SON8010U GEPON SYSTEM ONU
User Manual
STEPHEN TECHNOLOGIES CO.,LIMITED
ALL RIGHTS RESERVED

SON8010U GEPON ONU User Manual
陈泽科技有限公司
www.stephen-tele.com
C ntents
Chapter 1: Pr duct intr ducti n
1. Goods listing
. Front panel instruction
3. Back panel instruction
4. Indication light instruction
5. Main feature
6. Technology
Chapter 2: Installati n and link
1. Attention items for setting
Chapter 3: s ftware upgrade
1. Preparation
. Means and process
Chapter 4: Remark
Chapter 1: Pr duct intr ducti n
1. G ds listing
Open the package of fast Ethernet switch, and it contains the following:
A set of ONU, A power supply, a user’s manual and a stream line
Please contact with supplier if above product and accessory is missing or damaged.
2. Fr nt panel instructi n
Front panel of ONU have 17 kinds of status indicators, as the following picture
3. Back panel instructi n:
Back panel of ONU from left to right in turn is PON Port, two RJ45 Ports, a bunch port, a replacement switch and a power
supply jack, as following illustrate.
4. Indicati n light instructi n
The signification of indicator from left to right is as following:
LED C l r
Status Descripti n
POW
Green
light the indicator will light when ONU is opened.
-- Non-light
Checking the TX or power supply adaptor, make sure power
supply has connected well.
OPT Green
light Checking the TX or power supply adaptor, make sure power
supply has connected well.
-- Non-light
Optic link is ok.
HW Green
light Hardware is error
-- Non-light
Normal work status

SON8010U GEPON ONU User Manual
陈泽科技有限公司
www.stephen-tele.com
LLID1
-8
Green
light Optic link is ok
-- Non-light
Checking optic link is ok or not
100M Green
light Corresponding indicator will light when 100Mbps equipment
connect with relevant port.
-- Non-light
Non-light 100Mbps port does not joint equipment.
LINK
/ACT
Green
light Light when equipment normally connect with 100Mbps ONU
port
-- glitter Glitter when the port receive or transfer data
LINK100
Green
light Light when 100Mbps equipment link to relevant port
-- Non-light
Non-light when 100Mbps port does not joint equipment.
LINK1000
Green
light Light when 1000Mbps equipment link to relevant port
-- Non-light
Non-light when 1000Mbps port does not joint equipment.
DUP/
COL
Green
light Light when port is working base on full duplex mode
-- Non-light
Non-Light when port is working base on half duplex mode
ACT Green
Light Light when equipment normally connect with 100Mbps ONU
port
Green
glitter Glitter when the port receive or transfer data
5. Main feature:
●
Support single fiber WDM technology (downstream 1490mm, upstream 1310mm), only need to link with OLT
together by one fiber, the transfer length’s at least 0Km.
●
Bandwidth distribution has flexible, downstream share bandwidth by adapting encrypt broadcast transfer way for
different user. .Upstream share bandwidth by TDMA . Adjust automatically speed rate according to the line status.
Support minimum speed rate adjustment base on 1kbps, and establish firm basic to fractionize business for
telecommunication dealer.
●
Support generally team broadcast function. User can choose to achieve mutual video multimedia business by
themselves name (such as VOD, Video conference)
●
Bind user, MAC address and IP address together in order to prevent account was embezzled hostility, ramble, virus
spread abroad and attack of hostility data stream., so that can provide perfect safety guarantee measure for user.
●
Support multi LLID and single LLID configuration mean. Different user and business can adapt different LLID access.
Guarantee user’s different OOS grade.
Installation and maintenance are very easy. Support differed local/long-distance and many means to manage
configuration and upgrade of software. Work in partial port OLT. It can make long-distance malfunction diagnosis and
orientation function come true, and greatly reduces maintenance workload.
●
Network connects: Provide high speed date business for user.
●
FTTH connects: Provide high speed date business and CATV business for family user which already has speech copper
line resource.
●
FTTB connects: adapt the mean of fiber to corridor or big corridor to provide high speed data business.
Physics feature
●
Physics dimension (length16 x width117 x high30, unit: mm)
●
Power supply
:
DC 5V
●
Function loss
:
5W
●
Temperature
:
Operating temperature
:
0
~
50
℃
Storage temperature
:
-30
~
60
℃
Relative humidity
:
10
~
90% (non-condensation)
●
Weight
:
<500g

SON8010U GEPON ONU User Manual
陈泽科技有限公司
www.stephen-tele.com
Techn l gy guide line:
Standard :IEEE 80 .3ah
、
IEEE 80 .3
、
IEEE 80 .3u
、
IEEE 80 .3x
、
IEEE 80 .3z
、
IEEE80 .1d
、
IEEE 80 .1p
、
IEEE 80 .1q
、
IEEE 80 .1x
、
RFC1155
、
RFC1157
、
RFC111
、
RFC1113 and so on.
●
A fixed 10/100M BASE-TX Port
●
A fixed 10/100/1000M BASE-TX Port
●
1 8 digit AES Encrypt
●
Support 8 logic link.
●
Each Ethernet port support 64 Mac Addresses based on 80 .1D Bridging
●
Support 80 .1Q VLAN
●
Support 80 .1P
●
Support 40 stream ( 0 upstream/ 0 downstream)
●
Inbuilt 1. 5 MB buffering
●
Support 80 .3ah OAM
●
Support 80 .3ah transfer error and revise
●
Inbuilt MIB
Chapter 2: Installati n and link
1. Attenti n item f r setting
Please insure that there is suitable work environment and enough free space before installing machine. Please note the
installing requirement as following:
Power supply requirement: 100v- 40v alternating current, power supply jack and equipment should be within 1.8m.
Machine should be putted in the ventilated and dry environment, there must leave 10cm free space from front to back
of machine to airiness
Insure that around for machine has enough airiness port in order to diffuse quantity of heat, at the same time; don’t
put anything heavy on the converter.
Chapter 3
:
::
:
S ftware upgrade
As below introduction of software upgrade is available for single ONU. If it is mixed with our OLT, It’s better to operate it
in the OLT’s management section depend on professional people.
3.1 Preparati nz
1. A PC with RS- 3 -C port, a RS- 3 stream line.
. prepare Tera Term software in PC.
3. Prepare upgrade document: Boot3713_0093_SPI_8Mb.tkf,App3713_R13 _SPI_8Mb.tkf
,
Pers3713_R13 .tkf
3.2 Means and pr cess:
1. Start PC, and click “Tera Termpro”, then start the upgrade software.
. Set software, as following chart:

SON8010U GEPON ONU User Manual
陈泽科技有限公司
www.stephen-tele.com
3. Connect ONU with relevant bunch port on the PC RS- 3 , then turn on the power, as following chart:

SON8010U GEPON ONU User Manual
陈泽科技有限公司
www.stephen-tele.com
4. As the dos prompt shown above, input load order as following chart:
5. Firstly, upgrade Boot code, as following dos prompt input ”rxboot” click the ”file” and choose “send file” , then
“Boot3713_00XX_SPI_8Mb.tkf” you want to upgrade, as following char:

SON8010U GEPON ONU User Manual
陈泽科技有限公司
www.stephen-tele.com
Click “open”, start to upgrade”bootcode”, as following chart:
6. As above method, upgrade ”app”, “pers” in turn. Input”rxapp” order while upgrade “app”
choose”App3713_Rxxx_SPI_8Mb.tkf” file, input “rxpers” order when up grade “pers”, choose”Pers3713_RXXX.tkf” file.
7. After finishing the upgrade. Pls restart ONU to check if the status is ok or not..

SON8010U GEPON ONU User Manual
陈泽科技有限公司
www.stephen-tele.com
C pyright N tice:
No part of this document may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into
any language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise
without the prior written permission of Stephen Technologies Co.,Limited.
Disclaimer N tice:
No license is granted, implied or otherwise, under any patent or patent rights of Stephen Technologies Co.,LTD. Stephen
Technologies Co.,LTD, makes no warranties, implied or otherwise, in regard to this document and to the products
described in this document. The information provided by this document is believed to be accurate and reliable to the
publication date of this document. However, Stephen Technologies Co.,LTD assumes no responsibility for any errors in
this document. Furthermore, Stephen Technologies Co.,LTD, assumes no responsibility for the use or misuse of the
information in this document and for any patent infringements that may arise from the use of this document. The
information and product specifications within this document are subject to change at any time, without notice and
without obligation to notify any person of such change.
