Sub-Zero 611 User manual

Model 611 is our smallest combination
refrigerator/freezer. The 30" width enables
this model to be installed in the smallest
galley kitchen. The Sub-Zero dual refriger-
ation system assures superior food
preservation and no odor transfer. Model
611 is available in the framed, overlay and
stainless steel design applications and in
three stainless steel finishes.
Built-In Model 611
Over-and-Under
Features
Framed, overlay and stainless steel design
applications
Stainless steel design available in classic,
platinum and carbon finishes
Energy Star qualified
Dual refrigeration system
Electronic digital controls
Bright interior lighting
Adjustable, spill-proof glass shelves and
adjustable door shelves
High-humidity crisper drawer with
removable divider
Door alarm
Automatic ice maker
Front venting allows unit to be completely
built in and serviced from the front
With the installation of a harness kit, this
appliance is certified by Star-K to meet
strict religious regulations in conjunction
with specific instructions found on
www.star-k.org.
Model Options 611/F 611/O 611/S 611/P 611/B
Design/Finish Framed Overlay Classic Platinum Carbon
Louvered Grille
Panel Grille – Accepts Decorative Inserts
Heavy-Duty Stainless Steel Grille
Interior Features
Refrigerator
3 Adjustable Glass Shelves
1 Stationary Glass Shelf
High Humidity Compartment with Divider
Adjustable Roll-Out Deli Basket
2 Adjustable Door Shelves
Adjustable Dairy Compartment
Egg Container
Freezer
Full-Extension Roll-Out Freezer Drawer
Two-Tier Wire Storage Baskets
Automatic Ice Maker
Classic Stainless SteelFramed Overlay
Accessories
Louvered, panel and stainless steel
(classic, platinum and carbon) grilles in 1"
height increments from 10" to 15"
11" Heavy-duty classic stainless steel grille
(standard on classic stainless steel units)
Front and grille panels for framed design
(white and classic stainless steel)
Side panels in white and classic
stainless steel
Extended full-length framed handles
Stainless steel (classic, platinum and
carbon) tubular handles for overlay design
Polished chrome handles for overlay design
Gallon door shelf
Dozen egg container with lid
Accessories are available through your Sub-Zero
dealer. To obtain local dealer information, visit the
Locator section of our website, subzero.com.
Classic CarbonPlatinum

Installation Notes
For framed and overlay models, you will be
adding door panels for a custom look. Overlay
models also allow you to match surrounding
cabinetry hardware and the panel grille
accepts custom panel inserts.
Complete installation specifications, including
panel sizes, can be found on our website,
subzero.com.
Unit dimensions may vary by ±
1
/ 8 ".
30"
(762)
24"
(610)
84"
(2134)
301/8"
(765)
30"
(762)
291/4"
(743)
237/8"
(606)
BEHIND
FRAME
3/8" (10)
FRAME
EXTENSION
Specifications
Overall Width 30"
Overall Height (with standard 11" grille) 84"
Overall Depth 24"
Door Swing Clearance 301/8"
Refrigerator Capacity 12.7 cu ft
Freezer Capacity 3.9 cu ft
Opening Width 291/2"
Opening Height 833/4"*
Minimum Height Required 83"
Opening Depth 24"
Electrical Requirements 115 V AC, 60 Hz
15 amp dedicated circuit
Plumbing Requirements 1/4" OD copper line
20–100 psi
Annual Energy Usage $42**
Shipping Weight Framed – 430 lbs
Overlay – 430 lbs
Stainless Steel – 462 lbs
*Height with standard 11" grille.
**Based on 9.06 cents per kilowatt hour.
833/4"
(2127)
ROUGH
OPENING
HEIGHT
WITH
STANDARD
11" (279)
GRILLE
751/2"
(1918)
7"
(178)
6"
(152)
291/2"
(749)
ROUGH OPENING WIDTH
24"
(610)
ROUGH
OPENING
DEPTH
E
3"
(76) 18"
(457)
W
LOCATE WATER SUPPLY
WITHIN SHADED AREA
LOCATE ELECTRICAL
WITHIN SHADED AREA
6"
(152)
SHUT-OFF
VALVE
EXTEND WATER LINE
APPROX. 36" (914)
FROM BACK WALL
FRONT VIEW
TOP VIEW
Installation Specifications
Overall Dimensions
Built-In Model 611
Over-and-Under
Dimensions in parentheses are in
millimeters unless otherwise specified.
