Sub-Zero Built-in Series User manual

WARNING
Built-In units are heavy and can be unstable when
attempting to install them. When moving a Built-In unit,
keep the doors and drawers taped closed. The anti-tip
components supplied with Built-In units must be used as
specified in the installation guide. The front leveling legs of
a Built-In unit must be extended to the floor to complete
the installation. If a Built-In unit were to tip and fall, it could
cause serious injury or death!
CONTENTS
4 Bolt, Tensilock 5/16-18 × 3/4
1 Clip, cord plastic 5/16 × 1/2
6 Screw, #8-32 × 1/2pan head
4 Threaded insert, 5/16-18 hx opn
1 Trim, dual install center long
1 Bracket, dual install bot
4 Screw, 5/16 × 3/4thread-forming
1 Bracket, dual install top
3 Bracket assembly, dual trim
1 Threaded insert, install tool
1 Heater assembly, dual installation
1 Shim, assembly main frame
6 Nut, 10-24 hex flange lock
1 Machine screw, #10-24 × 21/4
1 Nut, #10-24 with nylon insert
1 Instructions, dual installation
INSTALL THE HEATER
Note: The heater assembly MUST be attached to the right
side of the left-hand unit.
1Clear the foil from the mounting holes of the heater
assembly.
2Place the heater against the right-hand side of the unit
with wires up and foil side in, positioning the heater 2”
(51 mm) from the top edge of the cabinet and 1” (25
mm) from the rear edge of the cabinet.
3Using the heater as a template, mark the heater
mounting holes on the cabinet with a pencil, then
remove the heater.
4Drill a 7/64" (3 mm) hole at each marked location.
Note: To avoid drilling through the inner liner, use a
short drill bit inserted into the drill chuck so that no
more than 1/2” (13 mm) to 3/4” (19 mm) of bit is
protruding.
5Attach the heater to the unit using the #8-32 × 1/2" pan
head screws into the drilled holes.
6Remove the four-prong safety plug from the panel-
mounted four-prong receptacle at the rear side of
the power cord box.
7Connect the heater’s four-prong plug to the receptacle.
8Attach the 5/16" × 1/2" plastic cord clip in a convenient
location near the water filter.
9Route the heater wires through the plastic cord clip and
any other available wire clips.
1”
2”
Power Cord Box and
4-Prong Heater Plug
Connection (Rear View)
INSTALL THE CENTER TRIM
Note: Assemble the center trim piece and trim brackets
first, then attach the trim to the right-hand side of the left-
hand unit.
1Attach the three L-shaped dual trim bracket assemblies
to the dual install center trim piece using the nuts
provided. Do not tighten the nuts at this time.
Built-In Series Dual Installation Kit
subzero.com 800.222.7820
7004565 REV. E 06/2018 Page 1 of 4 *7004565$REV.$E*

2With the trim brackets loosely attached, hold the center
trim piece at about a 75° angle against the right-hand
side main frame.
3Rotate the center trim piece toward the unit so the trim
brackets hook in behind the main frame.
4Align the bottom of the center trim piece with the
bottom of the main frame.
5Tighten the nuts.
Main
Frame
Center
Trim
(Top View)
Main
Frame
Center
Trim
INSTALL THE UNIT INTO THE LEFT-HAND SIDE OF THE
ROUGH-IN OPENING
Install the unit into the left-hand side of the rough-in
opening as specified in the installation guide.
INSTALL THE MAIN FRAME SHIM
Note: The shim assembly must be attached to the rear of
the left-hand side main frame of the right-hand unit.
1Remove the left-side main frame from the right-hand
unit.
2Remove the backing paper from the double-stick tape
that is attached to the main frame shim.
3Align the shim to the main frame so the two holes in the
shim are at the same height as the two middle main
frame mounting holes. Make sure the shim is tight to
the bend in the main frame, and the shim is in front of
the section of the main frame with the mounting holes.
4Attach the shim to the main frame. Make sure the holes
in the shim are next to but not over the main frame
mounting holes.
5Reattach the left-side main frame to the right-hand unit.
Shim
Left Main Frame
Top View of
Main Frame
and Shim
Built-In Series Dual Installation Kit
subzero.com 800.222.7820
Page 2 of 4

INSTALL THE SECOND UNIT TO THE RIGHT OF THE FIRST
Install, level, and align the unit until its main frame
bumps against the flange of the center trim piece, and
the bottom of the main frame aligns with the bottom of
the center trim piece.
Top View of
Main Frames
with Center
Trim Installed
JOIN THE UNITS TOGETHER AT THE BOTTOM
1Using a 1/2" wrench, install or adjust the bolts at the
bottom adjoining corners of the appliances so that
there is a 1/8" (3 mm) to 1/4” (6 mm) gap between the
bolt heads and the unit shell bottom.
▪For All-Refrigerator and All-Freezer Models:
Loosen the four bolts (two for each unit).
▪For Over/Under Models: Install four 5/16” × 3/4”
thread-forming screws (two for each unit).
2Align the four notches of the dual-installation bottom
bracket with the four bolts at the bottom adjoining
corners of the appliances.
3Push the bracket into position.
4Tighten the bolts.
1/8”-1/4”
Bottom View of Bolts and Bracket
INSTALL THE THREADED INSERTS AT THE TOP (FOR OVER/
UNDER MODELS)
Note: For all-refrigerator and all-freezer models, the
threaded inserts are already installed at the top. Skip these
instructions.
1Open both grilles, and locate the hexagonal holes at
the top adjoining corners of the units (two for each
unit).
2For each of the hexagonal holes:
a) Use a small screwdriver or similar tool to remove
the foam insulation from each hole to a depth of no
more than 1/2” (13 mm).
b) Screw the thread insert installation tool into a
threaded insert.
c) Position the threaded insert over one of the
hexagonal holes, and tap the threaded insert into
the hole.
d) Using a 1/2" wrench at the tool bolt top and a 9/16”
open-end wrench at the collar, spin the tool bolt
clockwise while holding the collar stationary. Stop
when it will spin no further.
e) Remove the tool from the insert.
(Grilles removed
for clarity)
Tool Bolt
Tool Collar
Insert
Hexagonal Hole
Built-In Series Dual Installation Kit
subzero.com 800.222.7820
Page 3 of 4

3Tighten the bolts.
(Grilles
removed
for clarity)
SECURE THE GRILLE FRAMES TOGETHER
1Secure the grilles together by inserting the #10-24 ×
21/4" machine screw into the upper rear holes in the
grille brackets.
2Attach the #10-24 nut to the machine screw, and
tighten it.
3Close the grilles.
#10-24 × 21/4”
Machine Screw
Front View
#10-24 Nut
Built-In Series Dual Installation Kit
subzero.com 800.222.7820
Page 4 of 4
JOIN THE UNITS TOGETHER AT THE TOP
1Working the dual-installation top bracket in from the
side, line up the holes of the top bracket with the
threaded inserts at the top adjoining corners of the
appliances.
2Insert four 5/16-18 × 3/4” Tensilock bolts through the
bracket into the threaded inserts.
