SturiaTronic rcB 1200 User manual

lithium pack
rcB 1200 / rcB 1800 Manual Master Englisch A17
Project No.: 1508 page 1 / 11 issued: 30.04.2014
Distribute to: SturiaTronic, meinrad.cc, cunabo, Lenz, Supplier, SGS updated: 18.08.2022
arranged: P.Greisdorfer, Ph. Maier, G.Kremer
File Name: lithium pack rcB 1200 rcB 1800 Manual Master Draft for FCC ENG A17.docx
History
Date
A
arranged
Modified
page
Modification
14.02.2017
06
P.Greisdorfer
3
Sicherheitshinweise verallgemeinert
05.04.2018
07
P.Greisdorfer
all
-Anpassung bzgl. heat glove 4.0
-Änderung App (kostenlos), Lenz Heat App Basic entfernt
-Remote control entfernt
09.01.2019
08
P. Greisdorfer
all
Sicherheitshinweise hinzugefügt/abgeändert
Informationen bzgl. Lenz heat app angepasst,
Wordings für App und Produkte angepasst
div. Schreibweisen/Formulierungen angepasst
Absatz ‘Zubehör und Ersatzteile’ entfernt
01.02.2019
09
P. Greisdorfer
8
Betriebssystem Mindestanforderungen gelöscht
04.06.2019
10
P. Greisdorfer
9
Hinweis bzgl. Übersetzung hinzugefügt
14.12.2020
26.01.2021
11
P. Greisdorfer
Ph. Maier
3,5
4, 9,
Sicherheitshinweis hinzugefügt, Modellbezeichnung hinzugefügt,
Abbildung bei Ladevorgang aktualisiert, Satz für Langzeitlagerung
geändert
Richtlinien aufgenommen, Laden nur zwischen 0°C und 45°C,
Verwendung im Wasser
Heizleistungstabelle entfernt
18.02.2021
12
Ph. Maier
4
9
Lade, Entlade und Lagertemperatur in den Sicherheitshinweisen
Wartung/Lagerung –Temperatur entfernt, siehe Sicherheitshinweise
Anwendung der Lithium Packs
13.10.2021
13
Ph. Maier
2, 3
Sicherheitshinweise aktualisiert nach Check mit TÜVCN
29.12.2021
14
Ph. Maier
3
Ladegerät entfernt
Sicherheitshinweise, Charger entfernt, Ladevorgang
07.02.2022
15
Ph. Maier
3-5
7
8
Sicherheitshinweise aktualisiert
Rechtschreibkorrektur
Funktionsbeschreibung & Bedienung und Funktion überarbeitet
18.07.2022
17
G.Kremer
11
FCC text added

lithium pack
rcB 1200 / rcB 1800 Manual Master Englisch A17
Project No.: 1508 page 2 / 11 issued: 30.04.2014
Distribute to: SturiaTronic, meinrad.cc, cunabo, Lenz, Supplier, SGS updated: 18.08.2022
arranged: P.Greisdorfer, Ph. Maier, G.Kremer
File Name: lithium pack rcB 1200 rcB 1800 Manual Master Draft for FCC ENG A17.docx
Contents
Introduction........................................................................................................................................................3
Package contents................................................................................................................................................3
Safety precautions..............................................................................................................................................3
Product description............................................................................................................................................6
Technical specifications......................................................................................................................................6
First use and charging.........................................................................................................................................6
Charging procedure........................................................................................................................................6
Safety functions..................................................................................................................................................7
Using the lithium packs ......................................................................................................................................7
Use with Lenz heat products..........................................................................................................................7
Important instructions for use ...........................................................................................................................8
Function description...........................................................................................................................................8
lithium pack rcB 1200 / lithium pack rcB 1800...............................................................................................8
Use and function ................................................................................................................................................8
Remote control...................................................................................................................................................9
Pairing Mode ..................................................................................................................................................9
Heating power - heating period .........................................................................................................................9
Service, storage and care .................................................................................................................................10
Disposal ............................................................................................................................................................10
<< nicht übersetzen>>
FORMAT ANWEISUNG:
Überschriften : 8Pkt.
Sicherheitshinweise: 8Pkt. (Nummern/Aufzählung nicht übernehmen, durch Aufzählungspunkte ersetzen)
Anderer Text: 6Pkt.
Symbole: min. 10mm
<<>>

lithium pack
rcB 1200 / rcB 1800 Manual Master Englisch A17
Project No.: 1508 page 3 / 11 issued: 30.04.2014
Distribute to: SturiaTronic, meinrad.cc, cunabo, Lenz, Supplier, SGS updated: 18.08.2022
arranged: P.Greisdorfer, Ph. Maier, G.Kremer
File Name: lithium pack rcB 1200 rcB 1800 Manual Master Draft for FCC ENG A17.docx
lithium pack rcB 1200 / lithium pack rcB 1800
Operating instructions / English
INTRODUCTION
Congratulations on your purchase of the lithium pack rcB 1200 / lithium pack rcB 1800.
Please carefully read the operating instructions before using the product.
The operating instructions are also available in electronic form on the manufacturer’s website:
www.lenzproducts.com
PACKAGE CONTENTS
2 lithium pack rcB 1200 or lithium pack rcB 1800
2 contact protectors
1 USB charging cable with charging plugs for lithium packs
SAFETY PRECAUTIONS
General safety precautions:
1. Keep these important instructions for future reference
Format Anweisung: Nächster HINWEIS FETT
2. WARNING: Please read all safety precautions and operating instructions
carefully. (b) Failure to follow the safety precautions and operating instructions may
result in electric shock, fire and/or serious injuries.
3. This product is expressly not recommended for use by persons (including children) with
restricted physical, sensory or mental capabilities or without experience and relevant
knowledge, unless they are supervised by a person responsible for their safety or have
been trained in how to use the product.
Children should be supervised to ensure that they do not use the product as a toy or
operate it on their own.
4. Not suitable for children under the age of 36 months. (a)
Format Anweisung: Nächste zwei HINWEISE FETT
5. This product is not recommended for people with the following illnesses, but the
list is not exhaustive:
• somatosensory disorders and/or neurological conditions that cause a
somatosensory disorder of the extremities, including diabetes, diabetic
neuropathy, peripheral neuropathies, traumatic brain injury, stroke, spinal
cord injury, multiple sclerosis and other
• circulatory disorders, including peripheral arterial occlusive disease,
thrombosis, moderate to severe varicose veins, lymphoedema and leg
swelling due to other causes
• unhealed injury of the extremities resulting in open skin wounds, ulcers,
bruises or inner injuries
• burns of the extremities
• active infections of the extremities
• skin diseases resulting in sensitive, dry or cracked skin, such as eczema
and other forms of dermatitis, all diseases connected with skin infections
and/or inflammations, physical urticaria and other
• vasospastic phenomena including, but not limited to Raynaud’s syndrome
6. If you suffer from one of the above-mentioned diseases or another that was not
mentioned and take medications either currently or regularly and/or are unable to

lithium pack
rcB 1200 / rcB 1800 Manual Master Englisch A17
Project No.: 1508 page 4 / 11 issued: 30.04.2014
Distribute to: SturiaTronic, meinrad.cc, cunabo, Lenz, Supplier, SGS updated: 18.08.2022
arranged: P.Greisdorfer, Ph. Maier, G.Kremer
File Name: lithium pack rcB 1200 rcB 1800 Manual Master Draft for FCC ENG A17.docx
sense heat or cold properly (e.g. persons with special needs, etc.), consult your
doctor prior to using the product!
7. Check your feet regularly for redness of the skin. Excessive heat levels over prolonged
periods of time can lead to burns.
8. If the heated sock is used in firmly closed or specially fitted footwear with a very narrow
shape, please make sure that the sock is not wrinkled in the area of the heating element.
This could result in painful pressure points.
9. Never use the heated sock in combination with other heated products (heated insole,
heated boot, etc.); there is a risk of excessive heat.
10. The heat should be switched off when entering an environment with a considerably
higher temperature.
11. Do not use the product for warming animals.
12. Check the product regularly for signs of wear or damage. If you notice any of these
signs, if the product was used improperly or if the product does not work, bring it back to
the dealer before using it again.
13. The lithium packs must only be used with compatible LENZ products!
14. Discharge and recharge the lithium packs half way every 6 months!
15. Only use the supplied USB charging cable (USB Charge Cord Type 1) to charge the
device. It is designed for indoor use and must not be exposed to humidity.
16. The lithium packs must not be charged or stored outside of the permitted ambient
temperature of +10°C to +30°C.
17. The lithium packs must not be discharged outside the permitted ambient temperature
of -20°C to +30°C.
18. Always store the lithium packs with the contact protector installed.
Format Anweisung: Nächste zwei HINWEISE FETT
19. When the lithium packs are not in use, keep them away from other metal objects
such as paper clips, coins, keys, nails, screws and other small metal objects which
could form a connection between the contacts. Short-circuiting the connections
may cause burns or fire.
20. Do not charge or store the lithium packs near flammable substances!
21. Never try to open the lithium packs! Improper handling of the lithium-ion batteries can
lead to an explosion!
22. Damaged lithium packs must no longer be used and must be disposed of immediately.
23. If the charging cables or any other parts of the product are damaged, discontinue the
use of the product.
24. Do not modify the product or divert it from its intended use.
25. If there is a defect, please dispose of the respective components properly at a
collection site for electronic waste.
26. Do not expose the lithium packs to fire or excessive temperatures. Exposing the lithium
packs to fire or temperatures above 130°C may lead to an explosion.
27. Do not puncture with a needle or similar! (c)
28. The product is not intended for use in hospitals.
29. The technology employed meets all relevant and legal requirements. The usability of
Lenz products in the proximity of other sensitive electronic products (e.g. avalanche
beacons, cardiac pacemakers, etc.) must be checked with their manufacturers.
30. Avoid kinking the product by placing other objects on top of it during the storage.
31. The lithium packs must not be used in or under water!

lithium pack
rcB 1200 / rcB 1800 Manual Master Englisch A17
Project No.: 1508 page 5 / 11 issued: 30.04.2014
Distribute to: SturiaTronic, meinrad.cc, cunabo, Lenz, Supplier, SGS updated: 18.08.2022
arranged: P.Greisdorfer, Ph. Maier, G.Kremer
File Name: lithium pack rcB 1200 rcB 1800 Manual Master Draft for FCC ENG A17.docx
32. If used improperly, liquid may leak out of the battery; avoid contact. In the event of
accidental contact, rinse with water. In the event of contact with eyes, also seek medical
assistance. Liquid leaking out of the battery may cause irritation or burns.
33. Do not used batteries or products if they have been damaged or modified. Damaged or
modified batteries can behave unpredictably, which may lead to fires breaking out or a risk
of injury.
34. Only use qualified repair personnel for maintenance, and only use identical spare
parts. This will ensure the product is safe to use.
35. Do not attempt to modify or repair the product or the battery (if applicable) in ways
other than those specified in the operating and care instructions.
Höhe min. 10mm
(a)
(b)
(c)

lithium pack
rcB 1200 / rcB 1800 Manual Master Englisch A17
Project No.: 1508 page 6 / 11 issued: 30.04.2014
Distribute to: SturiaTronic, meinrad.cc, cunabo, Lenz, Supplier, SGS updated: 18.08.2022
arranged: P.Greisdorfer, Ph. Maier, G.Kremer
File Name: lithium pack rcB 1200 rcB 1800 Manual Master Draft for FCC ENG A17.docx
PRODUCT DESCRIPTION
lithium pack rcB 1200 / lithium pack rcB 1800
•Snap fasteners to establish the connection to the charger and the heatable textile (Fig. 1.1)
•Heat setting display 1 / 2 / 3 (Fig. 1.2)
•Control button (Fig. 1.3)
•Contact protector (Fig. 1.4)
Charger
•USB charging cable (Fig. 2.1)
•Charge indicator (Fig. 2.2)
•Charger plug (Fig. 2.3)
TECHNICAL SPECIFICATIONS
lithium pack rcB 1200 (LZ Type 010)
Output: 3.7 V / 2400 mAh
lithium pack rcB 1800 (LZ Type 020)
Output: 3.7 V / 3600 mAh
USB charging cable (USB Charge Cord Type 1)
Input: 5 VDC / 1A
Output: 4.2 VDC / 0.9A
FIRST USE AND CHARGING
Important note:
Charge the lithium packs prior to their first use!
Charging procedure
1. Connect the USB charging cable (Fig. 2.1) with a USB power supply unit (5 V, 1 A, not included in
delivery) and plug the USB power supply unit into a socket. The charge indicator (Fig. 2.2) will light up
green.
2. Remove the contact protector (Fig. 1.4) and connect both lithium packs to the charging plugs of the
charging cable (Fig. 2.3). Please refer to the diagram on the charging plugs for correct orientation. The
lithium packs can be charged in any operating mode.
3. The charging process starts after one-time operation of the control button (Fig. 1.3.).
4. The charge indicator (Fig. 2.2) will light up red during the charging process.
5. Once the lithium packs are fully charged, the charging process automatically ends and the charge
indicator (Fig. 2.2) changes back to green.
6. The charging status can be monitored with the LEDs on the lithium pack, which light up successively as
the charge increases, or using the Lenz heat app* which offers convenient control.
7. After the end of the charging process, please disconnect both lithium packs from the charging plugs.
(Fig. 2.3)
Important note:
•Because naturally occurring minimal differences due to production can occur, the charge
indicator in the Lenz heat app* only serves as a general indicator.
•Charge the product after every use.
This helps extend the life of the lithium packs and ensures that the product is ready for use at any
time.
•The battery consists of lithium ion cells and can be charged in any state.
For this reason, the battery does not need to be fully discharged before charging.
•The full charging capacity of the product can only be conserved if the product is disconnected
from the charging plugs after the end of the charging process.
Charging
time
lithium pack rcB 1200
5 –7 h
lithium pack rcB 1800
7 –9 h

lithium pack
rcB 1200 / rcB 1800 Manual Master Englisch A17
Project No.: 1508 page 7 / 11 issued: 30.04.2014
Distribute to: SturiaTronic, meinrad.cc, cunabo, Lenz, Supplier, SGS updated: 18.08.2022
arranged: P.Greisdorfer, Ph. Maier, G.Kremer
File Name: lithium pack rcB 1200 rcB 1800 Manual Master Draft for FCC ENG A17.docx
SAFETY FUNCTIONS
•Short circuit protection: In the event of a short circuit at the contact or the heating element, the
integrated electronics automatically turn the product off. After removing the short circuit, please briefly
connect the lithium packs to the charging plugs. Next, press the control button once and the product is
ready again.
•Protection against overcharging and exhaustive discharge: The product is protected against
overcharging and exhaustive discharge with the integrated electronics system.
USING THE LITHIUM PACKS
Use with Lenz heat products
•Remove the contact protector from the lithium packs (Fig. 1.4).
•Place the lithium packs in the intended position (see figure A, B, C, D, E).
•Press the lithium packs onto the snap fasteners until they audibly snap into place (Fig. F).
•The lithium packs can be operated conveniently, either manually through the visual control window or the
textile (Fig. G), or optionally via the Lenz heat app on a smartphone.

lithium pack
rcB 1200 / rcB 1800 Manual Master Englisch A17
Project No.: 1508 page 8 / 11 issued: 30.04.2014
Distribute to: SturiaTronic, meinrad.cc, cunabo, Lenz, Supplier, SGS updated: 18.08.2022
arranged: P.Greisdorfer, Ph. Maier, G.Kremer
File Name: lithium pack rcB 1200 rcB 1800 Manual Master Draft for FCC ENG A17.docx
IMPORTANT INSTRUCTIONS FOR USE
•When using the heated product, the optimal heating power is only produced when all heated products,
textiles and socks you are wearing are dry.
•Do not operate the device at the highest heating power for longer than several minutes.
•Always set the product to a low or medium heat output to maintain a comfortably warm temperature
(the heater should be virtually unnoticeable).
FUNCTION DESCRIPTION
lithium pack rcB 1200 / lithium pack rcB 1800
Manual operation:
The lithium packs have 3 heating levels which are indicated by the heat setting display (Fig. 1.2) on the
lithium packs themselves.
Remote control:
When using remote control via the APP, the heat output can be set to one of 9 levels via the corresponding
controls in the APP.
USE AND FUNCTION
Turning on:
Turn on the product to the lowest heat setting by briefly pushing the control button (approximately 0.5
seconds) on the lithium pack (Fig. 1.3).
Setting the heat output:
This can be done by repeatedly pressing the function button on the lithium pack (Fig. 1.3), or using the
corresponding control in the APP when using remote control.
The respective heat level is indicated by the illumination of the heat setting display (Fig. 1.2) on the lithium
pack, or in the APP when using remote control.
Turning off:
Pressing the function button repeatedly turns the lithium pack off.
Note:
When using remote control, the APP must be closed to be able to turn off the lithium pack.
The lithium pack can still be turned on for 24 hours via the APP, but after that, only by pressing the button.
LED, steady on –low heating power
LEDs, steady on –medium heating power
LEDs, steady on –high heating power
OFF

lithium pack
rcB 1200 / rcB 1800 Manual Master Englisch A17
Project No.: 1508 page 9 / 11 issued: 30.04.2014
Distribute to: SturiaTronic, meinrad.cc, cunabo, Lenz, Supplier, SGS updated: 18.08.2022
arranged: P.Greisdorfer, Ph. Maier, G.Kremer
File Name: lithium pack rcB 1200 rcB 1800 Manual Master Draft for FCC ENG A17.docx
REMOTE CONTROL
The lithium packs rcB 1200 / lithium packs rcB 1800 can be controlled via the Lenz heat app* for
smartphones. The lithium packs must be in “Pairing Mode” to be able to couple them properly with the
smartphone.
Pairing Mode
Please switch the desired lithium packs to “Pairing Mode”. For this purpose, push the control button (Fig.
1.3.) for approx. 10 seconds until the heat setting displays (Fig. 1.2.) are blinking and then immediately
release the control button. The heat setting display in the middle is flashing constantly.
Note: The Pairing Mode remains active for 2 minutes! If no pairing takes place during this time, this
mode will end automatically!
*The optional Lenz heat app for convenient control is available for download via the Android Play Store and
the Apple Store.
HEATING POWER - HEATING PERIOD
For heating power and heating period data, please see the table on the product packaging. You can also
access the data online at www.lenzproducts.com
The heating period per charge depends on the selected heating level, the ambient temperature, the lithium
packs and the charge state as well as age of the lithium packs.
LED, steady on –Pairing Mode

lithium pack
rcB 1200 / rcB 1800 Manual Master Englisch A17
Project No.: 1508 page 10 / 11 issued: 30.04.2014
Distribute to: SturiaTronic, meinrad.cc, cunabo, Lenz, Supplier, SGS updated: 18.08.2022
arranged: P.Greisdorfer, Ph. Maier, G.Kremer
File Name: lithium pack rcB 1200 rcB 1800 Manual Master Draft for FCC ENG A17.docx
SERVICE, STORAGE AND CARE
To ensure a long life, we recommend storing the lithium packs in a cool room (see safety instructions) in a
half-charged state. Store the lithium packs turned off (the heat level display (Fig. 1.2) is dark) and
disconnected from the heatable textile as well as the charger.
Caution: Always store the lithium packs with the contact protector installed.
For long-term storage, the lithium packs should be discharged and recharged halfway at least every 6
months. This ensures that maximum performance is preserved for many years!
Clean the parts as needed with a soft, slightly damp cloth and a mild detergent.
Caution: Always remove the charger from the outlet before cleaning it.
DISPOSAL
•Once the product has served its purpose, please dispose of it and its packaging appropriately and in an
environmentally friendly manner.
•Please do not dispose of the charger together with the household waste. Instead, bring the parts to a
collection site for electronic waste. (d)
•Take the lithium packs to the intended collection sites for used batteries. (e)
•Packaging materials are raw materials and can be recycled. For this reason, please recycle the
packaging.
•Please contact your local authority for more information.
Höhe min. 10mm
Information subject to change.
>>This is a translation of the original German version<<
// nur bei Übersetzungen schreiben, nicht bei Deutsch!
This product complies with the relevant EU regulations and guidelines.
Directive 2014/35/EU
Directive 2015/863/EU
Directive 2006/66/EU
Directive 2009/125/EU
Directive 2014/53/EU
The full EU declaration of conformity can be downloaded from www.lenzproducts.com.
[CE / UKCA Zeichen] Höhe min. 10mm
(d)
(e)

lithium pack
rcB 1200 / rcB 1800 Manual Master Englisch A17
Project No.: 1508 page 11 / 11 issued: 30.04.2014
Distribute to: SturiaTronic, meinrad.cc, cunabo, Lenz, Supplier, SGS updated: 18.08.2022
arranged: P.Greisdorfer, Ph. Maier, G.Kremer
File Name: lithium pack rcB 1200 rcB 1800 Manual Master Draft for FCC ENG A17.docx
FCC Regulatory Compliance
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This
transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
