Uni-P Dry EpiFresh 550 Operation manual

Uni-P EpiFresh 550 AIR MOVERS
Installation, Operation & Service Instructions
Add: 4240 Latham Street, Suite D, Riverside, CA 92501
Tel: [phone]
E-mail: [e-mail]
READ AND SAVE THESE INSTRUCTIONS

Tel: [phone] Tel: [phone]
12
Uni-P EpiFresh 550 AIR MOVERS Installation, Operation & Service Instructions Uni-P EpiFresh 550 AIR MOVERS Installation, Operation & Service Instructions
Please note that the EpiFresh 550 should only be used with parts approved by Unipdry. The use of
unauthorized parts or alterations to the machine could void your warranty. Contact an approved
distributor for further assistance.
Unit must be electrically ground.
Insert 3-prong plug directly into outlet with Ground Fault Circuit Interrupting device.
Do not use an adapter with this unit.
Do not use the unit in standing water.
If electrical parts get wet, they must be dried prior to use.
INTRODUCTION
The Unip EpiFresh 550 is a convenient filtration system that cleans the air. The 550 uses an
effective blend of air flow and advanced filtration to expel airborne particles like mold spores,
dust, pollen, and pet dander. TheEpiFresh is ideal for for restoration jobs, including water,
sewage, and fire.
Safety Notes
To Avoid the Risk of Fire or Electric Shock:
Identification
How it works
Special Features
Congratulations on purchasing a Unip EplFresh 550 air scrubber. In order to take
advantage of the warranty plan, be sure to note the serial number and date of purchase.
1. When set to maxiumum airflow, the 550 draws air through two types of filters- a pre-filter
and a HEPA filter.
2. The first phase of filtration, the prefilter, catches the large particles, while the second phase
of filtration, the HEPA filter, catches smaller particles, down to 0.3 microns.
Using the auxillary outlet on the control panel, you can link up to 3 units together, creating a
maximum airfow 550 CFM. You can also daisy-chain the machines when they are stacked
vertically (limit of 2 units).
The Unip EpiFresh 550 can be operated in the vertical postion, as well as, when stacked
vertically (up to 2 units). When storing, the machines can be stacked horizontally to
save space.
Removable Intake Panel
The Unip EpiFresh 550 is equipped with a removable panel on the intake side of the machine. The
removable panel is quite useful in remediation applications, so you can draw air out the room and
create more negative pressure (use a manometer to monitor air pressure). To use panel:
1. Lift latches to remove the panel.
2. Install the machine outside the containment area to draw air out.
3. Cut a hole in the containment plastic that is the size of the units inlet
4. Insert the inlet into plastic and seal the circumference tightly with duct tape.
Key Features

Tel: [phone] Tel: [phone]
3 4
Uni-P EpiFresh 550 AIR MOVERS Installation, Operation & Service Instructions Uni-P EpiFresh 550 AIR MOVERS Installation, Operation & Service Instructions
SET UP
1. Place the Unip EpiFresh 550 so that it is in the upright, vertical position.
2. Plua the machine into a standard 115 volt outlet. Note: Each unit needs 3 amps to operate.
3. Power the unit on and adjust the speed by turning the variable speed control. The maximum
speed is 550 CFM and the minimum speed is 270 CFM.
4. The Unip EpiFresh 550 can be operated in the vertical or horizontal postion, depending on
the exact situation. At this point, adjust the machine to the optimal position.
INSTRUCTIONS
THE CONTROL PANEL
The Variable Speed Control is used to adjust the power of the machine. Turn the knob in a
clockwise direction, to increase the speed from minimum to maximum.The minimum speed
setting is located immediately under the OFF button. You can switch to minimum speed by
turning the knob counterclockwise.
Variable Speed Control
If more air filtation is necessary for a space, you can "daisy chain" or link up to 3 Unip EpiFresh
550's to the same outlet. There is a maximum amperage of 12 when the units are turned off, a
maxium of 9 amps when the units are turned on. Other equipment can be plugged into the same
outlet as the EpiFresh as long as it doesn't go above the max amperage
Auxillary Outlet
The Circuit Breaker Switch protects the unit if there are more than 12 amps of electricity
passing the circuit. Iif this occurs, the switch will cut off the power to the unit.
Circuit Breaker Switch
CHANGE THE FILTERS
1. Loosen the 4 locks that hold the fiter board in place
2. Slide out the fiter panel board.
3.Remove the used filters and replace with new fiters.
Always wear approved protective gear when changing the filters.
Filters should be changed after each remediation job.
If the indicator light is on, always change the HEPA filter.
WARNING
In this application, the Unip EpiFresh 550 should be placed in the center of the affected area. The
air scrubber will draw in the air, filter it, then blow out the newly cleaned air. To begin the process,
simply turn on the scrubber and it will start cleaning the air. Keep in mind that if you are working in a
large area or one divided by walls, you may need several air scrubbers to effectively clean the air.
APPLICATIONS
Water Damage
The Unip EpiFresh 550, when used with the optional activated carbon filer (P/N:), is excellent at
odor control, as well. Simply place the carbon filter in the pre-filter slot and it will capture a wide
variety of odor-causing gas molecules, such as volatile organic compounds (VOC's), smoke.soot,
and paint fumes.
Odor Control
The Unip EpiFresh 550 is also useful in many other applications including mold remediation, fire
damage, dust control, and sewage remediation.
Other Uses
WARNING
When using the Unip EpiFresh 550 in a containment area, always turn off power to open combustion
appliances, such as firelaces, furnaces, water heaters, and HVAC systems, to avoid the risk of
backdrafting carbon monoxide fumes.
If the Filter Change Light illuminates during the remediation process, immediately change the
HEPA filter
Breathing Hazard
Tipping Hazard
Use caution when stacking units,
Do not stack more than 2 units on top of each other
Falling equipment could cause bodily harm.

Tel: [phone] Tel: [phone]
5 6
Uni-P EpiFresh 550 AIR MOVERS Installation, Operation & Service Instructions Uni-P EpiFresh 550 AIR MOVERS Installation, Operation & Service Instructions
Unipdry Warranty Steps:
1. Once receive the goods, customers must log in www.alorair.com to fill out the warranty registration form and submit to
Unipdry company. We will receive your purchasing and installation information and save it. If no warranty registration is
sent to us, warranty period will begin the day the shipment left the warehouse. Please be sure to record serial # and date
of installation. You will need this information to receive the RA number.
2. If warranty service is necessary, customers must contact Unipdry Tech Support by [e-mail] or local technical
service phone to receive a Return Authorization (RA number). Once an RA has been issued, customers should bring the
unit to a certified repair center. Unipdry will arrange the shipping to bring the unit back to the warehouse (at the Unipdry
expense of the customers) if customers are not available.
3. After the unit has been received by (whether at a repair center or the warehouse), will have an initial Unipdry Unipdry
inspection. If it is determined to be invalid warranty claim (see exclusions below), customers have to pay for all associated
repair costs and shipping costs for units repair.
4. Customers can pick up the unit after repair at their own expense for shipping. Units will have a rigorous testing before
sending it back to customers
5. If the unit can no longer be fixed , and it is in the warranty period and determined to be valid claim, we will ship the
customer a new unit within the same year warranty from the date of replacement.
6. After parts are repaired or replaced by , the original warranty period continues to applies until meet its deadline. Unipdry
No extensions to the original warranty period.
Unipdry
Unipdry
Unipdry's
Unipdry
Unipdry
Always unplug the unit prior to performing any maintenance.
Check the power cord for damage (fraying, cuts, etc.) before use.
Verify that the GFCI outlet is working by powering on the machine and pressing the red GFCI
test button. If the outlet is working, the "reset" button will pop up. To operate, press the reset
button again.
To avoid electric shock, never use a water hose or pressure washer to clean the electrical
Components.
Check the pre-filter prior to operating the machine to ensure it is not clogged. If there is
anyir fow tilton change the fifter.
Make sure the unit is dry prior to installing clean flters.
When using the EpiFresh for remediation purposes, replace both filters at the same time
and always clean machine in between jobs. This will help prevent cross contamination.
Safety Notes
Warranty

N
Black
Black
Wind pressure switch
Relay
Relay
CHANGE
HEPA FILTER
PCB
Blue
Black
Brown
Black
12 AMP
CIRCUIT
BREAKER
WHITE
HOT
Green
Green
Green
POWR
White
White
LINE
LINE
LODE
GFCI
LOAD
GND
GND
FAN MOTOR
25UF
TRANSFORMER
L--IN
NL
L-OUT
N
110-120V/60Hz
Tel: [phone]
Wiring Diagram
7
