Su-Kam SU600WB User manual

USER'S MANUAL (IFU)
Salient features
Micro Controller based PWM technology using MOSFETs.
Digital flash memory.
Software controlled Auto Self - Test.
A convenient no load shutdown at battery mode.
Pure Sine wave output.
Change over with Phase synchronisation.
An extra wide input voltage range
Inbuilt SMPS based charger with automatic power factor correction.
Cold start at full load.
Software controlled double protection for Overload and short circuit.
RS- 232 interface for auto shutdown.
PURE SINE WAVE LI UPS
600VA600VA
GLOBAL CERTIFICATIONS:GLOBAL CERTIFICATIONS:
GOVERNMENT OF INDIAGOVERNMENT OF INDIA
MINISTRY OF SCIENCE & TECHNOLOGYMINISTRY OF SCIENCE & TECHNOLOGY
R&DR&D
Recognised Recognised
ISO 14001:2004
ISO 9001:2000
Before connecting, operating, or adjusting this unit, please read this instruction booklet carefully .
Customer Care : [phone]Customer Care : [phone]
PKG-ML-095

REV. 05-02-08
1. Introduction
1.1 Overview................................................................. 2
1.2 Panel's Explanation................................................... 3
1.3 LED Indications....................................................... 3
1.4 Smart AVR............................................................... 4
1.5 Safety Instructions....................................................4
2. Installation and operation
2.1 Installation............................................................... 5
2.2 Operation.................................................................5-6
2.3 Storage Instructions..................................................6
3. Communication Interface
3.1 DB9 Communication Port..........................................7
3.2 UPS Monitoring Software..........................................8-9
"Info Disc Manager"
4. Trouble Shooting 10
5. Technical Specifications
5.1 Sine Wave LI UPS...............................................11-12
6. Warranty Card 13-14
Introduction
Installation and operation
Communication Interface
Trouble Shooting
Technical Specifications
Warranty Card
ContentsContents
Contents
(1)
Sine Wave LI UPS

1.1 Overview
The Su-Kam Sine Wave UPS is an advanced high performance line
interactive Uninterruptible Power System (UPS) designed to
protect your computer and other computerized equipment from
utility line failures, disturbances, frequency deviations, spikes and
surges. In the event of utility power failure, the UPS will rapidly
transfer loads to an alternative power source, which derives power
from the battery placed inside the UPS.
The UPS has inbuilt SMPS based charger with automatic power
factor correction.
Introduction
(2)
REV. 05-02-08
Sine Wave LI UPS
1. Introduction1. Introduction

AlarmAlarm
REV. 05-02-08
(3)
Panel’s
Expl.
&
Led and
AlarmIndication
1. 3 Core 6A Input Plug (Mains Input).
2. 2 6A AC Output Socket (Universal).
3. 6A D-Type AC Output Socket.
4. T2.5A/250V (Slow Blow) fuse.
5. RS-232 Communication Port.
The UPS will turn OFF permanently in case of low battery, overload, short
circuit protection and also in case of no load shut down.
There will be no LED indication in such a case.
1.2 Panel's Explanation 1.3 LED Indications
Front Panel
Back Panel
SINE WAVE
LI UPS
Multi-Color LED
Green Color
Continuous Mode Blinking Mode
Slow Fast
Red Color
Continuous Mode
Backup ON Low Battery Overload
Blinking Mode
Slow Fast
Mains ON
Mains ON
Charging ON
Charging ON
Output OFF
Output ON
AC INPUT
OUTPUT
COM. PORT
3
FUSE
4
5
2
Sine Wave LI UPS

REV. 05-02-08
1.4 Smart–AVR
The UPS automatically regulates output voltages within the normal
range, both in low utility voltage and high utility voltage conditions.
The UPS is equipped with cold start function to enable the user to
start it without utility power.
1.5 Safety Instructions
The UPS contains voltages which are potentially hazardous.
The UPS has its own internal energy source (battery). The
output receptacles may be live even when the UPS is not
connected to an AC supply.
All repairs should be performed by qualified service personnel.
Safe and continuous operation of the UPS depends partially on the
care taken by user. Please observe the following precautions:
Do not disassemble the UPS.
Connect the UPS to a two pole, three-wire (Line, Neutral & Earth)
mains with receptacle. Connection with any other type of
receptacle may result in a shock hazard and may violate local
electrical codes.
Do not allow water or any foreign object to get inside the UPS and do
not put objects containing liquid on or near the UPS.
Keep UPS away from fire or heating sources.
The Power socket should be installed near the equipment and be
easily accessible. To isolate from AC input, disconnect the plug
of the power cord of the system .
The battery will discharge naturally. If it is charged periodically,
Its life will be prolonged. It will be damaged if it is not used for a
long Period. This won't be covered in our Warranty.
Smart AVR
&
Safety
Instructions
(4)
Sine Wave LI UPS

2.1 Installation.
When the Power Cord is connected with normal utility power,
UPS will turn ON automatically and goes through the procedure
of self test. If test results are O.K., the LED will blink in green
color indicating that the mains is available and UPS starts battery
charging. UPS output will be available only when front power
switch is pressed for few seconds (LED glows continuously when
O/P is ON)
Inspect the Carton Box for any damage that may have
occurred while in transit. Immediately notify the carrier and
place of purchase if there is any damage . Retain the package for
future use.
Connect the power cord to a verified grounded 3-wire receptacle.
For connecting your equipment to the UPS and to ensure that
your computer equipment will be protected during a utility
failure, it is important to make sure that the maximum power
need of the equipment is not over the rated capacity of the UPS
2.2 Operation
REV. 05-02-08
Installation
&
Operation
(5)
Sine Wave LI UPS
2. Installation and Operation2. Installation and Operation

REV. 05-02-08
For extended storage in moderate climates, the batteries must
be charged for 8 hours every 2 months by plugging the
power cord into the wall receptacle. Repeat it every month in high
temperature locations.
2.3 Storage Instructions
Press the front power switch again for few seconds, the UPS will
turn OFF the power to equipment (O/P OFF) . if the AC Power
Cord is still connected, LED will blink in green color indicating that
the battery is charging. To turn OFF the power completely,
please pull out the power Cord.
To test backup function during power failure, press the front
power switch for few seconds. The UPS will work in backup mode
with buzzer beeps. In this mode the LED glows continuously in
Red color. To turn OFF the UPS, Please press the front Power
Switch again for few seconds.
The UPS will automatically turn OFF the output power during
backup mode when power consumption is lower than 6% of full
specified load.
If overload condition occurs, the buzzer will beep rapidly. The
LED will also blink rapidly in red color indicating the condition of
overload. Please proceed to unplug the least critical equipment.
In case of low battery, the LED will blink slowly.
Storage
Instructions
(6)
Sine Wave LI UPS

3.1 DB 9 Communication Port
Located at the rear side of the unit, the com-connector is a plug
in interfacing port (9-pin sub. D-female) which enables
advanced communication between the UPS and Computer
(interface kit required).
The diagrammatic interface (communication cable) of UPS
with computer:
REV. 05-02-08
COMMUNICATION CABLE
1
6
7
8
1
2
3
4
6
7
8
2
3
4
1 1
6
7
8
6
7
8
2
3
4
9 Pin Female
PC Side
9 Pin Male
UPS Side
5 5
9 9
Communication
Port
(7)
Sine Wave LI UPS
3.Commnication Interface3.Commnication Interface

3.2 Info Disc Manager
The Su-Kam UPS monitoring software "Info Disc Manager Version 13-
09-07 S" is compatible with almost all popularly used operating
systems as Windows 95, 98, NT, 2000, Millennium and XP to name a few
with best reliability. An easy to install auto run software CD and DB-9
Communication connector cable is to be connected to facilitate
convenient interfacing of PC with UPS.
On first start, the software shows a registration form it is mandatory to
fill this for proper functioning of the software. Once registration is
completed, the software will ask user to select the communication port
for communication with the UPS. The port once selected will become
the default and the software will start automatically on that port every
time. In case user wants to change the port which is once made default
then he must change it in less than 30 seconds when the port form pops
up after the beginning of the software.
Once installed it will start automatically after completion of operating
system booting and continuously monitor the system by showing the
icon in the status bar of desktop.
When the battery low signal appears, the software sends the system to
shutdown thus preventing damage caused by abrupt shutdown. It
pops up message of power failure for the signal received. It logs data of
Power failure, Normal mode, Battery low to show the log records of last
three states of UPS.
REV. 05-02-08
Info Disc
Manager
(8)
Sine Wave LI UPS

13
14
The Graphical User Interface of software has following display console-
Flashing red or green communication icon in status bar of software
to show ongoing communication status.
Mains status indicator.
Power failure status indicator.
Low battery status indicator.
UPS power status last three log records.
This is a complete solution designed to prevent hard-disk crashes and
to take care of sophisticated compute components. It completely
eradicates the chances of abrupt shutdown thus providing total care,
security and convenience.
REV. 05-02-08
Info Disc
Manager
(9)
Sine Wave LI UPS
13
UPS Status During Normal Mains Mode
14

Contact your dealer
4. System failure
The trouble shooting chart covers most of the difficulties that you may
encounter under normal working conditions. Should the UPS fails to
operate properly, please check the following before calling for service:
1. Is the UPS plugged into an incorrect wall receptacle?
2. Is AC Input voltage / frequency out of range?
When calling for service, please offer the following information:
1. Model No. and Serial No.
2. Date of occurrence of the problem.
3. Full description of problem, including condition, environment
which it is installed, devices connected to the UPS.
4.Trouble Shooting4.Trouble Shooting
Possible Cause Problem Trouble Shooting
No light,
No Alarm
switch
1. AC fuse Blown Replace AC fuse of actual rating
Turn On mains switch
Contact your dealer
Reduce Load
Check load & output side properly for shorting
Battery is low due to excessive load or battery is
consumed.
Wait, until mains returns.
Connect AC power cord to wall rec eptacle
2.Power cord is loose
3. Mains switch is not "ON"
4. System failure
UPS switched off
Automatically or
RED buzzer beeps.
UPS switched off
UPS will not
switch to battery
mode.
1. Overload connected at
UPS’s outlet
2. Short circuit on Inverter
3. Battery Low
1. Mains failure, battery
discharged, battery
depleted.
Wait, until mains returns.
Allow the UPS to recharge the battery
for at least 6 hours
REV. 05-02-08
Trouble
Shooting
(10)
Sine Wave LI UPS

RS-232
Windows 95/98/NT/2000/XP/2003 Server
SU600WB
600VA/12V
MODEL
CAPACITY
INPUT PARAMETERS
OUTPUT PARAMETERS (MAINS MODE)
OUTPUT PARAMETERS (INVERTER MODE)
BATTERY PARAMETERS
USER INTERFACE
PROTECTION
Communication Port
Over/Under Voltage
Overload/Short Ckt
Low/High Battery
Surge Protection
Operating System
Voltage Regulation 200VAC-245VAC
50 ± 0.2Hz
Sine Wave
8 msec
105% for 3 mins, 160% for 5 secs
Frequency Regulation
Output Waveform
Transfer Time (Typical)
Overload Handling Capacity
Input Supply
Voltage range
Frequency Range
1 Phase, 3 Wire
145VAC-295VAC ± 5V
200VAC-255VAC ± 5V
Waveform
Voltage range
Frequency Range
Same as Input
Same as Input
Same as Input
12V
1 ± 0.1AA
Cell / Battery Type
Battery Voltage (Nominal)
Battery Charging Current
12V/7.2AH
Switch to battery O/P when mains is over/under
the specified range
Battery deep discharge / over charge protected
Yes
Fuse & current limited for battery mode,
Fuse protection for mains mode
5. Technical Specifications5. Technical Specifications
REV. 05-02-08
Info Disc
Manager
(9)
Technical
Specifications
(11)
Note : Specifications subject to change without prior notice.
Sine Wave LI UPS

Note : Specifications subject to change without prior notice.
REV. 05-02-08
Technical
Specifications
(12)
SU600WB
600VA/12V
MODEL
CAPACITY
ENVIRONMENTAL PARAMETERS
OTHERS
Protection Class
Dimensions W X D X H (in mm)
Weights (Kg)
LED Indications & Alarm
IP20
6.5
112 x 345 x 150
Indications & Alarm
Acoustic Noise (at 1 mts)
Operating Temperature
Relative Humidity
0-45°C
<50dB
0-90% non-condensing
Sine Wave LI UPS

Model No. :---------------------------------------------
Serial No. :---------------------------------------------
Name of Purchaser :---------------------------------------------
Address :---------------------------------------------
Date of Purchase :---------------------------------------------
Dealer's Name :---------------------------------------------
DEALER STAMP
REV. 05-02-08
(13)
Warranty
Sine Wave LI UPS

Su-Kam warrant to the original purchaser provided the product is still in
possession of and used by the original purchaser from the date of purchase.
The warranty stands on all parts (except LED's, switches and external body)
for UPS will be for a period of 12 months.
The warranty will be automatically terminated on the expiry of the warranty
period, even in case of the UPS no t being in use in the specified period.
This warranty is valid only if it is duly signed by the authorized dealer.
The warranty will be invalidated if defects arising in company's opinion by
reasons of accident, abuse, misuse, neglect, improper installation (if not
undertaken by the company or its representative), fire, flood, or other act of
GOD and any other natural calamities and any other unauthorized repairs
done or carried out will have to be borne by the purchaser. The problem of
fuse blown will not be included in the warranty of the product. The services
given for the same will be paid service.
The company is in no way liable for any loss or injury or damage caused to life
or property or death and disability caused to any form of life for any reason
whatsoever.
The warranty will not apply if the original seals are found broken or tampered
with.
Free service under the terms of warranty will be provided only by authorized
representatives/dealers of the company.
The company expressly denies the right of any person to incur or assure for it
any other liability or obligation in connection with the sale of UPS.
Claims if any, to this warranty shall be made only before courts having
jurisdiction in New Delhi.
Please send your query or Complaint to [e-mail]
TERMS AND CONDITIONS OF WARRANTY
REV. 05-02-08
Warranty
(14)
Sine Wave LI UPS

SU-KAM POWER SYSTEMS LTD.
FACTORY: 64, DIC INDUSTRIAL AREA, BADDI, DISTT. SOLAN (H.P) INDIA
CORP OFF.: 54, SECTOR-37,PH-VI,DISTT. GURGAON (HARYANA) INDIA
REGD.OFF.: WZ-1401/2, NANGAL RAYA , NEW DELHI-46
SU-KAM OFFICES ADDRESSES
rd
SCO-215-217, 3 Floor,
Office No. 302,
Sector-34 A,
Chandigarh-160019
Tel.: [phone]
E-mail: [email protected]
CHANDIGARH
389, Bomikhal, Cuttack Puri Road,
Bhubaneshwar- 751006
Orissa
Tel.: [phone]
BHUBANESHWAR
H.No.449, Ground Floor, 7 th Cross,
6th Main, MICO Layout, BTM II Stage,
Bangalore 560076
Karnataka
Tel.: [phone]
E-mail : [email protected]
BANGALORE
Flat No. 1, Govind Kunj,
Civil Line, Near Jabal Fabricator,
Raipur-492001
Chattisgarh
Tel.: [phone]
CHATTISGARH
Old No. 87 & New No-23,
Valluvar Salai, Arumbakkam
Chennai- 600106
Tel: [phone],
09940634442
E-mail: [email protected]
CHENNAI
Door No-27/77; Plot No-188,
8th Cross Road Girinagar,
Cochin, Ernakulam-682020, Kerala
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
COCHIN
203 Padmavati Complex,
Shrenik Park Char Rasta,
BPC Road, Akota,
Vadodara-390020
Tel: [phone]
E-mail: [email protected]
VADODARA
Vedwalia, Ward No-15, Bhusa Store,
Near Shiv Mandir, Sharanpur Road,
Village & P.O. Majra,
Deharadun-248001
Uttarakhand
Tel: [phone]
Email: [email protected]
DEHRADUN
WZ-1401/02, Nangal Raya,
Near Lajwanti Garden,
New Delhi-110046
Tel: [phone],
09971497598
Email: [email protected]
DELHI
940, 2nd Floor, Synagogue Street,
Near Railway Reservation Centre
Camp,
Pune-1, Maharashtra
Tel: [phone],
09975496268
Email: [email protected]
PUNE
74/D, Plot No. 1,
Park Road 3,
Ashok Nagar,
Ranchi-834002
Jharkhand
Tel: [phone]
Email: [email protected]
RANCHI
13/7, Site No. 3,
Meerut Road, Industrial Area-3,
Near Uttam Toyota,
Ghaziabad-201001
Uttar Pradesh
Tel: [phone],
9997797852
E-mail: [email protected]
GHAZIABAD
Plot No. 81, Syndicate Bank Colony
West Marredpally,
Secunderabad-500 026
Andhra Pradesh
Tel.: [phone]
E-mail: [email protected]
HYDERABAD
R-2, Near 8 Rasta Chowk,
Laxmi Nagar,
Nagpur-440022
Tel: [phone]
Email: [email protected]
NAGPUR
D-3, Jula Niketan,
West Boring Canal Road,
Anand Puri,
Patna-800001,
Bihar
Tel: [phone]
Email: [email protected]
PATNA
Malik Market, Channi Rama,
Bye Pass Road,
Jammu - 180004
J&K
Tel: [phone]
E-mail: [email protected]
JAMMU
403, 404 Gopala Chambar
4th Floor, Parade,
Kanpur
Tel: [phone]
Email: [email protected]
KANPUR
8th Floor, Room No-14,
Shanti Niketan Building,
8 Camac Street,
Kolkata-17,
West Bengal
Tel: [phone]
Email: [email protected]
KOLKATA
15, RNA Arcade, 1st Floor,
Cross Lane No. 3,
Lokhandwala Complex,
Andheri (West),
Mumbai - 400058
Email: [email protected]
Tel: [phone]
Fax: [phone]
MUMBAI
206, Adarsh Plaza Khasa,
Kothi Crossing, SJS Highway,
Jaipur
Rajasthan
Tel: [phone]
E-mail: [email protected]
JAIPUR
INDORE
F-47, MIG Colony,
Near Criestean Eminent School,
Indore 452001
Madhya Pradesh
Tel: [phone]
E-mail: [email protected]
PKG-ML-095
