Turbo 53 SE Combi Stiga
23-5298-14
TURBO/COMBI
TURBO 53 SE COMBI
A self propelled lawnmower with collector. The versatile lawn-
mower is working as three machines in one. Equipped with com-
fortable electric start.
The lawnmower is excellent when a very effective collection is
important. The model can also supply other needs. When you
need to work through really high grass you just drive without the
collector. Easily insert a plug and the lawnmower can also be
driven in Multiclip mode. Then you don’t have to rake or empty
grass. Mowing is quieter and you fertilise the grass at the same
time.
The cutting deck is galvanized which gives a better protection
against rust. Cutting width is 51 cm.
The standard is very high regarding performance and environment
friendly features.
Equipped with an environment friendly 5,0 hp motor.

Turbo 53 SE Combi (23-5298-14)
ENGINE
Brand B& S QX 50 ES CARB
Power 5,0 hp, 3,7 Kw, 4-stroke
Number of revolutions 2900 rpm
FUEL
Type of fuel Leadfree 95
WHEELS
Type of wheels Non PVC wheels with double ball bearings
Wheel size Front 170 mm. Rear 210 mm
Driving Self propelled
CUTTING SYSTEM
Type of cutting system Collecting - high impact plastic (PP) bag 60 l and Mulching
by plug
Cutting heights 5 heights, 30-75 mm
Cutting width 51 cm
Cutting height adjustment Central springloaded. 1 level - 4 wheels at the same time
CONTROLS
Electric start Yes
Handlebar Comfortable Stiga handlebar with soft OPC lever
MEASURES & WEIGHT
Weight 37 kg
Package size WxHxL 560x470x800 mm
Units on pallet 8 pcs
OTHER FACTS
Owner's Manual 71503880/0
EAN bar code 731 332 230 054 7
Other features Collecting - high impact fabric bag 70 l.
Galvanized cutting deck
Handle folded in box
