Stone 4262358530165 Operating instructions

ITA - istruzioni originali
COFFEE MACHINE FOR
DOMESTIC USE
User and maintenance manual
Translation of the original instructions

EN Congratulations on choosing the STONE espresso coffee machine.
This product is designed to satisfy your need for exquisite quality in cups of coffee-based bever-
ages.
Carefully read the instructions to operate the machine correctly.
This manual provides important guidelines for use, maintenance and safe installation.
It also contains useful recommendations that will allow you to maximise the potential of the STONE
machine.

STONE
3
EC DECLARATION OF CONFORMITY
STONE S.r.l.
Via E. Curiel 13 - 20060 LISCATE (MI) ITALY
being the manufacturer of COFFEE MACHINES, hereby declares that the product:
Modello STONE
to which this declaration refers, complies with the applicable essential requirements of the
following DIRECTIVES and REGULATIONS and subsequent amendments:
2014/68/UE Directive of pressure equipment (PED) with applied the exclusion to Chapter
1 Article 1 Par. 2 (f)
2014/30/UE Electromagnetic compatibility EMC Directive
2014/35/UE Low voltage Directive
2012/19/UE WEEE Directive
2011/65/UE RoHS Directive
1935/2004/EU Regulation on food contact materials
- in compliace with standards
EN 55014-1: 2017-04
EN 55014-1 / A11: 2020-03
EN 55014-2: 2015-04
EN 61000-3-2: 2014-08
EN 61000-3-3: 2013-08
EN 61000-3-3 / A1: 2019-08
EN 62233: 2008 / AC: 2008
EN 60335-2-15: 2016 / A11:
2018
EN 60335-1: 2012 / A2: 2019
The STONE S.r.l., Via E. Curiel, 13 - 20060 LISCATE (MI) - ITALY is responsible for establishing
and maintaining the technical le.
This declaration is null and void if the machine is modied without the express authorization of the
manufacturer or if improperly installed and used in a way that does not comply with indications in
the users’ manual and the instructions.
Date of Issue: Liscate
29 - 10 - 2021 Managing Director
Dott. Federico Alessandro Gallia

STONE
4
CONTENTS
1INTRODUCTION ............................................................................... 6
1.1 SYMBOLS AND TERMINOLOGY USED IN THE MANUAL.. 6
1.2 GENERAL INFORMATION ...................................................... 7
1.3 SAFETY INSTRUCTIONS ....................................................... 8
2UNPACKING ....................................................................................... 10
2.1 CONTENTS OF THE PACKAGE............................................. 10
3DESCRIPTION OF THE MACHINE .................................................. 11
3.1 INTENDED USE ....................................................................... 11
3.2 TECHNICAL SPECIFICATIONS ............................................. 11
3.3 MAIN COMPONENTS.............................................................. 12
3.4 ACCESSORIES ........................................................................ 13
3.5 TECHNICAL DATA ................................................................... 13
4INSTALLATION ............................................................................... 14
4.1 FILLING THE WATER TANK ................................................... 15
4.2 ELECTRICAL POWER SUPPLY ............................................. 15
5START-UP ............................................................................... 16
6MACHINE OPERATION..................................................................... 17
6.1 COFFEE PREPARATION ........................................................ 18
6.2 STEAM DISPENSING.............................................................. 19

STONE
5
7MAINTENANCE.................................................................................. 20
7.1 CLEANING THE STEAM WAND............................................. 20
7.2 CLEANING THE DISPENSING HEAD ................................... 21
7.3 CLEANING THE PORTAFILTER............................................. 50
7.4 CLEANING THE WATER TANK .............................................. 22
7.5 CLEANING THE DRIP TRAY................................................... 23
7.6 DESCALING ............................................................................. 24
7.7 WATER REPLACEMENT IN THE BOILER ............................ 24
8 ALARMS AND FAULTS ..................................................................... 26
8.1 ALARMS ............................................................................... 26
8.2 TROUBLESHOOTING ............................................................. 26
8.3 INACTIVITY .............................................................................. 28
9 DISPOSAL ............................................................................... 30

STONE
6
DANGER: this symbol indicates information or procedures which, if not carefully
followed, may cause serious personal injuries. Potential source of injury or harm
to health.
CAUTION
The instructions accompanied by this symbol contain information, requirements or
procedures, which can cause damage or malfunctions, if not carried out correctly.
INFORMATION
The guidelines indicating this symbol contain information on particularly important
topics and failure to comply with them may render the warranty null and void.
CAREFULLY READ the instruction manual before commissioning.
CAUTION:machine connected to the electrical mains!
Disconnect the power supply before performing any maintenance.
CAUTION:hot contact parts!
Wear protective gloves.
1- INTRODUCTION
1.1 Symbols and terminology used in the manual
BEFORE PERFORMING ANY OPERATION ON THE MACHINE, THE USER MUST
CAREFULLY READ THE INSTRUCTIONS CONTAINED IN THIS PUBLICATION
AND FOLLOW THEM THROUGHOUT THE INTERVENTIONS.
IF IN DOUBT ON THE CORRECT INTERPRETATION OF THE INSTRUCTIONS,
CONTACT OUR ASSISTANCE SERVICE FOR THE NECESSARY CLARIFICATIONS.
MACHINE
UNDER
MAINTENANCE
i
MACHINE
UNDER
MAINTENANCE
i
MACHINE
UNDER
MAINTENANCE
i
MACHINE
UNDER
MAINTENANCE
i
MACHINE
UNDER
MAINTENANCE
i
MACHINE
UNDER
MAINTENANCE
i
MACHINE
UNDER
MAINTENANCE
i
MACHINE
UNDER
MAINTENANCE
i
MACHINE
UNDER
MAINTENANCE
i

STONE
7
This manual is an essential part of the STONE product; therefore, it is crucial that you read
the enclosed warnings and precautions carefully before operating the machine. In particular,
pay attention to the safety instructions during installation, commissioning, use and cleaning.
Please keep this user manual in a safe location where it may be available to all users of the
machine.
The co󰀨ee machine description provided below is of a general nature and may,
therefore, not include all details on the various components.
The o󰀩cial language chosen by the manufacturer is Italian.
This manual reects the state of the machine at the time of supply. STONE reserves
the right to make, at any time, all the changes it deems appropriate to mass production and
update the related manuals without the obligation to update previous production and manuals,
as well as inform users of previously supplied machines.
CAUTION
THE MANUFACTURER SHALL NOT BE LIABLE FOR ANY DAMAGE CAUSED TO
PEOPLE OR PROPERTY DUE TO:
■ Improper use of the machine.
■ Use by unsuitable personnel (unauthorised and/or untrained).
■ Power supply defects.
■ Lack of maintenance on machine components.
■ Changes to the machine not authorised by the manufacturer.
■ Use of non-original spare parts.
■ Replacement of components supplied with the machine with other components having
di󰀨erent technical specications from those in the project.
■ Failure to comply with these instructions.
■ Failure to comply with the safety regulations.
TRANSPORT AND HANDLING
When handling the machine, take the necessary precautions to prevent it from falling,
damaging people, animals and things, as well as the machine itself. Do not carry out
this operation by yourself. It is recommended to have two people handle the appliance.
When handling the machine in the packaging, be sure to follow the wording “THIS
WAY UP” (identied by the symbol ) on the packaging.
Do not overturn the machine during handling. Handle with care.
The manufacturer cannot be held responsible for damage caused by incorrect handling
or by not complying with the indications provided.
OPERATOR: this symbol indicates information or procedures concerning the user of
the machine. Procedures within the competence of the person in charge of machine
operation, use and routine maintenance.
QUALIFIED TECHNICIAN: this symbol indicates information or procedures regard-
ing special maintenance (electrical / mechanical) for a qualied person authorised
by the manufacturer
1.2 General information
MACHINE
UNDER
MAINTENANCE
i
MACHINE
UNDER
MAINTENANCE
i
MACHINE
UNDER
MAINTENANCE
i

STONE
8
1. Do not leave the packing elements (plastic bags, expanded polystyrene, nails, cardboard,
etc.) within the reach of children, as these elements are potential sources of danger.
2. Install the machine on a at, water repellent surface (laminate, steel, ceramic, etc.) away
from heat sources (oven, cooking stove, replace, etc.) and in conditions in which the
temperature cannot drop below 5°C. Keep warm.
3. Do not leave the machine exposed to environmental elements or place it in damp rooms.
4. Do not obstruct the grids and do not cover with cloths, etc.
5. Keep the packed machine in a dry place, not exposed to environmental elements and in
conditions in which the temperature does not go below 5° C.
6. Do not place heavy items on the package.
7. In an emergency, such as re, unusual noise, overheating, etc., take immediate action by
disconnecting the power.
8. The installation and repair must conform to the codes and local electrical safety regulations.
9. The STONE machine must be installed after reading and understanding this publication
10. This machine is only safe when it has been correctly connected to an e󰀩cient earthing
system.
11. Check to see that the data on the rating plate corresponds to that of the main electrical mains
to which the machine will be connected. Before connecting the machine to the electrical
mains, make sure that the voltage, frequency and power of the machine correspond to
those of the local electrical mains. The electrical data are indicated on the machine data
plate.
12. We do not recommend the use of accessories such as adaptors, multiboards or extension
cords not recommended by the appliance manufacturer as they may cause injuries.
13. Do not use this machine if the cable, plug or any other part is damaged or if the machine
malfunctions. Return the machine to the nearest authorised service facility for examination,
repair or adjustment. CAUTION: The power cable must not be replaced by the user.
14. This machine has been designed for the sole purpose of producing co󰀨ee and dispensing
steam for hot beverages. All other uses are inappropriate and dangerous. The manufacturer
shall not be held responsible for any damage caused by inappropriate use.
15. To protect against electric shocks when using any electrical appliance including your STONE
machine:
a. Do not immerse the machine itself, cable and plugs in water or other liquid and do not
let the machine’s internal parts get in contact with liquid.
b. Prevent the power cable from being stretched or pulled tight.
c. Do not use the machine with wet hands or feet.
1.3 Safety warnings
MACHINE
UNDER
MAINTENANCE
i
MACHINE
UNDER
MAINTENANCE
i

STONE
9
d. Do not allow children or untrained persons to use the machine.
e. Do not operate the machine with bare feet.
f. Place a circuit breaker at the electrical mains feeding the machine.
g. Do not tip liquids on top of the machine.
h. The machine should not be exposed to elements such as sunlight, rain, snow, extreme
temperatures etc.
16. Always use STONE certied and manufactured spare parts and accessories.
17. Before performing any cleaning or maintenance turn the machine o󰀨 by means of the
machine’s power switch and disconnect the machine from the electrical supply.
18. This appliance is intended for domestic use.
19. If the machine operates in a faulty manner or stops working, turn it o󰀨 immediately and
disconnect it from the electrical supply. Do not attempt to repair it but contact an authorized
and qualied STONE technician. Any repair must be performed by the manufacturer or by
an authorized dealer using only original parts.
20. When the machine is not used for long periods of time it must be stored at a temperature
above zero (0°C / 32°F). This will prevent the hydraulic system from freezing, which could
damage the internal pipes and boiler
21. The machine must be used with drinking water. Use a water softener if water from the local
mains has a high mineral content. A build-up of mineral deposit may restrict the ow of
water within the hydraulic systems causing damage to the machine and risking personal
injuries. Conversely, highly “pure” waters may interfere with the electronic signals read by
the machine for both boiler level and water tank level indications. Use ltered water.
22. The appliance is not to be used by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have
been given supervision or instruction.
23. Keep the appliance and relevant cable out of reach of children.
24. Children must not play with the appliance.
25. Do not pull the power cable to disconnect the appliance from the power supply.
26. To ensure correct operation and e󰀩ciency of the machine, it is required to follow the man-
ufacturer’s instructions, carrying out cleaning and routine maintenance operations.
27. During machine operation some parts reach high temperatures, such as the dispensing
units, the portalters and the steam nozzles (indicate the photo with the gures?). Pay
attention not to touch or put your hands under these parts when using them, to prevent
scalds or burns.
28 Never remove (disengage/release) the portalter while dispensing co󰀨ee.

STONE
10
2- UNPACKING
Before proceeding, the machine
installation personnel must read
these instructions and, in particular,
the previous sections regarding
general information and safety
requirements.
MACHINE
UNDER
MAINTENANCE
i
2.1 Contents of the package
The weight of the unladen machine is indicat-
ed directly on the packaging or is visible on the
“CE” marking plate applied on the machine.
The packed machine must be protected in a
sheltered and moisture-free premises until it
is installed in a suitable environment.
After removing the packaging, it is required
to verify that the various components are in
perfect condition and that there are no traces
of tampering, damaged parts, etc.
It will also be necessary to check that the
machine is complete with all its parts, any
accessories and technical documentation as
per the transport documentation.
CAUTION! Before proceeding
with the installation, in case
anomalies are found in the checks
on delivery, report the ndings to
the manufacturer.
MACHINE
UNDER
MAINTENANCE
i
The packaging elements (plastic
bags, expanded polystyrene, nails,
cartons, etc...) must not be left within
the reach of children as they are
potential sources of danger.
These elements must be disposed
of in accordance with the local reg-
ulations in force
MACHINE
UNDER
MAINTENANCE
i
The machine is supplied fully assembled (with
the exception of the accessories contained in
the special boxes - g. 2.1).
g_2.1

STONE
11
3- DESCRIPTION OF THE
MACHINE
The machine has been designed and built
to be used to prepare espresso co󰀨ee and
hot drinks.
Any other use is to be considered unsuitable
and therefore dangerous.
The manufacturer cannot be
held responsible for any damage
caused to people or things due to
unsuitable, erroneous or irration-
al use of the machine
The operator must always follow the indica-
tions contained in this manual. In the case
of a failure or if the machine is not working
properly, switch it o󰀨 and do not attempt any
direct repair. Contact the service centre.
3.1 Intended use
MACHINE
UNDER
MAINTENANCE
i
3.2 Technical specifications
■ Eco mode available (see par. 6.3)
■ Boiler capacity:
1.5 litres (1000 W)
■ Voltage (version A): 220-240V - 50/60 Hz
for EC versions
Voltage (version B): 115V - 60 Hz
for USA/CAN versions
■ Co󰀨ee unit resistance:
200 W
■ Removable water tank:
1.2 L
■ Dimensions and weight (g_3.1)
Width: 225 mm
Depth: 440 mm
Height: 355 mm
Weight: 20.5 Kg
■ Panels (front, top, rear):
Stainless steel
■ Side panels:
Available in di󰀨erent colours and materials
g_3.1

STONE
12
3.3 Main components (g._3.2)
1. ON / OFF:
“O” = OFF
“I” = ON
2. Control indicators.
3. Co󰀨ee dispensing knob
4. Steam dispensing knob.
5. Steam wand
6. Pressure gauge.
g_3.2
7. Portalter.
8. Water tank holder compartment
9. Cup warmer
10. Cup warmer grids + tray.
11. Eco Mode button.
12. Removable side panels

STONE
13
Volt
■ Please refer to the technical data plate on the
machine.
Power
■ Please refer to the technical data plate on the
machine.
Temperature
■ The machine must not be operated with tem-
peratures under 5°C and over 36°C.
Water
■ The machine must be operated with soft, clean
drinking water. If the local water mains has a
high mineral content, use a water softener.
The water hardness must be between F° 4 - 7°
(French) / D° 7 - 16° (German).A build-up of
mineral deposit may restrict the ow of water
within the hydraulic systems causing damage
to the machine and risking personal injuries.
Boiler capacity
■ 1.5 litres
3.5 Technical data
3.4 Accessories
The machine is supplied complete with a wide
series of accessories (g._3.3).
The rst box contains the following parts and
accessories:
1. Portalter - single
2. Portalter - double
3. Tamper
4. Blind lter
5. Dispensing head cleaning brush.
g_3.3
The second box contains the following parts
and accessories (g._3.4):
1. Removable side panels
2. Grid
3. User manual.
g_3.4

STONE
14
If the machine is wet or very
damp, wait until it is completely
dry before installing or using it.
4- INSTALLATION
The machine must only be installed in places
where it is easy to use and access.
The support surface must be levelled, dry,
smooth, stable and at such a height that the
base is at least 100/105 cm approx. above the
ground. (g._4.1)
Do not use or install where water jets are used.
g_4.2
g_4.1
In order to ensure normal operation, the ma-
chine must be installed in areas where the
room temperature is between +5°C and +36°C
and humidity does not exceed 70%.
Ensure that there is an open area of at least
10 cm on each side and behind the machine
to allow adequate ventilation and facilitate its
use and the performance of any maintenance
operations. (g._4.2)
MACHINE
UNDER
MAINTENANCE
i
The machine is supplied without the remova-
ble side panels. Apply the 10 magnetic pan-
els (5 per side) respecting the arrangement
shown in the gure 4.3
g_4.3
click

STONE
15
MACHINE
UNDER
MAINTENANCE
i
4.1 Water fillingtank
Make sure to use water with a de-
gree of hardness suitable for this type
of machine (see par. 3.5 page 41)
The machine has to operate with clean soft
drinking water. Never attempt to operate the
machine with water of a hardness other than
that specied in paragraph 3.5.
Lift the cover of the tank compartment (1
g. 4.4) and ll with water (MAX 1.2 L).
The manufacturer recommends inserting a
softener bag in the water tank.
Pay attention to only pour water into the water
tank, use a funnel if required. (to remove the
tank for cleaning see chap. Maintenance page
48). Reposition the cover of the water tank
compartment.
MACHINE
UNDER
MAINTENANCE
i
g_4.5
MACHINE
UNDER
MAINTENANCE
i
Before connecting the machine
ensure that the identification
label data comply with those of
the local electric mains.
The earthing system must be car-
ried out in accordance with the provisions of
current legislation.
Connect the power supply cable (g. 4.5)
4.2 Electrical power supply
g_4.4
Check the package for validity of
the softener used (quantity of litres)
Arrange any excess cable on the
worktop, so that it cannot be pulled
by children or cause tripping
MACHINE
UNDER
MAINTENANCE
i
CAUTION:
If the power supply cable is
damaged it is to be replaced
by the manufacturer or by their
technical assistance service
or by a person with equivalent
qualication, in order to prevent
any risks.
MACHINE
UNDER
MAINTENANCE
i
The cable must be positioned correctly and
come out of the machine at the centre of the
rear side in the special groove in the lower
part of the sheet metal panel.

STONE
16
5- START-UP
We assume the machine has been installed
correctly.
■ Turn the On/O󰀨 switch (1 - g._5.1) from
position “O” to position “I”.
The indicator (2 - g._5.1) lights up with a
xed white light.
■Open the steam knob (3 - g._5.2). to start
lling the boiler with water (the noise of the
pump must be heard).
When the boiler is correctly lled with water,
the pump stops (the noise stops).
■ Then close the steam knob.
g_5.1
g_5.2
The boiler heating begins.
Wait for the boiler pressure gauge (4 - g._5.3)
to indicate approximately 1 bar.
■ Open the steam knobs (3 - g._5.4) for 5
seconds to allow some steam to escape.
This operation is highly impor-
tant as it eliminates any vacuum
inside the boiler which may
cause milk to be sucked into the
boiler once steam dispensing
has begun. Close the steam knob
again.
■ Wait for the boiler pressure gauge (4-
g._5.3) to reach 1 bar again.
g_5.3
MACHINE
UNDER
MAINTENANCE
i
g_5.4

STONE
17
g_5.5
■ Turn the brew paddle fully anticlockwise
(4 - g._5.5). Drain a cup of hot water from
the infuser unit head (5).
This operation must only be performed
once at rst use.
■ Fully turn the brew paddle clockwise to stop
the ow of water (g._5.6)
■ The machine is now ready for use
Allow a heating time of 15-18 min-
utes so that the head of the unit is
fully heated: the quality of the es-
presso will be greatly improved with
a hot unit and portalter inserted.
MACHINE
UNDER
MAINTENANCE
i
2. Now rotate the brew paddle to start the
water ow through the portalter. (g_6.2)
6- MACHINE OPERATION
Make sure that the machine is
ready for full safety operation
as described in the previous
chapters
MACHINE
UNDER
MAINTENANCE
i
g_6.1
1. Install the portalter by inserting it into the
unit head and rotate the relevant handle
from left to right. The portalter is inserted
properly once it is rmly inside the unit head
and the handle is sitting at 90 degrees from
the front of the machine (g._6.1)
g_5.6
MACHINE
UNDER
MAINTENANCE
i
It is recommended to perform a
first water dispensing without
co󰀨ee with a new portalter or
on first use. This operation is
recommended to eliminate any
processing residues
MACHINE
UNDER
MAINTENANCE
i
CAUTION:
The portalter unit heats up when
the machine is ready. Pay attention

STONE
18
3. It is important to leave the portafilter
hooked in the unit head when not in use.
The portalter must remain heated for an
optimal brew process. It will also prevent
the seal inside the unit head from drying
out prematurely.
g_6.2
6.1 Coffee preparation
1. Choose the portalter for the preparation
of one or two cups in a single dispensing
(g._6.3).
g_6.3
g_6.4
2. Fill with ground co󰀨ee and press (g._6.4),
removing any co󰀨ee residues on the edge
of the lter
2. Hook the portalter to the dispensing unit
and place the cup(s) under the co󰀨ee dis-
pensing spout.
g_6.5
3. Start dispensing by turning the paddle
anticlockwise. Turn the paddle clockwise
to stop dispensing.

STONE
19
MACHINE
UNDER
MAINTENANCE
i
The maximum duration of a single
dispensing is 100 seconds. After
this time, dispensing stops auto-
matically even if the user has not
closed the lever.
Dispensing has priority over lling:
if dispensing is requested while the
machine is lling water, lling is tem-
porarily suspended and dispensing
begins regularly. It is possible to
dispense even when the machine
has not yet reached the rst level.
MACHINE
UNDER
MAINTENANCE
i
g_6.6
4. Remove the portalter to empty and clean
it and then hook it up again (g_6.6)
6.2 Steam dispensing
With the machine turned on and pressure
gauge (see chap. 5 page 44) pressurised, it
is possible to dispense steam from the special
nozzle.
Take a jug and place the steam wand into the
drink and open the steam tap (3 - g_6.7)
g_6.7
Once the desired dispensing is com-
plete, close the tap and remove the
jug. Clean the nozzle with a damp
cloth.
Dispense steam for a few seconds
and then clean again with a damp
cloth (g_6.8)
g_6.8
MACHINE
UNDER
MAINTENANCE
i

STONE
20
MACHINE
UNDER
MAINTENANCE
i
For best results:
store milk at ≤ 5°C (≤ 41°F)
6.3 ECO mode
When ECO mode is enabled, the machine
enters standby after 60 minutes of inactivity.
When the machine is in standby, all heaters
are off and delivery is not possible. The
machine exits standby by operating the dis-
pensing paddle.
To activate the ECO-ON mode press the but-
ton under the machine (g_6.9).
g_6.9
Maintenance operations must be
carried out when the machine is
o󰀨 and cold. Some particular op-
erations must be performed when
the machine is operating.
Do not clean the machine by using metal
or abrasive devices, such as steel wool,
metal brushes, needles, etc. or general
detergents (alcohol, solvents, etc.)
When necessary, use special detergents
for co󰀨ee machines that can be purchased
in specialised service centres.
Keeping your machine clean will prolong its
life and produce better espresso beverages.
7- MAINTENANCE
MACHINE
UNDER
MAINTENANCE
i
MACHINE
UNDER
MAINTENANCE
i
CAUTION:
The jet of steam may cause burns.
7.1 Cleaning the steam wand
1. Clean the steam wand after every use by
wiping with a damp cloth. Turn the steam
wand on to release condensation and milk
residue.
2. If the steam jets become clogged with the
powdered milk, unscrew the nozzle and
unlock/clean with a paper clip (g._7.1).
g_7.1
MACHINE
UNDER
MAINTENANCE
i
MACHINE
UNDER
MAINTENANCE
i
The machine is supplied from the
factory with the ECO mode acti-
vated.
