Strongway 56608 User manual

READ & SAVE THESE INSTRUCTIONS
Hydraulic Bead Breaker
Owner’s Manual
WARNING: Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety
precautions may result in serious personal injury.
Item #56608

Page 2 of 11
Thank you very much for choosing a Strongway™product!
For future reference, please complete the owner’s record below:
Serial Number/Lot Date Code: ________________________________
Purchase Date: ____________________________________________
Save the receipt, warranty, and this manual. It is important that you read
the entire manual to become familiar with this product before you begin
using it.
This bead breaker is designed for certain applications only. Northern
Tool and Equipment is not responsible for issues arising from
modification or improper use of this product such as an application for
which it was not designed. We strongly recommend that this product not
be modified and/or used for any application other than that for which it
was designed.
For technical questions, please call 1-800-222-5381.

Page 3 of 11
Table of Contents
Intended Use..........................................................................................................................................4
Technical Specifications......................................................................................................................4
Important Safety Information...............................................................................................................4
Specific Operation Warnings...............................................................................................................6
Assembly Instructions..........................................................................................................................6
Before Each Use....................................................................................................................................6
Operating Instructions..........................................................................................................................6
Maintenance ..........................................................................................................................................7
Parts Diagram........................................................................................................................................8
Parts List................................................................................................................................................9
Replacement Parts................................................................................................................................9
Limited Warranty.................................................................................................................................10

Page 4 of 11
Intended Use
The Strongway Hydraulic Bead Breaker is used to dismantle tires with a maximum width of 5 inches
(outdoor use only). It works on all single, two-piece, and three-piece truck tires and rims, including
agricultural wheels. For use with a 10,000 PSI hydraulic pump to quickly break beads.
Technical Specifications
Property
Specification
Length (inches)
15
Ship weight (lb.)
60
Force Rating
10,000 PSI
Dimension L x W x H (inches)
15 x 17 x 18
Important Safety Information
⚠WARNING
Read and understand all instructions. Failure to follow all instructions may result in serious injury
or property damage.
The warnings, cautions, and instructions in this manual cannot cover all possible conditions or
situations that could occur. Exercise common sense and caution when using this tool. Always be
aware of the environment and ensure that the tool is used in a safe and responsible manner.
Do not allow persons to operate or assemble the product until they have read this manual and
have developed a thorough understanding of how it works.
Do not modify this product in any way. Unauthorized modification may impair the function and/or
safety and could affect the life of the product. There are specific applications for which the product
was designed.
Use the right tool for the job. DO NOT attempt to force small equipment to do the work of larger
industrial equipment. There are certain applications for which this equipment was designed. This
product will be safer and do a better job at the capacity for which it was intended. DO NOT use
this equipment for a purpose for which it was not intended.
Industrial or commercial applications must follow OSHA requirements.
⚠WARNING
WORK AREA SAFETY
Inspect the work area before each use. Keep work area clean, dry, free of clutter, and well-lit.
Cluttered, wet, or dark work areas can result in injury. Using the product in confined work areas
may put you dangerously close to cutting tools and rotating parts.
Do not use the product where there is a risk of causing a fire or an explosion; e.g., in the presence
of flammable liquids, gases, or dust. The product can create sparks, which may ignite the
flammable liquids, gases, or dust.
Do not allow the product to come into contact with an electrical source. The tool is not insulated
and contact will cause electrical shock.
Keep children and bystanders away from the work area while operating the tool. Do not allow
children to handle the product.

Page 5 of 11
⚠WARNING
PERSONAL SAFETY
Stay alert, watch what you are doing, and use common sense when operating the tool. Do not use
the tool while you are tired or under the influence of drugs, alcohol, or medication. A moment of
inattention while operating the tool may result in serious personal injury.
Dress properly. Do not wear loose clothing, dangling objects, or jewelry. Keep your hair, clothing
and gloves away from moving parts. Loose clothes, jewelry, or long hair can be caught in moving
parts. Air vents on the tool often cover moving parts and should be avoided.
Wear the proper personal protective equipment when necessary. Use ANSI Z87.1 compliant safety
goggles (not safety glasses) with side shields, or when needed, a face shield. Use a dust mask in
dusty work conditions. Also use non-skid safety shoes, hardhat, gloves, dust collection systems,
and hearing protection when appropriate. This applies to all persons in the work area.
Do not overreach. Keep proper footing and balance at all times.
Remove keys or wrenches before connecting the tool to an air supply, power supply, or turning on
the tool. A wrench or key that is left attached to a rotating part of the tool may cause personal
injury.
Secure the work with clamps or a vise instead of your hand when practical. This safety precaution
allows for proper tool operation using both hands.
⚠CAUTION
BEAD BREAKER USE AND CARE
Do not force the bead breaker. Products are safer and do a better job when used in the manner for
which they are designed. Plan your work, and use the correct product for the job.
Check for damaged parts before each use. Carefully check that the product will operate properly
and perform its intended function. Replace damaged or worn parts immediately. Never operate the
product with a damaged part.
Do not use a product with a malfunctioning switch. Any power tool that cannot be controlled with
the power switch is dangerous and must be repaired by an authorized service representative
before using.
Disconnect the power/air supply from the product and place the switch in the locked or off position
before making any adjustments, changing accessories, or storing the tool. Such preventive safety
measures reduce the risk of starting the tool accidentally.
Store the product when it is not in use. Store it in a dry, secure place out of the reach of children.
Inspect the tool for good working condition prior to storage and before re-use.
Use only accessories that are recommended by the manufacturer for use with your product.
Accessories that may be suitable for one product may create a risk of injury when used with
another tool. Never use an accessory that has a lower operating speed or operating pressure than
the tool itself.
Keep guards in place and in working order. Never operate the product without the guards in
place.
Do not leave the tool running unattended.

Page 6 of 11
Specific Operation Warnings
⚠WARNING
Risk of finger entrapment and laceration.
Wear ANSI Z87.1 compliant protective goggles and equipment.
Before use, fully deflate the tire.
Ensure the wheel is stable and the work area if free and clear of debris.
Secure and fully support any vehicles.
Assembly Instructions
⚠WARNING
Always deflate tires before disassembling.
Use the proper tools.
Always be aware of the risk that there are always crushing hazards
Lock the safety rods on the vehicle.
The safety valve is set and sealed by the manufacturer. Do not tamper with it or change its
calibration.
Follow all instructions to avoid injury to people or damages to objects and surroundings.
Connect the hydraulic pump (manual or air) to the bead breaker through the quick-couplers. If you use
the air/hydraulic pump, you must connect it to a source of compressed air of 100-120 PSI.
Test the bead breaker before you attach it to the rim. Release all air from the tire and remove the cap
and valve, as well as the valve extension included. Be sure to verify that the tire is completely
deflated!
Before Each Use
⚠WARNING
Before the bead breaker is used, carefully inspect the unit each time for damages, or any missing,
worn, or loose parts.
Explosion hazard. Deflate tire before removing a wheel, rim, or part of a rim clamp or nut.
Operating Instructions
⚠WARNING
Risk of finger entrapment and laceration.
Wear ANSI Z87.1 compliant protective goggles and equipment.

Page 7 of 11
Ensure the wheel is stable and the work area if free and clear of debris.
Secure and fully support any vehicles.
This bead breaker works on all types of rims (optional claws
may be required).
Depending on the type of wheel, make sure you have the right
accessories installed:
Unload the truck and lift it with the jack. Place the wheel in
position and release the tire pressure.
Hold the bead breaker to the rim as indicated in the photo.
Turn on the air-driven hydraulic pump switch. Place the
pump in working position.
With the claw pushing against the inner portion of the rim,
push the shovel and feet against the lateral ring and the
bead of the tire.
Maintaining pressure, push the shovel against the bead of the tire, breaking the bead from the
rim. Stop operation when the hydraulic rod reaches the stroke of 3 ¾". This helps to extend the
life of bead breaker.
Treadle the air-driven hydraulic pump to the oil return and release the pressure. The hydraulic
push rod will be retracted and loosen the claw.
Repeat this process around the rim as many times as needed to completely break the tire bead
from the rim of the wheel.
Maintenance
Checks
a) Every time the bead breaker is used, check for leaks, damages, missing or loose parts, and worn
parts.
b) We suggest skilled personnel check the bead breaker yearly and that all defective parts, worn
parts, etc., are replaced with original parts supplied by the manufacturer. (See the parts list.)
Damaged Tools
All damaged, worn, or ill-operating tools must be not be used. We suggest necessary repairs are
carried out by skilled personnel authorized by the manufacturer.
Bead Breaker Scrapping
After many years of use, when your bead breaker must be scrapped, you must remove oil from the
cylinder and from the pump. Oil must be recycled according to regulations.

Page 8 of 11
Parts Diagram

Page 9 of 11
Parts List
Item
No.
Description
Qty.
Item
No.
Description
Qty.
Item
No.
Description
Qty.
1-1
Handle
2
1-16
Extrusion leg
1
3-4
12 Copper
washer
1
1-2
M12 Nut
2
1-17
Pin
1
3-5
M12x20 Screw
1
1-3
12 Washer
2
2-1
6 Steel ball
1
4-1
M10x15 Screw
2
1-4
M5x50 Screw
1
2-2
M6x30 Screw
1
4-2
Bushing
2
1-5
5 Copper
washer
2
2-3
Washer
1
4-3
Left foot
1
1-6
Cylinder cap
1
2-4
O-ring
1
4-4
Right foot
1
1-7
O-ring
1
2-5
Cylinder
1
5-1
Snap ring
4
1-8
Spring A
1
2-6
Spring
1
5-2
Connection rod
2
1-9
Snap ring
1
2-7
Piston rod
1
5-3
Claw
1
1-10
Bushing
1
2-8
M5x70 Screw
1
5-4
Bushing
2
1-11
Snap ring
1
2-9
Joint block
1
5-5
M10x25 Screw
2
1-12
Piston rod
1
2-10
M12x45 Bolt
1
5-6
Shaft
1
1-13
Cylinder body
3-1
8 Steel ball
1
5-7
Screw
2
1-14
Y-seal
2
3-2
Ball seat
1
6-1
Plug
1
1-15
Bushing
2
3-3
Spring
1
Replacement Parts
For replacement parts and technical questions, please call Customer Service at 1-800-222-5381.
Not all product components are available for replacement. The illustrations provided are a
convenient reference to the location and position of parts in the assembly sequence.
When ordering parts, the following information will be required: item description, item model
number, item serial number/item lot date code, and the replacement part reference number.
The distributor reserves the rights to make design changes and improvements to product lines
and manuals without notice.

Page 10 of 11
Limited Warranty
Northern Tool and Equipment Company, Inc. ("We'' or "Us'') warrants to the original purchaser only
("You'' or "Your") that the Strongway product purchased will be free from material defects in both
materials and workmanship, normal wear and tear excepted, for a period of one year from date of
purchase. The foregoing warranty is valid only if the installation and use of the product is strictly in
accordance with product instructions. There are no other warranties, express or implied, including the
warranty of merchantability or fitness for a particular purpose. If the product does not comply with this
limited warranty, Your sole and exclusive remedy is that We will, at our sole option and within a
commercially reasonable time, either replace the product or product component without charge to You
or refund the purchase price (less shipping). This limited warranty is not transferable.
Limitations on the Warranty
This limited warranty does not cover: (a) normal wear and tear; (b) damage through abuse, neglect,
misuse, or as a result of any accident or in any other manner; (c) damage from misapplication,
overloading, or improper installation; (d) improper maintenance and repair; and (e) product alteration
in any manner by anyone other than Us, with the sole exception of alterations made pursuant to
product instructions and in a workmanlike manner.
Obligations of Purchaser
You must retain Your product purchase receipt to verify date of purchase and that You are the original
purchaser. To make a warranty claim, contact Us at 1-800-222-5381, identify the product by make
and model number, and follow the claim instructions that will be provided. The product and the
purchase receipt must be provided to Us in order to process Your warranty claim. Any returned
product that is replaced or refunded by Us becomes our property. You will be responsible for return
shipping costs or costs related to Your return visit to a retail store.
Remedy Limits
Product replacement or a refund of the purchase price is Your sole remedy under this limited warranty
or any other warranty related to the product. We shall not be liable for: service or labor charges or
damage to Your property incurred in removing or replacing the product; any damages, including,
without limitation, damages to tangible personal property or personal injury, related to Your improper
use, installation, or maintenance of the product or product component; or any indirect, incidental or
consequential damages of any kind for any reason.
Assumption of Risk
You acknowledge and agree that any use of the product for any purpose other than the specified
use(s) stated in the product instructions is at Your own risk.
Governing Law
This limited warranty gives You specific legal rights, and You also may have other rights which vary
from state to state. Some states do not allow limitations or exclusions on implied warranties or
incidental or consequential damages, so the above limitations may not apply to You. This limited
warranty is governed by the laws of the State of Minnesota, without regard to rules pertaining to
conflicts of law. The state courts located in Dakota County, Minnesota shall have exclusive jurisdiction
for any disputes relating to this warranty.

Page 11 of 11
Distributed by:
Northern Tool & Equipment Company, Inc.
Burnsville, Minnesota 55306
www.northerntool.com
Made in China
