Strobel VEB100-6 4 User manual

For the professional user
Für den professionellen Anwender
Betriebsanleitung
Class:
Klasse:
Model:
Ausführung:
Dated:
Stand:
VEB100-6
4
Operang Instrucons
Spezialmaschinen GmbH

Im Zeichen der Qualität
ou nd the Strobel trademark on every Strobel
machine leaving our works. And with good reason.
This symbol is a guarantee of the high quality of
our products. Quality which creates trust – trust
in our technology, our service and, not least of all,
in our good name.
ie nden die Strobel-Schutzmarke auf jeder
Strobel-Maschine, die unser Werk verlässt.
Und das aus gutem Grund. Denn dieses Zeichen
garanert Ihnen die hohe Qualität unserer
Produkte. Qualität, die Vertrauen scha – in unsere
Technik, unseren Service und nicht zuletzt in unseren
guten Namen.
S
Y
The sign of quality

trobel clients know that they can expect a parcularly high
standard of performance from our company and our machines.
Now you have seled for one of our products. For us this is a
source of encouragement and of obligaon to Jusfy your trust.
If you wish to prot from the performance and eciency of your
Strobel machine as long as possible, exact handling and tho-
rough care is necessary. For this reason we kindly request that
you read the operang instrucons closely.
It provides all the informaon you need for trouble free
operaon.
And if you do happen to need a spare part the enclosed spare
parts list gives a complete overview. It is clearly
classied according to components so that you can nd the
required part quickly and easily. In order to avoid errors we
request you to quote machine class, machine number and part
number completely on your spare part order.
We wish you lots of success in your work with your new Strobel
machine.
S
A decision with future
Spezialmaschinen GmbH

Garantiekarte/Warranty Sheet
Boschstraße 16
D-82178 Puchheim
Tel.: [phone]
Fax: [phone]
[email protected]
Maschinenklasse/Machine class:
Serien-Nr./Serial No:
Auftrags-Nr./Order Confirmation No:
Lieferdatum/Delivery Date:
Rechnungs-Nr./Invoice No:
Rechnungsdatum/Invoice Date:
Beanstandung/Complaint:
Datum/Date Unterschrift/Signature:
Bitte nicht vom Kunden ausfüllen/To be filled out by Strobel:
Datum
Bemerkung
EXA:
ETA:
PROD:
EXA:
BH:

1 BA_VEB100-6_A4_230102_en.doc
Operating instructions
STROBEL-Class VEB100-6
T a b l e o f C o n t e n t s
1General safety instructions ........................................................................................................ 3
2General ....................................................................................................................................... 5
2.1 Operating instructions ...................................................................................................... 5
2.2 Class description, serial number and initial basis for description .................................... 5
2.3 Range of application and intended use ............................................................................ 5
2.4 Power supply..................................................................................................................... 5
2.4.1 General notes...................................................................................................... 5
2.5 Technical data ................................................................................................................... 6
3Installation and putting into service .......................................................................................... 8
3.1 Unpacking.......................................................................................................................... 8
3.2 Installation (Fig. 1 and Fig. 7) ............................................................................................ 8
3.3 Sense of rotation............................................................................................................. 10
3.4 Motor drive via Toothed belts ........................................................................................ 10
3.4.1 Toothed belt tension (Fig. 2) ............................................................................ 10
3.4.2 Positions (Fig. 3, Fig. 4 und Fig. 5)..................................................................... 11
4Machine operation ................................................................................................................... 13
4.1 Needles, threads and tapes ............................................................................................ 13
4.2 Inserting the needle (Fig. 6)............................................................................................ 13
4.3 Threading and thread course (Fig. 7).............................................................................. 14
4.4 Thread tension (Fig. 7) .................................................................................................... 15
4.5 Tape course, inserting the tape and tape exchange ...................................................... 15
4.5.1 Tape course (Fig. 8 and Fig. 9) .......................................................................... 15
4.5.2 Inserting the tape (Fig. 10) ............................................................................... 17
4.5.3 Tape exchange (Fig. 10) .................................................................................... 18
4.6 Stitch depth regulation ................................................................................................... 18
4.6.1 General.............................................................................................................. 18
4.6.2 Setting the stitch depth (Fig. 9) ........................................................................ 18
4.7 Plunger limit stop............................................................................................................ 19
4.7.1 General (Fig. 11)................................................................................................ 19
4.7.2 Setting the plunger limit stop for sewing over cross seams (Fig. 11) ............. 20
4.7.3 Setting the automatic plunger (Fig. 12)............................................................ 20
4.8 Material feed................................................................................................................... 21
4.8.1 General.............................................................................................................. 21
4.8.2 Setting the stitch length (Fig. 9) ....................................................................... 21
4.8.3 Setting the feed dog ......................................................................................... 21
4.9 Skip stitch ........................................................................................................................ 22
4.9.1 General.............................................................................................................. 22
4.9.2 Actuating and adjusting the interval ................................................................ 22

2 BA_VEB100-6_A4_230102_en.doc
5Operating the machine............................................................................................................. 23
5.1 General............................................................................................................................ 23
5.2 Switching on.................................................................................................................... 23
5.3 Placing and removing the material - handling................................................................ 23
5.4 Operating modes ............................................................................................................ 24
5.4.1 General.............................................................................................................. 24
5.4.2 “Sewing with tape“ and without “Stitch counting with tape“ (Fig. 10) ........... 24
5.4.3 “Sewing with tape“ and with “Stitch counting with tape“ (Fig. 10)................ 24
5.4.4 “Sewing without tape“ and without “Stitch counting without tape“ (Fig. 10) 25
5.4.5 “Sewing without tape“ and with “Stitch counting without tape“ (Fig. 10) ..... 25
5.4.6 “Sewing with tape“ and “Sewing without tape“ alternating (Fig. 10) ............ 25
6Operating and function of the control..................................................................................... 26
6.1 General............................................................................................................................ 26
6.2 Switchable button functions........................................................................................... 27
6.2.1 General.............................................................................................................. 27
6.2.2 Assignment of the switchable button functions on the operating control V810
........................................................................................................................... 27
6.2.3 Sewing with tape .............................................................................................. 27
6.2.4 Open tape clamp............................................................................................... 29
6.2.5 Tape feed on ..................................................................................................... 30
6.3 Programming at technician or supplier level.................................................................. 31
6.3.1 General.............................................................................................................. 31
6.3.2 Programming the code number ....................................................................... 31
6.3.3 Calling up and changing parameters directly ................................................... 33
6.4 Sewing with tape............................................................................................................. 34
6.4.1 Sew-up stitches, stitch end............................................................................... 34
6.4.2 Tape clamp........................................................................................................ 34
6.4.3 Tape cutter........................................................................................................ 35
6.4.4 Tape feed .......................................................................................................... 35
6.5 Stitch count ..................................................................................................................... 40
6.5.1 General.............................................................................................................. 40
6.5.2 Stitch count without tape ................................................................................. 41
6.5.3 Stitch count with tape ...................................................................................... 42
6.6 Problems during sewing and possible solutions............................................................. 43
7Machine maintenance.............................................................................................................. 46
7.1 General............................................................................................................................ 46
8Variable sewing tools ............................................................................................................... 46
9Optional extras ......................................................................................................................... 48
9.1 Digital display 392.0637.................................................................................................. 48
Subject to change without prior notice

3 BA_VEB100-6_A4_230102_en.doc
1General safety instructions
Manuals and additional information can be found on the STROBEL website at:
http://www.strobel.biz
Every person in charge of setting up, operating, servicing and repairing the machine
must first read and understand the operating instructions and particularly the safety
instructions before starting up the machine.
Failure to comply with the following safety instructions can lead to physical injuries
or damage to the machine.
1. The machine must only be operated by persons familiar with the relevant
operating instructions and who have been instructed accordingly.
2. Before commissioning also read the notes on safety and the operating
instructions of the sewing drive manufacturer.
3. Only use the machine in the intended manner and never without the provided
guards. Always observe the pertinent safety regulations.
4. Switch off the main switch or pull the power plug for threading, changing the
bobbin, exchanging sewing tools such as needle, hook, stitch plate, transport
devices, trimming knive and cutting block, for cleaning and when leaving the
workplace as well as for maintenance.
5. General maintenance tasks may be carried out only by properly trained persons
in accordance with the operating instructions.
6. Repair work, retrofitting and maintenance may be carried out only by
technicians or specially trained personnel.
7. When servicing or repairing pneumatic equipment, the machine must be
disconnected from the pneumatic supply. Exceptions are only allowed for
adjustment work and tests of functionality performed by specially trained
technicians.
8. Only specially qualified technicians may work on the electrical equipment.
9. It is forbidden to work on electrically live components! Exemptions are covered
by the EN50110 (DIN VDE0105) regulations.
10. Any retrofitting or alterations to the machine may only be performed under
strict compliance with all pertinent safety regulations.
11. Only use our approved spare parts when servicing and/or repairing the machine.
12. It is forbidden to operate the sewing head until it is determined that the entire
sewing unit complies with EU provisions.

4 BA_VEB100-6_A4_230102_en.doc
13. It is essential that you observe and follow these instructions as well as the
generally valid safety regulations.
14. Warning instructions given in the operating instructions that pertain to
especially dangerous parts of the machine must be indicated at these positions
using a safety symbol.
Warning instructions given in the operating instructions that pertain to special
injury hazards for operating personnel or technicians must be indicated at these
positions using a safety symbol.

5 BA_VEB100-6_A4_230102_en.doc
2General
2.1 Operating instructions
Any person involved in the installation, operation, maintenance and repair of the
machine must have read and understood the operating instructions and mainly the
safety instructions before starting the machine.
2.2 Class description, serial number and initial basis for description
Für seitenbezogene Beschreibung ist die Bedienungsseite der Maschine die
Ausgangsbasis.
The class identification (type) as well as serial and model number (after the dash) are
located on the frontside of the housing.
2.3 Range of application and intended use
For blindstitching a tape coated on one side for example to front parts of sack coats or
for attaching facings.
After switching the function “Sewing with tape“ off, the machine is also ready for use
for other sewing tasks.
2.4 Power supply
2.4.1 General notes
C A U T I O N !
Work on the sewing machine's electrical equipment or sewing
drive may only be done by electricians!
There is the D A N G E R of a fatal electrical shock.
When working on the electrical equipment, the machine with
the S1 power switch has to be switched off and the power plug
pulled out!
The operating instructions (including safety instructions) of the
sewing machine and sewing drive must be observed!

6 BA_VEB100-6_A4_230102_en.doc
2.5 Technical data
Empfohlene Nennstichzahl /
Recommended rated speed
1800 min-1
Stichlänge / stitch length
3,0 - 7,0 mm (abhängig vom Nähmaterial /
depend on fabric) Auslieferzustand /
delivery condition 7,0 mm
Obertransport / top feed
Sägeverzahnung / saw thoothing
Pyramidenverzahnung / pyramid thoothing
optional
gefederter Drücker / spring loaded plunger
Drückervariation optional /plunger variation
optional
Stichplattenöffnung / needle plate opening
6,0 mm
Stichtiefenanzeige / stitch depth display
digital display optional
Intervall mit Stichtiefenregulierung /
skip stitch with depth regulation
1:2
Nadelsystem / needle system
Nadelstärke / needle size
GROZ-BECKERT
1669 EEO 90/14
Fadenabschneider / thread trimmer
Fadenspannung / thread tension
Faden / thread
Auslieferzustand / delivery condition 6 cN
Polyester, endlos gezwirnt /
polyester continuous filament 120/2
Automatische Bandeinführung und
Bandschere / automatic tape feeding
and cutting device
Bandführung / tape guide
15 - 25 mm einstellbar / adjustable
Auslieferzustand für 15 mm Bandbreite /
delivery condition for 15 mm tape size
Einblasdüse / tubes
bis 25 mm optional
Auslieferzustand 15 mm /
delivery condition 15 mm
Nahtlängenprogrammierung bis 254 Stiche /
programable seam length up to 254 stitches
Durchgangsraum / arm space
150 mm
LED Leuchte / LED sewing lamp

7 BA_VEB100-6_A4_230102_en.doc
Technischer Auslieferzustand / delivery condition:
Motor-Leistung min. / min. motor power
550 W
Zahnriemenscheibe Maschine /
toothed belt pulley/machine
Z = 38
Zahnriemenprofil / toothed belt profile
HTD 5M-9
Stichart / stitch type
Einfaden-Kettenstich-Blindstich Typ 103 /
single thread chain stitch type 103
Anschluss pneumatisch / pneumatic connection
6 bar
Luftverbrauch, Mittelwert /
avarage air consumption
95 l / h
Stellfläche / foot print
0,5 m x 1,1 m
Arbeitsgeräusch / operating noise at 2200 min-1
nach DIN 45635-48-1 KL3
LpAm 71 dB(A)

8 BA_VEB100-6_A4_230102_en.doc
3Installation and putting into service
3.1 Unpacking
Strobel machines are supplied either as complete units with head, stand and motor, or
head with motor only, or the head only.
Due to the high weight and to avoid damages during transport, complete units are
packed in several smaller cartons.
Machine head is removed from the stand. Reel stand, rods and other accessories are
packed into the stand packing.
Make sure that all accessories have been unpacked before throwing away any packing
material.
3.2 Installation (Fig. 1 and Fig. 7)
C A U T I O N ! Danger of Injury!
Danger of bodily injuries or finger bruises through pulling in of
garments or hairs!
The machine may not be operated without belt guards for head
and motor.
The tape feeding device is mounted to the machine head according to Fig. 7 (screw
(2)). The pneumatic devices are connected according to the given numbers. The 3-pole
diode plug is connected to the 3-pole diode socket at the machine.
Make sure that all screws on the stand are tight and retighten them, if necessary.
A T T E N T I O N !
Before putting the machine into service make sure that the
electric connecting data on the sewing drive’s name plate,
mainly voltage and frequency, correspond to your electric
network.
A T T E N T I O N !
The maintenance instructions according to the operating
instructions must be followed!

9 BA_VEB100-6_A4_230102_en.doc
Fig. 1

10 BA_VEB100-6_A4_230102_en.doc
3.3 Sense of rotation
The correct sense of rotation of the handwheel is clockwise (clockwise rotation).
3.4 Motor drive via Toothed belts
3.4.1 Toothed belt tension (Fig. 2)
C A U T I O N ! Danger of Injury!
When checking the belt tension, switch off the machine at the
mains. Do not operate the machine without the belt guard.
Otherwise there is a D A N G E R of crushing fingers, of
injuries to the body and of pulling in parts of clothing.
The machine may not be operated without belt guards for
motor.
The toothed belt should not be too tight. It should give about 5 mm when slightly
pressing with the thumb.
Too little or too tight toothed belt tensioning can impair the positioning of the
machine and therefore impair the function sequence.
Tensioning the toothed belt (Fig. 2):
Release the upper and the bottom retaining screw (1), (2) at the upper part of the
machine.
Pull out the motor slightly and tighten the bottom retaining screw (2) slightly.
Tension the toothed belt by swivelling the motor.
Tighten the upper and the bottom retaining screw (1), (2) again.
Fig. 2

11 BA_VEB100-6_A4_230102_en.doc
3.4.2 Positions (Fig. 3, Fig. 4 und Fig. 5)
C A U T I O N ! Danger of Injury!
Danger of pulling in parts of clothing and of hair and danger of
crushing fingers and stitching fingers with needles!
When checking positions with switched-on machine keep fingers
and hands away from moving parts.
The machine requires a needle position and depending on the sewing drive, possibly
also a reference position.
Reference position (Fig. 3):
The reference position must be set in such a way, that the point of the needle in
direction of the insertion stitch closes with the right (inner) edge of the needle
slide plate.
Fig. 3

12 BA_VEB100-6_A4_230102_en.doc
Needle position (with stop in and outside the seam (Fig. 4)):
The needle position must be set in such a way, that when the machine is
stopped, the hook of the thread knife catches the thread loop lying over the
looper securely without touching the looper.
Please check by manual activation of the thread trimmer afterwards.
Fig. 4
Notes for sewing drives which have two needle positions (Fig. 5):
The above mentioned needle position is position 2 at the sewing drive.
Position 1 must be set at the sewing drive in such a way, that the point of the needle
(1) in the direction of stitch exit closes with the right (inner) edge of the needle slide
plate. At the same time, the thread loop lies tensioned over the looper.
Fig. 5

13 BA_VEB100-6_A4_230102_en.doc
4Machine operation
4.1 Needles, threads and tapes
The sewing quality can be influenced to a considerable extent by choosing the most
suitable needles and threads for the material to be sewn.
It is recommended to use controlled GROZ-BECKERT needles system 1669 EEO only.
The machine is supplied with size 90/14 needles.
NOTICE: A perfect needle is of great importance for a good sewing result.
Damages of the needle point which often can be made visible under a
magnifier only may deteriorate the sewing result. Replace the needle in
time!
We recommend twisted polyester filament threads of size 120/2 respectively. Because
of their high strength and ability to slide, combined with a low volume they are to be
preferred over a spun thread.
For safety and function reasons, only common commercial coated attaching tapes
between 15 and 25 mm width should be used according to the width of the tape
device.
G u a r a n t e e d r e m a r k !
This machine has been set and sewn off with genuine GROZ-
BECKERT needles.
No guarantee can be granted if the settings are modified for
using different needle types.
4.2 Inserting the needle (Fig. 6)
C A U T I O N ! Danger of Injury!
Before replacing the needle, switch off the machine electrically,
and depress the motor switch pedal to make sure that the
machine is truly switched off.
Otherwise there is a danger of injury from crushing and needle
punctures.
The curved needle shape determines its position in the needle lever (1). Attention
should be paid only to ensure that the needle piston is pushed to the stop in the
channel of the needle lever and that the screw (3) Fig. 6 of the needle clamping plate
(2) is tightened well.

14 BA_VEB100-6_A4_230102_en.doc
Fig. 6
4.3 Threading and thread course (Fig. 7)
C A U T I O N ! Danger of Injury!
Switch off machine electrically and confirm that the machine is
really in standstill position by operating the treadle for the motor
control before threading.
Otherwise there is a danger of injury from crushing and needle
punctures.
Fig. 7 shows the correct thread course.
Fig. 7

15 BA_VEB100-6_A4_230102_en.doc
4.4 Thread tension (Fig. 7)
Depending on thread and fabric quality, nature and thickness the thread tension is set
by tension nut (1) (Fig. 7)
4.5 Tape course, inserting the tape and tape exchange
4.5.1 Tape course (Fig. 8 and Fig. 9)
C A U T I O N ! Danger of Injury!
Keep fingers and hands away from movable parts when inserting
the tape with the machine switched on.
Otherwise there is a danger of injury from crushing and needle
punctures.
At factory the machine is set to a standard tape with of 15 mm. Modification to
another tape (optional) width is possible.
After sewing on the ribbon with blind stitch, the blind stitch gives the looseness of the
ribbon on the jacket front and after ironing, the coated upper side of the ribbon is
fixed to the facing.
Fig. 8 shows the correct tape course.
After loosening clamping lever (2) Fig. 9 and removing tape roll plate (3) the tape roll
can be pushed onto the roll (4). Then re-mount the tape roll plate (3).
PLEASE OBSERVE: The tape roll (4) should rotate easily, therefore please leave a
corresponding distance between tape roll and tape roll plate
(approx. 1 to 2 mm).

16 BA_VEB100-6_A4_230102_en.doc
Fig. 8
Fig. 9
