stellar labs 555-16205 User manual

USERMANUAL
www.mcmelectronics.com
Tri-ColorCOB LEDSpotlight
Model 555-16205
The StellarLabsTri-ColorSpotlightisdesigned toprovidebright,controllablespot withawell–defined 5° beamangle.
Full control oftheRED,GREEN,BLUELED’sallowvirtuallyinfinitecontrol ofcolorblending.The LED designensures
efficient,cool operation,withCOBtechnologyproviding outstanding brightness andcolorclarity.
A.SPECIFICATIONS
• Voltage:100~240VAC, 50Hz~60Hz
• Powerconsumption:30W
• LED:COBTri-30W
• Beam angle:5°
• Operationmode: LED display,IRRemote(optional)
B.OPERATION
This unit features six modes:
• MultipleBuilt-in programs
• AutoRun
• DMXcontrol (master/slave)
• Soundactive
• Dimming mode
• Staticcolor

C. PROGRAMMENU
•Press MODE tochoosethe desiredoperatingmode. RepeatedlypressingtheMODE buttonwill scroll through
thevarious modes:DMXChannel,Slave,Sound Activated,Static Color,Preprogrammed,and Automatic
•Once inadesired mode,press SETUP to makechanges,usingthe UP or DOWNbuttons
Built-inProgramMode
•Press the MODE buttonmultipletimes untilPrxx is displayed(default is Pr01)
•Therearesevenavailable programs, each withauniquesequence of colorchangesandfades.Without pressing
the SETUP key,press UP or DOWN keys to choosePr01throughPr07
•Ifanyprogram isselected,otherthanPR01,youcancontrolthespeedofthosechanges.While theprogram is
running,press the SETUP key,thedisplaywill showSPxx.Usingthe UP or DOWN keys,youcanchooseany
numericalvalue from00to 99toadjustthespeed (99 isfastest).
•Pr01is thestatic colormode.If Pr01 is selected,you havetencolors to choosefrom. When in Pr01 mode,press
the SETUP onetime,then press the UP or DOWN keystoscroll throughthe ten preset colors. Atthistime,a
singlecolorwill be displayed,steadyon.
•Fromthispoint,tostrobethesecolors, press the SETUP key,the displaywill readF500.Usingthe UP and
DOWN keys, youcansetthe unit to strobe.F500isfull on,F501 is slowestrate,F599is fastest
Auto RunMode
•Press MODE buttonmultipletimesuntilthedisplayshows AUTO.Inthismode,theunitautomatically
sequencesthroughitssevenavailableprogramsdescribedabove.
•WhileintheAuto RunningMode,youcanadjust thespeedinwhichtheprograms change,aswell asset a
stroberate,ifdesired.ThisisaccomplishedinexactlythesamemannerasdescribedintheBuilt-in
ProgramMode.
StaticColorMode
•Press theMODEbutton multipletimes until COLrappears.
•Press theSETUPbutton multiple times,you will scrollthroughthefollowingoptions:
oRxxx –Red coloradjustment
oGxxx–Green coloradjustment
obxxx –Bluecoloradjustment
oF5.00–Strobe rateadjustment
•The “xxx”asstatedaboverepresentstherelativebrightness ofeach color.000 isoff,255isthehighest
brightness. You canindividuallyadjustthecolorsofall three RED,GREEN, BLUEemittersto achieveanearly
infinitenumberof blendsforvirtuallyanycolor
•F5.00allows you to setthe lighttostrobe. StrobevaluesrangefromF5.00toF5.99 (99 being fastest)
Sound-ActivatedMode
•Repeatedlypress the MODEbuttonuntil the displayshowsSUxx. ThedisplayrangeisSU01~SU31. Thisisthe
sound activated mode,the SUxx numberrepresents the sensitivity, with 31being the mostsensitive
•Press the UP or DOWNbuttonsto adjustthe sensitivity

DMXMode–forusewithDMXcontroller
•Therearethree DMXmodes,3-channel,6-channel and7-channel
•Press the MODE buttonmultipletimes until512appears inonthedisplay
•Press the SETUP keytwice,andthe channel mode willdisplay,either3/6/7 channel.Usethe UP and DOWN
keys to togglebetween thesethreemodes
•Once the channelmode is set, you cansetthe beginning DMX channel
•Press the SETUP keytwice,the displaywill display d.001.Usingthe UP and DOWN keys,you canset the
beginning DMXchannel
DMXChannelAllocations
7CHMode
CHANNELS VALUE FUNCTIONS
10-255 masterdimmer
20-255 R0-100%
30-255 G0-100%
40-255 B0-100%
0--24 strobe(thecolorselectedby 1CH-4CHstrobe)
25-49
built-inprogramsautorunning
50-74 built-inprograms2
75-99 built-inprograms3
100-124 built-inprograms4
125-149 built-inprograms5
150-174 biil-inprograms6
175-199 built-inprograms7
200-255 soundactivemode
6
0-255 thebigerbuilt-inprogramsrunningspeed,thefastersoundactivesensitivity
speed
7
0-255 thebigerstrobefrequencyvalue,thehigherfrequency
5
DMXChannelAllocations
3CHMode
CHANNELS VALUE FUNCTION
10-255 R0-100%
2 0-255 G0-100%
3 0-255 B0-100%

DMXChannelAllocations
6CHMode
CHANNELS VALUE FUNCTIONS
1 0-255 Masterdimmer
20-255 R0-100%
3 0-255 G0-100%
4 0-255 B0-100%
0--10 Nouse
11-255 Sound active
0--9 Nouse
11-255
strobe(colorstrobeselectedby1CH-4CH),thebigvalue,thehigherstrobe
frequency
0--255
Soundactivesensitivity
6
5
Master/ SlaveMode
Repeatedlypress the MODE buttonuntil SLAvappears,thisensuresthe unit isinthe slavemode.Inthismode,all
internalprogrammingisdisabled andtheunit will followstandardDMX-512 protocol.Itmay be controlled eitherby
anotheridenticallightfixtureorbyastandardDMXcontroller.
TestMode
Thismodeallowstheusertoquicklyverifythatall three(RED/GREEN/BLUE)LED’sareoperatingproperly.Thisis
especiallyuseful in large setupswhen manylight fixtures areinstalled,andneed tobe testedone atatime.
Repeatedlypress the MODE buttonuntiltEStappears.Thelightwill begin blinkingone ofitsthreecolors. Pressthe
SETUPbutton once,thenusing the UPandDOWNkeys,youcanscroll throughthethreecolors.Each colorwillstrobeat
afixed rate.
LED Display Description
Redstrobe
Greenstrobe
Blue strobe
RestoreFactorySettings
With theunit poweredoff,simultaneouslypress theMODE andSETUPbuttons. While holdingthem,powerthe unit on.
This will restoretheoriginalfactory settings.

Warranty
ThisStellarLabs deviceiswarranted,byMCMElectronicsagainst defectsforaperiodof365days fromthedateof
purchase.Thiswarrantyincludes manufacturedefectsandfailureduetonormaluseandoperation.Failuredueto
misuse,excessivewearordamage,improperinstallationorotherexternalfactorsisnotcoveredunderthis
warranty.MCMElectronicsisnot responsibleforanyconsequentialon inconsequentialdamagetoany otherunit
orcomponentincorporatedwiththisdevice.Thereareno otherwarranties,express orimplied,whichextend
beyondthisunit, andthereareno warrantiesoffitness forany particularpurpose.Thewarrantydoes notcover
consequentialdamageduetodefectiveorimproperuseofproducts.
