Su-Kam DSP SINEWAVE User manual

USER'S MANUAL (IFU)
GLOBAL CERTIFICATIONS:GLOBAL CERTIFICATIONS:
GOVERNMENT OF INDIAGOVERNMENT OF INDIA
MINISTRY OF SCIENCE & TECHNOLOGYMINISTRY OF SCIENCE & TECHNOLOGY
R&DR&D
Recognised Recognised
ISO 14001:2004
DSP SINE WAVE HOME UPS
Salient Features
!Designed Using World's Most Advanced DSP Technology.
!Runs Computer Along With Other Appliances.
!User Selector Switch for Computer / Air-Conditioner Operation.
!Fuzzy Logic Controlled Five Stage Battery Charger.
!Dual Selection for Battery Charging .
!User Friendly LCD Panel.
!Battery Water Topping Reminder.
!Smart Overload & Short Circuit Protection.
!Automatic Protection For High and Low Voltage.
!Smart Thermal Management.
!Great Power Saving.
Before connecting, operating, or adjusting this unit, please read this instruction booklet carefully .
Customer care: +91 - 124 - 4170561-566
PKG-ML- 098
SU-KAM POWER SYSTEMS LTD.
FACTORY: 64, DIC INDUSTRIAL AREA, BADDI, DISTT. SOLAN (H.P) INDIA
CORP OFF.: 54, SECTOR-37,PH-VI,DISTT. GURGAON (HARYANA) INDIA
REGD.OFF.: WZ-1401/2, NANGAL RAYA , NEW DELHI-46
SU-KAM OFFICES ADDRESSES
rd
SCO-215-217, 3 Floor,
Office No. 302,
Sector-34 A,
Chandigarh-160019
Tel.: [phone]
E-mail: [email protected]
CHANDIGARH
389, Bomikhal, Cuttack Puri Road,
Bhubaneshwar- 751006
Orissa
Tel.: [phone]
BHUBANESHWAR
H.No.449, Ground Floor, 7 th Cross,
6th Main, MICO Layout, BTM II Stage,
Bangalore 560076
Karnataka
Tel.: [phone]
E-mail : [email protected]
BANGALORE
Flat No. 1, Govind Kunj,
Civil Line, Near Jabal Fabricator,
Raipur-492001
Chattisgarh
Tel.: [phone]
CHATTISGARH
Old No. 87 & New No-23,
Valluvar Salai, Arumbakkam
Chennai- 600106
Tel: [phone],
09940634442
E-mail: [email protected]
CHENNAI
Door No-27/77; Plot No-188,
8th Cross Road Girinagar,
Cochin, Ernakulam-682020, Kerala
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
COCHIN
203 Padmavati Complex,
Shrenik Park Char Rasta,
BPC Road, Akota,
Vadodara-390020
Tel: [phone]
E-mail: [email protected]
VADODARA
Vedwalia, Ward No-15, Bhusa Store,
Near Shiv Mandir, Sharanpur Road,
Village & P.O. Majra,
Deharadun-248001
Uttarakhand
Tel: [phone]
Email: [email protected]
DEHRADUN
WZ-1401/02, Nangal Raya,
Near Lajwanti Garden,
New Delhi-110046
Tel: [phone],
09971497598
Email: [email protected]
DELHI
940, 2nd Floor, Synagogue Street,
Near Railway Reservation Centre
Camp,
Pune-1, Maharashtra
Tel: [phone],
09975496268
Email: [email protected]
PUNE
74/D, Plot No. 1,
Park Road 3,
Ashok Nagar,
Ranchi-834002
Jharkhand
Tel: [phone]
Email: [email protected]
RANCHI
13/7, Site No. 3,
Meerut Road, Industrial Area-3,
Near Uttam Toyota,
Ghaziabad-201001
Uttar Pradesh
Tel: [phone],
9997797852
E-mail: [email protected]
GHAZIABAD
Plot No. 81, Syndicate Bank Colony
West Marredpally,
Secunderabad-500 026
Andhra Pradesh
Tel.: [phone]
E-mail: [email protected]
HYDERABAD
R-2, Near 8 Rasta Chowk,
Laxmi Nagar,
Nagpur-440022
Tel: [phone]
Email: [email protected]
NAGPUR
D-3, Jula Niketan,
West Boring Canal Road,
Anand Puri,
Patna-800001,
Bihar
Tel: [phone]
Email: [email protected]
PATNA
Malik Market, Channi Rama,
Bye Pass Road,
Jammu - 180004
J&K
Tel: [phone]
E-mail: [email protected]
JAMMU
403, 404 Gopala Chambar
4th Floor, Parade,
Kanpur
Tel: [phone]
Email: [email protected]
KANPUR
8th Floor, Room No-14,
Shanti Niketan Building,
8 Camac Street,
Kolkata-17,
West Bengal
Tel: [phone]
Email: [email protected]
KOLKATA
15, RNA Arcade, 1st Floor,
Cross Lane No. 3,
Lokhandwala Complex,
Andheri (West),
Mumbai - 400058
Email: [email protected]
Tel: [phone]
Fax: [phone]
MUMBAI
206, Adarsh Plaza Khasa,
Kothi Crossing, SJS Highway,
Jaipur
Rajasthan
Tel: [phone]
E-mail: [email protected]
JAIPUR
INDORE
F-47, MIG Colony,
Near Criestean Eminent School,
Indore 452001
Madhya Pradesh
Tel: [phone]
E-mail: [email protected]
PKG-ML- 098
SeriesSeries

DSP Sine Wave Home UPS
ContentsContents
1 Introduction........................................................................................................1
2. Knowing Your DSP Sine Wave Home UPS....................................................2
a) Front Panel .............................................................................................2-7
b) Back Panel ..............................................................................................7-8
3. Quick Installation Guide ............................................................................9-10
4. Enhanced Features ....................................................................................10-11
5. Trouble Shooting .......................................................................................12-13
6. Our Recommendations .................................................................................14
7. Technical Specification .. ...........................................................................15-16
8. Warranty.....................................................................................................17-18
REV. 25-04-08
Contents

Introduction
(1)
Dear Customer,
We feel immense pleasure that you are now proud owner of Su-Kam DSP
Sine Wave Home UPS, Fusion Series designed and developed using state of
the art DSP technology .
The Distinguished Features of Su-Kam DSP Sine Wave Home UPS are:
IntroductionIntroduction
DSP Sine Wave Home UPSDSP Sine Wave Home UPS
!Designed Using World's Most Advanced DSP Technology.
!Runs Computer Along With Other Appliances.
!User Selector Switch for Computer / Air-Conditioner Operation.
!Fuzzy Logic Controlled Five Stage Battery Charger.
!Dual Selection for Battery Charging .
!User Friendly LCD Panel.
!Battery Water Topping Reminder.
!Smart Overload & Short Circuit Protection.
!Automatic Protection For High and Low Voltage.
!Smart Thermal Management.
!Great Power Saving.
REV. 25-04-08

Knowing Your DSP Sine Wave Home UPSKnowing Your DSP Sine Wave Home UPS
A) DESCRIPTION OF FRONT PANEL:
On the front panel of DSP Sine Wave Home UPS there is one UPS ON/OFF
switch and a LCD panel.
PARAMETERS DISPLAYED ON LCD PANEL OF DSP SINE WAVE
HOME UPS
1. Mains not Available & Home UPS Switch in OFF Condition.
In its most basic form, a Home UPS transforms Direct Current (DC) to
Alternating Current (AC). The battery bank with the UPS acts, as a reservoir
to ensure continuous supply of power whenever supply from utility power is
not available.
FAN STATUS : OFF
UPS TEMP : NORMAL
d.
CHARGING CURRENT
SELECTION AT 12A OR16A
a. WELCOMES YOU
MAINS FAIL
SWITCH ON UPS
b. c. MAINS FAIL
UPS SWITCH OFF
2. Mains not available & Home UPS Switch in ON Condition.
Whenever there is no mains & Home UPS is switched ON, Home UPS
performs Self-Test for once to check the status of the Home UPS. If
there is any fault, Short Ckt., Over Load the display shows only the fault
after Welcome Note.
Front Panel
(2)
DSP Sine Wave Home UPSDSP Sine Wave Home UPS
SU-KAM
SELF TEST
PASS
DSP SINE WAVE
UPS
k.
If self test fails then
restart the system
once or twice. If still
the problem exist call
the Service Engineer.
H/W Rev. : ___
S/W Rev. : ___
H / W a n d S / W
Revision
a.
b.
c.
d.
SYSTEM CAPACITY
........ VA
SELF TEST IN
PROGESS.....
LCD SELF TEST
WELCOMES YOU
System checks itself
for any fault before
s t a r t i n g i n t h e
following sequence.
e.
The above five message keeps scrolling on the LCD panel displaying Home
UPS Parameters one by one in the sequence shown above till Mains Input
recovers.
3. Mains available & Home UPS Switch in ON Condition.
After The Above Messages, Following Messages are Displayed in Cyclic Order:
a. MAINS FAIL
UPS ON c. O/P VOLT : ___V
O/P FREQ : ___ HZ
d. OUTPUT : 000%
[ ]
e. POWER CUT TIME FAN STATUS : ON
UPS TEMP : NORMAL OR HIGH
b. BATTERY : __V
a. MAINS PRESENT
BATTERY CHARGED
Displays Battery status in mains
mode. Whether Batter y is
charging or Charged.
I/P VOLT : ___V
I/P FREQ : ___ HZ
b.
Mains Input voltage & Frequency.
c. CHARGING CURRENT
SELECTION AT16A
DSP Sine Wave Home UPSDSP Sine Wave Home UPS
(3)
Front Panel
SU-KAM
BATTERY ..... V
e. f.
f.
BUZZER TEST
BATTERY : __ V
DSP TEST
O.K.
g.
LCD display shows all
digits as shown above.
Either buzzer O.K. or
Faulty.
h.
Battery Voltage.
i.
j.
HR : MIN : SEC
MODE : UPS/W-UPS
f. g.
REV. 25-04-08REV. 25-04-08

d.
FAN STATUS : ON OR OFF
UPS TEMP : NORMAL OR HIGH
e.
or
BATTERY CHARGING
[ ]
BATTERY CHARGED
[ ]
Under Various Protection Condition
I. Overload Occuring -With Buzzer Beep 2. Overload Shutdown
Occurred
a. * ATTENTION *
OVERLOAD > 100% b.
** REMEDY **
REDUCE SOME LOAD
c.
* PROTECTION *
OVERLOAD SHUTDOWN
d. REDUCE LOAD AND
RESTART UPS
This display shows that Home UPS is in Over Load Condition (condition I,
See above), i.e., the running load (VA) on the Home UPS is above the rated
system capacity, In this case system resets itself automatically and makes 4
attempts to turn ON again. If the overload continues even after the 4th
attempts, it turns OFF permanently (condition 2 above) and will turn ON
after the switch on the front panel is turned OFF and then turned ON.
3. Short Circuit Occurred - With Buzzer Beep
This Display shows that Short Circuit has occurred in the Output and Home
UPS has gone into Shutdown immediately with continuous buzzer beep.
Switch OFF the Home UPS. Switching OFF Home UPS will stop beeping the
buzzer immediately. Now remove Short-circuit and then switch ON the
Home UPS.
Repeatedly switching ON the Home UPS when short circuit
Note : -
is present at the output may damage the Home UPS.
* PROTECTION *
SHORT CKT. / OVERLOAD
CHECK WIRING AND REDUCE LOAD AND RESTART UPS
** REMEDY **
DSP Sine Wave Home UPSDSP Sine Wave Home UPS
Front Panel
(4)
4. Low Battery Attention - With Buzzer Beep
This display is shown when battery goes down to a limit during discharge. It
will start displaying (Condition 4, See above) When battery voltage falls
below 20% of its rated capacity. The buzzer will start beeping and the Home
UPS will Shut off after few minutes. In this condition Home UPS will make
four attempts to restart again and if low battery continues, it turns off
permanently (condition 5). It will turn ON only when ON/OFF switch on the
front panel is turned OFF and then switched ON.
* ATTENTION *
BATTERY LOW
** REMEDY **
REDUCE LOAD OR SHUTDOWN UPS
6. Mains MCB Trip
This Display shows when the Mains MCB Trips.
First Switch OFF The Mains and Home UPS then Switch ON MCB and Reset
the Switch to ON.
7. Mains Low Cut (UPS Switch ON)
This display shows Mains Low cut protection. In this condition system comes
on Home UPS mode and the Mains will get cut off. The above message keep
on scrolling on the LCD panel displaying above parameters one by one till
Mains recover.
* PROTECTION *
MAINS MCB TRIP
** REMEDY **
SWITCH ON THE MCB
AT BACK PANEL
& RESET THE SWITCH
5. Low Battery Protection - Without Buzzer Beep
* PROTECTION *
BATTERY LOW
DSP Sine Wave Home UPSDSP Sine Wave Home UPS
MODE : UPS/W-UPS
f.
MAINS LOW CUT
UPS ON
O/P VOLT : ___V
O/P FREQ : ___HZ
a. b. c.
d. POWER CUT TIME
HH : MM : SS
e. FAN STATUS OFF
UPS TEMP : NORMAL / HIGH
f.
O/P LOAD : ...........%
[ ]
BATTERY : ___V
[ ]
MODE : UPS/W-UPS
g.
(5)
Front Panel
REV. 25-04-08REV. 25-04-08

8. Mains Low Cut (UPS Switch OFF)
In this condition the system gets permanently shutdown but battery keeps
charging with 2-3 amps up to Main input voltage 140 Volts.
CHARGING CURRENT
SELECTION AT 12 A
CHARGING CURRENT
SELECTION AT 16 A
9. Mains High Cut (UPS Switch ON)
This Display shows Mains High Cut protection. In this condition, the system
comes on Home UPS mode and the mains will get cut off. The above
message keep on scrolling on the LCD panel displaying above parameters one
by one till Mains recover.
10. Mains High Cut (UPS Switch OFF)
In this condition the system gets permanently shutdown. For using, Home
UPS should be switched ON if the battery is charged.
DSP Sine Wave Home UPSDSP Sine Wave Home UPS
11. Charging Current Change With Selection Switch
* PROTECTION *
OVER TEMPERATURE
ROUTINE REMINDER
PL. CHECK BATTERY
WATER LEVEL &
RESTART UPS
B) DESCRIPTION OF BACK PANEL
1) Mains Input MCB : This isolates mains input from Home UPS.
2) Battery MCB : This isolates battery from Home UPS.
3) Maintenance Bypass Rotary Switch : A three position rotary
switch is provided for
(i) Home UPS Output (ii) Output OFF (iii) Bypass
1) Home UPS Output: This is the normal running position, when
output is fed to the load.
2) Output OFF: The output of system is disconnected from load.
3) Bypass: The load is bypassed from Home UPS and is connected to
Mains Supply only.
4) Battery Charging Selection Switch : Selector switch to adjust the
battery charger for different battery capacity. Set 12A for 100 - 150 Ah
Battery and 16A for 160 - 200Ah Battery. In case of frequent power cut,
set the switch Position at high charging current (16A) to charge your
batteries in lesser time.
DSP Sine Wave Home UPSDSP Sine Wave Home UPS
(7)
Front Panel
&
Back Panel
MAINS LOW CUT
UPS SWITCH OFF
I/P VOLT : ___V
I/P FREQ : ___HZ
a. b. c.
d. BATTERY : ___V FAN STATUS : OFF
UPS TEMP : NORMAL/HIGH
e. MODE : UPS/W-UPS
f.
[ ]
MAINS HIGH CUT
UPS ON
O/P VOLT : ___V
O/P FREQ : ___HZ
a. b. c.
d. POWER CUT TIME
HH : MM : SS
e. FAN STATUS ON
UPS TEMP : NORMAL / HIGH
f.
O/P LOAD : ...........%
[ ]
BATTERY : ___V
[ ]
MODE : UPS/W-UPS
g.
FAN STATUS : ON
UPS TEMP.: HIGH
PL. CHECK FAN AT
THE BACK PANEL
a. b.
b.
c.
* ATTENTION *
CHARGING CURRENT
STATUS CHANGED
RESTART UPS
Front Panel
(6)
MAINS HIGH CUT
UPS SWITCH OFF
I/P VOLT : ___V
I/P FREQ : ___HZ
a. b. c.
d. BATTERY : ___V FAN STATUS : OFF
UPS TEMP : NORMAL/HIGH
e. MODE : UPS/W-UPS
f.
[ ]
a. b. FROM FRONT PANEL
TO ACTIVATE
c.
a.
TEMP. SENSOR FAIL
* ATTENTION *
This is displayed when system is overheated.
14. After Every 3 Months Routine Reminder is Displayed
12. Over Temp. Protection with Buzzer Beep
13. Temperature Sensor Fail Condition
This is Displayed when charging selection switch at back panel is toggled,
Restart Home UPS to activate the changed charging current.
REV. 25-04-08REV. 25-04-08

5) Selection of Switch for UPS / W-UPS Mode :
If you want to run PC load select the switch to UPS mode.
Other wise keep the switch to W-UPS mode.
6) Input Terminal Block.
7) Output Terminal Block.
BACK PANEL
(8)
Back Panel
DSP Sine Wave Home UPSDSP Sine Wave Home UPS
Quick Installation Guide
1) Mount the Home UPS securely in horizontal position in a clean, dry and
ventilated enclosure.
2) Ensure that the front panel ON/OFF switch and battery MCB at the
rear panel is in OFF position before you begin the installation.
3) Connect the positive terminal of the battery to the positive wire (RED)
of the Home UPS and negative terminal to negative wire (BLACK) of
the Home UPS. Immediately check the connections & switch ON
Battery MCB.
4) Now connect the Output terminal to the load.
5) Switch ON the front panel switch and run the load without AC input
Power. Place a load on the Home UPS and make sure it works.
6) Connect AC input supply to the input terminal such that Line is
connected to the terminal marked 'L' ; Neutral is connected to terminal
marked 'N' and Earth is connected to the Earth terminal marked 'E'.
7) Switch ON the mains MCB & Home UPS should now show 'Mains
Present, Battery Charging' on the LCD. After the delay for mains
synchronization (approx. 30Sec), the load is connected to mains &
simultaneously the Battery starts charging.
8) Now disconnect the AC input power, the load should be transferred to
the Home UPS mode immediately.
Quick Installation Guide
Quick
Installation
Guide
(9)
DSP Sine Wave Home UPSDSP Sine Wave Home UPS
1
2
3
5
4
67
REV. 25-04-08REV. 25-04-08

NOTE: - Never disconnect the battery cables while Home UPS is delivering
power or battery charger is operating. The ON/OFF switch has no effect on
the charger, it turns OFF only the Home UPS. To disconnect the batteries for
service
a) Turn OFF the power switch.
b) Disconnect all AC power.
c) Disconnect all the battery cables.
Enhanced Features
!Battery Management Protocol (BMP)
Su-kam Home UPS has highly advanced battery management
algorithm that is designed to prevent damage to batteries and extend the
useful life of your batteries by regulating the charging voltage and current.
Batteries can overheat if the charge rate is too high.
!ATM Charger
ATM stands for Auto Trickle Mode. ATM with pulse charger is used
for the first time in Home UPS. ATM with pulse charger, charges the
battery to its full capacity and after charging, it maintains the battery at its
float voltage level, so the water loss in battery is very less.
!Auto Reset
Su-Kam Sine Wave Home UPS has auto reset function in case of
Overload, Low battery. It will reset the Home UPS in fault condition
automatically and will make 4 attempts for the same.
!Automatic Protection
Low battery cutout, high battery cutout, over current and short circuit..
Enhanced Features
Installation
&
Enhanced
Features
(10)
DSP Sine Wave Home UPSDSP Sine Wave Home UPS
!Intelligent Thermal Control
Su-Kam Sine Wave Home UPS senses the overheating and displays the
warning with buzzer beep. It also automatically shutdown the Home UPS
in case of over temperature.
!Auto Power Saving
Fan control system takes care of operation of fan when ever necessary.
This saves your power and also enhances the life of fan.
!AC Mains Cut-Out
Su-Kam Sine Wave Home UPS continuously monitors the AC mains
Voltage. When AC voltage falls below the preset level, the Home UPS
automatically transfers from AC to DC power. This cut out voltage is
Factory preset as Per technical specification mentioned on Page 15.
Enhanced
Features
(11)
DSP Sine Wave Home UPSDSP Sine Wave Home UPS
REV. 25-04-08REV. 25-04-08

SYMPTOMS RECTIFICATIONS
Home UPS mode, but no output Check the position of rotary switch at
the back panel.
Check if over temp. Shutdown
protection is displayed. Allow the unit
to cool down.
Check if low battery protection is
displayed. Allow the battery to
charge.
Check if overload/short circuit
protection is displayed. Reduce load
and switch OFF/ON front panel
switch. Check wiring for short
circuit.
Mains power is coming. Home UPS
shows MCB trip on its LCD
Panel.
Short circuit protection at the
time of installation.
Buzzer beeps continuously with .
'Charging current status changed'
message is displayed.
Reduce load and switch ON mains
MCB at the rear panel and restart
Home UPS
If again the MCB trips, then Please
check the mains wiring for short
Circuit and call our customer care.
Input mains is connected to the output of
the Home UPS. Please check & correct
the Wiring Immediately
Battery Charger status is changed from
back panel. To activate restart Home UPS,
else change the position of switch to
previous mode.
Trouble shooting Trouble shooting
Trouble
Shooting
(12)
DSP Sine Wave Home UPSDSP Sine Wave Home UPS
Trouble shooting Trouble shooting
SYMPTOMS
Buzzer beeps with 'UPS Temp: High'
& message is displayed.
Fan is not Running
LCD displays 'Routine Reminder:
PI check battery water level &
restart Home UPS along with
Buzzer beeps
Check fan at the back panel. Shutdown
UPS & allow it to cool down.If
problem is repeated continuously,
Please call our customer care.
Check the fan status at display panel, if
fan status : OFF, then intelligent fan
control mode is active. ELSE if fan
status : ON, then call our customer
care.
This is a routine reminder that repeats
after every 3 months. Please check
battery water Level, do water topping
& restart Home UPS. To ignore reset
Home UPS.
RECTIFICATIONS
Trouble
Shooting
(13)
DSP Sine Wave Home UPSDSP Sine Wave Home UPS
REV. 25-04-08REV. 25-04-08

Our Recommendations
[ Never use Automobiles Batteries with your Home UPS. They are not
suitable for these applications.
[ Always use Deep cycle batteries that are best suited for Home UPS.
[Place the battery charger switch to 12A for (100-150Ah) and 16A for
(160-200Ah).
[In case of frequent power cuts or in winters you may switch to 16A
charging selection for fast charging of batteries.
[Always check the water level in batteries, when ever reminder for
battery water topping (after every 3 months) occurs. This will keep your
batteries in good condition & also enhance its life.
[Use good quality wires with Input and Output power terminals.
Recommended wire ratings are
Capacity DC Voltage Input Output Battery Wire
2.5KVA 48 4 mm 2.5 mm 10 mm
3.5KVA 48 6 mm 4 mm 16 mm
5KVA 96 8 mm 6 mm 16 mm
!Never disconnect battery wires or switch OFF battery MCB while
Home UPS or battery charger is operating.
Our Recommendations
(14)
Our
Recommendations
DSP Sine Wave Home UPSDSP Sine Wave Home UPS
Technical Specifications Technical Specifications
W-UPS (Wide UPS Mode) :
Mains AC Lower Voltage Limit : 140V+5V
Mains AC Lower Recovery Voltage : 150V+5V
Mains AC Higher Voltage Limit : 270V+5V
Mains AC Higher Recovery Voltage : 260V+5V
Mains AC Lower Voltage Limit : 180V+5V
Mains AC Lower Recovery Voltage : 190V+5V
Mains AC Higher Voltage Limit : 260V+5V
Mains AC Higher Recovery Voltage : 265V+5V
OUTPUT PARAMETERS ( UPS Mode ) :
Output Voltage : 220V+5%
Output Freq. : 50Hz +0.3Hz
Output Freq in Mains mode : Same as Input
Change Over Time : < 10ms
BATTERY PARAMETERS :
DSP Controlled PWM charging with soft start over full range of mains. (140V
to 270V)
Maximum Charging current limit (Switch Selectable) : 12A+1A or 16A+1A
Max. Float Voltage Level : 13.7V+0.2V/Battery
Max. Boost Voltage Level : 14.3V+0.2V/Battery
Battery Low Voltage Limit : 10.0V+0.2V/Battery
Battery Type : 12V (SMF / Flooded)
Technical
Specifications
(15)
DSP Sine Wave Home UPSDSP Sine Wave Home UPS
UPS Mode :
2
2
2
22
22
2 2
INPUT PARAMETERS
MODEL : FUSION SERIES
REV. 25-04-08REV. 25-04-08

Capacity DC Voltage Dimensions(DxWxH) Weight
2.5KVA 48 395 245 350 27.3 Kg
3.5KVA 48 395 245 350 31.5 Kg
5KVA 96 450 245 425 45.0 Kg
(16)
DSP Sine Wave Home UPSDSP Sine Wave Home UPS
DEALER STAMP
Model No. :---------------------------------------------
Serial No. :---------------------------------------------
Name of Purchaser :---------------------------------------------
Address :---------------------------------------------
Date of Purchase :---------------------------------------------
Dealer's Name :---------------------------------------------
SeriesSeries
Warranty
(17)
DSP Sine Wave Home UPSDSP Sine Wave Home UPS
REV. 25-04-08REV. 25-04-08
Technical
Specifications
ENVIRONMENTAL:
Acoustic Noise : <50 dB
Operating Temperature : 0 to 40 C
Storage Temperature : 0 to 45 C
Relative Humidity : 0 to 95% Non-condensing
TECHNOLOGY :
DSP based state of the art technology using MOSFETs.
DSP controlled Fuzzy logic battery charger for optimum charging &
enhanced battery life.
MECHANICAL:
„
„
*Note: Due to Continuous product improvement specifications are subject to
change without prior notice*

SU-KAM POWER SYSTEMS LIMITED warrant to the original purchaser
provided the product is still in possession of and used by the original
purchaser from the date of purchase.
The warranty stands on all parts (except LCD's, switches and external body)
for Home UPS will be for a period of 24 months.
The warranty will be automatically terminate on the expiry of the warranty
period, even in case of the Home UPS no t being in use in the specified period.
This warranty is valid only if it is duly signed by the authorized dealer.
The warranty will be invalid if defects arising in company's opinion by reasons
of accident, abuse, misuse, neglect, improper installation (if not undertaken
by the company or its representative), fire, flood, or other act of GOD and
any other natural calamities and any other unauthorized repairs done or
carried out will have to be borne by the purchaser. The problem of fuse blown
will not be included in the warranty of the product. The services given for the
same will be paid service.
The company is in no way or will be held liable for any loss or injury or damage
caused to life or property or death and disability caused to any form of life for
any reason whatsoever.
The warranty will not apply if the original seals are found broken or tampered
with.
Free service under the terms of warranty will be provided only by authorized
representatives/dealers of the company anywhere in India.
The company expressly denies the right of any person to incur or assure for it
any other liability or obligation in connection with the sale of Home UPS.
Claims if any, to this warranty shall be made only before courts having
jurisdiction in New Delhi.
Please send your queries, Complaints or Suggestions to info@su-
kam.com or Customer care no: [phone]
Terms and conditions of warrantyTerms and conditions of warranty
Warranty
(18)
DSP Sine Wave Home UPSDSP Sine Wave Home UPS
REV. 25-04-08
"
