ELECTRICAL HAZARD:
The circuit provided must be protected by
activation current not exceeding 30 mA.
ELECTRICAL HAZARD:
electrical outlet if the plug or the cable is
damaged.
Do not connect or touch a damaged cable
supply.
live parts.
1. Prepare a at area along the edge of the lawn for positioning
thechargingbase,preferablyinanareaofthegardenfrom
which the sky is fully visible.
2. In the area in front of the charging base there must be a
stretch of land at least 1.5 m wide and at least 3 m long
without obstacles.
3. If the sky is not completely visible from the charging base
installation point, the satellite reference station must be
installed in another area
WARNING:
belongtothe productmustremainoutside the
cutting area to maintain their distance from
hazardousmovingparts and preventdamage
live parts.
4. Set up the installation area of the power supply unit in
such a way as to prevent it from being submerged by
water under all weather conditions. Preferably install in a
closed room and protected from weather conditions, in a
location not easily accessible by unauthorised persons.
2.1.3. CHECKSTODEFINETHEVIRTUALPERIMETERS:
1. Check that the maximum slope of the work area is less
than or equal to 45% or 50% depending on the model
(see par. 7 TECHNICAL DATA). When dening the virtual
perimeters, observe the rules shown in Fig. 4.
WARNING:
slope of 45% or 50% depending on the model.
WARNING:
2. Check the entire work surface:assess the obstacles and
areas to be excluded from the work area which must be
programmed as areas to be avoided.
2.2. CRITERIA FOR DELIMITING WORK AREAS
AND TRANSFER ROUTES
1. If there is a pavement or path at the same level as the
lawn, the virtual perimeter can coincide with the edge of
the pavement (Fig. 5.A).
2. In the presence of a swimming pool, pond or excavated
areas, the virtual perimeter must be programmed at a
distance of at least 1 meter.If the pool, pond or excavated
area are positioned at the end of a slope, the virtual
perimeter must be programmed at a distance of at least
1.5 meters (Fig. 5.B).
3. In the case of trees with protruding roots, the virtual
perimeter must be programmed to prevent the robot lawn
mowerfrompassingoversuchunevensurfaces(Fig.5.C).
4. The virtual perimeter must be programmed so that the
robot lawn mower is kept at a distance of at least 30 cm
from areas with gravel or small stones (Fig. 5.D).
5. In the case of sloping areas, follow the instructions
provided in par. 2.1.3.
6. Inthecaseofcontinuousstructuralelements(walls,fences,
hedges, etc.) higher than 50 cm, the virtual boundary
must be programmed at a minimum distance of 40 cm
from them (Fig. 5.E).
7. In all other cases, the virtual boundary must allow a
minimumdistanceof30cmbetweentherobotlawnmower
and the obstacle (Fig. 5.F).
8. In the case of delimitation of obstacles less than 70 cm
apart, delimit them as a single obstacle respecting the
distances indicated above (Fig. 5.G).
CAUTION:
The operating area and more generally the
2.2.1. TRANSITIONS BETWEEN DIFFERENT AREAS
OF THE GARDEN
1. In the case of corridors, the distance between two dierent
virtual perimeters must be Z ≥2 m (Fig. 6).
2. In the event of a passage Z <2 m, the area (Fig.6.A) might
not be reached by the robot mower automatically.Please
refer to the Smart User Manual.
2.2.2. TRANSITION ROUTES
Areas of the garden separated by areas which are not to be
mowed must be connected by transition routes.
1. Assess the possible routes and choose the easiest
transition route that allows the robot to maintain the
furthest distance from any obstacles and that does not
cross areas usually used for parking or the transit of
vehicles or pedestrians.
2. The distance between the transition route and the various
obstacles must under no circumstances be less than 2
meters .
2.3. COMPONENTS INSTALLATION
ELECTRICAL HAZARD:
provided by the manufacturer. Improper use
maycauseelectricshockand\oroverheating.
CAUTION:
Danger of cutting hands.
Use protective gloves to avoid cutting your
hands.
