Steenbeck ST3512 User manual

Copyright
©
2009 – 2013.
Steenbeck is a trademark.
No part of this manual may be reproduced ithout the prior ritten permission of Steenbeck.
Specifications, colours etc. are subject to change ithout notice. Images are an example.
USER MANUAL
ST3512 - ST3514 - ST3516

V4E-2013 35mm Ne Line
1
FILM AND SOUND CONTROLLING AND VIEWING TABLES.
STEENBECK ST3512 (35mm – 1 scr n – 2 plat )
ST3514 (35mm – 1 scr n – 4 plat )
ST3516 (35mm – 1 scr n – 6 plat )
USER MANUAL
Tabl of cont nts
S ction pag
1.0 Introduction 2
2.0 G n ral data 2-3
3.0 T chnical data 4-5
4.0 Important saf ty instructions 6
4.1 Warranty information 7
5.0 ST3512 / 14 / 16: g n ral d scription 8-9
Figur s: 1 – 12 10-15
6.0 Op ration manual / instructions 16
6.1 G n ral ov rvi w 16-17
6.2 Working with th N w Lin St nb ck 18-19
Film- and sound thr ading 20-21
Proj ction lamp adjustm nt and r plac m nt 22
6.3 Touch scr n: Hom 23
Work light 23
Calculator 24
Cu / cu ing 25-26
Count 1 / 2 26-27
Sound 27-28
S nsor 29
6.4 Univ rsal count r 29
Figur s 15 – 27 30-36
Pictur s ST3516 - top SEPMAG thr ading 37
- b low wind thr ading 37
7.0 Foot control 38

V4E-2013 35mm Ne Line
2
1.0 INTRODUCTION
Th ‘ NEW LINE ’ 35mm St nb ck film tabl is a compl t N w G n ration of
Film and Sound controlling an vi wing tabl s.
This N w G n ration has b n sp cially d v lop d for th film archiv s and
film labs.
With this n w s ri s St nb ck r ach d a v ry high standard with maximum
of s cur film handling and transport. Changing th sprock ts for shrunk n
film mat rial is now possibl within a f w minut s.
2.0 GENERAL DATA:
- Th following typ s of th N w Lin 35mm St nb ck ar availabl :
ST3512: 1 scr n - 2 plat s, COMOPT st r o sound (mono switchabl )
ST3514: 1 scr n - 4 plat s, COMOPT st r o sound (mono switchabl )
SEPMAG st r o 1 track (mono switchabl )
SEPOPT (optional) mono
ST3516: 1 scr n - 6 plat s, COMOPT st r o sound (mono switchabl )
SEPMAG st r o 2 tracks (mono switchabl )
SEPOPT (optional) only on track 1, mono.
- Compl t n w film and sound track d sign with saf and scratch fr
COMOPT sound r ad r.
- COMOPT with whit light or optional r d light sound r ad r.
(int rchang abl by us r)
- Maximum for 600 m./2000ft. pictur film or PE sound film.
- Switchabl for 3 imag formats (optional) lik standard, cin mascop ,
and S35.
- Film plat s MAG. 1 (on ST3514) and MAG.2 can b switch d off.
- Int rchang abl proj ction lamp cond ns r syst m with h at filt r.
Lamp: halog n 12Volt / 100 Watt.
- Sync sound sp ds: 24 / 25 fram s p r s c. (f.p.s.)
- Variabl (vario) sp d from 14 to 32 f.p.s.
- Maximum wind through sprock ts: approx. 130 f.p.s.
- Maximum wind in wind mod : approx. 3 m t rs / 10 f t p r s cond.
- Automatic stop at nd of film or wh n film br aks.
- MAG. 1 SEPMAG has a pictur -sound shift syst m, s l ctabl for xactly on
fram or continuously.

V4E-2013 35mm Ne Line
3
- N w count r display:
count of film or MAG. 1
running sp d of film or PE sound film
warning signal for Vario sp d.
- Touch scr n (TS) with us rs fri ndly m nu structur :
digital sound fad rs for pr and main sound amplifi rs: l v l – tr bl – bass.
sound mut ( ach pr -amp) - h ad phon l v l - mono/st r o switch
xt rnal input.
count r s l ctabl : fram s- tim – m t rs/d cim tr s/fram s – f t/fram s.
z ro r turn and fiv cu points
film format calculator and laps d tim count r.
- Sound syst m: 2 way loudsp ak r, nominal 2 x 40 Watt.
input with RCA conn ctor – 10dB.
XLR balanc d output +4dB.
- Bi phas 50 Hz - mast r output for xt rnal synchronising.
- Pow r r quir m nts: 100 – 240 Volt 50 or 60 Hz.
- Pow r consumption: approx. 1000 watt.

V4E-2013 35mm Ne Line
4
3.0 TECHNICAL DATA:
Th r ar scr n proj ction m thod via an optical comp nsation syst m with
18-fac r volving prism giv s a v ry brilliant, bright and sharp pictur .
Th standard dim nsions of th proj ction ar 212 x 288 mm.
Accurat film transport is achi v d by r volving sprock ts on th l ft and right
sid of th polygon.
Th l ft sprock t is spring driv n, guarant ing a smooth and car ful film
transport and a v ry good pictur st adin ss.
With th ‘N w Lin ’ S ri s it is possibl to chang sprock ts within a minut
for shrunk n film (optional).
Th r ar two shrunk n sprock t syst ms availabl .
Th r is a possibility that th pictur st adin ss with shrunk n film sprock ts
is poor r.
Framing is possibl in running mod .
Mor ov r, with th ‘N w Lin ’ it is now possibl to hav thr pictur /imag
formats:
Standard (acad my) and (optional) Cin mascop , S35 or Wid scr n.
Th proj ction lamp can b asily r plac d and adjust d.
In stand-still mod th light is automatically dimm d to pr v nt h at damag s
to th film. Th v ry asy thr ading sav s tim and prot cts th film from b ing
damag d.
SOUND
High quality sound r production is possibl with sp cially d sign d digital pr
amps and main amp of 2 x 40 W output.
Th “N w Lin ’ s ri s St nb ck hav th following standard s t up:
ST3512: COMOPT St r o optical sound, mono switchabl .
ST3514: COMOPT St r o optical sound, mono switchabl .
SEPMAG: MAG 1 st r o / 2 chann ls / 17,5mm, mono switchabl .
Optional: SEPOPT mono.
SEPMAG 35mm, 2, 3 or 4 chann ls.
ST3516: COMOPT St r o optical sound, mono switchabl .
SEPMAG: MAG 1 st r o / 2 chann ls / 17,5mm, mono switchabl .
Optional: SEPOPT mono (on MAG 1 track only)
SEPMAG 35mm, 2, 3 or 4 chann ls.
For all typ s is standard availabl :
- h ad phon output with ¼”jack.
- XLR balanc d audio output + 4dB.
- lin -input with RCA / cinch conn ctor – 10dB.
- loudsp ak rs 2-way, 2 x 40 W.

V4E-2013 35mm Ne Line
5
All audio adjustm nts can b mad via th Touch Scr n (TS) (s s ction 6.3).
In th TS all kinds of audio mix s can b mad .
Each pr -amp has:
l v l – tr bl – bass - balanc (L-R) adjustm nt – mono switch.
Th so call d synchroniz points for film and PE sound film ar only availabl
on r qu st as an option
GENERAL
Pow r: 1- phas 100 – 240 Volts - 50 / 60 Hz.
Pow r consumption: approx. 1000 W.
Switch on curr nt: 10 Amps.
Th fus s can b found on th back sid of th machin (s s ction 6.5).
IMPORTANT: all fus s in th St nb ck machin s ar T (slow blown) and
should n v r b r plac d by F (fast blown) fus s.
Always r plac th fus s by th xact pr scrib d typ .
Dim nsions of a full r ct d machin , including monitor and loudsp ak rs ar :
H ight: 124,5 cm.
Width: 143,5 cm.
D pth: 119,0 cm.
W ight ST3512 250 kg.
ST3514 265 kg.
ST3516 275 kg.
All dim nsions and w ights ar approximat ly.
IMPORTANT:
Th installation of th St nb ck machin should b don by th St nb ck
factory or appoint d and/or c rtifi d d al r / ag nt.
Moving th machin to anoth r room:
Wh n th doors tc. ar too small to mov th machin in anoth r room, th
machin has to b partly tak n apart.
(This xplanation is und r construction)

V4E-2013 35mm Ne Line
6
4.0 IMPORTANT SAFETY INSTRUCTIONS:
Th installation and maint nanc should always b don by St nb ck factory
ngin rs or appoint d / c rtifi d St nb ck ag nt / d al r.
Absolut ly important is a w ll-conn ct d and saf pow r ground syst m.
This is important for:
- th saf ty of th us r of th St nb ck machin .
- all print d circuit boards, motor and m chanical parts to n d a prop r
ground syst m.
- discharg of static l ctricity.
Th St nb ck machin should always b plac d in a dry room and fr of
dust.
Th t mp ratur should b b tw n approx. b tw n 10ºC and 30º
( 50ºF and 90ºF)
Humidity should b approx. b tw n 40% and 70%.
A high r humidity can also caus corrosion on l ctronic contacts.
IMPORTANT:
N v r put drinks/liquids on th St nb ck machin .
Liquid spill, wh n l aking into th machin , can caus gr at damag and can
b dang rous for its us r.
R gularly cl an th machin with th brush and sp cial cloth d liv r d with
machin . NEVER us st l cl aning tools.
N v r op n th machin .
If th r is any m chanical of l ctronically alignm nt n d d, th s should b
don by a St nb ck ngin r or by St nb ck train d staff.
It’s advis d to us good train d p rsonn l to work at th St nb ck machin .
It’s important that this p rsonn l has r ad and studi d th us rs manual.
IMPORTANT:
Th r is always a p rsonal dang r b caus of th r volving sprock ts.
B awar of this dang r wh n having long hair, n cklac s, brac l ts, long
sl v s tc..

V4E-2013 35mm Ne Line
7
4.1 WARRANTY INFORMATION:
St nb ck film machin s ar mad with th b st possibl accuracy and
pr cision possibl . Aft r xt nsiv runs and t sts th machin is r ady for
shipm nt.
St nb ck film machin s ar mad for “quality, r liability and long lif ” with a
minimum of maint nanc . Only us th machin for th purpos it was
construct d for.
Th r is always a slight possibility that within th warranty p riod of 1 (on )
y ar aft r purchasing th St nb ck, a part is not working prop rly.
In such cas , pl as contact th St nb ck factory or your local St nb ck
ag nt/d al r at onc .
D f ctiv parts will b r pair d or r plac d by St nb ck.
B for r placing th part St nb ck has th right to ch ck th part b for
r placing it.
No warranty in cas of:
- wh n th machin is us d for diff r nt purpos th n what is
was mad for.
- d lib rat damag .
- an untrain d t chnician work d at th machin .
- d f ctiv proj ction or optical sound lamp, wir br akag .
- damag to lacqu r by us , bumping or cl aning with not advis d
solv nts.
D f ctiv parts should b s nd to th St nb ck factory in Holland or local
d al r/ag nt at cost and risk of th own r/us r of th St nb ck machin .
Th costs for r pair or r plac m nt of parts is in principl always at th cost of
St nb ck. St nb ck factory always r turns parts fr of charg .
Th r plac d parts ar prop rty of St nb ck factory.
If a St nb ck ngin r is r quir d to tak car for warranty r pairs or
r plac m nts, all trav lling and staying costs ar for th own r/us r of th
St nb ck machin .

V4E-2013 35mm Ne Line
8
5.0 OPERATION MANUAL
GENERAL DESCRIPTION
1. Driving d ck pictur track fig. 1
2. Driving d ck sound (ST3516 only) fig. 1
3. Friction l ft pictur track fig. 1
4. Friction right pictur track fig. 1
5. Friction l ft sound track 1 (MAG 1 – ST3514 – ST3516 only)
6. Friction right sound track 1 (MAG 1 – ST3514 – ST3516 only)
7. Friction l ft sound track 2 (MAG 2 – ST3514 – ST3516 only)
8. Friction right sound track 2 (MAG 2 – ST3514 – ST3516 only)
9. Guid film roll r for r winding fig. 1 – 2
10. Op ration pan l fig. 1 – 2 – 4
11. Sp d switch / paddl fig. 2
12. Ground glass fig. 2
13. Film rul r fig. 2
14. Touch scr n (TS) fig. 2 (70)
15. Em rg ncy stop push button fig. 1 / fig. 4a
16. Main pow r on / off switch fig. 1 / fig. 4a
17. H adphon ¼” sock t fig. 1 (at the left side of frame)
18. Proj ction lamp fig. 18
19. ------
20. Univ rsal film count r fig. 2 - 12
21. Shutt r for s v ral imag s fig. 3
22. Back conn ction pan l fig. 11

V4E-2013 35mm Ne Line
9
OPERATION PANEL fig. 5 – 6 – 7 – 8 – 9 – 10
23. Standby: switch from standby (r d) to op ration (On – gr n)
24. Synchronous sp d switch for 24 / 25 fram s p r s cond (f.p.s)
25. Clutch / brak switch pictur track (ST3514 - ST3516 only)
26. Framing
27. Lamp: on / off proj ction lamp
28. Clutch / brak switch sound track 1 / MAG 1 (ST3514 - ST3516 only)
29. Sound shift <<: pictur – sound shift r tard MAG 1 only.
30. Sound shift >>: pictur – sound shift advanc MAG 1 only.
31. MAG 2: clutch / brak switch (ST3516 only)
32. Excit r lamp COMOPT pow r on / off
33. Excit r lamp SEPOPT pow r on / off MAG 1 only.
34. Ground glass: pow r on / off. Backlit d LED sourc 7.000ºK
35. Wind: switch for wind op ration
36. R mov Film: Warning signal for wind mod
Th film should b r mov d from th pictur track b for winding
37. T nsion COMOPT: push button t nsion for playback COMOPT sound
38. Variabl sp d: switch on / off variabl synchronous sp d
39. Pot ntiom t r for variabl sync sp d control from 14 to 30 f.p.s.
40. Fus s
CONNECTION PANEL ( back sid ) fig. 11
41. Pictur – sound – shift display conn ctor
42. Univ rsal count r conn ctor
43. Fan (do not cov r)
44. LED working light conn ctor. 12 volt - 1 amp. Max.
45. 230 volt working lamp conn ctor - 60 Watt max.
46. Bi-phas 50Hz conn ct. (output – mast r only)
47. Loudsp ak r conn ctors
48. Audio Lin out: balanc d XLR output
49. Audio Lin in: - 10dB RCA / Cinch audio input

V4E-2013 35mm Ne Line
10
Fig. 1
1
3
5
7
17
9
10
15/16
4 9
6
2
8
17

V4E-2013 35mm Ne Line
11
57
9 13 14 12 10 11
20 54
58
56
55
Fig 2.
Fig. 3
21

V4E-2013 35mm Ne Line
12
Fig. 4
10
Fig. 4a
16
15

V4E-2013 35mm Ne Line
13
Fig. 5
10
Fig. 6
23 24 25 26 27
Fig. 7
28 29 30 31

V4E-2013 35mm Ne Line
14
Fig. 8
32 33 34
Fig. 9
35 36
Fig. 10
37 38 39

V4E-2013 35mm Ne Line
15
Fig. 11
44 45 46
47
48 49
43
42
41
40
Fig. 12
83 85 82
84
90
89
88
80
87
81
81

V4E-2013 35mm Ne Line
16
6.0 OPERATION MANUAL STEENBECK ST3512 – ST3514 – ST3516
6.1 GENERAL OVERVIEW
Th ‘NEW LINE’ STEENBECK is a high quality film vi wing and controlling
tabl for motion pictur and p rforat d magn tic sound film and sp cifically
d sign d for film archiv s and film laboratori s.
Th most important goal of this n w d sign is to vi w and transport fragil film
and sound mat rial in th b st possibl way with a minimal amount of physical
w ar.
With th s tabl s films can b ch ck d for any kind of d gr of scratch s,
fading of colour and optical or magn tic sound.
Th driv and sound syst m is proc ssor controll d.
Th s proc ssors can b align d for us rs’ sp cification.
Wh n th film br aks or at th nd of th film th tabl will stop automatically
as it’s d t ct d by s nsors.
Th film plat s of th dis ngag d MAG tracks (ST3514-ST3516 only) will also
stop turning.
Standard Bi-phas 50 Hz output for synchronising (mast r only)
An optional foot p dal is availabl .
Pictur r production is don via an optical comp nsation syst m with an
highly rat d 18 fac r volving prism.
Two r volving sprock ts nsur of an accurat transport, a smooth and car ful
film transport and an xc ll nt pictur st adin ss.
A third sprock t is for th COMOPT sound r production.
All thr sprock ts can b r plac d by sp cial sprock ts for shrunk n film
within a minut . Th r ar two kits availabl .
Th lighting syst m is quipp d with a 12V – 100W halog n lamp.
Th proj ction lamp and th cond ns r syst m with h at filt r ar fitt d in a
quickly r movabl syst m nabling v ry asy r plac m nt of brok n lamps.
Light is automatically r duc d wh n th film transport is stopp d, which allows
vi wing of th film fram for an unlimit d tim without causing any damag .
Th proj ction syst m is fitt d with highly polish d front surfac coat d
mirrors. A hard ov r coating nsur s long lif with constant pictur quality.
Th sp cial clos grain d scr n is of a sp cial plastic to nsur maximum
vi w quality within a vi wing angl of approximat ly 70º.

V4E-2013 35mm Ne Line
17
Sound syst m can b controll d by th touch scr n (TS).
Ev ry pr -amplifi r for optical and / of magn tic sound can b s l ct d by th
touch scr n m nu. Fad rs for volum , tr bl , bass and balanc ar availabl .
Each pr amplifi r has two chann ls / st r o, can b s t in mono and mut .
Th mix of th pr -amplifi rs is availabl on th balanc d XLR +4dB outputs.
An xtra RCA -10dB input is availabl for mixing or monitoring an xt rnal
analogu audio sourc .
Th summing amplifi r is fitt d with th mast r volum control for audio
including tr bl , bass and balanc of this signal.
A high quality pow r amplifi r with 40 W output and 2 way compact
loudsp ak rs guarant s an xc ll nt sound r production.
R production of 4-chann l COMMAG films and s parat (SEPOPT) 35mm
sound film or sound n gativ s is also possibl as an option.
Audio playback is automatically mut d wh n th tabl runs mor than 30 f.p.s..
Th St nb ck Univ rsal count r is standard quipm nt.
This count r for all formats m asur s all film l ngth, laps d tim and fram s
and is abl to conv rt v ry count imm diat ly into anoth r count.
Within th univ rsal count r display is also monitor d:
- th xacts running sp d of th film.
- m asur m nt of th MAG 1 sound track, by switching.
- Vario sp d is activ .
- th s l ct d synchronous sp d.
- th pictur -sound shift advanc / r tard fram s
( for ST3514-ST3516 only).
Th univ rsal count r syst m is op rat d mainly from th touch scr n m nu
which also has a film format calculator and transf r counts to a cu ing syst m.
Th advanc and r tard syst m for sound tap (only on MAG 1 of ST3514 and
ST3516) can b op rat d at all sp ds by a diff r ntial g ar.
By using th advanc and r tard switch th sync mod can b match d to
within on t th of a fram or aft r switching ov r in singl fram in ith r
dir ction to th pictur . This nabl s in a short tim xact p rforation
synchronisation.
Th touch scr n is th op ration c ntr of th ‘N w Lin ’ St nb ck.
This touch scr n giv s th op rator of th tabl som int r sting tools:
- light m nu for l v lling working lamp for standard light as w ll as LED light.
- calculator m nu to calculat and transf r counts, op ration of univ rsal
count r.
- cu m nu: r turn z ro syst m and 5 cu point ar availabl .
- count 1 and 2 m nu.
- sound m nu.
- s nsor m nu.
- laps d tim count r for maint nanc .
All pr c ding it ms ar xplain d in s ction 6.3 and 6.4.

V4E-2013 35mm Ne Line
18
6.2 WORKING WITH THE NEW LINE STEENBECK
Conn ct th St nb ck to pow r as d scrib d in s ction 3.0 and 4.0.
Pl as tak car that th pow r conn ctor at th tabl is s cur d with th
saf ty clamping d vis at th fram .
Always ch ck if th pow r is according to th giv n voltag and fr qu ncy,
which can b found on th typ and s rial numb r plat at th back of th
fram .
Always ch ck that th grounding of th pow r sock t is corr ct.
Without a prop r grounding, th op rator might b at dang r.
Us a fr pow r group of at l ast 16 Amps.
Switch th pow r ON with th main pow r switch (16).
A part of th l ctronics of th tabl will go in standby and th fan will start
moving.
Th push button 23 (standby) will show a RED light.
Wh n th standby button (23) is push d th light will turn to GREEN and th
tabl will start up in s v ral stag s in a short tim .
B for switching OFF, it’s advis d to always switch off th sub functions (27-
32-33-34-35) off first and th n th Standby button 23. Finally th main pow r
switch 15 can b switch d off.
Aft r switching ON th proc ssor th touch scr n (TS) is activat d too.
Aft r a short tim you will h ar a ‘p p’ and th hom pag m nu can b s n.
Now th tabl is r ady for us and all th n d d sub-functions can b chos n
now.
It’s advis d to switch on only sub-functions which ar n d d.
Th sound is also activat d aft r switching on.
If you don’t n d sound, th n pl as always MUTE th mast r sound control.
( s s ction 6.3 ) If you int nd to us on sound sourc , pl as tak car that
oth r pr -amps ar mut d.
FILM THREADING.
Thr ading of th film is don as xplain d in fig. 29 – 30 - 31 .
Th l ft hand sprock t has a spring, nabling th film ton b s t with th
corr ct t nsion in combination with th right hand sprock t.
Always ch ck th t nsion b for running th tabl !! Th film can g t damag d!
Wh n a film with optical sound has to b vi w d thr at th film as shown in
fig.29 .
Now push button 37 ( t nsion COMPOPT) and th t nsion roll r 58 can b
dis ngag d.
Align th film now by pulling th film to th right giving a margin of at l ast
on p rforation at th t nsion roll r.
K p th film at that spot and ngag again with button 37.

V4E-2013 35mm Ne Line
19
SOUND THREADING. (s fig. 30 - 31 ) (for ST3514 – ST3516 only)
In th standard configuration th sound tracks MAG 1 and MAG 2 of th N w
Lin s ri s ar s t up for 17,5mm p rforat d magn tic sound film for 2
chann ls/tracks and/or st r o.
Only sound track MAG 1 has th following possibiliti s:
-optional SEPOPT r ad r ST68, mono, incl. pictur roll rs and pr ssur arms.
-optional SEPMAG, 4 chann ls r play incl. guid roll rs and pr ssur arms.
Thr ading th sound film as shown in fig. 30 -31 .
Switch on track by pushing buttons 28 and / or 31.
W do advis to us 100mm film cor s only.
50. thr ading film. (fig. 29)
51. thr ading film with optical sound. (fig. 29)
52. thr ading p rforat d magn tic sound film MAG 1. (fig. 30)
53. thr ading p rforat d magn tic sound film MAG 2. (fig. 31)
54. film sprock t l ft hand sid . (with spring) (fig. 29)
55. film sprock t right hand sid . (fig. 29)
56. film sprock t COMOPT (optical sound). (fig. 29)
57. polygon. (fig.29)
58. t nsion arm with roll r COMOPT / optical sound. (fig. 29)
59. pictur pr ssur arms. (fig.29)
60. push button to lock and unlock pictur pr ssur arm. (fig. 29)
61. int rchang abl cond ns r syst m proj ction lamp. (fig. 29)
62. focus alignm nt. (fig.29)
63. turning knob for proj ction formats (optional). (fig.29)
64. housing optical lamp. (fig.29)
65. optical sound r ad r. (fig.29)
66. sound pr ssur arm. (fig.29)
67. magn tic sound r play h ad MAG 1. (fig. 30)
(or optional SEPOPT r ad r)
68. magn tic sound r play h ad MAG 2. (fig. 31)
69. sound pr ssur arm MAG 1 / 2 . ( fig. 30/31)
