Storage Canopy FB335017DP User manual

1
Fabric Building
Double Truss Peak Style
Model# FB335017DP 33’x50’x17’
(10’ arch space)
Assembly Instructions

2
Equipment List
Speed Wrench
22#.23#.24#
Hammer (30lb)
Rope (12#)
Long Tape (50m)
Hammer Drill*1
Lifter*2
Crane*1
Forklift*1
Protective
equipment

3
YOU MUST READ THIS DOCUMENT BEFORE YOU BEGIN TO ASSEMBLE THE SHELTER.
Thank you for purchasing our shelter. When properly assembled and maintained, this product will provide years
of reliable service. These instructions include helpful hints and important information needed to safely assemble
and properly maintain the shelter. Please read these instructions before you begin.
If you have any questions during the assembly, please contact local dealer for assistance.
SAFETY PRECAUTIONS
. Wear eye protection.
. Wear head protection
. Wear gloves when handling metal tubes
. Use a portable GFCI (Ground Fault Circuit Interrupter) when working with power tools and cords.
. Do not climb on the shelter or framing during or after construction.
. Do not occupy the shelter during high winds, tornadoes, or hurricanes.
. Provide adequate ventilation if the structure is enclosed.
. Do not store hazardous materials in the shelter.
. Provide proper ingress and egress to prevent entrapment.
ANCHORING INSTRUCTIONS
Prior to assembling this shelter, please read the MUST READ document included with the shipment.
WARNING: The anchor assembly is an integral part of the shelter construction. Improper anchoring may
cause shelter instability and failure of the structure. Failing to anchor the shelter properly will void the
manufacturer’s warranty and may cause serious injury and damage.
LOCATION
Choosing the proper location is an important step before you begin to assemble the structure.
The following suggestions and precautions will help you determine whether your selected location is the best
location.
. Never erect the structure under power lines.
. Identify whether underground cables and pipes are present before preparing the site or anchoring the
structure.
. Location should be away from structures that could cause snow to drift on or around the building
. Do not position the shelter where large loads such as snow and ice, large tree branches, or other overhead
obstacles could fall.
. Your shelter’s cover can be quickly removed and stored prior to severe weather conditions. If strong winds or
severe weather is forecast in your area, we recommend removal of cover.
SITE
After choosing a location, proper preparation of the site is essential. The following site characteristics will help
ensure the integrity of the structure.
. The support structure must be level to properly and safely erect and anchor the frame.
. Drainage: Water draining off the structure and from areas surrounding the site should drain away from the site
to prevent damage to the site, the structure, and contents of the structure.
WARNING: The individuals assembling this structure are responsible for designing and furnishing all
temporary bracing, shoring and support needed during the assembly process. For safety reasons, those who are
not familiar with recognized construction methods and techniques must seek the help of a qualified contractor.

4
Fabric Building 33’x50’x17’ Parts List
Part
Code
Description
Qty/
pcs
1
top truss for 2nd to 5th arch
4
1A
top truss for 1st and 6th arch
2
2
roof truss for 2nd to 5th arch
8
2A
roof truss for 1st and 6th arch
4
3
shoulder truss for 2nd to 5th arch
8
3A
shoulder truss for 1st and 6th arch
4
4
upright truss
12
5
purlin
35
6
connection plate for steel wire No.21,
No.21A
20
7
tensioning tube for roof cover, (5+1)
pcs/set
2 sets
8
corner base plate (left & right) for 1st
and 6th arch, installed with ratchet
4
9
interior base plate for 2nd to 5th arch,
installed with ratchet
8
10
tube clip for steel wire No.21, No.21A
40

5
11
bolt M8x60 for truss swaged end
connection
192
12
bolt M10x70 for purlin connection
42
13
end plug (Φ32) for tensioning tube
No.7
4
14
belt for ratchet on base plate
12
15
rope for roof cover, 4 bundles
1 pack
16
roof cover
1
17
duct tape
3
18
expansion bolt
48
19
steel wire turnbuckle
20
20
steel wire clamp
40
21
steel wire
8
21A
steel wire
12
22
square tube post on the lower left
side of the front and back door
2
23
square tube post on the lower right
side of the front and back door
2
24
square tube post on the upper left
side of the front and back door
2
25
square tube post on the upper right
side of the front and back door
2
26
connection plate for square tube post
No.22, 23, 24, 25
4+4

6
27
cross beam for front and back
door,2pcs/set
2 sets
28
vertical tube for door beam No.27
2
29
upper rail for front and back wall
4
30
lower rail for front and back wall
4
31
door winch bracket
2
32
support tube for winch bracket
2
33
pole for door opening
1
34
door bracing tube 2pcs/set
6 sets
35
bottom bracing tube with hole
2pcs/set
2 sets
36
bolt M10x30 for rail and connection
plate
28
37
bolt M10x50 for post and truss
8
38
bolt M6x40 for door bracing tube
No.34, No.35
8
39
bolt M12x130 for square tube post
No.22, 23, 24, 25
20
40
bolt M10x70 for square tube post
No.22, 23, 24, 25
18
41
rope for front and back cover,5
bundles
2 packs
42
cable tie for fixing front and back
cover
100
43
expansion bolt
16
44
steel wire for front and back door
2
bundles

7
45
steel wire clamp
8
46
door winch
2
47
front and back cover
2

8
INSTALLATION PROCESS
A—BASE PLATES INSTALLATION
Please refer to the below diagram to mark the position of base plate.
The measurement is from center to center of base plates. Referring to the diagram and confirm the
place of base plates. ENSURE THAT THE FOUNDATION IS SQUARE.
Note: The expansion bolt (No.18, No.43) applies for fixing base plate on concrete ground.

9
B—FRAME INSTALLATION
First & Sixth Arch and Front & Back Wall
1. Find Trusses (No.1A, 2A, 3A, 4) for first and sixth arch and connect them by bolt M8x60 (No.11).
2. Find relative parts of posts and rails for front and back wall and assemble them according to the
below diagram.

10
Second Arch to Fifth Arch Installation
3. Find Trusses (No.1, 2, 3 and 4) for second to fifth arch and connect them by bolt M8x60 (No.11).

11
Purlin and Steel Wire Installation
4. Lift the assembled arches onto base plates (No.8 and No.9) and connect them by bolt M8x60
(No.11).
5. When finish installing the first and second arches, install purlin (No.5) and connect them by bolt
M10x70 (No.12). Then the third arch and purlins. In this turn, one arch and then purlin tubes until
the sixth arch.
6. Install steel wires (No.21 & No.21A) between arches by steel wire turnbuckle (No.19), steel wire
clamp (No.20), connection plate (No.6) and tube clip (No.10).
7. Wrap every truss joint by duct tape (No.17) to protect roof cover.

12
C-INSTALLING COVER
Front & Back Cover and Winch Door Installation
Install the winch door refer to the diagram bellow.
Winch Door Installation

13
1. Install the front door frame and door winch bracket
2. Fix the winch to the bracket. Make sure the winch handle faces the outside. Refer to Figure 1.

14
3. Take out the door curtain cloth and lay it on the ground. Pay attention to the direction. The side with
pipe pockets faces inward.
4. Connect the door bracing tube (2pcs/set) with M6x40 bolt.
5. Thread the door bracing tube into the pocket from top to bottom. Pay attention to the bottom
bracing tube. There are holes on both sides for fixing steel wire rope. Refer to Figure 2.

15
6. Put the steel wire rope through the pulley on the door frame as shown in Figure 3, so that the steel
wire rope is located on the inner side of the door frame and on the same plane as the pulley, and then
the steel wire rope sags naturally. Keep the length of both sides equal, and naturally sag to the ground.
7. Fix each end of steel wire rope to the hole on bottom bracing tube with steel wire clamps. Make
sure fix it firmly.
8. Put the door bracing tube into the track from the gap at the bottom,from top to bottom.

16
9. Adjust the length of the steel wire rope to be equal on both sides.Fix the wire rope fold to the hole in
the winch. Refer to Figure 4.
4

17
10. Turn the winch clockwise to lift the door curtain cloth and bracing tubes to a position about
40-50cm away from the cross beam. Lace the eyelets on the cloth to cross beam with a rope. Refer to
Figure 5.

18
11. Now the winch door installation is completed.Turn the winch clockwise to raise and
counterclockwise to lower the door. The steel wire rope shall be evenly wound on the winch so that the
door can rise and fall smoothly.

19
Front & back Cover Installation
Install front & back cover (No.47) to the first and sixth arch and posts and rails on front and back wall
with rope (No.41) and cable tie (No.42).
Roof Cover Installation
NOTE: DO NOT install the cover onto the frame of your building in high wind conditions. A slight breeze
is the most advantageous for cover installation. To take advantage of the breeze, pull the cover up over
the arches with the breeze blowing in the cover like a sail filled with air.
1. Roll out the roof cover on a ground sheet. Align the cover evenly to each end of the frame. Be sure
doing not over pull the end of roof cover.
2. Pull the roof cover over frame EVENLY, CAREFULLY AND SLOWLY. Insert tensioning tube (No.7) into
the pipe pockets. Cut a small opening over against every base plate. Put the belt (No.14) around
tensioning tube and go through ratchet on base plate and loosely secure. DO NOT TIGHTEN. Adjust
the cover so that it is square and evenly centered on the frame.
Note: The end flaps must overhang evenly at both ends.
3. Use Rope (No.15) to tighten roof cover to end arches.
4. When roof cover is tidy and ready, drive the ratchet tie down forth and back and then roof cover is
tightened in the vertical direction.
5. Tidy the cover. Pull the strap inside the end of roof cover, make the cover well fold to end arches
and fasten the strap with ratchet.

20
Now your assembly is completed.
