Struers LaboUI User manual

LaboUI
Instruction Manual
Original Instructions
Doc. no.: 16207025-01_C_en-us
Date of release: 2023.03.13

Copyright
The contents of this manual are the property of Struers ApS. Reproduction of
any part of this manual without the written permission of Struers ApS is not
allowed.
All rights reserved. © Struers ApS 2023.04.04.
2 LaboUI

Table of Contents
1 About this manual 5
2 Safety 5
2.1 Intended use 5
2.2 LaboUIsafety precautions 5
2.2.1 Read carefully before use 5
2.3 Safety messages 6
2.4 Safety messages in this manual 7
3 Getting started 8
3.1 Device description 8
3.2 LaboUI 8
4 Transport and storage 9
4.1 Long-term storage or shipping 9
5 Installation 9
5.1 Unpack the machine 9
5.2 Check the packing list 9
5.3 Installation - LaboUI 10
5.4 Noise and vibration levels 10
6 Operate the device 11
6.1 Control panel functions 11
7 Maintenance and service 12
7.1 General cleaning 12
7.2 Daily 12
7.3 Weekly 13
7.4 Spare parts 13
7.5 Service and repair 13
7.6 Disposal 13
LaboUI 3

8 Troubleshooting 14
9 Technical data 14
9.1 Technical data - LaboUI 14
9.2 Diagrams - LaboUI 14
9.3 Legal and regulatory information 16
10 Manufacturer 16
Declaration of Incorporation of Partly Completed Machinery 17
4 LaboUI

1 About this manual
CAUTION
Struers equipment must only be used in connection with and as
described in the Instruction Manual supplied with the equipment.
Note
Read the Instruction Manual carefully before use.
Note
If you wish to view specific information in detail, see the online
version of this manual.
2 Safety
2.1 Intended use
The device is for professional manual materialographic preparation (grinding
or polishing) of materials for further materialographic inspection.
LaboUI is intended to be used in combination with:
• LaboPol-20
• LaboPol-30
• LaboPol-60
Do not use the machine for the
following
Other equipment than stated in the
section "Intended use".
Model LaboUI
2.2 LaboUIsafety precautions
2.2.1 Read carefully before use
Ignoring this information and mishandling of the equipment can lead to severe
bodily injuries and material damage.
1 About this manual
LaboUI 5

General safety precautions
1. The machine must be installed in compliance with local safety regulations. All
functions on the machine and any connected equipment must be in working
order.
2. This device must be mounted securely on the machine.
3. The operator must read the safety precautions and Instruction Manual, as
well as relevant sections of the manuals for any connected equipment and
accessories.
4. If you observe malfunctions or hear unusual noises, switch off the machine
and call technical service.
5. In case of fire, alert bystanders and the fire brigade. Disconnect the electrical
power supply. Use a powder fire extinguisher. Do not use water.
6. This machine must be operated and maintained only by skilled/trained
personnel.
7. Always switch off the electrical power supply and remove the plug or power
cable before dismantling the machine or installing additional components.
8. The machine must be disconnected from the electrical power supply before
any service. Wait 5 minutes until residual potential on the capacitors is
discharged.
9. Struers equipment must only be used in connection with and as described in
the Instruction Manual supplied with the equipment.
10. If the equipment is subjected to misuse, incorrect installation, alteration,
neglect, accident or incorrect repair, Struers will accept no responsibility for
damage to the user or the equipment.
11. Dismantling of any part of the equipment, during service or repair, should
always be performed by a qualified technician (electromechanical, electronic,
mechanical, pneumatic, etc.).
2.3 Safety messages
Struers uses the following signs to indicate potential hazards.
ELECTRICAL HAZARD
This sign indicates an electrical hazard which, if not avoided, will
result in death or serious injury.
DANGER
This sign indicates a hazard with a high level of risk which, if not
avoided, will result in death or serious injury.
6 LaboUI
2 Safety

WARNING
This sign indicates a hazard with a medium level of risk which, if
not avoided, could result in death or serious injury.
CAUTION
This sign indicates a hazard with a low level of risk which, if not
avoided, could result in minor or moderate injury.
CRUSHING HAZARD
This sign indicates a crushing hazard which, if not avoided, could
result in minor, moderate or serious injury.
HEAT HAZARD
This sign indicates a heat hazard which, if not avoided,
can result in minor, moderate or serious injury.
General messages
Note
This sign indicates that there is a risk of damage to property, or a
need to proceed with special care.
Hint
This sign indicates that additional information and hints are
available.
2.4 Safety messages in this manual
WARNING
Struers equipment must only be used in connection with and as
described in the Instruction Manual supplied with the equipment.
CAUTION
Keep clear of rotating parts during operation.
CAUTION
When working at machines with rotating parts, take care to
prevent clothes and/or hair from being caught by the rotating
parts.
2 Safety
LaboUI 7

3 Getting started
3.1 Device description
LaboUI is a control panel (grinding/polishing) which can be mounted on the
following machines for manual materialographic preparation: LaboPol-20,
LaboPol-30 and LaboPol-60.
On the control panel the operator can set the rotation speed of the preparation
disc, start and stop the machine, control water application and the disc spin
function.
The operator selects the grinding/polishing surface and the cooling fluid/abrasive
suspension to be applied. The operator holds the specimen during the
preparation.
The operator sets the rotation speed of the preparation disc before starting the
process.
The operator starts the machine by pressing the Start button on the control panel.
Cooling water is applied automatically when the operator opens the water tap.
The operator applies other fluids manually or by using a separate dosing unit.
The operator stops the machine by pressing the Stop button on the control panel.
The operator cleans the specimens before the next preparation step or
inspection.
The machine must always be used with the splash guard in place.
If the emergency stop is activated, the power to all moving parts is cut.
3.2 LaboUI
Front view
AControl panel
BDisc speed control
CControl panel column
8 LaboUI
3 Getting started

4 Transport and storage
If, at any time after the installation, you have to move the unit or place it in
storage, there is a number of guidelines we recommend that you follow.
• Package the unit securely before transportation. Insufficient packaging
could cause damage to the unit and will void the warranty. Contact
Struers Service.
• We recommend that you use the original packaging and fittings.
4.1 Long-term storage or shipping
For instructions on how to prepare the unit for long-term storage or shipping,
see the specific machine manual.
Pay specific attention to the following:
• Disconnect the unit from the electrical power supply.
• Remove the control panel or specimen mover.
• Place the machine and accessories in their original packaging.
5 Installation
5.1 Unpack the machine
Note
We recommend that you keep all original packaging and fittings
for future use.
1. Cut the packing tape on the top of the box.
2. Remove the loose parts.
3. Remove the unit from the box.
5.2 Check the packing list
Optional accessories may be included in the packing box.
The packing box contains the following items:
Pcs. Description
1 LaboUI
1 Instruction Manual set
4 Transport and storage
LaboUI 9

5.3 Installation - LaboUI
Note
This device must be mounted securely on the machine.
Procedure
Install the control panel in the connection hole of the machine.
1. Remove the plastic disc
protecting the communication
cable.
2. Connect the communication
cable on the column to the
connection port on the
machine.
3. Guide the column down into
the connection hole.
4. Slide the black V-ring down
the column until it covers the
connection hole.
5. Use the Allen key to tighten
the two fastening screws. Do
not tighten the screws
completely.
6. Cover the holes with the two
cover caps.
Allen key and cover caps are
supplied with LaboPol. AV-ring
BFastening screws
5.4 Noise and vibration levels
For information about noise and vibration levels, see the specific machine
manual.
10 LaboUI
5 Installation

6 Operate the device
For instructions on how to operate the device, see the specific machine
manual.
See also the section "Intended use" for the specific machine manual.
6.1 Control panel functions
CAUTION
Keep clear of rotating parts during operation.
CAUTION
When working at machines with rotating parts, take care to
prevent clothes and/or hair from being caught by the rotating
parts.
ADisc speed control
Button Function
Disc rotation
• Starts rotation of the disc (Spin function).
Water
Manual override
• Press the button to apply water. Water is applied when no
process is running.
• Press the button again to stop applying water.
6 Operate the device
LaboUI 11

Button Function
Start
• Starts the preparation process.
Stop
• Stops the preparation process.
7 Maintenance and service
Technical questions and spare parts
If you have technical questions or when you order spare parts, state serial number
and voltage/frequency. The serial number and the voltage are stated on the type
plate of the machine.
7.1 General cleaning
To ensure a longer lifetime for your machine, we strongly recommends regular
cleaning.
Note
Do not use a dry cloth as the surfaces are not scratch resistant.
Note
Do not use acetone, benzol or similar solvents.
If the machine is not to be used for a longer period of time
• Clean the machine and all accessories thoroughly.
7.2 Daily
• Clean all accessible surfaces with a soft, damp cloth.
12 LaboUI
7 Maintenance and service

7.3 Weekly
• Clean all accessible surfaces with a soft damp cloth and common
household detergents.
7.4 Spare parts
For specific safety related parts, see the section "Safety Related Parts of the
Control System (SRP/CS)" in the section "Technical data" in this manual.
Technical questions and spare parts
If you have technical questions or when you order spare parts, state serial
number and voltage/frequency. The serial number and the voltage are stated
on the type plate of the machine.
For further information, or to check the availability of spare parts, contact
Struers Service. Contact information is available on Struers.com.
7.5 Service and repair
We recommend that a regular service check be carried out yearly or after
every 1500 hours of use.
When the machine is started up, the display shows information about total
operation time and the machines service information.
After 1500 hours of operation time, the display will show a message
reminding the user that a service check should be scheduled.
Note
Service must only be performed by a qualified technician
(electromechanical, electronic, mechanical, pneumatic, etc.).
Contact Struers Service.
7.6 Disposal
Equipment marked with a WEEE symbol contains
electrical and electronic components and must not be
disposed of as general waste.
Contact your local authorities for information on the
correct method of disposal in accordance with national
legislation.
For disposal of consumables and recirculation fluid,
follow local regulations.
7 Maintenance and service
LaboUI 13

8 Troubleshooting
For troubleshooting guidance, see the specific machine manual.
9 Technical data
9.1 Technical data - LaboUI
Subject Specifications
Safety standards See the Declaration of Conformity
Noise level See the noise level stated for: LaboPol
Operating environment Surrounding
temperature
5-40°C/41-104°F
Humidity < 85 % RH non-
condensing
Storage and transport
conditions
Surrounding
temperature
0 – 60°C/32 – 140°F
Humidity < 85 % % RH non-
condensing
Power supply LaboUI is connected directly to LaboPol
Dimensions and weight Width 15 cm/5.9"
Depth 13.5 cm/5.3”
Height 37.6 cm/14.8”
Weight 0.8 kg/1.8 lbs
9.2 Diagrams - LaboUI
Title No.
LaboUI, Block diagram 16203050 B
14 LaboUI
8 Troubleshooting

16203050 B
5 5
4 4
3 3
2 2
1 1
D D C C B B A A
MPT / OHO
THIS DOCUMENT CONTAINS CONFIDENTAL AND PROPRIETARY INFORMATION THAT IS THE SOLE PROPERTY OF STRUERS A/S („STRUERS“) AND NO OWNERSHIP OR LICENSE RIGHT
ARE GARANTED BY DELIVERY OF THIS DOCUMENT TO THE RECEPIENT. THIS DOCUMENT AND ALL INFORMATION DISCLOSED HEREIN (A) SHALL NOT BE USED TO MANUFACTURE,
CONSTRUCT OR FABRICATE THE GOODS DISCLOSED HEREIN OR ANY DERIVATIVE WORKS OF THE SAME; (B) SHALL NOTBE E PLOITED OR SOLD BY ANY MEANS; (C) SHALL NOT BE COPIED OR OTHERWISE REPRODUCED IN WHOLE OR IN PART; (D) SHALL NOT BE REVEALED OR DISCLOSED TO ANYONE E CEPT THOSE PERSONS EMPLOYED OR ENGANGED BY THE RECEPIENT AND HAVING A LEGITIMATE „NEED TO KNOW“ THE INFORMATION CONTAINED IN THIS DOCUMENT, OR IN ANY MANNER MADE PUBLIC WITHOUT THE E PRESS WRITTEN
PERMISSION OF STRUERS; (E) SHALL BE HELD BY RECEPIENT OF THIS DOCUMENT IN STRICT CONFIDENCE AS A FIDUCIARY; AND (F) SHALL BE PROTECTED AND KEPT SEPARE FROM THE DOCUMENTS AND MATERIALS OF THE RECEPIENT OF THIS DOCUMENT. THIS DOCUMENT AND ALL INFORMATION CONTAINED HEREIN SHALL REMAIN PROPERTY OF STRUERS AND SHALL BE RETURNED UPON DEMAND ALL PROPRIETARY INFORMATION IS PROVIDED „AS IS“ WITHOUT WARRANTY OF ANY KIND, WHETHER E PRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION ANY WARRANTIES REGARDING THE TIMELINESS, ACCURACY OR COMPLETENESS OF THE PROPRIETARY INFORMATION.
B
3
STOP
X5 SHIELD
FRONT FOIL
X1
SB1
( 4 keys )
LED
STRIPE
HL1
( light )
RPM 50-500
X4
RP1
Keyboard
2
X1
Connector inside metal tube
X6
POWER VALVE 1 RUN SPIN CONNECTION TO
LABOPO L-20/30/60
1 1
A1
Printed Circuit Board (User Interface + LaboForce-50/Mi )
LED OUT
6
2
RevB (MPT 2016-11-14): STOP connection on X4 removed; SHIELD to X1 added REV NOTES
shield
shield
Size Scale
CAGE Code DWG NO Re v
Sheet
o f
telephone: [phone] Struers A/S
16203050
Monday, November14, 2016 1 1
A2
Pederstrupvej 84 DK-2750 Ballerup Denmark
LaboSystem-100 User Interface, Block Diagram
Size Scale
CAGE Code DWG NO Re v
Sheet
o f
telephone: [phone] Struers A/S
16203050
Monday, November14, 2016 1 1
A2
Pederstrupvej 84 DK-2750 Ballerup Denmark
LaboSystem-100 User Interface, Block Diagram
Size Scale
CAGE Code DWG NO Re v
Sheet
o f
telephone: [phone] Struers A/S
16203050
Monday, November14, 2016 1 1
A2
Pederstrupvej 84 DK-2750 Ballerup Denmark
LaboSystem-100 User Interface, Block Diagram
9 Technical data
LaboUI 15

9.3 Legal and regulatory information
FCC notice
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
10 Manufacturer
Struers ApS
Pederstrupvej 84
DK-2750 Ballerup, Denmark
Telephone: [phone]
Fax: [phone]
www.struers.com
Responsibility of the manufacturer
The following restrictions should be observed, as violation of the restrictions may
cause cancellation of Struers legal obligations.
The manufacturer assumes no responsibility for errors in the text and/or
illustrations in this manual. The information in this manual is subject to change
without notice. The manual may mention accessories or parts not included in the
supplied version of the equipment.
The manufacturer is to be considered responsible for effects on safety, reliability,
and performance of the equipment only if the equipment is used, serviced, and
maintained in accordance with the instructions for use.
16 LaboUI
10 Manufacturer

Based on: 16207901 B
Declaration of Incorporation of Partly Completed
Machinery
Manufacturer Struers ApS • Pederstrupvej 84 • DK-2750 Ballerup • Denmark
Name LaboUI
Model N/A
Function Control panel for LaboPol 20/30/60 grinding/polishing machine
Type 620
Cat. no. 06206901
The above listed machinery is only intended
to be used with:
And shall not be put into service until the final
machinery into which it is to be incorporated
has been declared in conformity with this
regulation, where appropriate.
Struers machinery, cooling units and consumables
Serial no.
Module H, according to global approach EU
We declare that the product mentioned is in conformity with the following legislation, directives and standards:
2011/65/EU EN 50581:2012
2014/30/EU EN 61000-3-2:2014, EN 61000-3-3:2013, EN 61000-6-1:2007, EN 61000-6-3:2007, EN 61000-6-3-
A1:2011, EN 61000-6-3-A1-AC:2012
2014/35/EU EN 60204-1:2006, EN 60204-1-A1:2009, EN 60204-1/Corr.:2010,
Additional standards NFPA 79, FCC 47 CFR Part 15 Subpart B
Authorized to compile technical file/
Authorized signatory
Date: [Release date]

en For translations see
www.struers.com/Library
bg За преводи вижте
cs Překlady viz
da Se oversættelser på
de Übersetzungen finden Sie unter
el Για μεταφράσεις, ανατρέξτε στη διεύθυνση
es Para ver las traducciones consulte
et Tõlked leiate aadressilt
fi Katso käännökset osoitteesta
fr Pour les traductions, voir
hr Za prijevode idite na
hu A fordítások itt érhetők el
it Per le traduzioni consultare
ja 翻訳については、
lt Vertimai patalpinti
lv Tulkojumus skatīt
nl Voor vertalingen zie
no For oversettelser se
pl Aby znaleźć tłumaczenia, sprawdź
pt Consulte as traduções disponíveis em
ro Pentru traduceri, consultați
se För översättningar besök
sk Preklady sú dostupné na stránke
sl Za prevode si oglejte
tr Çeviriler için bkz
zh 翻译见
