Stirling D90N30ASLR-T4-H User manual

INSTRUCTION MANUAL
Model Number D90N30ASLR-T4-H
30L Microwave Oven
with Grill and Convection
IM Version No: V1.0 Issue Date: 26 November 2014
N13275
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: D90N30ASLR-T4-H PRODUCT CODE:49023 05/2015

2
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: D90N30ASLR-T4-H PRODUCT CODE: 49023 05/2015
Welcome
Congratulations on choosing to buy a STIRLING®product.
All products brought to you by STIRLING®are manufactured to the highest
standards of performance and safety and, as part of our philosophy of customer
service and satisfaction, are backed by our comprehensive 3 Year Warranty. We
hope you will enjoy using your purchase for many years to come.

3
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: D90N30ASLR-T4-H PRODUCT CODE: 49023 05/2015
Contents
02 Welcome
04 Warranty Details
05 General Safety Instructions
08 Product Overview
10 Getting Started
13 Instructions
21 Other Useful Information
25 Recipes
31 Repair and Refurbished Goods or Parts Notice

4
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: D90N30ASLR-T4-H PRODUCT CODE: 49023 05/2015
30L Microwave Oven
with Grill and Convection
Warranty Details
The product is guaranteed to be free from defects in workmanship and parts
for a period of 36 months from the date of purchase. Defects that occur
within this warranty period, under normal use and care, will be repaired,
replaced or refunded at our discretion, solely at our option with no charge for
parts and labour. The benefits conferred by this warranty are in addition
to all rights and remedies in respect of the product that the consumer
has under the Competition and Consumer Act 2010 and similar state and
territory laws.
Our goods come with guarantees that cannot be excluded under the
Australian Consumer Law. You are entitled to a replacement or refund for
a major failure and to compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired or
replaced if the goods fail to be of acceptable quality and the failure does
not amount to a major failure.
YEAR WARRANTY
3

5
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: D90N30ASLR-T4-H PRODUCT CODE: 49023 05/2015
General Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
Read this manual thoroughly before first use. The safety precautions enclosed
herein reduce the risk of fire, electric shock and injury when correctly adhered to.
Keep the manual in a safe place for future reference, along with the completed
warranty card, purchase receipt and carton. Note the product serial number
on this manual, so you always have it ready at hand. If applicable, pass these
instructions on to the next owner of the appliance.
Always follow basic safety precautions and accident prevention measures
when using an electrical appliance, including the following:
Precautions to avoid possible exposure to excessive microwave energy
• DO NOT tamper with the safety locking mechanism, and do not attempt to use
the microwave oven with the door open. The door needs to be tightly shut to
prevent harmful exposure to microwave energy.
• DO NOT allow any object to prevent the door from closing. Also, do not allow
cleaner residue to accumulate on sealing surfaces.
• DO NOT use the oven if it is damaged. It is particularly important that there is
no damage to the oven door (bent, warped or otherwise damaged), hinges and
latches (broken or loosened), door seals and sealing surfaces.
• WARNING: If the door or door seals are damaged, the oven must not be
operated until it has been repaired by a competent person.
• WARNING:DO NOT attempt to repair the oven or adjust it yourself. Any
repair or service must only be carried out by suitably qualified personnel. It is
hazardous for anyone else to remove a cover which protects against exposure
to microwave energy.
Precautions to avoid the risk of fire in the microwave interior
• Keep an eye on the microwave oven when heating food in plastic or paper
containers as these could ignite.
• If you detect smoke, switch the oven off immediately, unplug it and keep the
door closed in order to stifle any flames.
• Remove wire twist ties from paper or plastic bags before placing them in the
microwave oven.
• Do not leave paper products, cooking utensils, or food in the interior, and do
not use the oven for storage purposes when it is not in use.
• WARNING: Do not heat food in sealed containers as they could explode.
• Do not use corrosive chemicals in this appliance.
• Do not use the oven when it is empty.

6
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: D90N30ASLR-T4-H PRODUCT CODE: 49023 05/2015
General Safety Instructions (Cont.)
Electrical safety and cord handling
• Voltage: Make sure that your outlet voltage and circuit frequency correspond
to the voltage stated on the appliance rating plate.
• Power outlet: Connect the appliance to a properly earthed power outlet,
which must be readily accessible so that you can easily unplug it if necessary.
• Power cord: Do not kink or damage the power cord. Do not let it hang over
the edge of a table or benchtop, and do not let it touch hot or sharp surfaces.
Make sure the cord does not run under the microwave oven. Run it so that
there will be no risk of anyone pulling it inadvertently or tripping over it.
• Electrical safety: Do not insert any objects into the appliance.
• WARNING: Protect from moisture: To reduce the risk of electrocution and
other electrical hazards, do not immerse the cord or plug in water, do not spill
liquids into the oven, and do not operate it with wet hands.
• WARNING: Damage:DO NOT operate this appliance if it has a damaged cord
or plug, if it is not working properly, or if it has been damaged or dropped. In
case of damage, contact our after sales support line for advice.
• WARNING:If the appliance and/or its supply cord are damaged, it must be
replaced by the manufacturer, its service agent or a similarly qualified person
in order to avoid a hazard. Do not attempt to repair, disassemble, or modify
the appliance. There are no user-serviceable parts contained within.
• Disconnection: Switch the appliance off and unplug it from the power
supply after use and before cleaning, servicing, maintenance, or moving the
appliance. Do not pull the cord when disconnecting, grip the plug and pull it
gently out of the outlet.
• Safety switch: The installation of a residual current device (safety switch) is
recommended to provide additional safety protection when using electrical
appliances. It is advisable that a safety switch with a rated residual operating
current not exceeding 30mA be installed in the electrical circuit supplying the
appliance. See your electrician for professional advice.
Usage conditions and restrictions
• Domestic use only: This appliance is intended for indoor domestic use only,
which includes use in households, staff kitchen areas, shops, offices, farm
houses and in other working environments, use by clients in hotels, motels,
bed and breakfast establishments and other residential type environments.
• Intended use: This microwave oven is specifically designed for heating or
cooking food or beverages in a domestic environment. It is not suitable for
industrial or laboratory use.
• No outdoor use: Do not use the appliance outdoors.

7
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: D90N30ASLR-T4-H PRODUCT CODE: 49023 05/2015
General Safety Instructions (Cont.)
• Inappropriate use: Do not use the appliance for anything other than its intend-
ed purpose. Drying of food or clothing and heating of warming pads, slippers,
sponges, damp cloths and similar items may lead to risk of injury, ignition or fire.
• Usage restrictions The appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or lack of experi-
ence and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
• Children: Young children should be supervised to ensure they do not play with
the appliance. Only allow children to use the oven without supervision when
adequate instructions have been given so that the child is able to use the oven
in a safe way and understands the hazards of improper use.
• Cleaning: Maintain the oven in a clean condition to avoid surface deterioration,
which could affect its working life and result in a hazard risk. Clean the oven
regularly and remove food residues from door seals, cavities and adjacent parts.
• Improper use: Improper installation or use of accessories not recommended in
this manual may result in fire, electric shock and/or personal injury.
• Liability: We accept no liability for any eventual damages due to improper use,
incorrect handling or noncompliance with these instructions.
Safe microwave cooking
• Only use utensils that are suitable for use in a microwave oven.
• WARNING: Never heat food in sealed containers as they may explode.
• CAUTION: Hot! Use pot holders or oven mitts to handle cooking utensils
which have become hot following a cooking process.
• Take care when handling containers with hot drinks, as microwave heating of
beverages can result in delayed eruptive boiling.
• WARNING: To avoid burns, stir or shake the contents of feeding bottles and
baby food jars and always check the temperature before serving.
• Do not attempt to fry food in the oven, as hot oil can damage oven parts and
utensils, or cause skin burns.
• Do not heat eggs in their shell or whole hard-boiled eggs, as they may
explode, even after microwave heating has ended.
• Pierce foods with nonporous skins such as potatoes, whole squash, apples,
chestnuts or sausages before cooking.
Safe convection / grill / combination cooking
• Take care when using the oven in combination, convection or grill mode as
the inside and parts become hot during use. Wear oven mitts when handling
food and touching any part of the oven that has become hot during use.

8
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: D90N30ASLR-T4-H PRODUCT CODE: 49023 05/2015
Product Overview
1 Handle
2 Door latch
3 Oven window
4 Oven air vent
5 Roller ring
6 Glass turntable
7 Shaft
(on the bottom of the cavity)
8 Grill element
9 Baking plate (for use in grill or
convection mode only)
10 Door safety lock system
11 Control panel (see opposite)
1234 5 6 9 8411
710
Do not use the baking plate in
microwave or combination mode!
The microwave oven

9
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: D90N30ASLR-T4-H PRODUCT CODE: 49023 05/2015
Product Overview (Cont.)
• Display window
Indicates clock, cooking time, etc.
• Preset cooking settings
Spaghetti, Reheat, Cake, Pizza, Potato,
Popcorn, Beverage, Skewered Meat.
• Number pads
Use to set the time of day, cooking time,
temperature, etc.
• Micro+Grill
Press to select one of two combination
cooking settings.
• Micro+Convection
Press to select one of four combination
cooking settings.
• Convection
Press to program convection cooking.
• Grill
Press to set a grill cooking program.
• Power
Press to select microwave power level.
• Defrost
Press and enter a time to defrost food.
• Timer/Clock
Use to set the clock and the minute timer.
• Weight Defrost
Press to defrost food by weight.
• Start/Quick Start
Press to start a cooking program, or to
start the oven quickly at full power.
• Cancel
Press to stop a cooking program, or to
clear all previous settings before cooking
starts.
The control panel

10
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: D90N30ASLR-T4-H PRODUCT CODE: 49023 05/2015
Getting Started
Before first use
• Unpack: When unpacking the appliance, make sure to remove any packing
materials from the interior. Keep all packaging materials until you have
made sure your new microwave oven is undamaged and in good working
order. The carton is recyclable. Whenever possible, recycle the carton when
disposing of the packaging materials. Plastic wrapping can be a suffocation
hazard for babies and young children, so ensure all packaging materials are
out of their reach. Dispose of any plastic wrapping safely.
• Inspect: Unwind the power supply cord to its full length and inspect it
for damage. Then check the microwave oven for any damage, such as a
misaligned or bent door, damaged door seals and sealing surfaces, broken
or loose door hinges and latches, dents inside the cavity or on the door.
WARNING: If there is any damage to the appliance or its cord, do not operate
the microwave oven! Contact our after sales support line.
• Read: Read this manual to familiarise yourself with the parts and operating
principles. Pay particular attention to the safety advice on the previous pages.
• Clean: Wipe the inside surfaces of the microwave oven with a damp cloth.
Wash the glass turntable with a soft cloth in warm water and a little dish
detergent to remove any dust from transport. Rinse and dry thoroughly.
Installation
• Position: Place the microwave oven on a flat, stable surface that can support
the weight of the oven plus the heaviest foods likely to be cooked in it.
WARNING: Do not place the microwave oven where heat, moisture or high
humidity are generated, or near combustible materials. Do not place it in a
cabinet; it is intended to be used freestanding.
• Clearances: For correct operation, the microwave oven must have sufficient
airflow. Allow 20cm of space above the oven, 10cm at the back and 5cm
on both sides. Do not cover or block any openings on the appliance. Do not
remove the feet.
• Assembly: Place the roller ring in its position in the cavity base and the shaft
in the centre. Then fit the glass turntable on top of the shaft, making sure it
sits securely in place and can move freely on the roller ring.
WARNING: Do not operate the appliance without the turntable, roller ring
and shaft in their proper positions.
• Power cord: Make sure that the power cord does not run under the oven
and that the socket is readily accessible so it can be easily unplugged in an
emergency.

11
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: D90N30ASLR-T4-H PRODUCT CODE: 49023 05/2015
Radio interference
Operation of the microwave oven can cause interference to your radio, TV
or similar equipment. In such a case, try to reduce or eliminate interference by:
• Cleaning the microwave oven door and seal.
• Re-orienting the antenna of the radio or television.
• Relocating the microwave with respect to the receiver.
• Moving the microwave oven away from the receiver.
• Plugging the microwave oven into a different power outlet so that it and the
receiver are on different branch circuits.
Getting Started (Cont.)
Grounding/earthing instructions
This appliance must be earthed (grounded). We accept no liability for damage
to the oven or personal injury resulting from failure to observe any electrical
connection procedures.
In the event of a malfunction or breakdown, earthing will reduce the risk of an
electric shock by providing a path of least resistance for the electric current.
The plug must be connected to an appropriate outlet that is installed and earthed
in accordance with all local standards and requirements. If unsure, consult an
electrician or a service representative. Do not, under any circumstances, cut or
remove the third (grounding) prong from the power plug.
It is recommended that a separate circuit be provided for use by the microwave
alone. The wires in the appliance power supply cord are coloured in accordance
as follows: green and yellow = earth; blue = neutral; brown = live.
NOTE: This product is Group 2 Class B ISM equipment. In Group 2 equipment,
radio-frequency energy is intentionally generated and/or used in the form
of electromagnetic radiation. Class B equipment is suitable for use in
domestic establishments and in establishments directly connected to
a low voltage power supply network which supplies buildings used for
domestic purposes.
First use
The oven may produce fumes or odour when the grill or convection function is
first used. This is due to lubricating oils burning off the heating elements. It is a
normal phenomenon and no cause for concern. It will disappear after a period of
use. Ensure sufficient ventilation.

12
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: D90N30ASLR-T4-H PRODUCT CODE: 49023 05/2015
Microwave cookware guide
• Cookware used for microwaving must be microwave safe. Use the table
below to help you select the right cookware and utensils for use in the oven.
Getting Started (Cont.)
* Applicable for both “Micro+Grill” and “Micro+Convection” cooking.
Cookware Microwave Grill Convection Combination*
Heat-resistant glass Yes Yes Yes Yes
Non heat-resistant glass No No No No
Heat-resistant ceramics Yes Yes Yes Yes
Microwave-safe plastic Yes No No No
Kitchen paper Yes No No No
Metal tray or metal rack No Ye s Yes No
Aluminium foil or container No Yes Ye s No
• We recommend round/oval dishes for microwave cooking rather than square/
oblong ones, as food in the corners of a container tends to overcook.
• Microwaves cannot penetrate metal, so do not use any cookware made of
or containing metal, such as dishes with a metallic trim, metal racks, trays or
utensils, aluminium foil, or foil containers. The provided metal baking plate
is specially designed for this microwave when used in convection or grill
mode. Do not use the baking plate in microwave or combination mode!
• Do not use recycled paper products when microwave cooking, as they may
contain small metal fragments which may cause sparks and/or fires.
• You may wrap narrow strips of aluminium foil around parts of the food to
prevent overcooking of exposed areas. However, take care not to use too
much foil, and keep a distance of 3cm between the foil and the interior wall.
• Cover the food, but not tightly, as some ventilation is necessary for even heating.
Microwave cooking principles
• Watch the cooking time. Cook for the shortest amount of time indicated and
add more time as needed. Severely overcooked food can smoke or ignite.
• Cover the food, but not tightly, to prevent spattering and help food cook evenly.
• Turn foods over once during microwaving to speed up the cooking time for
smaller pieces of food. Large pieces must be turned over at least once.
• Arrange the food so the thickest parts are towards the outside of the dish.
• Pierce foods with nonporous skins such as potatoes, squash, apples,
chestnuts or sausages before cooking.
NOTE: Once the microwave oven has stopped cooking, the fan inside will still
run to cool the oven. It will stop automatically.

13
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: D90N30ASLR-T4-H PRODUCT CODE: 49023 05/2015
Instructions
Plug the microwave oven into a suitable power point. On first connection to the
power supply, the digital CLOCK (1:00) will be illuminated on the display. You will
have to set it to the correct time.
Setting the clock
This microwave oven has a 12 or 24-hour clock. To set it:
• Press and hold the TIMER/CLOCK pad for 3 seconds to select a 24-hour
clock, or press it again to select a 12-hour clock.
• Use the number pads to enter the correct time (hours and minutes).
• Press the TIMER/CLOCK pad to confirm and display the time.
Quick start
This is a convenient setting for cooking or heating food quickly at full microwave
power.
• Press the START/QUICK START pad in quick succession to set the cooking
time (in 30 second intervals, maximum: 10 minutes). The oven will auto-start
two seconds later.
Minute timer
This microwave oven features a timer that you can set to remind you when to
turn food over, for example, or for any other reason unrelated to cooking.
• Press the TIMER/CLOCK pad once.
• Use the number pads to enter the time to be counted down (seconds/minutes).
• Press the START/QUICK START pad. A buzzer will beep twice when the
countdown ends.
NOTE: The remaining time countdown will be shown for five seconds before the
clock or cooking time will be displayed again.
Stopping the oven during operation
• Press the CANCEL button to pause the microwave oven during operation.
Child safety lock
The child safety lock prevents unsupervised operation by young children.
• To set the child safety lock, press and hold the CANCEL pad for three
seconds: a beep will sound and the indicator light will come on. In locked
state, all pads are disabled. A buzzer will beep when a tab is pressed.
• To cancel the child safety lock, press and hold the CANCEL pad for three
seconds: a beep will sound and the indicator light will go off.

14
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: D90N30ASLR-T4-H PRODUCT CODE: 49023 05/2015
Instructions (Cont.)
Microwave cooking
Microwave cooking allows you to customise cooking power and time. First,
select a power level by pressing the POWER pad a number of times (see the
table below). Then set the cooking time (maximum 99 min. and 99 sec.), using
the numeric pads, before pressing the START/QUICK START pad.
Press POWER Pad Power Level Press POWER Pad Power Level
1x 100% (P-HI) 6x 50% (P-50)
2x 90% (P-90) 7x 40% (P-40)
3x 80% (P-80) 8x 30% (P-30)
4x 70% (P-70) 9x 20% (P-20)
5x 60% (P-60) 10x 10% (P-10)
Example: To cook food for 5 minutes at 60% power level:
• Place food into the microwave oven and close it.
• Press the POWER pad 5 times to set the power level to 60%.
• Press the number pads to enter the cooking time (5:00).
• Press the START/QUICK START pad.
NOTE: You can press the number pads directly to enter the cooking time before
pressing START/QUICK START. The default power is 100%. During the
cooking program, press the POWER pad to check the power level.
NOTE: Microwave safe cookware must be used for microwave cooking.
Grill cooking
A grill element inside the oven allows you to grill meat (such as steaks, chops,
kebabs, sausages), smaller pieces of chicken, fish fillets or vegetables suitable
for grilling. This function is also suitable for preparing grilled sandwiches and
snacks with a crumbed or grated cheese topping.
The heat setting for grill cooking is automatic. You only need to program the
grilling time. The maximum grill cooking time is 99 min., 99 sec.
Example: To program grill cooking for 12 minutes:
• Place food into the oven and close it.
• Press the GRILL pad.
• Press the number pads to enter the cooking time (12:00).
• Press the START/QUICK START pad.
NOTE: The supplied baking plate or ovenproof cookware must be used for grill
cooking.

15
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: D90N30ASLR-T4-H PRODUCT CODE: 49023 05/2015
Instructions (Cont.)
Convection cooking (baking)
During convection cooking, hot air is circulated throughout the oven cavity to
bake food evenly from all sides with a crispy exterior. This setting is suitable for
roasting meat or vegetables and baking cakes or pastries.
The oven can be set to 10 different cooking temperatures. The maximum cooking
time on this setting is 9 hours and 99 minutes (9H:99).
To cook with convection, press the CONVECTION pad once and then press the
number pads to enter the desired convection temperature:
Example: To bake food at 200˚C for 40 minutes:
• Place food into the oven and close it.
• Press the CONVECTION pad.
• Press the number pad 0.
• Use the number pads to enter the cooking time (H:40).
• Press the START/QUICK START pad.
• To check the convection temperature during cooking, press CONVECTION.
Preheating before convection cooking (baking)
The oven can be programmed to combine preheating and convection cooking,
which is useful when baking a cake.
Example: To preheat the oven to 170˚C and then bake for 35 minutes:
• Press the CONVECTION pad.
• Press number pad 7 to set the convection temperature to 170˚C.
• Press START/QUICK START: “PREH” will flash on the display until it reaches the
set temperature.
• Open the door and place the container of food in the centre of the turntable.
• Use the number pads to enter the cooking time (H:35).
• Press the START/QUICK START pad.
NOTE: The supplied baking plate or ovenproof cookware must be used for
convection cooking.
Press Mode
Pad
Number
Pad
Conv.
Temp.
Press Mode
Pad
Number
Pad
Conv.
Temp.
CONVECTION 1 110˚C CONVECTION 6 160˚C
CONVECTION 2 120˚C CONVECTION 7 170˚C
CONVECTION 3 130˚C CONVECTION 8 180˚C
CONVECTION 4 140˚C CONVECTION 9 190˚C
CONVECTION 5 150˚C CONVECTION 0 200˚C

16
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: D90N30ASLR-T4-H PRODUCT CODE: 49023 05/2015
Instructions (Cont.)
Microwave + grill cooking
This feature allows you to combine grill with microwave cooking on two
different settings. First, press this pad once or twice to choose the appropriate
combination setting (as explained below), then enter the desired cooking time
with the number pads (maximum cooking time is 99 min. 99 sec.). After you have
pressed the START/QUICK START pad, the system begins to count down.
To check the temperature during cooking, press the MICRO+GRILL pad.
Select one of the following microwave + grill combination options:
Combination 1 (30% microwave, 70% grill)
The Combination 1 setting is particularly suitable for food that you want cooked
through fast and crispy on top: fish, for example, or au gratin dishes. The
program consists of two different cooking stages: 30% of the total cooking time
is devoted to microwave cooking and the remaining 70% is spent grilling.
Example: To program Combination 1 cooking for 25 minutes:
• Place food into the oven and close it.
• Press the MICRO+GRILL pad once.
• Use the number pads to enter the cooking time (25:00).
• Press the START/QUICK START pad.
Combination 2 (55% microwave, 45% grill)
The Combination 2 setting is particularly suitable for cooking pudding, omelettes,
baked potatoes or poultry – food that needs proportionally longer microwave
cooking than on the other combination setting. The program consists of two
different cooking stages: 55% of the total cooking time is devoted to microwave
cooking and the remaining 45% is spent grilling.
Example: To program Combination 2 cooking for 12 minutes:
• Place food into the oven and close it.
• Press the MICRO+GRILL pad twice.
• Use the number pads to enter the cooking time (12:00).
• Press the START/QUICK START pad.
NOTE: Microwave safe and ovenproof cookware must be used for microwave +
grill combination cooking.
Press Mode Pad Display Microwave Grill
MICRO+GRILL 1× C-1 30% 70%
MICRO+GRILL 2× C-2 55% 45%

17
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: D90N30ASLR-T4-H PRODUCT CODE: 49023 05/2015
Microwave + convection cooking
This oven has four pre-programmed settings that combine both convection heat
and microwave energy for cooking and baking. On these settings, microwaves
cook your food fast while convection heat bakes surfaces crispy all round at the
set temperature. The maximum cooking time is 9 hours and 99 minutes.
These settings are particularly suitable for roasting larger pieces of meat or
baking.
Press the MICRO+CONVECTION pad, then use number pads 1 - 4 to program
the convection temperature as follows, and then use the number pads to enter a
cooking time:
Example: To bake for 25 minutes in microwave + convection mode at 170˚C:
• Place food into the oven and close it.
• Press the MICRO+CONVECTION pad.
• Press number pad 3 to enter the convection temperature.
• Use the number pads to enter the cooking time (H:25).
• Press the START/QUICK START pad to start.
• To check the convection temperature during cooking, press the
MICRO+CONVECTION pad.
Instructions (Cont.)
As microwaves cook food faster than convection heat, we suggest you reduce
cooking times when cooking in combination mode. Start with approximately
two thirds of the time given for a convection oven and add extra time if needed.
Press Mode Pad Press Number Pad Convection Temperature
MICRO+CONVECTION 1 110˚C
MICRO+CONVECTION 2 140˚C
MICRO+CONVECTION 3 170˚C
MICRO+CONVECTION 4 200˚C
NOTE: Microwave safe and ovenproof cookware must be used for microwave +
convection combination cooking.

18
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: D90N30ASLR-T4-H PRODUCT CODE: 49023 05/2015
Instructions (Cont.)
Weight defrost
If you do not know how long it will take to defrost your frozen food, choose the
Weight Defrost setting. This feature automatically sets an appropriate defrosting
cycle once you have entered the weight of the food to be thawed.
As soon as you press the WEIGHT DEFROST button, "100" will appear on the
display. This is the default weight in grams. Press the button again, repeatedly,
until a weight appears that matches your food to be frozen. (The maximum
food quantity that can be defrosted automatically is 1800g; any food package
weighing more must be defrosted using the DEFROST setting.)
Example: To defrost 500g of frozen steak:
• Press the WEIGHT DEFROST pad five times until "500" appears on the
display.
• Press the START/QUICK START pad.
NOTE: During the defrosting program, the microwave oven will pause and sound
a beep tone to remind you to turn food over. To resume the defrosting
after turning the food, press the START/QUICK START pad.
Time defrost
Time defrost lets you customise the defrosting time. You can use it to defrost
food that is not covered by the automatic settings, or for portions that exceed
the maximum weight that can be set for the WEIGHT DEFROST program. Just
press the DEFROST pad and then enter a suitable defrost time.
Example: To defrost frozen food and you know the appropriate defrost time:
• Press the DEFROST pad.
• Use the number pads to enter the defrost time.
• Press the START/QUICK START pad.
NOTE: During the defrosting program, the microwave oven will pause and sound
a beep tone to remind you to turn food over. To resume the defrosting
after turning the food, press the START/QUICK START pad.
NOTE: Microwave safe cookware must be used for microwave defrosting.

19
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: D90N30ASLR-T4-H PRODUCT CODE: 49023 05/2015
Instructions (Cont.)
Auto-Cook Pad Weight Options
Spaghetti 100g, 200g, 300g (Add boiling water before cooking.)
Reheat 200g, 300g, 400g, 500g, 600g, 700g, 800g
Cake 475g only
Pizza 150g, 300g, 450g
Potato (230g each) 1, 2, 3
Popcorn 100g
Beverage (200ml each) 1, 2, 3
Skewered meat 100g, 200g, 300g, 400g, 500g (The oven will stop during
cooking to let you turn the food over. Afterwards, close the
door and press START/QUICK START to resume cooking.)
Multistage cooking
Some recipes may require more than one type of cooking. Your oven can be set
to change from one to another automatically, for up to three sequences. The
following example shows the steps involved in setting up such a program.
Example: To program the oven to start with microwave cooking and then follow
with convection cooking:
• Press the POWER pad to set the power level (see page 14).
• Use the number pads to enter the cooking time.
• Press the CONVECTION pad once.
• Use the number pads to enter the convection temperature.
• Use the number pads to enter the convection cooking time.
• Press the START/QUICK START pad.
NOTE: Logically, the Time Defrost program can only be set in the first stage.
Weight Defrost and Auto-Cook programs cannot be set in a multistage
program.
Auto-cook menu (preset cooking settings)
This microwave oven has several preset cooking settings for cooking particular
types and quantities of food automatically, without the need for setting cooking
time or power level. Just select the type of food (spaghetti, cake, pizza, potato,
popcorn, beverage, skewered meat, or reheat) and enter its weight or quantity.
• To select the weight, press the relevant menu pad once or repeatedly. See
below for programmed weight options, or the next page for program details.
• Press the START/QUICK START pad.
NOTE: Microwave safe cookware must be used for multistage and auto-cooking.

20
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: D90N30ASLR-T4-H PRODUCT CODE: 49023 05/2015
Instructions (Cont.)
Auto-cook menu: program details
Food Press
Pad
Weight
(g) Display Mode and Power Level
Cooking
Time
(mins)
Spaghetti
1x 100 100
Microwave 80%
22:00
2x 200 200 27:00
3x 300 300 32:00
Reheat
1x 200 200
Microwave 100%
1:30
2x 300 300 2:00
3x 400 400 2:30
4x 500 500 3:00
5x 600 600 3:30
6x 700 700 4:00
7x 800 800 4:30
Cake 1x 475 475 Convection 170˚C 42:00
Pizza
1x 150 150
Convection 200˚C
10:00
2x 300 300 12:00
3x 450 450 14:00
Potato
1x 230 1
Microwave 100%
5:00
2x 460 2 8:00
3x 690 3 12:00
Popcorn 1x 100 100 Microwave 100% 3:00
Beverage
1x 200 1
Microwave 100%
1:30
2x 400 2 2:40
3x 600 3 3:50
Skewered
Meat
1x 100 100
Convection 200˚C
Microwave 100%
9:00
2x 200 200 12:00
3x 300 300 15:00
4x 400 400 18:00
5x 500 500 21:00
NOTE: Auto-cook results are affected by the shape and size of the food to be cooked,
how well it is placed in the microwave oven, voltage fluctuations and your preferences. If
your food is not cooked to your satisfaction, please adjust the cooking time accordingly.
