Studio Tools Mobile Frame User manual

User Manual
Mobile Frame

!
Studioboards
• Use only Studiotools Studioboards and Layers
• Studioboards and Layers can be put on the Board
Rail with the Studiotools Magnetic Connector Clips
• Layers and Studioboards can be moved horizontally
on the Board Rail
User Manual Mobile Frame 1,2m / 1,9m
• Up to 8 Studioboards or Layers can be stowed in the Mobile
Frame
• Studioboards can be connected to the sides of the Mobile
Frame with the Magnetic Connector Clips
!
Caution:
• Maximum Load on Mobile Frame must not
exceed 180 kg.
• Compatible with VESA Standard 50/50 - 400/600 mm
• Mobile Frame 1.2: Max 65”(recommended 50”)
Monitor, 50 kg and 90mm depth
max. 85“
max 80 kg
max.
10 kg
44lbs
max.
20 kg
44lbs
max.
30 kg
44lbs
• Mobile Frame 1.9 : Max 85”(recommended 75”)
and 80 kg, 90mm depth
• For the monitor installation, it is essential to read the
Studiotools Screen Mount Assembly Instructions.
(www.studiotools.io/pages/downloads)
• Max. 8 Studioboards, 4 Cubes, 1 Easel and 1 Toolbox can
be stowed on a Mobile Frame V19 (equals 85 kg)
• Do not step on Mobile Frame in any case.
• For any additional Studiotools products please read the
User Manual Flow Collection (www.studiotools.io/pages/downloads)
max.
10 kg
44lbs
max .
20 kg
44lbs
max.
90 mm

!
Caution:
• Mobile Frames are to be pushed by at least two
people.
• Look out for and remove any obstacles from path.
• Keep escape routes free.
User Manual Mobile Frame V12 and V19
• Generally move slowly and be cautious with hurdles.
• Remove any loose items from Mobile Frames before
moving. The shelves must be empty.
• Release every brake before moving. Your Mobile Frame
might tip and injure people severly.
• Unplug any electrical devise and stow main power cable
before moving.
• Ramps down lenghtwise and only with two persons
• Never park on a ramp
!
Caution:
• Any electrication and installations should be done by pro-
fessionals.
• Secure cables with cable clips and avoid large loops.
• Avoid any loose and hanging cables. This can cause serious harm
to people or damages to property.
• Make sure to protect any electric devise or other
electrications from water.
• Use soft, damp cloths or sponges with mild and
ecofriendly detergents.
• Dust & dirt can be vacuumed from the PET panels.
• For disinfection common household disinfectants are
eective
• General instructions for use:
Studiotools products are not intended for outdoor use. Avoid prolonged
exposure of the products to direct sunlight or humidity. In particular,
large-surface products should not be placed directly next to heaters, air
conditioners or other sources of heat or cold. Large temperature dier-
ences between the front and back can cause large surfaces to warp.
