Stevens Aero Model Swift 100 Manual

AR6410LBL Based Micro Aerobat!
Wing Span: 21 inches | Wing Area: 92 square inches | Average Flying Weight: 3.3 ounces
Build Instructions - Version 1.18 (revised 05.15.2014)
Build Instructions
Swift (100) - Build Instructions © 2014 Stevens AeroModel, all rights reserved.!Page 1

WARRANTY
Stevens AeroModel guarantees this kit to be free from defects in both material and workmanship at the
date of purchase. This warranty does not cover any component parts damaged by use or modification.
In no case shall Stevens AeroModel’s liability exceed the original cost of the purchased kit. Further,
Stevens AeroModel reserves the right to change or modify this warranty without notice.
LIABILITY RELEASE
In that Stevens AeroModel has no control over the final assembly or material used for final assembly,
no liability shall be assumed nor accepted for any damage resulting from use by the user. By the act of
using the user-assembled product, the user accepts all resulting liability.
If the buyer is not prepared to accept the liability associated with the use of this product, the buyer is
advised to return this kit immediately in new and unused condition to the place of purchase.
THIS PRODUCT IS NOT INTENDED FOR CHILDREN 12 YEARS OF AGE OR YOUNGER.
WARNING: This product may contain chemicals known to the state of California to cause cancer
and/or birth defects or other reproductive harm.
PRODUCT SUPPORT
This product has been engineered to function properly and perform as advertised, with the suggested
power system and supporting electronics as outlined within this product manual. Product support
cannot be provided, nor can Stevens AeroModel assist in determining the suitability or use of
electronics, hardware, or power systems not explicitly recommended by Stevens AeroModel.
For product assembly support, replacement parts, hardware, and electronics to complete this model,
please contact Stevens AeroModel at www.stevensaero.com.
Stevens AeroModel
26405 Judge Orr Rd., Colorado Springs, CO 80808 USA
719-387-4187 www.stevensaero.com
Build Instructions
Swift (100) - Build Instructions © 2014 Stevens AeroModel, all rights reserved.!Page 2

Swift (100) - Kit Inventory
☐Laser-cut wood, 9 sheets (See Sheet Wood Inventory, page 5)
☐Illustrated Build Instructions
☐Detail sheets, 2 pages, 11 in. x 17 in.
☐2 Leading edge stock, 1/4 in. square x 12 in. balsa strip wood
Taped to back of wood brick:
☐1 Landing gear, wire, .032 in. x 12 in.
☐2 Push rods, wire, .020 in. x 18 in.
Hardware Bag:
☐1 - Part F8, motor mount, 1/16 in. plywood
☐1 - Heat shrink tube, 1/16 in. dia. x 6 in. length
☐1 - Hardwood dowel, 1/8 in. dia. x 3.5 in. length [1019]
☐1 - Pair, 1-1/8 in. dia., plastic wheels [SIGSH540]
☐2 - Part W13, balsa servo cuffs
☐2 - Motor shims, #4 nylon washers [3018]
☐3 - Screws, #2 x 1/4 in. [3011]
☐6 - Rubber bands, #16
Swift (100) - Background
Loosely inspired by the 1930 Comper Swift. The Stevens AeroModel Swift (100) is a “toon” version of the
British classic and features spunky lines and solid sport aerobatic performance. Designed to receive
popular E-Flite micro electronics, the 3 oz flying weight and low wing loading of the Swift 100 makes an
ideal model for larger indoor venues or smaller outdoor flying sites.
Build Instructions
Swift (100) - Build Instructions © 2014 Stevens AeroModel, all rights reserved.!Page 3

Suggested Items to Complete this Model
Many of the suggested items listed below are available at your local hobby shop. For your convenience,
Stevens AeroModel stocks all the power system components and most of the building supplies required
to complete this kit. If you have difficulties sourcing any of these items locally, please visit our website,
stevensaero.com to purchase the items necessary to complete your model.
Required Electronics
☐Spektrum compatible RC transmitter with at least 4 channels
☐Receiver/ESC/Servo brick (SPMAR6410LBL)*
☐Ultra-Micro servos, two required (SPMSA2005)
☐Ultra-Micro “Y” Harness, 3 in. (SPMA2002)
☐SA Sport BL180 brushless motor (SUPA1504-18)
☐Propeller, 4.5 x 3.0 GWS HD (GW/EP4530)
☐Propeller adapter, rubber press-fit (ADP001) or set-screw attached (EFLM1927)
☐LiPo battery, 180 mAh 7.4V (HP-LG325-0180-2S)
☐JST ESC connector and wire (EFLA242)
Covering Film Requirements
While any high-quality covering film may be used to finish this model, superior results will be achieved by
using genuine AeroLITE brand covering film, available exclusively from Stevens AeroModel. The lower
working temperature and light weight of AeroLITE are especially desirable for this type of model.
AeroLITE is one third the weight of typical model covering films, and will present a significant weight
savings when applied to this model.
☐3-4 - PatchPaks AeroLITETM (2-3 base color, 1 trim color)
Sealing Bare Wood
While not required, it is suggested that a high-quality clear lacquer be used to protect and seal any
unfinished wood. One single light coat of clear lacquer should be sufficient to protect the model from
moisture, without adding significantly to the model’s final flying weight.
Many parts of this model may be colored using a lacquer-based spray paint. Listed below are some of
the products we have used on our models. Please feel free to use whatever products you prefer.
☐DEFT clear lacquer-based sealant (available at most hardware stores)
☐Design Master Color Tool, lacquer-based spray paint (available at most arts and crafts stores)
Build Instructions
Swift (100) - Build Instructions © 2014 Stevens AeroModel, all rights reserved.!Page 4
Required Building Supplies and Tools
☐CA glue, medium, 1/4 oz (PAAPT04)
☐CA glue, thin, 1/4 oz (PAAPT10)
☐CA glue applicator tips (PAAPT21)
☐CA glue accelerator (PAAPT15)
☐Hobby knife with supply of #11 blades
☐Sanding block with 400 and 600 grit paper
Building Supplies and Tools
☐Covering iron and heat gun
☐Needle nose pliers, small
☐Clear tape, 1/2 in. (DUB916)
☐Velcro for mounting battery (PKZ1039)
☐Masking tape (low-tack blue painters’ tape)
☐Double sided servo tape (DUB634)
Optional Building Supplies and Tools
☐Wheels, 1-1/2 in. foam (DUB150MW)
☐Balsa filler (HCAR3401)
☐CA glue, thick, 1 oz (PAAPT20)
☐equired Building Supplies
☐
☐CA glue de-bonder (PAAPT16)
☐Clear lacquer-based sealant (DEFT)
☐Lacquer-based paint (Design Master®)

Sheet Wood Inventory
Build Instructions
Swift (100) - Build Instructions © 2014 Stevens AeroModel, all rights reserved.!Page 5

Builder’s Notes
Build Instructions
Swift (100) - Build Instructions © 2014 Stevens AeroModel, all rights reserved.!Page 6

General Assembly Instructions
Thank you for purchasing the Swift (100) from Stevens AeroModel.
This model has been developed and manufactured using state-of-the-art CAD/CAM systems. Our kits
feature a unique interlocking construction process, that when compared to traditional building methods,
saves countless hours of measuring, cutting, sanding, and fitting. We are certain that you’ll find our kit to
offer a truly exceptional build experience.
As this kit is recommended for the novice model builder and pilot, we invite beginners who have
purchased this kit to seek the help of an experienced builder and pilot. If at any time during the assembly
of this kit, should you run across a term or technique that is foreign to you, please contact our staff with
any questions.
IMPORTANT!
Please READ and RE-READ these build instructions along with any other included documentation before
starting your build and/or contacting our staff for builder support.
Pre-Sanding
DO NOT SKIP THIS STEP. Before removing any parts from the laser-cut sheet wood, use a sanding
block loaded with 250 - 400 grit sandpaper and lightly sand the back side of each wood sheet. This step
removes any residue produced as a result of the laser cutting process. We have found that most stock
wood sizes run several thousandths of an inch oversized. This step also slightly reduces the thickness of
each sheet of wood. Leave all parts in the sheet wood until required for assembly.
Protecting Your Work Surface
Use the poly bag that this kit was shipped in as a nonstick barrier between your work surface and the
product assembly.
Bonding the Assembly
This product’s tabs and notches interlock like a 3D puzzle. We strongly suggest that when fitting parts,
you dry fit (use no glue) the parts together first. It is advised to work 1 - 2 steps ahead in the instructions,
using this dry-fit technique. This allows the opportunity to inspect the fit and location of assembled
components, and shows the benefits of our construction technique. As each successive part is added, it
contributes to pulling the entire assembly square. Once you arrive at the end of a major assembly
sequence, square your work on a flat work surface and bond the dry fit joints with glue. Using the dry-fit
process, you’ll be able to recover from a minor build mistake and will ultimately end up with a square and
true assembly.
Unless otherwise noted in the instructions, we find it easier to “tack glue” parts (temporarily bonding parts
in assemblies, using a small dot of glue). When using medium CA glue, apply with a fine-tip CA glue
applicator. Never bond painted or covered assemblies with thin CA, as it can destroy the finish of a
beautifully prepared model.
Never Force the Fit!
This is a precision laser-cut kit. Our lasers cut to within 5 thousandths of an inch in accuracy. Yet the
wood stock supplied to us by the mill may vary in thickness by up to 20 thousandths. This variance in the
wood stock can cause some tabs and notches to fit very tightly. With this in mind, consider lightly sanding
or lightly pinching a tight-fitting tab, rather than forcing the parts together. You will break fewer parts in
assembly, and end up with a square and true airframe.
Manual Updates
Please check our website for updates to these instructions before starting the build. To obtain downloads
and updates to this model aircraft kit, please visit the product page at stevensaero.com
Build Instructions
Swift (100) - Build Instructions © 2014 Stevens AeroModel, all rights reserved.!Page 7

Fuselage
Fuselage parts are designated with a “F” followed by a numeric. Parts have been numbered so that the
fuselage assembly and required parts follows in numeric order from F1 to F30.
Note: When initially bonding parts, use a single, small drop of medium CA glue, applied sparingly with a
CA glue applicator tip, to “tack glue” the part in place. Should you commit an error in assembly, it will be
easier to recover from the mistake and remove or correct the part in error, if you do not soak the assembly
with glue after each step! This method of assembly will allow our interlocking design to do its job.
As each successive part is installed within the fuselage, it will help pull the entire structure square and
true. When a major assembly is completed, revisit all joints and bond completely. Do not use excessive
amounts of glue, as this only adds weight to the model.
1. Fit center crutch F2 (sheet 02/09, 1/20 in. balsa) to right fuselage side F1 (sheet 01/09, 1/20
in. balsa) observing “Top” orientation etched on part F2.
2. Fit and bond F3a (sheet 01/09, 1/20 in. balsa) to F3b (sheet 02/09, 1/20 in. balsa) to make
former F3. Note: Upper tab on F3 extends beyond outer surface of fuselage side.
3. Fit and tack glue formers F3 and F4 (sheet 04/09, 1/20 in. balsa) at each end of crutch F2,
as indicated on the plan..
4. Fit battery tray F5 (sheet 03/09, 1/20 in. balsa) to fuselage side and F5 observing “Bottom”
orientation.
5. Fit ply part F6 (sheet 09/09, 1/32 in. ply) to fuselage side and F5.
6. Fit former F7 (sheet 01/09, 1/20 in. balsa) to F5 and fuselage side.
7. Fit ply motor mount F8 (1/16 in. ply) to fuselage side. Inspect fit of all formers installed in
steps 1-7. With parts properly seated, proceed to tack glue each former to retain within
fuselage assembly at the tab and notch locations.
8. Fit F9 (sheet 08/09, 3/32 in. balsa) to fuselage side and F2. Tack glue to retain.
Build Instructions
Swift (100) - Build Instructions © 2014 Stevens AeroModel, all rights reserved.!Page 8
□
□
□
□
□
□
□
□

Build Instructions
Swift (100) - Build Instructions © 2014 Stevens AeroModel, all rights reserved.!Page 9
Step 1
Step 2
Step 3
Step 4 Step 8
Step 7
Step 6
Step 5
F1
F2
Top
Front
F3a
F3b
Build part F3
F3
F4F2
F1
Bottom
F1
F3 F5
F1
F6
F7
F5
Bottom View
Bottom View
F5
F1
F1
F8
F9
F2

Fuselage (continued)
9. Fit F10 (sheet 08/09, 3/32 in. balsa) to back of F9, fuselage side, and F2. Once satisfied
with fit bond F9 to F10.
10. Fit left fuselage side F11 (sheet 03/09, 1/20 in. balsa) to assembly. Square assembly then
bond all mating surfaces between fuselage side, formers and crutch with medium CA.
11. Fit ply part F12 (sheet 09/09, 1/32 in. ply) to back side of F6 and fuselage sides.
12. Fit ply part F13 (sheet 09/09, 1/32 in. ply) to back of F12 and fuselage sides. Bond F12 and
F13 within position along outside edges using thin CA glue. Wick minimal amounts of CA
within “pocket” area between ply parts.
13. Bond balsa fuselage doubler F14 (sheet 06/09, 3/32 in. balsa) to right and left fuselage side
with thick or medium CA.
14. Bond second doubler F15 (sheet 07/09, 3/32 in. balsa) over F14. Align F15 using a 1/8 in.
drill bit, or length of 1/8 in. dowel, in the forward alignment holes. Remove alignment dowel
before the glue sets.
15. Fit and glue the edge of nose sheeting F16 (sheet 06/09, 3/32 in. balsa) to the top of F3...
16. ...now, wrap F16 over fuselage sides to nose of model. Bond to fuselage sides/doublers,
F3, and motor mount F8. TIP: Moisten outside of F16 with glass cleaner to soften it. This
will make it easier to bend around the curve of the nose. Tape part in position using a low
tack painters tape and allow to dry thoroughly prior to bonding.
Build Instructions
Swift (100) - Build Instructions © 2014 Stevens AeroModel, all rights reserved.!Page 10
□
□
□
□
□
□
□
□

Build Instructions
Swift (100) - Build Instructions © 2014 Stevens AeroModel, all rights reserved.!Page 11
Step 9
Step 10
Step 11
Step 12 Step 16
Step 15
Step 14
Step 13
F2
F10
F9
F11
F12
F6
F13
F14
F15
F16

Fuselage (continued)
17. Fit and tack glue former F17 (sheet 02/09, 1/20 in. balsa) between fuselage sides where
indicated on plan.
18. Fit and tack glue former F18 (sheet 01/09, 1/20 in. balsa) between fuselage sides at rear of
model.
19. Fit and tack glue former F19 (sheet 08/09, 3/32 in. balsa) to underside of the rear of the
fuselage.
20. Fit F20 (sheet 07/09, 3/32 in. balsa) to the top of F4 and F17, with aft end centered on top
of F18. Bond F17 and F20 permanently to fuselage sides, each other, F4 and F18.
21. Fit and bond F21 (sheet 08/09, 3/32 in. balsa) to rear edge of cockpit, against F4. Note:
Lower edge of F21 will extend beyond exterior edge of cockpit. F21 will later be sanded
flush with edge of fuselage.
22. Assemble and bond parts F22a (sheet 04/09, 1/20 in. balsa) and F22b (sheet 03/09, 1/20
in. balsa) to form a right and left keel F22. Fit and bond keel to the right and left notches in
bottoms of all formers, motor mount, and edge of F19.
Build Instructions
Swift (100) - Build Instructions © 2014 Stevens AeroModel, all rights reserved.!Page 12
□
□
□
□
□
□

Build Instructions
Swift (100) - Build Instructions © 2014 Stevens AeroModel, all rights reserved.!Page 13
Step 17
Step 18
Step 19
Step 20 Step 22 Cont.
Step 22
Step 21 Cont.
Step 21
F17
F18
F19
F20
F21
F22a
F22b
Bottom View
Bottom View

Fuselage (continued)
23. Fit then bond ply doublers F23 (sheet 09/09, 1/32 in. ply) to outside surface of right and left
keels F22 between F13 and F7.
24. Fit and bond ply F24 (sheet 09/09, 1/32 in. ply) spanning right and left keel and F13.
25. Fit and bond ply F25 (sheet 09/09, 1/32 in. ply) spanning right and left keel and F7.
26. Fit and bond long side stringers F26 (sheet 01/09, 1/20 in. balsa) to notches in fuselage
doublers and along right and left fuselage sides.
27. Fit and bond short stringers F27 (sheet 02/09, 1/20 in. balsa) along top edge of fuselage
sides aft of cockpit.
28. Assemble doubler F28 from parts F28a (sheet 04/09, 1/20 in. balsa) and F28b (sheet 03/09,
1/20 in. balsa) and install along lower edge of fuselage sides F1/F11. Bottom profile of F28
should match lower profile of fuselage side. Reference detail sheet for part positioning.
29. Fit and bond center shape stringer F29 (sheet 03/09, 1/20 in. balsa) to right and left
fuselage side. Reference detail sheet for part location
Build Instructions
Swift (100) - Build Instructions © 2014 Stevens AeroModel, all rights reserved.!Page 14
□
□
□
□
□
□
□

Build Instructions
Swift (100) - Build Instructions © 2014 Stevens AeroModel, all rights reserved.!Page 15
Step 23
Step 24
Step 25
Step 26 Step 29
Step 28
Step 27
Step 26 Cont.
F23
F24
F25
F26
F26
F27
F28a and F28b
Bottom View
F29

Fuselage (continued)
30. Sand fuselage lightly. Sand cockpit side flush with edge of former F4. Round corners of
nose. Bevel edges of F20 with fuselage sides. Set fuselage aside until final assembly.
Tail Group
The horizontal and vertical stabilizers, rudder, elevator, and sub-fin are designated with a “H”, “V”, “R”, or
“E”, as appropriate, followed by a numeric. Parts have been numbered so that the assembly and required
parts follows in numeric order. Assemble parts over the plan, protecting the plan with the poly bag that
this kit was shipped in.
31. Dry assemble horizontal stabilizer over the plan, from parts H1 through H5 (sheet 07/09,
3/32 in. balsa). Bond with thin CA. Lightly sand stabilizer, rounding the leading edge and
leaving the trailing edge square. Locate the elevator part E. Bevel the straight leading
edge at a 45 degree angle, following the “Elevator and Aileron Tape Hinge Diagram “ on the
wing detail sheet. Lightly sand the elevator, leaving the trailing edge square.
32. Dry assemble the vertical stabilizer and rudder over the plan from parts V1 through V5
(sheet 08/09, 3/32 in. balsa) and R1 through R4 (sheet 08/09, 3/32 in. balsa). Bond rudder
and stabilizer parts with thin CA. Note: do not bond rudder to the stabilizer. Lightly sand
stabilizer, rounding the leading edge and leave the trailing edge square.
Bevel the leading edge of the rudder at a 45 degree angle, following the “Rudder Tape
Hinge Diagram” on the fuselage detail sheet. Lightly sand the rudder, leaving the trailing
edge square.
Wing
The wing is composed of one spar, leading edge, trailing edge, ribs and tip sheeting. Wing parts are
designated with a “W” followed by a numeric. Parts have been numbered so that the wing assembly and
required parts follows in numeric order from W1 to W15.
The wing is assembled one half at a time - left side first, then mirror build sequence to the right side.
When a part is required in the build sequence (for instance “W3”) refer to the detail sheet for part
placement.
You will dry fit the majority of this wing assembly together only gluing at the final instructional steps.
When parts cannot easily be retained with friction, use a single tiny drop of medium CA glue applied
sparingly through a CA glue applicator tip to “tack glue” the part in place. Should you commit an error in
assembly it will be easier to recover from the mistake and remove or correct the part fit in error if you do
not slather the assembly in glue after each step! Further, this method of assembly will allow our
interlocking design to do it’s job as each successive part installed within the wing will help pull the entire
structure square and true.
33. Begin by building left half of wing. Join parts W1a (sheet 05/09, 1/16 in. balsa) and W1b
(sheet 05/09, 1/16 in. balsa) along the matching dove-tail joints, to create W1 main spar.
Using the detail sheet as a guide, dry fit left side rib W2 (sheet 05/09, 1/16 in. balsa) to main
spar W1. Note: The bottoms of all ribs should seat flush with bottom of spars.
34. Fit rib W3 (sheet 05/09, 1/16 in. balsa) to outer slot of spar W1. Refer back to plan for part
placement.
35. Fit trailing edge W4 (sheet 07/09, 3/32 in. balsa) to ribs W2, and W3. Properly seat then
tack glue assembled parts to retain within assembly.
Build Instructions
Swift (100) - Build Instructions © 2014 Stevens AeroModel, all rights reserved.!Page 16
□
□
□
□□
□□
□□

Build Instructions
Swift (100) - Build Instructions © 2014 Stevens AeroModel, all rights reserved.!Page 17
Step 30
Step 30 Cont.
Step 30 Cont.
Step 31 Step 35
Step 34
Step 33
Step 32
H1
H2
H3
H4
H4
H5
H5
E
V1
V2
V4
V3
V5 R1 R2
R3
R4
W2
W1a and W1b
W3
W4

Wing (continued)
36. Fit rib W5 (sheet 05/09, 1/16 in. balsa) and W6 (sheet 05/09, 1/16 in. balsa) to spar W1 and
trailing edge W4. Square assembly over the plan and tack glue ribs to spar and trailing
edge.
37. Fit and tack glue tip support W7 (sheet 05/09, 1/16 in. balsa) to rib W3. Note: upward taper
on part W7 should match that of spar.
38. Repeat “□□” steps 33 through 37 to complete the rib installation for right half of the wing.
39. Fit one each 12 in length of 1/4 in. square balsa, leading edge stock, beginning each piece
to share a “landing” point centered across the thickness of either left or right W2 rib (see the
detail sheet set for additional guidance). Seat the leading edge stock within the squared
notches cut to the leading edge of the wing ribs. Bond with medium CA to retain the
leading edge within the wing assembly.
40. Assemble two wing tips W8 from parts W8a (sheet 05/09, 1/16 in. balsa) and W8b (sheet
05/09, 1/16 in. balsa). Bond W8a/b with thin CA.
41. Fit left wing tip W8 to tab on leading edge of left rib W3. Align Leading edge of wing tip
along back surface of leading edge stock and against forward portion of rib W6. Tack glue
along leading edge to retain. Repeat process for right wing tip. Allow glue to cure prior to
completing next step.
42. With wing held flat against the table, bend left wing tip over rear portion of ribs, fitting to tab
on W7 and notch in aft end of rib W3. Tack glue to hold position then revisit wing tip with
CA to thoroughly bond part to assembly. Repeat for the right wing tip.
43. Trim excess leading edge stock just beyond left rib W3. Repeat for right side.
Build Instructions
Swift (100) - Build Instructions © 2014 Stevens AeroModel, all rights reserved.!Page 18
□□
□□
□
□
□
□
□
□

Build Instructions
Swift (100) - Build Instructions © 2014 Stevens AeroModel, all rights reserved.!Page 19
Step 36
Step 37
Step 38
Step 39 Step 43
Step 42
Step 41
Step 40
W6
W5
W7
1/4 in. Leading edge
W8a
W8b
“Tack Glue”
Trim
Bottom View

Wing (continued)
44. Locate the laser cut strips of 3/32 square balsa W9a (sheet 07/09, 3/32 in. balsa), W9b
(sheet 07/09, 3/32 in. balsa), and W10 (sheet 07/09, 3/32 in. balsa). Fit W9a and W9b in
the notches over the spar and bond to the spar and ribs with medium CA. Fit W10 in the
notches in the forward portion of the ribs and nesting within slot at wing tip. Bond with
medium CA.
45. Fit and bond W11 (sheet 02/09, 1/20 in. balsa) to the bottom of ribs W2
46. Fit and bond the left and right ply servo mounting plates W12 (sheet 09/09, 1/32 in. ply) to
the notches in left and right of spar W1 and ribs W5.
47. Bond the left and right balsa servo cuffs W13 (3/16 in. balsa) to the BOTTOM of each left
and right servo mounting plate, to create a pocket for the servo to rest in.
48. Fit ply trailing edge reinforcement W14 (sheet 09/09, 1/32 in. ply) within notch of part W4 at
trailing edge of wing. Bond with medium CA glue.
49. Use the detail sheet as a guide for proper positioning of balsa diagonal sub ribs W15 (sheet
05/09, 1/16 in. balsa). Fit right and left sub ribs to assembly, hold wing flat against your
building board and bond with medium CA to retain parts.
50. Sand the leading edge to shape. Match the contour of the leading edge to fit the wing
saddle on the fuselage. Flow the leading edge smoothly into the wing tip.
51. Dry assemble ailerons from parts A1 through A5 (sheet 06/09, 3/32 in. balsa). Bond with
thin CA. Following the “Elevator and Aileron Tape Hinge Diagram” on wing plan sheet,
bevel the underside of the leading edge of the ailerons at a 45 degree angle. Note: Ensure
that you sand the leading edges on the correct side so that you will end up with a LEFT and
a RIGHT aileron.
Build Instructions
Swift (100) - Build Instructions © 2014 Stevens AeroModel, all rights reserved.!Page 20
□
□
□
□
□
□
□
□
