Stihl HLA 135 User manual

HLA 135, 135 K
2 - 24 Instruction Manual

Contents
1 Introduction................................................. 2
2 Guide to Using this Manual.........................2
3 Overview..................................................... 3
4 Safety Precautions......................................5
5 Preparing Hedge Trimmer for Operation.. 10
6 Charging the Battery, LEDs...................... 10
7 Activating and Deactivating Bluetooth®
Radio Interface..........................................11
8 Assembling the Hedge Trimmer............... 11
9 Removing and Fitting the Battery..............12
10 Switching the Hedge Trimmer On/Off....... 12
11 Testing the Hedge Trimmer and Battery...12
12 Operating the Hedge Trimmer.................. 13
13 After Finishing Work..................................15
14 Transporting..............................................15
15 Storing.......................................................16
16 Cleaning....................................................16
17 Maintenance............................................. 16
18 Repairing...................................................17
19 Troubleshooting........................................ 17
20 Specifications............................................18
21 Combinations of Carrying Systems...........20
22 Spare Parts and Accessories....................20
23 Disposal.................................................... 20
24 EC Declaration of Conformity................... 20
25 UKCA Declaration of Conformity.............. 21
26 General Power Tool Safety Warnings.......21
1 Introduction
Dear Customer,
Thank you for choosing STIHL. We develop and
manufacture our quality products to meet our
customers’ requirements. The products are
designed for reliability even under extreme con‐
ditions.
STIHL also stands for premium service quality.
Our dealers guarantee competent advice and
instruction as well as comprehensive service
support.
STIHL expressly commit themselves to a sus‐
tainable and responsible handling of natural
resources. This user manual is intended to help
you use your STIHL product safely and in an
environmentally friendly manner over a long
service life.
We thank you for your confidence in us and hope
you will enjoy working with your STIHL product.
Dr. Nikolas Stihl
IMPORTANT! READ BEFORE USING AND
KEEP IN A SAFE PLACE FOR REFERENCE.
2 Guide to Using this Manual
2.1 Applicable Documents
The local safety regulations apply.
► In addition to this User Manual, you should
also read, understand and retain the following
documents:
–User manual of the carrying system you are
using
–User Manual for STIHL AR battery
–User Manual for "AP belt bag with connect‐
ing cable"
–Safety notices and precautions for
STIHL AP battery
–User Manual for STIHL AL 101, 301, 301-4,
500 chargers
–Safety information for STIHL batteries and
products with built-in battery:
www.stihl.com/safety-data-sheets
For further information on STIHL connected,
compatible products and FAQs, please visit
www.connect.stihl.com or available from a STIHL
servicing dealer.
The Bluetooth® word mark and logos are regis‐
tered trademarks owned by Bluetooth SIG, Inc.
These word marks/logos are used by STIHL
under license.
Batteries with are equipped with a Bluetooth®
radio interface. Local operating restrictions (in
aircraft or hospitals, for example) must be
observed.
2.2 Warning Notices in Text
DANGER
■ This notice refers to risks which result in seri‐
ous or fatal injury.
► Serious or fatal injuries can be avoided by
taking the precautions mentioned.
WARNING
■ This notice refers to risks which can result in
serious or fatal injury.
► Serious or fatal injuries can be avoided by
taking the precautions mentioned.
English
2 0458-683-0121-B
© ANDREAS STIHL AG & Co. KG 2022
0458-683-0121-B. VA1.E22.
Printed on chlorine-free paper Printing inks contain vegetable oils, paper can be recycled.
Translation of Original Instruction Manual 0000009192_006_GB

NOTICE
■ This notice refers to risks which can result in
damage to property.
► Damage to property can be avoided by tak‐
ing the precautions mentioned.
2.3 Symbols in Text
This symbol refers to a chapter in this
instruction manual.
3 Overview
3.1 STIHL HLA 135 long-reach
hedge trimmer and battery
2
3
12
11
10
13
15
14
4
5
1
#
16
17
6
18
9
7
8
6
0000097309_003
22
#
21
20
19
1 Shaft
The shaft connects all components.
2 Loop handle
For holding and controlling the long-reach
hedge trimmer.
3 Handle hose
For holding and controlling the long-reach
hedge trimmer.
4 Cutting blades
The cutting blades cut the material to be trim‐
med.
5 Blade scabbard
The blade scabbard protects against contact
with the cutting blades.
6 Screw plug
The screw plug closes the filler opening for
STIHL gear grease.
7 Swivel handle
Serves to adjust angle of cutting blades.
8 Sliding sleeve
Unlocks the blade angle adjuster.
9 Locking lever
The locking lever holds the battery in the bat‐
tery compartment.
10 Battery compartment
The battery compartment holds the battery.
11 Cover1
The cover is the placeholder for a Smart Con‐
nector 2 A.
12 Trigger lockout
The trigger lockout unlocks the trigger.
13 Release slide
The release slide is used to switch on the
long-reach hedge trimmer.
14 LED
These LEDs indicate the selected power
level.
15 Carrying ring
The carrying ring is for attaching the carrying
system.
16 Trigger
Switches the long-reach hedge trimmer on
and off.
17 Control handle
For operating, holding and controlling the
long-reach hedge trimmer.
18 Air filter
The air filter filters the air entering the engine.
19 Battery
Supplies power to the long-reach hedge trim‐
mer.
20 LEDs
The LEDs indicate the state of charge of the
battery and any faults.
1The cover is part of the motor housing. Only remove the cover to install a Smart Connector 2 A and
store it safely for later re-installation. Always use the long-reach hedge trimmer with the cover or Smart
Connector 2 A installed.
3 Overview English
0458-683-0121-B 3

21 Pushbutton
The pushbutton activates the LEDs on the
battery. The pushbutton activates and deacti‐
vates Bluetooth® radio interface (if available).
22 "BLUETOOTH®" LED (only for batteries with
)
The LED indicates the activation and deacti‐
vation of the Bluetooth® interface.
# Rating plate with the machine number
3.2 STIHL HLA 135 K long-reach
hedge trimmer and battery
2
11
10
9
12
14
13
3
4
1
#
15
16
5
17
8
6
7
5
0000097310_003
21
#
20
19
18
1 Shaft
The shaft connects all components.
2 Handle hose
For holding and controlling the long-reach
hedge trimmer.
3 Cutting blades
The cutting blades cut the material to be trim‐
med.
4 Blade scabbard
The blade scabbard protects against contact
with the cutting blades.
5 Screw plug
The screw plug closes the filler opening for
STIHL gear grease.
6 Swivel handle
Serves to adjust angle of cutting blades.
7 Sliding sleeve
Unlocks the blade angle adjuster.
8 Locking lever
The locking lever holds the battery in the bat‐
tery compartment.
9 Battery compartment
The battery compartment holds the battery.
10 Cover2
The cover is the placeholder for a Smart Con‐
nector 2 A.
11 Trigger lockout
The trigger lockout unlocks the trigger.
12 Release slide
The release slide is used to switch on the
long-reach hedge trimmer.
13 LED
These LEDs indicate the selected power
level.
14 Carrying ring
The carrying ring is for attaching the carrying
system.
15 Trigger
Switches the long-reach hedge trimmer on
and off.
16 Control handle
For operating, holding and controlling the
long-reach hedge trimmer.
17 Air filter
The air filter filters the air entering the engine.
18 Battery
Supplies power to the long-reach hedge trim‐
mer.
19 LEDs
The LEDs indicate the state of charge of the
battery and any faults.
20 Pushbutton
The pushbutton activates the LEDs on the
battery. The pushbutton activates and deacti‐
vates Bluetooth® radio interface (if available).
21 "BLUETOOTH®" LED (only for batteries with
)
The LED indicates the activation and deacti‐
vation of the Bluetooth® interface.
2The cover is part of the motor housing. Only remove the cover to install a Smart Connector 2 A and
store it safely for later re-installation. Always use the long-reach hedge trimmer with the cover or Smart
Connector 2 A installed.
English 3 Overview
4 0458-683-0121-B

# Rating plate with the machine number
3.3 Symbols
The symbols which may be on the long-reach
hedge trimmer and battery have the following
meanings:
The clamp nut is unscrewed in this posi‐
tion. The shaft can be extended.
The clamp nut is locked in this position.
The shaft cannot be extended.
This icon marks the release slide.
1 LED lights up red. The battery is too
warm or too cold.
4 LEDs flash red. There is a fault in the
battery.
L
W
A
Guaranteed sound power level in
accordance with Directive 2000/14/EC
in dB(A) for the purpose of comparing
the sound emissions of products.
The battery is equipped with a Bluetooth®
radio interface and can be paired with the
STIHL connected app.
The information next to the symbol indi‐
cates the energy content of the battery
according to the cell manufacturer’s specifi‐
cation. The energy content available in
operation is lower.
Do not dispose of the product with domes‐
tic waste.
4 Safety Precautions
4.1 Warning Symbols
Meanings of warning signs and labels on the
long-reach hedge trimmer or battery:
Observe safety notices and take the
necessary precautions.
Read, understand and keep the User
Manual.
Wear safety glasses and a hard hat.
Wear safety boots.
Wear work gloves.
Do not touch moving cutting blades.
Maintain a safety distance.
Remove the battery during work stop‐
pages, transport, storage, maintenance
or repair.
Protect battery from heat and fire.
Do not immerse battery in fluids.
Observe the permitted battery temper‐
ature range.
Do not touch hot surface.
4.2 Intended Use
The STIHL HLA 135 long-reach hedge trimmer is
used to cut low growing shrubs, tall hedges, tall
shrubs, tall bushes and tall thickets.
The STIHL HLA 135 K long-reach hedge trimmer
is used to cut low growing shrubs, tall hedges,
tall shrubs, tall bushes and tall thickets.
The long-reach hedge trimmer may be used in
the rain.
The long-reach hedge trimmer is powered by a
STIHL AP battery or a STIHL AR battery.
The battery with in combination with the
STIHL connected app enables customization and
the transfer of information to the battery using
Bluetooth® technology.
WARNING
■Batteries not explicitly approved for the long-
reach hedge trimmer by STIHL may cause fire
or explosion. Persons may be seriously or
fatally injured, and property may be damaged.
4 Safety Precautions English
0458-683-0121-B 5

► Use the long-reach hedge trimmer with a
STIHL AP battery or a STIHL AR battery.
■ Using the long-reach hedge trimmer or the
battery for purposes for which they were not
designed may result in serious or fatal injuries
and damage to property.
►Use the long-reach hedge trimmer as
described in this User Manual.
► Use the battery as described in this User
Manual, STIHL AR battery User Manual,
STIHL connected app and at www.con‐
nect.stihl.com.
4.3 The Operator
WARNING
■ Users without adequate training or instruction
cannot recognize or assess the risks involved
in using the hedge trimmer and battery. The
user or other persons may sustain serious or
fatal injuries.
► Read, understand and save the
instruction manual.
► If the hedge trimmer or battery is passed on
to another person: Always give them the
instruction manual.
►Make sure the user meets the following
requirements:
–The user must be rested.
–The user must be in good physical con‐
dition and mental health to operate and
work with the hedge trimmer and bat‐
tery. If the user’s physical, sensory or
mental ability is restricted, he or she
may work only under the supervision of
or as instructed by a responsible per‐
son.
–The user is able to recognize and
assess the risks involved in using the
hedge trimmer and battery.
–The user must be of legal age or is
being trained in a trade under supervi‐
sion in accordance with national rules
and regulations.
–The user has received instruction from a
STIHL servicing dealer or other experi‐
enced user before working with the
hedge trimmer for the first time.
–The user must not be under the influ‐
ence of alcohol, medication or drugs.
► If you have any queries: Contact a STIHL
servicing dealer for assistance.
4.4 Clothing and equipment
WARNING
■Long hair may be pulled into the long-reach
hedge trimmer during operation. This may
result in serious injury to the user.
►Tie up and confine long hair above your
shoulders.
■ Objects can be thrown at high speed during
operation. This may result in injury to the user.
► Wear close-fitting safety glasses.
Suitable safety glasses are tested in
accordance with EN 166 or national
regulations and available commer‐
cially with the corresponding mark‐
ing.
■Falling objects can cause head injuries.
► wear a hard hat.
■ Dust can be whipped up during operation.
Whipped up dust can damage the respiratory
passages and cause allergic reactions.
►If dust is generated: Wear a dust respirator
mask.
■ Unsuitable clothing may snag on wood, thick‐
ets or the long-reach hedge trimmer. Users
not wearing suitable clothing are at risk of seri‐
ous injury.
►Wear close-fitting clothing.
► Remove scarves and jewelry.
■ The user may come into contact with the cut‐
ting blades during cleaning or servicing. This
may result in injury to the user.
► Wear work gloves made from resist‐
ant material.
■ Wearing unsuitable footwear may cause the
user to slip. This may result in injury to the
user.
► Wear sturdy, closed-toed footwear
with high-grip soles.
4.5 Work Area and Surroundings
4.5.1 Long-reach hedge trimmer
WARNING
■Bystanders, children and animals cannot rec‐
ognize or assess the dangers of the long-
reach hedge trimmer or flying debris. This may
result in serious injury to bystanders, children
and animals and damage to property.
English 4 Safety Precautions
6 0458-683-0121-B

► Do not allow bystanders,
children or animals within 5
meters of the work area.
► Maintain a clearance of 5 meters from
objects.
► Do not leave the long-reach hedge trimmer
unattended.
► Ensure that children cannot play with the
long-reach hedge trimmer.
■ Electrical components of the long-reach hedge
trimmer can generate sparks. Sparks may
cause fires and explosions in highly flammable
or explosive environments. Persons may be
seriously or fatally injured and property may
be damaged.
►Do not work in a highly flammable or explo‐
sive environment.
4.5.2 Battery
WARNING
■ Bystanders, children and animals cannot rec‐
ognize or assess the dangers of the battery.
Bystanders, children and animals may be seri‐
ously injured.
►Keep bystanders, children and animals
away from the work area.
► Do not leave the battery unattended.
► Make sure that children cannot play with
the battery.
■ The battery is not protected against all ambi‐
ent conditions. If the battery is exposed to cer‐
tain ambient conditions, the battery may catch
fire, explode or be irreparably damaged. This
may result in serious injury to people and
damage to property.
► Protect battery from heat and fire.
► Do not throw the battery into a fire.
► Use and store the battery at temper‐
atures between ‑ 10 °C and + 50 °C.
► Do not immerse the battery in fluids.
► Keep battery away from small metal parts.
► Do not expose the battery to high pressure.
► Do not expose the battery to microwaves.
► Protect the battery from chemicals and
salts.
4.6 Safe Condition
4.6.1 Long-reach hedge trimmer
The long-reach hedge trimmer is in a safe condi‐
tion if the following points are observed:
–The long-reach hedge trimmer is not dam‐
aged.
–The long-reach hedge trimmer is clean.
–The controls function properly and have not
been modified.
–The cutting blades are correctly fitted.
–Only original STIHL accessories designed for
this long-reach hedge trimmer are fitted.
–The accessories are correctly attached.
WARNING
■ If not in safe condition, components may no
longer operate correctly and safety devices
may be disabled. This may result in serous or
fatal injury to people.
►Work only with an undamaged long-reach
hedge trimmer.
► If the long-reach hedge trimmer is dirty:
Clean the long-reach hedge trimmer.
► Do not modify the long-reach hedge trim‐
mer.
► If the controls do not function properly: Do
not work with the long-reach hedge trim‐
mer.
►Only fit original STIHL accessories
designed for this long-reach hedge trimmer.
► Attach accessories as described in this
User Manual or in the User Manual for the
accessories.
►Never insert objects into the openings of
the long-reach hedge trimmer.
► Replace worn or damaged labels.
► If you have any doubts, be sure to consult a
STIHL dealer.
4.6.2 Cutting Blades
The cutting blades are in a safe condition if the
following points are observed:
–Cutting blades are undamaged.
–Cutting blades are not deformed.
–Cutting blades move freely.
–Cutting blades are properly sharpened.
–Cutting blades have no burrs.
WARNING
■If they are in an unsafe condition, parts of the
cutting blades may come off and be thrown at
high speed. This can result in serious injuries.
►Work only with undamaged cutting blades.
► Make sure the cutting blades are properly
sharpened and deburred.
4 Safety Precautions English
0458-683-0121-B 7

► If you have any queries: Contact your
STIHL servicing dealer.
4.6.3 Battery
The battery is in safe condition when the follow‐
ing conditions are met:
–The battery is not damaged.
–The battery is clean and dry.
–The battery is working and has not been modi‐
fied.
WARNING
■ The battery cannot function safely if it is not in
safe condition. There is a risk of serious injury
to persons.
►Use an undamaged and functioning battery.
► Do not charge a damaged or defective bat‐
tery.
► If the battery is dirty or wet: clean the bat‐
tery and allow it to dry.
► Do not modify the battery.
► Do not insert objects into the apertures in
the battery.
► Never connect the battery terminals to met‐
allic objects and cause a short circuit.
► Do not open the battery.
► Replace worn or damaged warning signs.
■ Fluid may leak from a damaged battery. If the
fluid contacts the skin or eyes, this may cause
irritation.
►Avoid contact with the fluid.
► In the event of contact with the skin: wash
the affected areas with plenty of soap and
water.
►In the event of contact with the eyes: rinse
the eyes with plenty of water for at least 15
minutes and seek medical attention.
■A damaged or defective battery may emit an
unusual odour, smoke or catch fire. This may
result in serious or fatal injury to people and
damage to property.
►If the battery emits an unusual odour or
smoke: do not use the battery and keep it
away from flammable materials.
►If the battery catches fire: try to extinguish
the battery using a fire extinguisher or
water.
4.7 Working
WARNING
■In certain situations, the user may no longer
be able to concentrate on their work. This may
result in the user stumbling, falling and suffer‐
ing serious injury.
►Keep calm and plan your work.
► If light and visibility are poor: Do not work
with the long-reach hedge trimmer.
► Operate the long-reach hedge trimmer
alone.
► Watch out for obstacles.
► Work standing on the ground and keep your
balance. If you have to work at a height:
Use a mobile elevating work platform or
secure scaffolding.
►If you start feeling fatigue: Take a break.
■ Working above shoulder height can cause fati‐
gue sooner. This may result in serious injury to
the user.
►Work above shoulder height for short peri‐
ods only.
► Take breaks.
■ If the moving cutting blade makes contact with
a hard object it can be brought to a sudden
stop. The reactive forces that occur can cause
the user to lose control of the long-reach
hedge trimmer and be seriously injured.
►Hold the long-reach hedge trimmer firmly
with both hands.
► Before starting work, check hedge for hard
objects and remove any such objects.
■ The moving cutting blades can cut the user.
This may result in serious injury to the user.
► Do not touch moving cutting blades.
► If the cutting blades are blocked by
an object: Switch off the long-reach
hedge trimmer and remove the bat‐
tery. before clearing the jam.
■If the behavior of the long-reach hedge trim‐
mer changes during operation or feels
unusual, it may no longer be in a safe condi‐
tion. This may result in serious injury to people
and damage to property.
►Stop working, remove the battery and con‐
sult a STIHL dealer.
■ Vibrations may occur while using the long-
reach hedge trimmer.
► Wear gloves.
► Take breaks.
► If signs of a circulatory disturbance occur:
Consult a doctor.
■ Note that the cutting blades continue to run for
a short period after you release the trigger.
The moving cutting blades may cut the user.
They may cause serious injury to persons.
►Wait until the cutting blades come to a com‐
plete standstill.
English 4 Safety Precautions
8 0458-683-0121-B

■ In an emergency, the user may start to panic
and forget to take off the carrying system. This
may result in serious injury to the user.
►Practice taking off the carrying system.
DANGER
■Working near live electric cables may result in
accidental contact with and damage to the cut‐
ting blades. This may result in serious or fatal
injury to the user.
► Maintain a clearance of
15 meters from live cables.
4.8 Transporting
4.8.1 Hedge Trimmer
WARNING
■ The hedge trimmer may turn over or shift dur‐
ing transport. This may result in personal inju‐
ries and damage to property.
► Remove the battery.
► Fit the blade scabbard so that it completely
covers the cutting blades.
► Secure the hedge trimmer with lashing
straps or a net to prevent it turning over and
moving.
4.8.2 Battery
WARNING
■The battery is not protected against all ambi‐
ent conditions. The battery may be damaged if
it is exposed to certain ambient conditions,
and damage to property may occur.
►Never transport a damaged battery.
■ The battery may turn over or shift during trans‐
port. This may result in injury to people and
damage to property.
►Pack the battery in packaging in such a way
that it cannot move.
► Secure the packaging so that it cannot
move.
4.9 Storing
4.9.1 Long-reach hedge trimmer
WARNING
■Children are not aware of and cannot assess
the dangers of the long-reach hedge trimmer.
Children may be seriously injured.
► Remove the battery.
► Push the blade scabbard over the cutting
blades, ensuring that it completely covers
the cutting blades.
►Store the long-reach hedge trimmer out of
the reach of children.
■ Dampness can corrode the electrical contacts
on the long-reach hedge trimmer and metal
components. The long-reach hedge trimmer
may be damaged.
► Remove the battery.
► Store the long-reach hedge trimmer in a
clean and dry condition.
4.9.2 Battery
WARNING
■ Children are not aware of and cannot assess
the dangers of the battery Children may be
seriously injured.
►Store the battery out of the reach of chil‐
dren.
■ The battery is not protected against all ambi‐
ent conditions. If the battery is exposed to cer‐
tain ambient conditions, the battery may be
irreparably damaged.
►Store the battery in a clean and dry condi‐
tion.
► Store the battery in an enclosed space.
► Store the battery separately from the hedge
trimmer.
► If the battery is stored in the charger, dis‐
connect the mains plug and store the bat‐
tery at a state of charge between 40% and
60% (2 lit green LEDs).
►Store the battery at a temperature range
between - 10 °C and + 50 °C.
4.10 Cleaning, Maintenance and
Repair
WARNING
■The long-reach hedge trimmer may start unin‐
tentionally if the battery is left in place during
cleaning, maintenance or repair operations.
This may result in serious injury to people and
damage to property.
4 Safety Precautions English
0458-683-0121-B 9

► Remove the battery.
■ The gear housing can get hot during opera‐
tion. There is a risk of burn injuries.
► Do not touch a hot gear housing.
■ Aggressive cleaning agents, a water jet or
pointed objects can damage the long-reach
hedge trimmer, cutting blades and the battery.
If the long-reach hedge trimmer, cutting blades
or battery are not cleaned correctly, compo‐
nents may no longer function properly or
safety devices may be rendered inoperative.
They may cause serious injury to persons.
► Clean the long-reach hedge trimmer, cut‐
ting blades and battery as described in this
User Manual.
■If the long-reach hedge trimmer, cutting blades
or battery are not serviced or repaired cor‐
rectly, components may no longer function
properly or safety devices may be rendered
inoperative. This may result in serous or fatal
injury to people.
►Do not attempt to service or repair the long-
reach hedge trimmer or battery.
► If the long-reach hedge trimmer or the bat‐
tery require servicing or repairs: Contact
your STIHL dealer for assistance.
►Maintain the cutting blades as described in
this User Manual.
■ The user may be cut while cleaning or servic‐
ing the sharp cutting blades. This may result in
injury to the user.
► Wear work gloves made from resist‐
ant material.
5 Preparing Hedge Trimmer
for Operation
5.1 Preparing the Long-Reach
Hedge Trimmer for Operation
The following steps must be performed before
commencing work:
► Ensure that the following components are in a
safe condition:
–Long-reach hedge trimmer, 4.6.1.
–Cutting blades, 4.6.2.
–Battery, 4.6.3.
►Check the battery, 11.2.
► Fully charge battery as described in the User
Manual for the STIHL AL 101, 301, 301-4, 500
chargers.
►Clean the long-reach hedge trimmer, 16.1.
►Assembling the long-reach hedge trimmer,
8.1.
►Mount the loop handle (HLA 135), 8.2.
►Adjust the angle of the cutting blades, 12.1.
►Fit and adjust the shoulder strap, 12.2.
►Check the controls, 11.1.
► If you cannot carry out these steps: Do not use
the long-reach hedge trimmer and contact
your STIHL authorized dealer for assistance.
5.2 Connecting a battery with Blue‐
tooth® radio interface with the
STIHL connected app
►Activate the Bluetooth® radio interface on the
mobile device.
►Activating the Bluetooth® radio interface on
the battery, 7.1.
► Download the STIHL connected app to the
mobile device from the App Store and create
an account.
► Open and sign in to the STIHL connected app.
► Add the battery in the STIHL connected app
and follow the instructions on the screen.
For contacts and other information, please visit
https://support.stihl.com or see the STIHL con‐
nected app.
The STIHL connected app is available interna‐
tionally.
6 Charging the Battery, LEDs
6.1 Charging the Battery
The charging time depends on various factors,
e.g. the battery temperature or the ambient tem‐
perature. The actual charging time may vary
from the charging time indicated. The charging
time is indicated at www.stihl.com/charging-
times.
► Recharge the battery as described in the User
Manual for the STIHL AL 101, 301, 301-4, 500
chargers.
English 5 Preparing Hedge Trimmer for Operation
10 0458-683-0121-B

6.2 Displaying the charge level
0000079877_002
20-40%
40-60%
60-80%
80-100%
0-20%
1
► Press the button (1).
The LEDs light up green for about 5 seconds
and indicate the state of charge.
► If the LED on the right flashes green: Charge
the battery.
6.3 LEDs on Battery
The LEDs can show the state of charge or mal‐
functions. The LEDs can glow or flash green or
red.
The state of charge is indicated when the LEDs
glow or flash green.
► If the LEDs glow or flash red: Troubleshooting,
19.
There is a malfunction in hedge trimmer or
battery.
7 Activating and Deactivating
Bluetooth® Radio Interface
7.1 Activating the Bluetooth® Radio
Interface
►If the battery has a Bluetooth® radio interface:
Press and hold the pushbutton until the
"BLUETOOTH®" LED next to the symbol
lights up blue for approximately 3 seconds.
The Bluetooth® radio interface on the battery
is activated.
7.2 Deactivating the Bluetooth®
Radio Interface
►If the battery has a Bluetooth® radio interface:
Press and hold the pushbutton until the
"BLUETOOTH®" LED next to the symbol
lights up blue six times.
The Bluetooth® radio interface on the battery
is deactivated.
8 Assembling the Hedge
Trimmer
8.1 Assembling the Long-Reach
Hedge Trimmer
► Switch off the long-reach hedge trimmer and
remove the battery.
14
3
2
3
5
a
90°
90°
0000098180_001
► Remove the protective cap (1).
► Undo the screws (2).
► Push the transmission (3) onto the shaft (4) in
such a way that the following conditions are
met:
–In case of assembly of an HLA 135:
a = approx. 53 cm
–In case of assembly of an HLA 135 K:
a = approx. 38 cm
► Align the housing (5) and transmission (3) as
shown.
► Tighten down the screws (2) firmly.
The long-reach hedge trimmer does not need to
be dismantled again.
8.2 Mounting the Loop Handle
(HLA 135)
► Switch off the long-reach hedge trimmer and
remove the battery.
7
4
6
5
11
2
2
3
7
a
0000097311_001
► Fit the clamp (4) in the loop handle (3).
► Place the loop handle (3) with clamp (4) on the
shaft (5).
► Fit the washers (2) on the screws (1).
► Press the clamp (6) against the shaft (5).
► Insert the screws (1) through holes in the loop
handle (3) and clamps (4 and 6).
► Slide the loop handle (3) until the distance (a)
is 20 cm.
7 Activating and Deactivating Bluetooth® Radio Interface English
0458-683-0121-B 11

► Screw on and firmly tighten the nuts (7).
9 Removing and Fitting the
Battery
9.1 Inserting the Battery
1
2
0000097033-001
► Insert the battery (1) up to the limit stop into
the battery compartment (2).
The battery (1) engages with a click and is
now locked.
9.2 Removing the Battery
► Stand the hedge trimmer on a level surface.
2
1
0000097034-001
► Press both locking levers (1).
The battery (2) is released and can be
removed.
10 Switching the Hedge Trim‐
mer On/Off
10.1 Switching on the long-reach
hedge trimmer
► Hold the long-reach hedge trimmer with one
hand on the control handle - wrap your thumb
around the handle.
► Hold the long-reach hedge trimmer firmly with
your other hand on the loop handle or handle
hose - wrap your thumb around the loop han‐
dle or handle hose.
3
1
2
0000097312_001
► Press the trigger lockout (1) with your hand
and keep it pressed.
► Push the release slide (2) in the direction of
the loop handle with your thumb and hold it
there.
The LEDs emit light to indicate the power level
used last.
► Press the trigger (3) with your index finger and
keep depressed.
The long-reach hedge trimmer accelerates
and the cutting blades run.
The long-reach hedge trimmer can also be
switched on by first pressing the release slide (2)
and pressing the trigger lockout (1) within 5 sec‐
onds (as long as the LEDs are flashing). The trig‐
ger (3) is now unlocked and the long-reach
hedge trimmer is ready for use.
The LEDs continue flashing for 5 seconds after
the trigger (3) and trigger lockout (1) are
released after switch-on. As long as the LEDs
flash, the long-reach hedge trimmer can be
switched on again without having to actuate the
release slide (2).
10.2 Switching off long-reach hedge
trimmer
► Release the trigger and trigger lockout.
► Wait until the cutting blades come to a com‐
plete standstill.
► If the cutting blades continue to run: Remove
the battery and contact your STIHL dealer for
assistance.
There is a malfunction in the long-reach hedge
trimmer.
11 Testing the Hedge Trimmer
and Battery
11.1 Checking the controls
Trigger lockout and trigger
► Remove the battery.
► Try pressing the trigger without pressing the
trigger lockout.
English 9 Removing and Fitting the Battery
12 0458-683-0121-B

► If the trigger can be pulled: Do not use the
long-reach hedge trimmer and contact your
STIHL dealer for assistance.
The trigger lockout is faulty.
► Press and hold the trigger lockout.
► Squeeze and release the trigger.
► If the trigger or trigger lockout is stiff or does
not spring back to the idle position: Do not use
your long-reach hedge trimmer and contact
your STIHL dealer.
The trigger or the trigger lockout is defective.
Switching on the long-reach hedge trimmer
► Insert battery.
► Press and hold the trigger lockout.
► Push the release slide in the direction of the
cutting blades with your thumb.
► Press and hold the trigger.
The cutting blades run.
► If 3 LEDs flash red: Remove the battery and
consult a STIHL dealer.
There is a malfunction in the long-reach hedge
trimmer.
► Release the trigger.
The cutting blades come to a complete stand‐
still.
► If the cutting blades continue to run: Remove
the battery and contact your STIHL dealer for
assistance.
There is a malfunction in the long-reach hedge
trimmer.
11.2 Testing the Battery
► Press button on battery.
The LEDs glow or flash.
► If the LEDs do not glow or flash: Do not use
the battery and contact your STIHL servicing
dealer.
There is a malfunction in the battery.
12 Operating the Hedge Trim‐
mer
12.1 Adjusting the Angle of the Cut‐
ting Blades
The angle of the cutting blades can be adjusted
to 4 different positions upwards and 7 different
positions downwards to suit the application and
the height and reach of the user.
► Switch off the long-reach hedge trimmer and
remove the battery.
1
2
55°
90°
0000097313_001
► Pull back the sliding sleeve (1) and hold it
there.
► Grip the swivel handle (2) and swing cutting
blade to required angle.
► Release the sliding sleeve (1).
► Move swivel handle (2) back and forth until the
sliding sleeve (1) engages.
The sliding sleeve (1) butts against the hous‐
ing. You have adjusted the angle of the cutting
blades.
► Check that the swivel handle (2) cannot be
pushed in or pulled out any more.
12.2 Fitting and Adjusting the Shoul‐
der Strap
2
1
0000-GXX-2990-A0
► Put on the shoulder strap (1).
► Adjust the shoulder strap (1) so that the cara‐
biner (2) is about a hand’s width below your
right hip.
Other approved carrying systems are listed in
this User Manual, 21.
12.3 Holding and controlling the
long-reach hedge trimmer
2
1
0000-GXX-7807-A1
► Connect the carrying ring (2) to the carabi‐
ner (1).
12 Operating the Hedge Trimmer English
0458-683-0121-B 13

0000097178_001
► Hold the long-reach hedge trimmer with one
hand on the control handle and clasp the con‐
trol handle with your thumb.
► Hold the long-reach hedge trimmer firmly with
your other hand on the handle hose and clasp
the handle hose with your thumb.
HLA 135
0000-GXX-4570-A0
► Hold the long-reach hedge trimmer with one
hand on the control handle and clasp the con‐
trol handle with your thumb.
► Hold the long-reach hedge trimmer with your
other hand on the loop handle and clasp the
loop handle with your thumb.
12.4 Setting the performance level
Depending on the application, 3 power levels
can be set. The LEDs indicate the selected
power level. The higher the power level, the
faster the cutting blades can run.
The selected power level affects the battery’s
runtime. The lower the power level, the longer
the runtime.
1
2
0000097314_001
► Press and hold the trigger lockout (1).
► Push the release slide (2) in the direction of
the cutting blades with your thumb.
The LEDs emit light to indicate the power level
selected.
► Push the release slide (2) forwards, hold it
briefly in that position and allow it to spring
back.
This selects the next power level. After the
third performance level, it starts again with the
first performance level.
► Push the release slide (2) forwards and allow
it to spring back as many times as necessary
to select the required power level.
12.5 Cutting
Cutting close to the ground (HLA 135)
0000084757_002
► Set the cutting blades to a suitable angle.
► Swing the long-reach hedge trimmer evenly
back and forth in an arc.
► Move forward slowly in a controlled manner.
► If cutting performance deteriorates: Sharpen
the cutting blades.
Cutting the side of the hedge
► Use pruning shears or a chainsaw to cut out
thick branches first.
0000084758_002
► If you have to cut at a certain distance from
the hedge: Set the cutting blades to a suitable
angle.
► Swing the long-reach hedge trimmer in an arc
at one side of the hedge while making the cut.
► Move forward slowly in a controlled manner.
► Cut the other side of the hedge in the same
way.
► If cutting performance deteriorates: Sharpen
the cutting blades.
English 12 Operating the Hedge Trimmer
14 0458-683-0121-B

Cutting the top of the hedge
► Use pruning shears or a chainsaw to cut out
thick branches first.
0000097227_002
► Hold the cutting blades at an angle of 0° to 10°
to the top of the hedge.
► Swing the long-reach hedge trimmer horizon‐
tally and in an arc while making the cut.
► If cutting performance deteriorates: Sharpen
the cutting blades.
Cutting overhead
► Use pruning shears or a chainsaw to cut out
thick branches first.
0000097226_001
► Set the cutting blades completely to a suitable
angle.
► Hold the cutting blades at an angle of 0° to 10°
to the top of the hedge.
► Swing the long-reach hedge trimmer horizon‐
tally and in an arc while making the cut.
► If cutting performance deteriorates: Sharpen
the cutting blades.
13 After Finishing Work
13.1 When Work is Finished
► Switch off the long-reach hedge trimmer and
remove the battery.
► If the long-reach hedge trimmer is wet: Allow
the hedge trimmer to dry.
► If the battery is wet: Leave the battery to dry.
► Clean the long-reach hedge trimmer.
► Clean cutting blades.
► Push the blade scabbard over the cutting
blades, ensuring that it completely covers the
cutting blades.
► Clean the battery.
14 Transporting
14.1 Transporting the long-reach
hedge trimmer
► Switch off the long-reach hedge trimmer and
remove the battery.
► Push the blade scabbard over the cutting
blades, ensuring that it completely covers the
cutting blades.
Carrying the long-reach hedge trimmer
4
3
2
1
0000097315_001
► Pull back and hold the sliding sleeve (4).
► Grip the swivel handle (3) and fold down the
cutting blades (1).
The cutting blades (1) are parallel to the
shaft (2).
► Release the sliding sleeve (4).
The sliding sleeve (4) engages and is posi‐
tioned on the housing. The cutting blades (1)
are in the transport position.
► Carry the long-reach hedge trimmer with one
hand on the shaft, ensuring that the cutting
blades (1) are pointing to the rear.
Transporting the long-reach hedge trimmer in a
vehicle
► Secure the hedge trimmer so that it cannot
turn over or move.
14.2 Transporting the Battery
► Switch off the hedge trimmer and remove the
battery.
► Check that the battery is in a safe condition.
► Pack the battery in packaging in such a way
that it cannot move inside the packaging.
► Secure the packaging so that it cannot move.
The battery is subject to the Carriage of Danger‐
ous Goods regulations. The battery is classified
as UN 3480 (lithium ion batteries) and has been
tested pursuant to UN Manual Tests and Criteria
Part III, Subsection 38.3.
The transport regulations can be found at
www.stihl.com/safety-data-sheets.
13 After Finishing Work English
0458-683-0121-B 15

15 Storing
15.1 Storing the Hedge Trimmer
► Switch off the hedge trimmer and remove the
battery.
► Fit the blade scabbard so that it completely
covers the cutting blades.
► Observe the following points when storing the
hedge trimmer:
–Hedge trimmer is out of the reach of chil‐
dren.
–Hedge trimmer is clean and dry.
15.2 Storing the Battery
STIHL recommends keeping the battery in a
charging state between 40% and 60 % (2 green
LEDs lit).
► The battery should be stored in such a way
that the following conditions are fulfilled:
–The battery is out of the reach of children.
–The battery is clean and dry.
–The battery is in an enclosed space.
–Battery is stored separately from the hedge
trimmer.
–If the battery is stored in the charger, dis‐
connect the mains plug and store the
rechargeable battery at a battery charge
status between 40 % and 60 % (2 lit green
LEDs).
–The battery is in a temperature range
between - 10 °C and + 50 °C.
NOTICE
■ If the battery is not stored as described in this
user manual, the battery may become deeply
discharged and irreparably damaged.
►Charge a discharged battery before storing
it. STIHL recommends keeping the battery
in a charging state between 40% and 60%
(2 lit green LEDs).
►Store the battery separately from the hedge
trimmer.
16 Cleaning
16.1 Cleaning the long-reach hedge
trimmer
► Switch off the long-reach hedge trimmer and
remove the battery.
► Clean the long-reach hedge trimmer with a
damp cloth or STIHL resin solvent.
► Clean vents with a paintbrush.
► Remove foreign objects from the battery com‐
partment and clean the battery compartment
with a damp cloth.
► Clean the electrical contacts in the battery
compartment with a paintbrush or soft brush.
16.2 Cleaning the Cutting Blades
► Switch off the hedge trimmer and remove the
battery.
► Spray both sides of blades with STIHL resin
solvent.
► Fit the battery.
► Switch on the hedge trimmer for 5 seconds.
The cutting blades run. STIHL resin solvent is
distributed evenly.
16.3 Cleaning the Air Filter
► Switch off the long-reach hedge trimmer and
remove the battery.
0000097125-001
1
2
► Clean the area around the air filter (2) with a
damp cloth or a soft brush.
► Turn the screw (1) counterclockwise until the
air filter (2) can be removed.
► Swing the air filter (2) upwards and pull it off.
► Pass the air filter (2) under running water to
rinse off coarse dirt from the outside.
► If the air filter (2) is damaged: Install a new air
filter (2).
► Allow the air filter (2) to dry in the air.
► Install the air filter (2) in the housing and fold it
down.
The air filter (2) must sit flush in the housing at
all sides.
► Insert and tighten down the screw (1) firmly.
16.4 Cleaning the Battery
► Clean the battery with a damp cloth.
17 Maintenance
17.1 Maintenance intervals
Maintenance intervals depend on the ambient
conditions and the operating conditions. STIHL
recommends the following maintenance inter‐
vals:
After every 25 hours of operation
► Lubricate the gearbox.
After every 50 hours of operation
English 15 Storing
16 0458-683-0121-B

► Clean the air filter.
Annually
► Have the long-reach hedge trimmer checked
by a STIHL dealer.
17.2 Lubricating the gearbox
1
2
1
2
0000097316_001
► Unscrew the screw plugs (1).
► If no grease is visible at the screw plugs (1):
► Screw in the tube of "STIHL Getriebe‐
fett" (2).
► Squeeze 5 g of STIHL gear grease into the
gear housing.
► Unscrew the tube of "STIHL Getriebe‐
fett" (2).
► Screw in the screw plugs (1) and tighten
them.
► Switch on the long-reach hedge trimmer for
1 minute.
The STIHL gear grease is distributed
evenly.
17.3 Sharpening the cutting blade
STIHL recommends you have the cutting blades
resharpened by a STIHL dealer.
WARNING
■ The teeth of the cutting blades are very sharp.
This may result in the user cutting themselves.
► Wear work gloves made from resistant
material.
► Switch off the long-reach hedge trimmer and
remove the battery.
0000-GXX-1426-A0
► Use a STIHL flat file to sharpen each cutting
edge on the upper blade. The file only sharp‐
ens on the forward stroke. Maintain the pre‐
scribed sharpening angle, 20.2.
► Turn the long-reach hedge trimmer over.
► Sharpen the remaining cutting edges.
► Deburr each cutting edge from below.
► Turn the long-reach hedge trimmer over.
► Deburr the remaining cutting edges.
► Use a damp cloth to remove the filing dust.
► Spray both sides of cutting blades with STIHL
resin solvent.
► Switch on the long-reach hedge trimmer for 5
seconds.
The cutting blades run. STIHL resin solvent is
distributed evenly.
► If you have any doubts, be sure to consult a
STIHL dealer.
18 Repairing
18.1 Repairing the Hedge Trimmer
and Battery
The hedge trimmer, cutting blades and battery
cannot be repaired by the user.
► If the hedge trimmer or cutting blades are
damaged: Do not use your hedge trimmer and
contact your STIHL servicing dealer.
► If the battery has a malfunction or is damaged:
Replace the battery.
19 Troubleshooting
19.1 Troubleshooting the Hedge Trimmer and Battery
Fault LEDs on the
battery
Cause Remedy
Hedge trimmer
does not start
when switched
on.
1 LED flashing
green.
State of charge of the
battery is too low.
► Charge battery as described in the User
Manual for chargers STIHL AL 101, 301,
301-4, 500.
1 LED emits
red light.
The battery is too
warm or too cold.
► Remove the battery.
► Allow the battery to cool down or warm
up.
18 Repairing English
0458-683-0121-B 17

Fault LEDs on the
battery
Cause Remedy
3 LEDs flash‐
ing red.
There is a malfunction
in the hedge trimmer.
► Remove the battery.
► Clean electrical contacts in the battery
compartment.
► Insert battery.
► Switch on the hedge trimmer.
► If 3 LEDs continue to flash red: Do not
use the hedge trimmer and contact your
STIHL dealer for assistance.
The cutting blades do
not run freely.
► Spray both sides of cutting blades with
STIHL resin solvent.
► If 3 LEDs continue to flash red: Do not
use the hedge trimmer and contact your
STIHL dealer for assistance.
3 LEDs light
up red.
Hedge trimmer is too
hot.
► Remove the battery.
► Allow hedge trimmer to cool down.
4 LEDs flash‐
ing red.
There is a fault in the
battery.
► Remove battery and reinsert it.
► Switch on the hedge trimmer.
► If 4 LEDs continue to flash red: Do not
use the battery; contact a STIHL author‐
ized dealer.
No electrical contact
between hedge trim‐
mer and battery.
► Remove the battery.
► Clean electrical contacts in the battery
compartment.
► Insert battery.
Hedge trimmer or bat‐
tery is damp.
► Allow hedge trimmer or battery to dry.
Hedge trimmer
cuts out during
operation.
3 LEDs light
up red.
Hedge trimmer is too
hot.
► Remove the battery.
► Allow hedge trimmer to cool down.
There is an electrical
fault.
► Remove battery and reinsert it.
► Switch on the hedge trimmer.
Hedge trimmer
runtime is too
short.
The battery is not fully
charged.
► Fully charge battery as described in the
User Manual for the STIHL AL 101, 301,
301-4, 500 chargers.
The battery service
life has been excee‐
ded.
► Replace battery.
STIHL connected
app unable to
find the battery
with .
Bluetooth® radio inter‐
face on the battery or
mobile device is deac‐
tivated.
►Activate Bluetooth® radio interface on the
battery or mobile device.
Distance between bat‐
tery and mobile
device is too long.
►Reduce distance, 20.3.
► If the battery still cannot be found with
the STIHL connected app: contact a
STIHL authorized dealer for assistance.
19.2 Product Support and Assis‐
tance on Use
Product support and assistance on use are avail‐
able from STIHL servicing dealers.
For contacts and other information, please visit
https://support.stihl.com or www.stihl.com.
20 Specifications
20.1 STIHL HLA 135, HLA 135 K
long-reach hedge trimmer
HLA 135
–Permitted batteries:
–STIHL AP
–STIHL AR
–Weight without battery: 5.6 kg
English 20 Specifications
18 0458-683-0121-B

–Degree of electrical protection: IPX4 (protec‐
tion against splash water from any direction)
HLA 135 K
–Permitted batteries:
–STIHL AP
–STIHL AR
–Weight without battery: 5.2 kg
–Degree of electrical protection: IPX4 (protec‐
tion against splash water from any direction)
The running time is shown at www.stihl.com/
battery-life.
20.2 Cutting blades
HLA 135
–Tooth spacing: 34 mm
–Cutting length: 600 mm
–Sharpening angle: 45°
HLA 135 K
–Tooth spacing: 34 mm
–Cutting length: 600 mm
–Sharpening angle: 45°
20.3 STIHL AP battery
–Battery technology: lithium-ion
–Voltage: 36 V
–Capacity in Ah: see rating label
–Energy content in Wh: see rating label
–Weight in kg: see rating label
–Permissible temperature range for operation
and storage: + 10 °C to + 50 °C
–Bluetooth® radio interface (only for batteries
with ):
–Data connection: Bluetooth® 5.1. The
mobile appliance must be compatible with
Bluetooth® Low Energy 5.0 and support
Generic Access Profile (GAP).
–Frequency band: ISM band 2.4 GHz
–Maximum RF power transmitted: 1 mW
–Signal range: approx. 10 m. The signal
strength depends on the ambient conditions
and the mobile terminal. Signal range can
vary greatly depending on local conditions,
including the receiver. The range may be
perceptibly reduced inside enclosed rooms
and through metal barriers (such as walls,
shelves or cases).
–Mobile appliance operating system require‐
ments: Android or iOS (current version or
higher)
20.4 Sound Values and Vibration
Values
The K-value for sound pressure levels is 2 dB(A).
K-value for sound power levels is 2 dB(A). The
K-value for vibration levels is 2 m/s².
HLA 135
STIHL recommends wearing ear defenders.
–Sound pressure level LpA measured according
to ISO 22868: 85 dB(A)
–Sound power level LwA measured according to
ISO 22868: 96 dB(A)
–Vibration level ahv measured according to
ISO 22867, with handle hose
– – Control handle: 3.3 m/s²
–Handle hose: 2.5 m/s²
–Vibration level ahv measured according to
ISO 22867, with loop handle
––Control handle: 2.5 m/s²
–Loop handle: 3.7 m/s²
HLA 135 K
STIHL recommends wearing ear defenders.
–Sound pressure level LpA measured according
to ISO 22868: 85 dB(A)
–Sound power level LwA measured according to
ISO 22868: 96 dB(A)
–Vibration level ahv measured according to
ISO 22867
–Control handle: 2.7 m/s²
–Handle hose: 2.3 m/s²
The vibration levels indicated were measured
according to a standardized test method and can
be used as a basis for comparing electric power
tools. The vibration levels actually occurring may
vary from the values indicated, depending on the
type of application. The vibration levels indicated
can be used for an initial estimate of the vibration
stress. The actual vibration stress has to be esti‐
mated. The times when the electric power tool is
switched off and the times when it is switched on
but running under no load can be taken into
account in the estimate.
For information on compliance with Employers'
Vibration Directive 2002/44/EC see
www.stihl.com/vib.
20.5 REACH
REACH is an EC regulation and stands for the
Registration, Evaluation, Authorisation and
Restriction of Chemical substances.
20 Specifications English
0458-683-0121-B 19

For information on compliance with the REACH
regulation see www.stihl.com/reach.
21 Combinations of Carrying
Systems
21.1 Combinations of Carrying Sys‐
tems
The long-reach hedge trimmer must be used
only in combination with a carrying system.
Approved carrying systems are listed in this User
Manual:
Shoulder strap
Full harness
STIHL AR battery together with the
support cushion
Battery belt with strap and attached
“AP belt bag with connecting cable”
together with the support cushion
Battery belt with attached “AP belt bag
with connecting cable” together with
the shoulder strap
Carrying system with built-in “AP belt
bag with connecting cable” together
with the support cushion
RTS backpack carrying system
22 Spare Parts and Accesso‐
ries
22.1 Spare parts and accessories
These symbols indicate original STIHL
spare parts and original STIHL acces‐
sories.
STIHL recommends the use of original STIHL
spare parts and accessories.
Despite ongoing market observation, STIHL is
unable to judge the reliability, safety and suitabil‐
ity of other manufacturers' spare parts and
accessories; accordingly, STIHL cannot warrant
for the use of those parts.
Original STIHL spare parts and original STIHL
accessories are available from STIHL dealers.
23 Disposal
23.1 Disposing of the Hedge Trim‐
mer and Battery
Contact the local authorities or your STIHL
dealer for information on disposal.
Improper disposal can be harmful to health and
pollute the environment.
► Take STIHL products including packaging to a
suitable collection point for recycling in accord‐
ance with local regulations.
► Do not dispose with domestic waste.
24 EC Declaration of Con‐
formity
24.1 STIHL HLA 135, HLA 135 K
long-reach hedge trimmer
ANDREAS STIHL AG & Co. KG
Badstraße 115
D-71336 Waiblingen
Germany
declare under our sole responsibility that
–Category: Cordless long-reach hedge trimmer
–Manufacturer's brand: STIHL
–Model: HLA 135, HLA 135 K
–Serial identification: HA04
conforms to the relevant provisions of Directives
2011/65/EU, 2006/42/EC, 2014/30/EU and
2000/14/EC and has been developed and manu‐
factured in compliance with the following stand‐
ards in the versions valid on the date of produc‐
tion: EN 55014-1, EN 55014-2, EN 62841-1 and
EN 62841-4-2.
Applied conformity assessment procedure in
accordance with Directive 2000/14/EC, Annex V.
–Measured sound power level: 96 dB(A)
–Guaranteed sound power level: 98 dB(A)
The technical documents are stored at
ANDREAS STIHL AG & Co. KG Produktzulas‐
sung.
The year of manufacture, country of manufacture
and serial number are shown on the long-reach
hedge trimmer.
Done at Waiblingen, 15.07.2021
ANDREAS STIHL AG & Co. KG
English 21 Combinations of Carrying Systems
20 0458-683-0121-B
