI-D
( 1 ) Option excludes 1 x power cord and 1 x AC power adapter.
( 2 ) Casing depth will be extended from 500mm ( 19.7" ) to 570mm ( 22.4" )
*** For DC power option :
DC power

1-888-STEALTH - www.stealth.com
The company reserves the right to modify product specifications without prior notice and assumes no responsibility
for any error which may appear in this publication.
All brand names, logo and registered trademarks are properties of their respective owners.
Copyright 2013 Stealth.com Inc. (Stealth Computer) All rights reserved.
