STM MINI-REVOLUTION User manual

POWER
Standard 110V
.25 Horse Gear Motor with a 10:1 Ratio
Full-Load 7 Amps (FLA)
5-1/2 ft. Cord Length
SOFTWARE &
UPGRADES Manual Control Panel
OPERATION Integrated Plunger System
CYCLE
CUSTOMIZATION Single Cycle Operation with Variable Dial
TRAINING Training Videos via Client Portal
THROUGHPUT
MATERIALS
Encased in SAE 304 Stainless Steel
Aluminum & Other Food Grade Components
6061 Aluminum, Food-Grade Plastics
WEIGHT &
DIMENSIONS
COMPLIANCE
OSHA Compliant
UL-Listed Components
100% Food-Grade
LIFE CYCLE 10 Years
MINI-REVOLUTION
USER MANUAL
POWER SUPPLY CE,UL,EAC listed
Small Footprint
Approx. 56 lbs
30" L x 17.5" H x 10-1/2" W
Up to 1 lbs +/- every 2 minutes
MOTOR CE listed
LIMIT SWITCH UL, CE listed
ICE CUBE RELAY CE, SA, EAC listed

Table of Contents ............................................. 1
Components ...........................................,,,........ 2
Getting Started .................................................. 4
Operation of The Machine ............................... 5
Front End ............................................................ 6
Density Testing .................................................. 7
1
TABLE OF CONTENTS
Blade Maintenance ......................................... 8
Backing Plate ................................................... 9
Pushrod ......................................................... 10
Hopper ........................................................... 11
Terms of Business ........................................ 12

2
COMPONENTS
1. Power Switch - Turns the machine
on and off.
3. Wingnut - 5 wingnuts hold the
faceplate in place over the blade
chamber.
4. Pushrod - Easy to operate, lightweight
pushrod allows easy feeding into the
machine
5. Hopper - A wide hopper entrance
allows for a wide variety of material sizes
1. Power Switch
2. Adjustable Dial - Controls the
blade speed
5. Hopper
4. Pushrod
3. Wingnuts
2. Adjustable Dial

3
3. Chute
COMPONENTS
IMPORTANT! Always unplug machine before disassembly.
1. Blade
2. Wingnut Locations
4. Limit Switch
1. Blade - Grinds your material.
3. Chute - Where material exits
after grinding.
2. Wingnuts (5) - Line up your blade
cover with these spots for
reattachment.
4. Limit Switch - This prevents
the machine from running if the
front end is not attached.
COARSE BLADE FINE BLADE COLLECTION BIN

4
PREPARING WORK AREA
Your Mini-Revolution™ is equipped with 4 legs that grip
most surfaces for easy placing. We suggest setting up
your proccessing area as follows.
Material Prep Area
Material Prep for Mini-
Revolution™ use.
Mini-Revolution Area
For trained person(s) to
operate the Mini-Revolution™.
Loading Area
Dedicated to housing your
material for loading.
Unloading Area
Dedicated to unloading your
freshly ground material into
Shop Vac
Stainless Steel Cleaner
Moisture Reader
70%+ Isopropyl Alcohol
Spray Bottle
Collection Bin
4" Stain Proof Paint Brush
SUGGESTED TOOLS AND ACCESSORIES
Scoop for Material
GETTING STARTED
POWERING ON THE MINI-REVOLUTION
Power on the Mini-Revolution™ by plugging it
into a 120v outlet.
Press the orange button to the ON position.
CONTROL PANEL

5
Sift material for better quality pre-rolls.
Refer to density training videos for desired
weight and results. bit.ly/rb2-density-testing
Helpful Tips
OPERATION OF MACHINE
Turn on power and adjust your speed
dial to 10 or "HIGH". Maximum power
is achieved by turning the dial fully
clockwise.
Pull the pushrod back and insert
material into the hopper.
Push material forward with the
pushrod into the blades. Only fill
enough where the material is even
with the bottom of the hopper.
Pull pushrod back after material has
been fed. Repeat steps 2-4 until your
desired amount of material is ground.
USING THE MINI-REVOLUTION™
Sift material with a sieve and use as
desired.
IMPORTANT! Ensure your moisture content is between 7-10% to prevent clogs.

Align the 5 holes from the front
end of the machine with the 5 bolts
located around the blade chamber.
See components from photo guide.
ATTACHING THE FRONT END
REMOVING THE FRONT END
Your Mini-Revolution™ comes equipped with an easy feed hopper, variable speed levels, and
easy accessibility to your blade area making cleaning a breeze. The front end is able to be easily
removed and reattached for easy cleaning and maintenance.
6
FRONT END
Slip the front end over these bolts and
secure the wingnuts tightly.
Loosen and remove the (5) wingnuts from the bolts
located on the front end of the machine, around the
edge of the front of the machine.
Hold on to the Hopper and pull back on the front end
of the machine to remove the front plate.
This will expose the blade, blade chamber, and safety
limit switch.
(5) Wingnuts
Front End Plate with an easy feed hopper
Pushrod to move material into your blades
FRONT END IS EQUIPPED WITH
IMPORTANT! Always unplug machine before disassembly.

7
Fill the included beaker up to the 10 mL line
with ground material.
Add material to the beaker until it reaches the 10
mL fill line and turn the machine to High, hold for
one minute.
Continue adding material until it settles at the
10ml fill line while the beaker is vibrating in the
machine.
Remove beaker from machine and place onto
the scale with torn beaker weight. Weigh beaker
with material inside on the thousandth scale.
PERFORMING A DENSITY TEST
Tare empty 10 mL beaker on thousandths scale.
Repeat density test 3x and average for optimal results.
It is recommended to use a thousandths scale for accuracy.
Helpful Tips
DENSITY TESTING
WHAT IS DENSITY?
Density is a characteristic property of a
substance. The density of a substance is
the relationship between the mass of
the substance and how much space it
takes up (volume).
FOR ROCKETBOX USERS ONLY

8
REMOVING THE BLADES
Using a 1/8” Allen Wrench, begin to loosen the (8)
Blade locking bolts located on the outside edge of
the Blade.
BLADE MAINTENANCE
Unscrew the bolts halfway and twist the Blade by
hand counterclockwise, to release the Blade from
the locking holes for the bolts.
Pull the Blade away from the machine and bolts to
remove it.
ATTACHING THE BLADES
Hold on to the Backing Plate and keep it in place
while installing the Blade.
Place Blade on to loosened (8) Blade locking bolts.
Turn the Blade clockwise on the Blade locking bolts
until the Blade comes to a stop against the bolts.
Screw-in and tighten the (8) Blade Locking Bolts to
the Blade using a ⅛” Allen Wrench.
CLEANING THE BLADES
Spray your Blade with Isopropyl Alcohol and allow
it to sit for 10-15 seconds.
Using a microfiber soft cloth buff away any
residue and wipe clean.
Use your paintbrush to remove excess material
from your Blade.
For a deeper clean, your blades can be
scrubbed with a nylon brush and dish soap.
SUPPLIES YOU'LL NEED
1/8" Allen Wrench
Diamond Cut-proof gloves
Spray bottle of Isopropyl Alcohol
Stain-proof paintbrush
Microfiber soft cloth
Dish soap (optional)
IMPORTANT! Always unplug machine before disassembly.
Press the center blade hole onto the nipple of the
center drive shaft. This allows for the disc to
become perfectly center every time.

9
REMOVING THE BACKING PLATE
After following the "Removing the Blades"
section you can now remove the Backing Plate.
BACKING PLATE
Using a ⅛” Allen Wrench, remove the (4) bolts
located in the center of the Backing Plate.
Once the (4) bolts have been removed,
pull the Backing Plate from the machine.
ATTACHING THE BACKING PLATE
Place the Backing Plate on to motor drive arm.
Insert the (4) bolts that were taken out with
the ⅛” Allen Wrench in the (4) holes located
in the Backing Plate.
Screw in and tighten the (4) bolts in the Backing
Plate to the machine to lock into place.
CLEANING THE BACKING PLATE
Spray your Backing Plate with Isopropyl
Alcohol and allow it to sit for 10-15 seconds.
Using a microfiber soft cloth buff away
any residue and wipe clean.
Use your paintbrush to remove excess
material from your backiung Plate.
For a deeper clean, your Backing Plate can be
scrubbed with a nylon brush and dish soap.
SUPPLIES YOU'LL NEED
1/8" Allen Wrench
Spray bottle of Isopropyl Alcohol
Stain-proof paintbrush
Microfiber soft cloth
Dish soap (optional)
IMPORTANT! Always unplug machine before disassembly.

10
PUSHROD
CLEANING THE PUSHROD
Spray your Pushrod with Isopropyl Alcohol
and allow it to sit for 10-15 seconds.
Using a microfiber soft cloth buff away
any residue and wipe clean.
Use your paintbrush to remove
excess material from your Pushrod.
For a deeper clean, your Pushrod can be
scrubbed with a nylon brush and dish soap.
REMOVING THE PUSHROD
The faceplate of the Hopper is located where
the handle of the Pushrod meets the Hopper.
Remove the (6) - 5/32” bolts from the front
plate on the Hopper.
Remove the faceplate after bolts have
been remove by pulling the Pushrod out
of the Hopper.
Remove the face of the Pushrod by using a
5/16” Allen Wrench. Face Plate can now be
removed.
ATTACHING THE PUSHROD
Place face plate back onto Pushrod handle.
Attach the face of the Pushrod by screwing in
the 5/16” bolt into the face of the Pushrod.
Place Pushrod back into the Hopper.
Line up the holes in the faceplate with the
holes in the front of the Hopper and screw in
the (6) - 5/32” bolts until tight and secure.
SUPPLIES YOU'LL NEED
5/16” Allen Wrench
5/32” Allen Wrench
Spray bottle of Isopropyl Alcohol
Stain-proof paintbrush
Microfiber soft cloth
Dish soap (optional)
IMPORTANT! Always unplug machine before disassembly.

11
REMOVING THE HOPPER
The faceplate of the Hopper is located
where the handle of the Pushrod meets
the Hopper. Remove the (4) - 5/32” bolts
from the front plate on the Hopper.
HOPPER
ATTACHING THE HOPPER CLEANING THE HOPPER
Spray your Hopper with Isopropyl Alcohol and
allow it to sit for 10-15 seconds. Wipe clean.
SUPPLIES YOU'LL NEED
5/16” Allen Wrench
5/32” Allen Wrench
Spray bottle of Isopropyl Alcohol
Stain-proof paintbrush
Microfiber soft cloth
Dish soap (optional)
Utilize compressed air if possible to remove
any dry debris. If no compressed air a dry
microfiber rag or paper towel can used.
For a deeper clean, your Hopper can be scrubbed with a
nylon brush and dish soap.
The faceplate of the Hopper is located
where the handle of the Pushrod meets
the Hopper. Reattach the (4) - 5/32” bolts
from the front plate on the Hopper.

12
TERMS OF BUSINESS
PURCHASING TERMS & CONDITIONS
All products are first-come-first-serve and that receipt of payment is required in order to receive a confirmed shipping date in the queue. STM
Canna & STM Supply reserve the right to specify collection by certified check, money order, or company check. Personal checks are not accepted.
Due to high demands, certain items may have a lead time of 4-8 weeks or more from payment date, unless otherwise stated. Following the receipt
of an invoice, STM Canna must receive payment within a maximum of 7 days before the invoice expires – leaving lead times, quoted prices, specials
and discounts on all items subject to change. If a deposit is applicable for any special reason, my deposit is non-refundable. Purchaser agrees to
adhere to the Customer Awareness Program and Terms of Business herein.
A 12-month warranty on each product that is applicable with regards to manufacturer’s defects, including parts and labor.
STM Client Services department is dedicated to ensuring the success and satisfaction of all STM clients.
STM Tech department provides our clients with all software updates, phone support and virtual support, as needed.
An easy-to-use client portal with tools such as product F.A.Q.’s and Best Practices, along with an extensive video library to help guide you
towards success with your STM equipment.
CUSTOMER AWARENESS PROGRAM (C.A.P.)
STM takes pride in the products we make and the services we offer. To ensure our customers fully understand the services we provide, along with
the capabilities and expectations of our products, we have executed and outlined the Customer Awareness Program contents below:
All orders are required to electronically agreed to our terms by clicking "I agree" during the checkout process in our
online store. All completed orders, whether "Paid" or "Awaiting Payment" agree to and are held to our Terms of Business.
All STM systems carry a limited one-year warranty against defects in workmanship and/or materials.
Accessories are excluded from this warranty.

13
TERMS OF BUSINESS
WHO IS COVERED?
This warranty covers the original purchasing company, unless otherwise discussed prior to the sale and authorized in writing by STM Canna & STM
Supply. Warranties do not transfer for resold machines regardless of age of the model.
Please note that results with STM Canna & STM Supply products can yield varying results which depend on a myriad of factors, including but not
limited to: correct grind size, age of material, quality of material, moisture content, strain, temperature, correct sized cone usage, quality of cones
used, skill of the operator, and more. Our quoted weight ranges for flower, and trim are all general averages that have been reported to us by our
customers, however your material may behave completely differently. We take no responsibility whatsoever for your results, only for the working
functionality of our products. If you have any questions or concerns, please do not hesitate to talk to us about this very important disclaimer. There
are no warranties on paper products. Machines come with a 1- year parts and labor warranty. See Returns & Voidable actions below.
EXPECTATIONS AND CAPABILITIES OF YOUR STM EQUIPMENT: STM MINI-REVOLUTION
With our detailed manual and training videos you can expect a complete and comprehensive training program to educate your team on best
practices, as well as the cleaning and maintenance of your machine and accessories. By following the guidelines provided to you via the user
manual and training videos, you will be able to produce a quality and consistent product that will be easily repeatable. The shaker box within the
machine contains an area where material may escape during operation. With the 400 hour break-in period, STM advises against re-purposing this
excess waste due to potential metal contaminants residing in the shaker box from regular usage. Results are not guaranteed and can greatly vary
from operation to operation.
EXTENT OF WARRANTY
There are no warranties on paper products. Machines come with 1-year parts and labor warranty. Accessories are excluded from this warranty. See
Returns on Page 16.

14
TERMS OF BUSINESS
Abuse, misuse, improper installation, and modifications.
Custom applications.
No proof of purchase at the time of warranty. The claimant must provide proof of purchase, warranty card, and a warranty authorization
number (RMA) obtained from STM.
Finishes such as plating or painted surfaces with discoloration or rust due to inclement weather conditions, exposure to salt, exposure to
chemicals, or lack of maintenance by the customer are not covered.
International gray-market products purchased through a dealer/distributor not authorized for your country will not be supported by this
warranty.
Electrical parts are not covered under warranty.
VOIDABLE ACTIONS

15
TERMS OF BUSINESS
SHIPPING
All orders must be paid in full before the order is shipped. Orders received will fall in line and be serviced accordingly where the shipment date may
be sooner than originally quoted. We will ship by the most reasonable means based on the volume of the order unless otherwise specified. Since
the ownership of product transfers at the FOB point, claims for damaged, lost, or short shipments must be made at the time of receipt. We provide
a disclaimer in your tracking email located at the bottom that states: "If your order arrives damaged, please do not accept the shipment. If the
shipment is accepted and your items are damaged you will be responsible for filing a claim with the carrier. We always advise, if possible, to keep
the carrier there so you can unpack your order to ensure it is complete and undamaged."
SPECIAL ORDERS
All special order items must be paid in full before the order is placed. These items are non-returnable and no refund will be given. All special order
items will also take a longer period of time for the customer to receive, which will be quoted at the time of payment.
LIABILITY
The purchaser of any products releases the manufacturer of those parts and STM Canna from all liabilities pertaining to use of the products.
Reference your instruction sheet and double-check all instructions.
Always take time to examine problems in detail.
When all else fails, please call the STM technical support line at [phone] or email us at clientservic[email protected].
TROUBLESHOOTING
The technical line is open 8:00am – 4:00pm Monday through Friday, Pacific Time. Please have the following information handy: Name of Company
the purchase was made under, Date of Purchase, and Serial number.

16
TERMS OF BUSINESS
RETURNS
No Refunds/Exchanges: We do not accept returns or exchanges unless the item purchased is defective. No item will be accepted for return without
prior approval. All approved returns must be accompanied by a return authorization (RA) number and must be in new and unused condition. All RA
numbers must be clearly displayed on the outside of the box. All returns are subject to restocking fees, not to exceed 20% unless damaged. Refunds
are issued in the form of like payment. All refused shipments are subject to a 20% restocking fee and all applicable freight charges. All items that we
ship are insured; if an item comes that is damaged from shipping, we will work closely with you to get you replacement parts as soon as possible.
We may also request pictures or other identifying information to establish that damage was caused by the shipping carrier.
If you receive an item you believe is defective, please contact us with details of the product at [phone] or email us at
[email protected].
We may ask you for pictures, videos, descriptions, and other identifying information to make a determination. If you are unable to provide adequate
documentation requested, your return request will be denied. If your item is deemed defective, which is solely at STM’s discretion, we will issue you
an RMA # which you will need to place in and on the package. After receiving your RMA #, you may send the item to:
STM Canna
3038 E Trent Avenue, Suite C
Spokane, WA 99202
Upon receipt of the returned product, we will fully examine it and notify you via e-mail, within a reasonable period of time, whether you are entitled
to a replacement as a result of the defect. If you are entitled to a replacement, we will replace the product at no additional cost to you.
