STRATOS SCP8412BKLL Manual

Page 1 of 8
Roof-Mounted Fan
Installation Instructions & User Manual
&
SKU: SCP8412BKLL
SKU: SCP8448BKLL
CONTACT:
Phone: [phone]
Email: [e-mail]
Website: stratosclimate.com
Mail: 809 110th St, Arlington, TX 76011

Page 2 of 8
PARTS LIST
Ref. Qty. Part Description
A 1 Dome
B 1 Base
C1 1 Roof Adapter
C2 1 Roof Adapter
D 1 Control Panel
E 4 Vents
F 1 Convoluted Tubing
G 1 Wiring Harness
H 1 Main Mounting Hole Template
Hardware
J 10 Cable Ties
K 4 #8 x 1” Phillips Pan HD Screw
L 10 #8 x 5/8” Phillips Pan HD Screw
M 4 #8 x 3/4” Phillips Pan HD Screw
P 4 #8 x 3/4” Phillips Oval HD Screw
R 1 Harness Adapter
S Adhesive Tie Mount
SUGGESTED TOOLS
• Variable Speed Jig Saw
• 11 to 14 TPI Saw Blade
• Sawhorses
• Drill Motor
• Drill Bit Size: (3/8”)
• Marker or Pencil
• Tape Measure
• 7/16” Wrench
• 7/16” Socket
• Phillips HD Screwdriver
• Deburring Tool
• Cable Tie Cutter
IMPORTANT SAFETY INFORMATION
The 12v version of this product is made to be
used on 12-volt gas-powered vehicles only. Do
not attempt to hookup the 12v Fan to a non-12
volt vehicle as damage to the unit may occur.
Only operate the fan while the unit is securely
installed on the vehicle.
Do not block fan’s air intake around the dome
and maintain at least a 3” clearance.
Do not operate this product in the rain.
Do not operate fan with an enclosure covering
the dome.
Possibility of personal injury when working on
high voltage electrical circuitry and batteries.
Use best safe practices and remove jewelry
before hooking up to the battery to make sure
that metal jewelry such as bracelets and rings
do not come in contact with battery terminals
and cause shorting.
Shorting across battery terminals may cause
explosion.
FEATURES OVERVIEW
Electronic Eyes (48v only):
Prevent unnecessary battery drain as the fan
only operates when passengers are detected.
Airflow Control Knob:
From a gentle breeze to a powerful blast of
refreshing air.
Energy Management:
Using soft start technology, this product
prevents the excessive drain of traditional
electric fans.
360° Rotating Vents:
Direct the air precisely where you need it. You
can also close the vents completely to keep
cold air out.

Page 3 of 8
A
B
D
E
H
C1
C2
G
R
K L M
JP
S
F
ROOF-MOUNTED FAN
HOLE TEMPLATE
1. LOOK FOR THE FLATTEST AREA ON ROOF CLOSEST TO CENTER.
2. MAKE CROSS-MARK AT CENTER POINT OF INSTALL LOCATION.
3. REMOVE ADHESIVE BACKING AND ALIGN YOUR MARK WITH ALIGNMENT HOLE.
4. DRILL 3/8“ STARTER HOLE ON INNER EDGE OF TEMPLATE.
5. USE JIG SAW ON LOW-SPEED TO CUT AROUND OUTSIDE TEMPLATE EDGE.
6. CLEAN UP EDGES WITH DEBURRING TOOL OR SANDPAPER AS NEEDED.
INSTRUCTIONS
9.53mm (3/8”)
ALIGNMENT HOLE
CUT OUTSIDE EDGE
WITH 11 TO 14 TPI BLADE
AT LOW-SPEED
STARTER HOLE
6.35mm (.25”)
PARTS DIAGRAM

Page 4 of 8
INSTALLATION INSTRUCTIONS
Roof Modifications
1. Remove the roof and place it onto sawhorses
with the top side facing up.
2. Determine preferred install location by
centering the unit and adjusting on all sides
to clear any roof contours.
Note: Look for the flattest area on the roof while
also considering fan control location for ease-of-use.
3. Make a crossmark at center point of install
location.
4. Remove the adhesive backing of Main
Mounting Hole Template (H) and align so
that your mark is centered in the template
alignment hole. (Figure 1)
FIGURE 1
5. Drill a 3/8” diameter hole on the inner edge
of the template. This will be your starter hole
for the saw blade.
6. Using a jig saw on a low-speed setting, begin
cutting around the outside of the template
edge. Carefully cut all the way around, then
clean up the hole edges with a deburring tool
or sandpaper as needed.
Fan Installation
7. Remove adhesive backing and place Roof
Adapter (C1) into main mounting hole, taking
care to center within the hole and align with
roof. Secure with screw (M) in four places.
(Figure 3)
FIGURE 3
8. Remove the adhesive backing and secure the
base (B) using screw (L) in 10 places. (Figure 4)
FIGURE 4
9. Secure dome (A) using screw (K) in 4 places.
(Figure 5)

Page 5 of 8
FIGURE 5
10. Flip the roof over so the underside faces up.
11. Set Roof Adapter (C2) onto the base. Install
the Control Panel (D) to the Base while
plugging in all connectors to the matching
color marked holes. Begin with either the far
left or far right connector and work your way
to the opposite end. (Figure 6)
Note: While lowering the control panel, ensure
no wire interference with the vent mount holes.
FIGURE 6
12. Secure the control panel to the Base, through
Adapter (C2), using screw (P) in 4 places.
Insert the four vents (E) into the control
panel by pressing down and snapping into
place. (Figure 7)
FIGURE 7
13. Reinstall the roof onto the vehicle.
Wiring Harness/Switched Power Connection
14. Run the Wiring Harness from the fan unit to
the battery compartment.
15. 48V vehicle: To correctly power the fan,
attach the Wiring Harness red wire to the 48V
output terminal having a red wire leading
away from the battery pack, and the black
wire to the 48V ground output terminal
having a black wire leading away from the
battery pack. Refer to your vehicle owner’s
manual to help determine correct battery
terminal connections if needed.
12V vehicle: Connect the red wiring harness
cable to the positive battery terminal and the
black wiring harness cable to the 12V negative
battery terminal. (Figure 8)
FIGURE 8

Page 6 of 8
16. This step will vary depending on your vehicle
model. Locate a switched power connection
and connect using the Harness Adapter (R).
(Figure 9). This is commonly located on a
solenoid in the battery compartment or a
designated accessory terminal behind the
dash. Refer to your vehicle owner’s manual
to determine ideal switched power hook-up
location.
FIGURE 9
Finalize Installation
17. Connect the power cable to the Wiring
Harness (G) power connector and check
system operation.
18. Cover exposed wiring at fan connector with
convoluted tubing (F).
19. Secure harness to vehicle frame using cable
ties (J). Secure harness to roof using adhesive
tie mounts (S). (Figure 10)
FIGURE 10
20. Secure fuse, relay, and dress wires in battery
compartment with cable ties.

Page 7 of 8
4 x 360° Air Vents
Ultra Bright
LED Lighting
Ultra Bright
LED Lighting
4 x Brushless Fans
Electronic Eyes
LED Indicator Fan Speed
Control Knob
OPERATING GUIDE
Electronic Eyes (48v only)
The fan is equipped with two pairs of fans that
operate independently based on Electronic
Eye detection of occupants. When the driver is
present, only the driver-side fans will engage,
which is the same for the passenger side.
Battery Fail-Safe Sensor
5-Mode Fan Speed Control Knob
To power on the fan, turn on the key switch
and then turn the Fan Speed Control knob from
the off position to the desired mode. The LED
Indicator will light up when the fan is powered
on.
1 - Off
2 - Low Speed
3 - Medium Speed
4 - High Speed
5 - Turbo Mode*
* When Turbo Mode is engaged, all four fans will
spin at maximum speed regardless of electronic
eye detection (48v only).
Ultra-Bright LED lighting
Can be toggled on and off by pressing the square
button located between the LEDs. Only the key
switch needs to be on for the lights to function.
TROUBLESHOOTING
Problem: Unit will not power on.
Cause 1: The fan needs to be reset.
Solution: Reset the fan by turning key switch
to the off position while ensuring the fan is set
to mode 1 (off). Once both are off, turn the key
switch on first, then power on the fan.
Cause 2: Inadequate power connection.
Solution: Ensure proper harness connections,
including the power connector, harness adapter,
and switched power connection.
Cause 3: Inadequate battery connection.
Solution: Check battery terminals to ensure
a clean, proper connection to the positive and
negative terminals.
Cause 4: Improper switched power connection.
Solution: Using a volt/ohm meter, ensure a proper
12v (or 48v) connection when key is turned off/on.
Cause 5: Battery fail-safe sensor
Solution: Recharge the batteries. The fail-safe
sensor will automatically shut the fan off when
battery voltage drops below a preset threshold.
Problem: Electronic Eyes will not power off the
fans.
Solution: Ensure there are no objects in path of
the Electronic Eye beam. Any objects left on or
around the seat could fool the fan into thinking a
passenger is present.

Page 8 of 8
ROOF-MOUNTED FAN TWO-YEAR
LIMITED WARRANTY
TSI Products, Inc./Stratos Climate are
warranted to the original retail purchaser,
to be free from defects in materials and
workmanship except as otherwise provided
herein. This warranty is not transferrable
and is effective from the date of the
original purchase.
This Warranty Covers:
1. During the first year from the original
retail purchase date, TSI Products/
Stratos Climate will, at its option,
repair or replace defective components,
including labor and cost of shipment to
original consumer.
2. After the first year from original
retail purchase date, up to the term
of the warranty, TSI Products/Stratos
Climate will repair or replace defective
components with an identical or
reasonably equivalent new component
for a $5.00 service charge which includes
labor and cost of shipment to the
original consumer.
This Warranty Does Not Cover:
1. Cost of shipping the product to TSI
Products/Stratos Climate.
2. Normal wear, scratches or fading of the
product.
3. Damage caused by abuse, misuse,
neglecting to follow use procedures,
failure to follow installation procedures
or product modifications made by
consumer.
4. Damage to home or vehicle electrical
system or components caused by
inadequate wiring to the product plug-
in point.
5. Damage to any object placed close to
the air output of the heater.
6. Damage caused by dropping of heater.
7. Product sold outside the USA.
8. Consequential damages, incidental
damages or expenses, including
damages to property. Some states do
not allow the exclusion or limitation of
incidental or consequential damages, so
above limitation or exclusion may not
apply to you.
Procedures for Warranty service:
1. Contact TSI Products/Stratos Climate
(844-233-4121) for a return authorization
number. Write this number on the
carton being returned to TSI Products/
Stratos Climate.
2. Attach, to the product itself, a tag
showing your name, address, phone
number, description of the problem
and proof of retail purchase date.
Enclose a cashier’s check, check, Visa or
MasterCard information or money order
for applicable service charges.
3. Package the product carefully to ensure
that no damage occurs during return
shipment. Return the product, postage
prepaid, to TSI Products/Stratos Climate.
Implied Warranty:
This warranty is limited to the provisions
clearly stated herein. Any implied
warranties, warranties of merchantability,
warranties of fitness for a particular use are
excluded.
If any provision of this warranty is
prohibited by federal, state, or local law,
that provision shall not be applicable.
