Stirling D80D20EL-Y4 User manual

INSTRUCTION MANUAL
AFTER SALES SUPPORT
AUS Hotline Costs
1300 886 649 [email protected]
AUS
MODEL: D80D20EL-Y4 PRODUCT CODE:3158 08/2014
N13275
Model Number D80D20EL-Y4
20L Microwave Oven with Grill

AFTER SALES SUPPORT
AUS Hotline Costs
1300 886 649 [email protected]
AUS
MODEL: D80D20EL-Y4 PRODUCT CODE:3158 08/2014
Contents
01 Warranty Details
02 Welcome
03 General Safety Instructions
06 Product Overview
08 Getting Started
12 Instructions
17 Other Useful Information
20 Recipes
25 Repair and Refurbished Goods or Parts Notice

1
AFTER SALES SUPPORT
AUS Hotline Costs
1300 886 649 [email protected]
AUS
MODEL: D80D20EL-Y4 PRODUCT CODE:3158 08/2014
20L Microwave Oven with Grill
Warranty Details
The product is guaranteed to be free from defects in workmanship and parts
for a period of 36 months from the date of purchase. Defects that occur
within this warranty period, under normal use and care, will be repaired,
replaced or refunded at our discretion, solely at our option with no charge for
parts and labour. The benefits conferred by this warranty are in addition
to all rights and remedies in respect of the product that the consumer
has under the Competition and Consumer Act 2010 and similar state and
territory laws.
Our goods come with guarantees that cannot be excluded under the
Australian Consumer Law. You are entitled to a replacement or refund for
a major failure and to compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired or
replaced if the goods fail to be of acceptable quality and the failure does
not amount to a major failure.
YEAR WARRANTY
3

2
AFTER SALES SUPPORT
AUS Hotline Costs
1300 886 649 [email protected]
AUS
MODEL: D80D20EL-Y4 PRODUCT CODE:3158 08/2014
Welcome
Congratulations on choosing to buy a STIRLING®product.
All products brought to you by STIRLING®are manufactured to the highest
standards of performance and safety and, as part of our philosophy of customer
service and satisfaction, are backed by our comprehensive 3 Year Warranty. We
hope you will enjoy using your purchase for many years to come.

3
AFTER SALES SUPPORT
AUS Hotline Costs
1300 886 649 [email protected]
AUS
MODEL: D80D20EL-Y4 PRODUCT CODE:3158 08/2014
General Safety Instructions
Read this manual thoroughly before first use. The safety precautions enclosed
herein reduce the risk of fire, electric shock and injury when correctly adhered to.
Keep the manual in a safe place for future reference, along with the completed
warranty card, purchase receipt and carton. Note the product serial number
on this manual, so you always have it ready at hand. If applicable, pass these
instructions on to the next owner of the appliance.
Always follow basic safety precautions and accident prevention measures when
using an electrical appliance, including the following:
Precautions to avoid possible exposure to excessive microwave energy
• Do not tamper with the safety locking mechanism, and do not attempt to use
the microwave oven with the door open. The door needs to be tightly shut to
prevent harmful exposure to microwave energy.
• Do not allow any object to prevent the door from closing. Also, do not allow
cleaner residue to accumulate on sealing surfaces.
• Do not use the oven if it is damaged. It is particularly important that there is no
damage to the oven door (bent, warped or otherwise damaged), hinges and
latches (broken or loosened), door seals and sealing surfaces.
• WARNING:Do not attempt to repair the oven or adjust it yourself. Any
repair or service must only be carried out by suitably qualified
personnel. It is hazardous for anyone else to remove a cover
which protects against microwave energy exposure.
Precautions to avoid the risk of fire in the microwave interior
• If you detect smoke, switch the oven off immediately, unplug it, and keep the
door closed in order to stifle any flames.
• Keep an eye on the microwave oven when heating food in plastic or paper
containers as these could ignite.
• WARNING:Do not heat food in sealed containers as they could explode.
• Do not leave paper products, cooking utensils, or food in the interior, and do
not use the oven for storage purposes when it is not in use.
• Remove wire twist ties from paper or plastic bags before placing them in the
microwave oven.
• Do not use corrosive chemicals in this appliance.
• Do not use the oven when it is empty.

4
AFTER SALES SUPPORT
AUS Hotline Costs
1300 886 649 [email protected]
AUS
MODEL: D80D20EL-Y4 PRODUCT CODE:3158 08/2014
General Safety Instructions (Cont.)
Electrical safety and cord handling
• Voltage: Make sure that your outlet voltage and circuit frequency correspond
to the voltage stated on the appliance rating plate.
• Safety switch: The installation of a residual current device (safety switch) is
recommended to provide additional safety protection when using electrical
appliances. It is advisable that a safety switch with a rated residual operating
current not exceeding 30mA be installed in the electrical circuit supplying the
appliance. See your electrician for professional advice.
• Wall outlet: The socket must be readily accessible so that you can easily
unplug the microwave oven in an emergency.
• Electrical safety: Do not insert any objects into the appliance.
• Power cord: Do not kink or damage the power cord. Do not let it hang over
the edge of a table or benchtop, and do not let it touch hot or sharp surfaces.
Make sure the cord does not run under the microwave oven. Run it so that
there will be no risk of anyone pulling it inadvertently or tripping over it.
• Disconnect: Switch the appliance off and unplug it from the power supply
after use and before cleaning, servicing, or moving it. When disconnecting, do
not pull the cord. Grip the plug and pull it gently out of the outlet.
• WARNING: Do not immerse! To reduce the risk of electrocution and other
electrical hazards, do not immerse the cord or plug in water, do not spill liquids
into the oven, and do not operate it with wet hands.
• Damage: Do not operate this appliance if it has a damaged cord or plug, if it is
not working properly, or if it has been damaged or dropped.
• Repair: If the appliance and/or its supply cord are damaged, it must be
replaced by the manufacturer, its service agent or a similarly qualified person
in order to avoid a hazard. Do not attempt to repair, disassemble, or modify
the appliance. There are no user-serviceable parts contained within.
Usage conditions and restrictions
• Intended use: This appliance is intended for indoor domestic use only.
Do not use the appliance outdoors. Appropriate domestic settings include
households, staff kitchen areas, shops, offices, farm houses and other
working environments, use by clients in hotels, motels, bed and breakfast
establishments and other residential type environments.
• Purpose: This microwave oven is specifically designed to heat, cook or dry
food in a domestic environment. It is not designed for industrial or laboratory
use. Do not use the appliance for anything other than its intended purpose.

5
AFTER SALES SUPPORT
AUS Hotline Costs
1300 886 649 [email protected]
AUS
MODEL: D80D20EL-Y4 PRODUCT CODE:3158 08/2014
General Safety Instructions (Cont.)
• Usage restrictions: The appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or lack of experi-
ence and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
• Children: Young children should be supervised to ensure they do not play with
the appliance. Only allow children to use the oven without supervision when
adequate instructions have been given so that the child is able to use the oven
in a safe way and understands the hazards of improper use.
• Cleaning: Maintain the oven in a clean condition to avoid surface
deterioration, which could affect its working life and result in a hazard risk.
Clean the oven regularly and remove food residues from door seals, cavities
and adjacent parts.
• Appropriate installation and use: Improper installation or the use of
accessories not recommended in this manual or by the appliance manufacturer
may result in fire, electric shock and/or personal injury. We accept no liability for
any damage due to improper use or incorrect handling.
Grounding/earthing instructions
This appliance must be earthed (grounded). We accept no liability for damage
to the oven or personal injury resulting from failure to observe any electrical
connection procedures. In the event of a malfunction or breakdown, earthing will
reduce the risk of an electric shock by providing a path of least resistance for the
electric current.
The plug must be connected to an appropriate outlet that is installed and earthed
in accordance with all local standards and requirements. If unsure, consult an
electrician or a service representative. Do not, under any circumstances, cut or
remove the third (grounding) prong from the power plug.
It is recommended that a separate circuit be provided for use by the microwave
alone. The wires in the appliance power supply cord are coloured in accordance
as follows: green and yellow = earth; blue = neutral; brown = live.
NOTE: This product is Group 2 Class B ISM equipment. In Group 2 equipment,
radio-frequency energy is intentionally generated and/or used in the form of
electromagnetic radiation. Class B equipment is suitable for use in domestic
establishments and in establishments directly connected to a low voltage power
supply network which supplies buildings used for domestic purposes.

6
AFTER SALES SUPPORT
AUS Hotline Costs
1300 886 649 [email protected]
AUS
MODEL: D80D20EL-Y4 PRODUCT CODE:3158 08/2014
Product Overview
8
9
10
11
56
43
27
1 Door safety lock system
2 Observation window
3 Grill heater
4 Glass tray
5 Roller (beneath the glass tray)
6 Wave guide cover (do not remove)
7 Control panel (described on the opposite page)
8 Function buttons (described on the opposite page)
9 Function dial
10 Door handle
11 Grill rack (for use in grill mode only)
The microwave oven
1

7
AFTER SALES SUPPORT
AUS Hotline Costs
1300 886 649 [email protected]
AUS
MODEL: D80D20EL-Y4 PRODUCT CODE:3158 08/2014
Product Overview (Cont.)
The control panel
MENU ACTION DISPLAY SCREEN
Cooking time, power, action indicators and
clock time are displayed.
POWER LEVEL
This button is used to set the microwave
cooking power level.
GRILL/COMBI.
This button is used to set a grill cooking
program or two combination cooking programs.
WEIGHT DEFROST
This button is used to set a weight based
defrost program.
CLOCK/PRESET
This button is used to select a 12-hour or 24-
hour clock cycle. It is also used to program the
oven for a delayed start time.
PAUSE/CANCEL
This button is used to cancel a setting or reset
the oven before setting a program. It is also
used for setting the child lock.
START/QUICK START (FUNCTION DIAL)
This button is used to start a program and to set
the quick start function.
MENU/TIME/WEIGHT (FUNCTION DIAL)
This dial is used to to set the oven clock time,
input cooking time, and enter the weight or
amount of food. Turning it anticlockwise allows
you to select from the auto-cooking menu.

8
AFTER SALES SUPPORT
AUS Hotline Costs
1300 886 649 [email protected]
AUS
MODEL: D80D20EL-Y4 PRODUCT CODE:3158 08/2014
Getting Started
Before first use
• Unpack the appliance and remove any packing materials from the interior.
Keep all packaging materials until you have made sure your new microwave
oven is undamaged and in good working order. Plastic wrapping can be a
suffocation hazard for babies and young children, so ensure all packaging
materials are out of their reach.
• Unwind the power supply cord to its full length and inspect it for damage.
Then check the microwave oven for any damage, such as a misaligned or bent
door, damaged door seals and sealing surfaces, broken or loose door hinges
and latches, or dents inside the interior or on the door.
WARNING:If there is any damage to the appliance or its cord, do not operate
the microwave oven! Contact our after sales support line.
• Read this manual to familiarise yourself with the parts and operating principles.
Pay particular attention to the safety instructions on the previous pages.
• Wipe the inside surfaces of the microwave oven with a damp cloth. Wash the
glass tray in warm water with a little washing detergent to remove any dust
from transportation, using a soft cloth or sponge. Rinse with clean water and
dry thoroughly.
• The oven may produce fumes or odour when the grill function is first used.
This is due to lubricating oils burning off the heating elements. This is normal
and no cause for concern. It will disappear after a period of use. Ensure
sufficient ventilation.
Installation
• Place the microwave oven on a flat, stable surface which can support the
weight of the oven plus the heaviest foods likely to be cooked in it.
WARNING: Do not place the microwave oven where heat, moisture or high
humidity are generated, or near combustible materials.
Do not place it in a cabinet; it is intended to be used freestanding.
• For correct operation, the microwave oven must have sufficient airflow. Allow
20cm of space above the oven, 10cm at the back and 5cm on both sides. Do
not cover or block any openings on the appliance. Do not remove the feet.
• Place the glass tray's roller in position on the floor of the microwave's interior
with the shaft in the centre. Then fit the glass tray on top of the shaft, making
sure it sits securely in place and can move freely on the roller.
WARNING: Do not operate the appliance without the glass tray, roller and
shaft in their proper positions.

9
AFTER SALES SUPPORT
AUS Hotline Costs
1300 886 649 [email protected]
AUS
MODEL: D80D20EL-Y4 PRODUCT CODE:3158 08/2014
Radio interference
Operation of the microwave oven may interfere with your radio, TV, or similar
equipment. When there is interference, it may be reduced or eliminated by taking
the following measures:
• Cleaning the microwave oven door and sealing surfaces.
• Re-orienting the antenna of the radio or television.
• Relocating the microwave oven with respect to the receiver.
• Moving the microwave oven away from the receiver.
• Plugging the microwave oven into a different power outlet so that the
microwave oven and the receiver are on different branch circuits.
Getting Started (Cont.)
Safe microwave cooking
• Only use utensils that are suitable for use in a microwave oven. See page 10
for a detailed list of suitable cookware.
• WARNING: Never heat food in sealed containers as they may explode.
• CAUTION: Hot! Use pot holders or oven mitts to handle cooking utensils that
have become hot following a cooking process.
• Take care when handling containers with hot drinks, as microwave heating can
result in eruptive boiling.
• WARNING: To avoid burns, stir or shake the contents of feeding bottles and
baby food jars and always check the temperature before serving.
• Do not attempt to fry food in the oven, as hot oil can damage oven parts and
utensils, or cause skin burns.
• Do not heat eggs in their shell or whole hard-boiled eggs, as they may
explode, even after microwave heating has ended.
Safe grill / combination cooking
• Take care when using the oven in combination or grill mode as the inside and
parts become hot during use.
• Wear oven mitts when handling food and touching any part of the oven that
has become hot during use.
• The provided grill rack is specially designed for use in the microwave oven in
grilling mode only so that it can be used without creating a hazard. However,
other metallic items, and items which appear metallic, should not be placed in
the microwave.

10
AFTER SALES SUPPORT
AUS Hotline Costs
1300 886 649 [email protected]
AUS
MODEL: D80D20EL-Y4 PRODUCT CODE:3158 08/2014
Getting Started (Cont.)
Microwave cookware guide
• Cookware used for microwaving must be microwave safe. Use the table below
to help you select the right cookware and utensils for use in the oven.
Cookware Microwave Grill Combination
Heat-resistant glass Yes Yes Yes
Non heat-resistant glass No No No
Heat-resistant ceramics Yes Yes Yes
Microwave safe plastic Yes No No
Kitchen paper Yes No No
Metal tray or metal rack No Yes No
Aluminum foil or container No Yes No
• We recommend round/oval dishes for microwave cooking rather than square/
oblong ones, as food in the corners of a container tends to overcook.
• Microwaves cannot penetrate metal, so do not use any cookware made of
or containing metal, such as dishes with a metallic trim, metal racks, trays
or utensils, aluminium foil, or foil containers. The provided metal rack is
specially designed for this microwave when used in grill mode. Do not
use the rack in microwave or combination mode!
• Do not use recycled paper products when microwave cooking, as they may
contain small metal fragments which may cause sparks and/or fires.
• You may wrap narrow strips of aluminium foil around parts of the food to
prevent overcooking of exposed areas. However, take care not to use too
much foil, and keep a distance of 3cm between the foil and the interior wall.
• Cover the food, but not tightly, as some ventilation is necessary for even heating.
Microwave cooking principles
• Watch the cooking time. Cook for the shortest amount of time indicated and
add more time as needed. Severely overcooked food can smoke or ignite.
• Cover the food, but not tightly, to prevent spattering and help food cook evenly.
• Turn foods over once during microwaving to speed up the cooking time for
smaller pieces of food. Large pieces must be turned over at least once.
• Arrange the food so the thickest parts are towards the outside of the dish.
• Pierce foods with nonporous skins such as potatoes, squash, apples,
chestnuts or sausages before cooking.
NOTE: Once the microwave oven has stopped cooking, the fan inside will still
run to cool the oven. It will stop automatically.

11
AFTER SALES SUPPORT
AUS Hotline Costs
1300 886 649 [email protected]
AUS
MODEL: D80D20EL-Y4 PRODUCT CODE:3158 08/2014
Getting Started (Cont.)
Setting the clock
This microwave oven has a 12 or 24-hour clock.
• To set the desired clock cycle (12 or 24 hours), press the CLOCK/PRESET
button once or twice.
• To set the microwave oven clock time, turn the MENU/TIME/WEIGHT dial
to set the desired hour. Press the CLOCK/PRESET button again, then turn the
MENU/TIME/WEIGHT dial again to set the desired minutes. Press the CLOCK/
PRESET button again to confirm the setting.
• To check the time during cooking, press the CLOCK/PRESET button.
Setting microwave controls
• Each time a button is pressed, a beep will sound to acknowledge the action.
• Two beeps indicate that the oven does not accept the entry. Please check
and try again.
• At the end of a set cooking program, the oven will beep several times and
"End" will appear on the screen. It will keep beeping until you open the door
or press PAUSE/CANCEL to reset.
Quick start
This is a convenient setting for heating food quickly at full microwave power.
• To set the cooking time, press the START/QUICK START dial repeatedly. The
oven will automatically start working at full power.
• To extend the cooking time during cooking, press the START/QUICK START
dial. Each press adds 30 seconds up to a maximum of 10 minutes.
Child safety lock
The child safety lock prevents unsupervised operation by young children. Once
set, the lock indicator will appear on the display and the oven cannot be operated.
• To set the child safety lock, press and hold the PAUSE/CANCEL button
for four seconds: a beep will sound and the lock indicator will appear on the
display. In locked state, all buttons are disabled.
• To cancel the child safety lock, press and hold the PAUSE/CANCEL button
for four seconds: a beep will sound and the lock indicator will go off.
Stopping the oven during operation
• To pause the oven during operation, press the PAUSE/CANCEL button.

12
AFTER SALES SUPPORT
AUS Hotline Costs
1300 886 649 [email protected]
AUS
MODEL: D80D20EL-Y4 PRODUCT CODE:3158 08/2014
Instructions
Microwave cooking
Microwave cooking allows you to customise cooking power and time. First, select
a power level by pressing the POWER LEVEL button a number of times (see the
table below). Then set the cooking time (maximum 95 minutes), using the MENU/
TIME/WEIGHT dial, before pressing the START/QUICK START button.
Press POWER LEVEL Power Cooking Power
Once 100% High
Twice 80% Med. High
3 times 60% Medium
4 times 40% Med. Low
5 times 20% Low
Example: To cook for food for 5 minutes at 60% of the microwave's full power:
• Press POWER LEVEL three times until 60% is shown on the display.
• Turn the MENU/TIME/WEIGHT dial to 5:00.
• Press START/QUICK START to begin.
NOTE:
• Press POWER LEVEL check the present cooking power during cooking.
• Microwave safe cookware must be used for microwave cooking.
Auto cooking
This microwave oven has several preset cooking settings for cooking particular
types and quantities of food automatically, without the need for setting cooking
time or power level. Just select the type of food (popcorn, coffee/beverage, fresh
vegetables, potato, pizza, reheat, grilled chicken, and grilled steak) and enter its
weight. You may need to turn the food over during the process to ensure even
cooking. Details of each program are in the table below and on the next page.
NOTE: The results of auto cooking depend on factors such as fluctuations of
voltage, the shape and size of the food, your personal cooking preferences, and
even how well you place the food in the oven. Adjust if necessary.
To set an auto cooking program:
• In standby mode, turn the MENU/TIME/WEIGHT dial anticlockwise to select
the code. An icon will light up on the menu action screen to show which food
is represented by each code. Press the dial (START/QUICK START) to confirm.
• Turn the MENU/TIME/WEIGHT dial to select the weight or amount of food.
• Press the dial (START/QUICK START) to begin.

13
AFTER SALES SUPPORT
AUS Hotline Costs
1300 886 649 [email protected]
AUS
MODEL: D80D20EL-Y4 PRODUCT CODE:3158 08/2014
Instructions (Cont.)
Code Food Weight (g) Display Function/
Power
Cooking Time
(min:sec)
A01 Popcorn 99 99 Microwave
100%
2:30
A02 Coffee/Beverage
(200ml/cup)
200 1
Microwave
100%
1:30
400 2 2:40
600 3 3:50
A03 Fresh Vegetable
100 100
Microwave
100%
3:00
200 200 4:00
300 300 5:00
400 400 6:00
500 500 7:00
A04 Potato
230 1
Microwave
100%
5:00
460 2 9:00
690 3 13:00
A05 Pizza
150 150
Microwave
100%
0:50
300 300 1:20
450 450 1:50
A06 Reheat
200 200
Microwave
100%
1:30
300 300 2:00
400 400 2:30
500 500 3:00
600 600 3:30
700 700 4:00
800 800 4:30
A07 Grilled Chicken
(see note below)
800 800
Combi 2
33:00
1000 1000 36:00
1200 1200 39:00
1400 1400 42:00
A08 Grilled Steaks
(see note below)
100 100
Combi 1
9:00
200 200 12:00
300 300 15:00
400 400 18:00
500 500 21:00
Auto cooking menu
NOTE: The oven will beep during this program, and pause to remind you to turn food over. Press START/QUICK
START to resume cooking.

14
AFTER SALES SUPPORT
AUS Hotline Costs
1300 886 649 [email protected]
AUS
MODEL: D80D20EL-Y4 PRODUCT CODE:3158 08/2014
Instructions (Cont.)
Grill cooking
A grill element inside the oven allows you to grill meat (such as steaks, chops,
kebabs, sausages), smaller pieces of chicken, fish fillets or vegetables suitable
for grilling. This function is also suitable for preparing grilled sandwiches and
snacks with a crumbed or grated cheese topping. The heat setting for grill
cooking is automatic. You only need to program the time (maximum grilling time
is 95 minutes).
Example: To program grill cooking for 12 minutes:
• Press the GRILL/COMBI button once. The display screen will show 1S and the
grill icon.
• Turn the MENU/TIME/WEIGHT dial to enter 12:00.
• Press START/QUICK START once for the grill program to start. It will stop after
the set time.
NOTE: The supplied metal grill rack may be used for grill cooking.
Weight defrost
The microwave oven is perfect for easy defrosting of frozen meat, poultry,
seafood or ready cooked frozen food. Just enter the weight of the frozen food
you want to defrost (between 100g and 1800g); the defrosting time and power
level are automatically set.
Example: To defrost 500g of frozen mince:
• Press the WEIGHT DEFROST button once. The display screen will show 1S,
100g, and the defrost icon.
• Rotate the MENU/TIME/WEIGHT dial to select 500g.
• Press START/QUICK START to begin.
NOTE:
• The defrost process is divided into three stages, each stage taking up
one third of the defrosting time. After two thirds of the defrosting time, the
microwave oven will pause and beep to remind you to turn the food over (or to
remove parts of the food that are already defrosted). Press the START/QUICK
START dial to resume the defrosting.
• Microwave safe cookware must be used for microwave defrosting.

15
AFTER SALES SUPPORT
AUS Hotline Costs
1300 886 649 [email protected]
AUS
MODEL: D80D20EL-Y4 PRODUCT CODE:3158 08/2014
Instructions (Cont.)
Combination cooking
This feature allows you to combine grill with microwave cooking on two
different settings. The two options divide the cooking time into stages, so that
a percentage of the cooking time is devoted to microwave cooking and the
remaining percentage is spent grilling.
Press
GRILL/COMBI
Display Microwave Grill
1× 1S 0% 100%
2× 1S, CO-1 30% 70%
3× 1S, CO-2 55% 45%
Combination 1 (30% microwave, 70% grill)
The Combination 1 setting is particularly suitable for food that you want cooked
through fast and crispy on top: fish, for example, or au gratin dishes. On this
setting 30% of the total cooking time is devoted to microwave cooking and the
remaining 70% is spent grilling.
Example: To set the oven to cook with COMBINATION 1 for 12 minutes.
• Press GRILL/COMBI twice. The code 1S, CO-1 will appear on the screen.
• Turn the MENU/TIME/WEIGHT dial to enter 12:00.
• Press START/QUICK START to begin.
Combination 2 (55% microwave, 45% grill)
The Combination 2 setting is particularly suitable for cooking pudding, omelettes,
baked potatoes or poultry – food that needs proportionally longer microwave
cooking than on the other combination setting. On this setting 55% of the total
cooking time is devoted to microwave cooking and the remaining 45% to grilling.
Example: To set the oven to cook with COMBINATION 2 for 25 minutes.
• Press GRILL/COMBI 3 times. The code 1S, CO-2 will show on the screen.
• Turn the MENU/TIME/WEIGHT dial to enter 25:00.
• Press START/QUICK START to begin.
NOTE:
• The maximum cooking time is 95 minutes.
• The cookware used for combination cooking must be microwave safe and
ovenproof.

16
AFTER SALES SUPPORT
AUS Hotline Costs
1300 886 649 [email protected]
AUS
MODEL: D80D20EL-Y4 PRODUCT CODE:3158 08/2014
Instructions (Cont.)
Preset cooking (timer function)
The preset timer allows you to program the oven to start cooking at a later time.
NOTE: To use this preset timer, the clock must be set to the correct time.
Example: To set the oven to start up at 11:30 at 80% power:
• Place food in the oven and close the door.
• Press the POWER LEVEL button twice so that 80% is selected.
• Rotate the MENU/TIME/WEIGHT dial to input the cooking time.
• Press the CLOCK/PRESET button once.
• Rotate the MENU/TIME/WEIGHT dial to input the hour: 11.
• Press the CLOCK/PRESET button.
• Rotate the MENU/TIME/WEIGHT to input the minutes: 30.
• Press START/QUICK START to confirm. The oven will start cooking at 11:30.
• To cancel the operation after it has begun, press CLOCK/PRESET, then press
PAUSE/CANCEL.
Multistage cooking
Some recipes may require more than one type of cooking. Your oven can be set
to change from one program to another automatically, for up to three sequences.
The following example shows the steps involved in setting up such a program.
Example: To set the oven for a microwave cooking program followed by a grill
cooking program, and then a combination 1 program:
• Input a microwave cooking program without pressing START/QUICK START.
• Input a grill program without pressing START/QUICK START.
• Input a Combination 1 cooking program.
• Press START/QUICK START.
NOTE:
• Quick start, Weight defrost and Auto cook cannot be set in a multistage
cooking program.
• The respective lights (1S, 2S, and 3S) will appear on the menu action screen to
show which stage the oven is operating in.
• Microwave safe cookware must be used for multistage cooking.

17
AFTER SALES SUPPORT
AUS Hotline Costs
1300 886 649 [email protected]
AUS
MODEL: D80D20EL-Y4 PRODUCT CODE:3158 08/2014
Cleaning and care
CAUTION: Before cleaning or maintenance, make sure to turn off the microwave
oven and disconnect the plug from the wall socket. Also make sure the oven has
cooled sufficiently before cleaning as the sides of a combination oven may get
hot during use.
• Keep the inside of the microwave oven clean. When food splatters or liquids
spill and adhere to the microwave oven ceiling and walls, wipe them with a
damp cloth. Mild detergent may be used if the microwave oven is very dirty.
Avoid the use of caustic, abrasive or other harsh cleaners as they may stain,
streak or dull the door surface.
• CAUTION: To prevent damage to the operating parts inside the microwave
oven, do not let water seep into the ventilation openings. Clean the outside
surfaces with a damp cloth only.
• When cleaning the control panel, leave the microwave oven door open to
prevent the microwave oven from turning on.
• Wipe the door and window, the door seals and adjacent parts with a damp
cloth to remove any spills. Do not use abrasive cleaners.
• Do not allow the control panel to become wet. Clean it with a soft, damp cloth.
• If steam accumulates inside or around the outside of the microwave oven
door, wipe it with a soft cloth. This is normal and may occur when the
microwave oven is operated under high humidity conditions.
• It is occasionally necessary to remove the glass tray for cleaning. Wash it in
warm, sudsy water, or in a dishwasher.
• To avoid excessive noise, wipe the roller and microwave floor regularly with
a damp cloth. When removing the glass tray's roller from the interior floor for
cleaning, be sure to replace it afterwards in the proper position on the shaft.
• To remove persistent odours from your microwave oven, combine a cup of
water with the juice and skin of one lemon in a deep microwavable bowl and
microwave for five minutes. Then wipe the oven thoroughly and dry with a soft
cloth.
• Make sure to clean your microwave oven regularly and remove any food
residues. Failure to maintain the microwave in a clean condition could lead
to deterioration of the surface, which could adversely affect the life of the
appliance and could present a potential hazard.
Other Useful Information

18
AFTER SALES SUPPORT
AUS Hotline Costs
1300 886 649 [email protected]
AUS
MODEL: D80D20EL-Y4 PRODUCT CODE:3158 08/2014
Troubleshooting guide
If you encounter problems with your microwave oven, check the issues raised
below to see whether your problem can be solved easily without a service call.
• Check to ensure that the microwave oven is plugged in securely. If it is
not, remove the plug from the outlet, wait 10 seconds, and plug it in again
securely.
• Check for a blown circuit fuse or a tripped circuit breaker. If these seem to be
operating properly, test the outlet with another appliance.
• Check to ensure that the control panel is programmed correctly.
• Check to ensure that the door is securely closed and the door safety lock
system is engaged. Otherwise, the microwave energy will not flow into the
oven.
• If it becomes necessary to replace the microwave light, consult a qualified
electrician to have it replaced or contact the after sales support line for
assistance.
If none of the solutions offered on this page help you solve the problem, then
contact a qualified technician or our after sales support line for advice on
examination, repair or return of the product.
WARNING: DANGER!
Do not try to adjust or repair the microwave oven yourself. This appliance
has no user-serviceable parts contained within. Do not attempt to repair,
disassemble or modify the appliance. Do not try to adjust or repair the
microwave oven yourself. Do not attempt to take the appliance apart.
Other Useful Information (Cont.)
