Teknik FLEXI User manual

[FLEXI]
LED SPOTLIGHT
Teknik Lighting Solutions Pty Ltd
ABN: 44 608 397 913
Tel: [phone]
www.tekniklighting.com.au
12W, 24W
USER MANUAL

INTRODUCTION
Thank you for selecting the [FLEXI] LED SPOTLIGHT. Please ensure that the luminaire is installed in
accordance with the below instructions. TEKNIK assumes no responsibility for inappropriate use or
installation of the product, including any associated damage caused.
1. Read the entire manual carefully prior to
installation and operation.
2. The warranty period is listed on the product
as well as on the packaging. Teknik will
repair or replace the product if it becomes
defective under normal use due to a
manufacturing defect within the prescribed
period.
3. Declared lumen output is based upon
measurements obtained during operation
on the appointed LED electronic driver
under standardised laboratory conditions.
4. Installation must be performed by a licenced
and qualied electrician, in accordance with
these instructions and relevant Australian
Standards.
5. Instant restart is allowed.
PRECAUTION
6. Do not change or tamper with any internal
electric circuits, add any wires, connectors
or cables for any reason.
7. Please do not insert any physical objects of
any nature into the tting as this may cause
electric shock, malfunction or damage to
the products.
8. Before replacement of the tting turn the
power o and allow to cool down.
9. In case of weight discrepancy when
replacing old lamps, please ensure that the
mounted structure is rated to withstand
the weight of the new lamp and installation
materials.
10. For further information, please contact
Teknik (www.tekniklighting.com.au) or your
local distributor.

SPECIFICATIONS
Input Voltage
Power 12W 24W
Lumen Output (Normal) 1,000lm 2,000lm
Colour Temperature
CRI
Beam Angle
Connection
Net Weight 0.7kg 1kg
Lifetime
IP Rating
Type LH LD BH BD
Single 99 76 58 114
Twin 99 76 58 114
Unit = mm
LD
LH LH
LD
BD BD
Body DiameterLight Diameter Body HeightLight Height
BH BH
Tri-colour (3000K.4000K/5700K)
Terminal Block with Quick-Connect
>80
120o
>30,000hrs
IP54
220-240 VAC ~ 50/60Hz

5/26-34 Dunning Ave, Rosebery NSW 2018 | 1300 313 780 | [email protected]
www.tekniklighting.com.au
INSTALLATION
DISCLAIMERS
1. This product must be installed and used as per these instructions.
2. This product contains no serviceable parts and no attempt should be made to repair this
product. If the product has a fault, it should be returned to Teknik or the point of sale.
3. Electrical installations periodically receive transient over voltages. This product has been
designed to minimise the eect of such voltages on connected equipment. It may not give full
protection for extreme over-voltage transients such as those resulting from a close lighting strike.
4. This product has been designed to operate in ambient temperatures: -20°C to +40°C.
5. Teknik reserves the right to modify the specication of this product at any time.
Disconnect power to circuit.
Check that the base plate is securely
fitted to the wall and the “UP” arrow is
orientated correctly.
According to the mounting hole location, drill the wall and screw the
base plate onto the wall using suitable plastic wall plugs and screws.
Connect the power source to the
“L” ,“N” and Earth according to the
wiring diagram.
Fit the head unit to the base plate ensuring that the three Quick-Connect pins and mounting legs are lined
up. Re-fit the head unit screws. Caution: Do not over tighten head unit screws.
1 2
3
4
5
