22
Remote Keyless Entry
1. Lock/Arm
 •Presstolockalldoorsandthe
rear gate.
 •Ifanyofthedoorsortherear
gate are not fully closed, an
electronic chirp will sound ve
times and the hazard lights will
ash ve times to alert you that
the doors or the rear gate are
not properly closed.
 •Toactivatethevehiclender
function, press three times
(within ve seconds). If you are
within 30 feet of the vehicle,
the horn will sound one time
and the hazard lights will ash
three times.
Keyless Access
with Push Button
Start System
(if equipped)
By simply carrying the access
key in your pocket, you can
lock and unlock doors, open
the rear gate and start your car
without ever having to take the
keyfob out of your pocket.
2. Unlock/Disarm
 •Pressoncetounlockthe
driver’s door.
 •Presstwice(withinve
seconds) to unlock all doors.
 •Whenthe“Unlock/Disarm”
button is pressed, the dome
and map lights will illuminate
if the dome light switch is in
the middle position.
3. Unlocking the
Rear Gate
Press the button to unlock
the rear gate.
4. Panic Alarm
 •Pressonceandthehornwill
sound and the hazard lights
will ash.
 •Pressanybuttononthe
remote to deactivate.
1
2
3
4
1353095_14a_Subaru_Forester_QRG_021913.indd 2 2/19/13 9:33 AM

3
Getting
Started
Instrument
Panel
Gauges Personalize Controls While
Operating
Safety/In Case
of Emergency
Additional
Information
3
Getting
Started
Seating
10-Way Power Driver’s Seat
(if equipped)
1. Forward/Backward, Angle and Height
Move the switch toward the front or rear to move
the seat forward or backward. Pull the switch up
or push down on the front of the switch to adjust
the angle of the seat cushion. Pulling the switch
straight up or pushing the switch straight down
will adjust the height of the entire seat cushion.
2. Seatback
Move the switch in the corresponding direction
to adjust the angle of the seatback.
3. Lumbar Support
Press the front part of the switch to increase
lumbar support; press the rear part of the switch
to decrease lumbar support.
Heated Seats
(if equipped)
Press the switch in the
corresponding direction for
the desired seat temperature.
To turn off the seat heater,
slightly press in the opposite
direction of the current position.
Folding the
Rear Seat
Lower the headrests. Pull up on
the release knob on the seat side
that you want to fold down. To
return the seatback to its original
position, raise the seatback until
it locks into place, making sure
that it is securely locked.
1
2
3
Getting
Started
1353095_14a_Subaru_Forester_QRG_021913.indd 3 2/19/13 9:33 AM

44
Instrument Panel
pg. 16 pg. 6-9 pg. 29pg. 30 pg. 28pg. 16
1353095_14a_Subaru_Forester_QRG_021913.indd 4 2/19/13 9:33 AM

5
Getting
Started
Instrument
Panel
Gauges Personalize Controls While
Operating
Safety/In Case
of Emergency
Additional
Information
5
pg. 18-21 pg. 22-27pg. 17
Clock
Pressthe“+”buttontoadvancetimeorthe
“–”buttontoreversethetime.Vehicleswitha
navigation system please refer to the separate
“OperatingInstructionsforNavigationSystem.”
Instrument
Panel
1353095_14a_Subaru_Forester_QRG_021913.indd 5 2/19/13 9:33 AM

Trip meter A/B selection and trip meter reset knob
Trip meter and odometer
Forester 2.5i
Forester 2.5i Premium
Tachometer
6
Gauges
Seatbelt warning
Front passenger
seatbelt warning
SRS airbag system
Security indicator light
Door open
Charge warning
Oil pressure warning
Power steering warning
Brake system
Hot coolant temperature /
Cold coolant temperature
High beam indicator light
AT OIL TEMP
(Automatic Transmission)
ABS warning
Low fuel
All-Wheel Drive
(Automatic Transmission)
Windshield washer
uid warning
Immediate Attention
Caution
Informational
1353095_14a_Subaru_Forester_QRG_021913.indd 6 2/19/13 9:33 AM

Information display selection knob
Speedometer
Fuel gauge
7
Getting
Started
Instrument
Panel
Gauges Personalize Controls While
Operating
Safety/In Case
of Emergency
Additional
Information
Gauges
Vehicle Dynamics
Control/Vehicle Dynamics
Control operation
Vehicle Dynamics Control OFF
CHECKENGINE/
Malfunction indicator
Tire pressure warning light
FrontpassengerairbagON
Front passenger airbag OFF
Incline start assist
Engine oil level warning light
Smart key system
(if equipped)
Turn signals
Front fog light indicator
light (if equipped)
Headlight indicator light
Cruise control
indicator light
Cruise control set
indicator light
1353095_14a_Subaru_Forester_QRG_021913.indd 7 2/19/13 9:33 AM

Trip meter A/B selection and trip meter reset knob
8
Gauges
Tachometer
Forester 2.5i Limited
Forester 2.5i Touring
Forester 2.0i XT Premium
Forester 2.0i XT Touring
Immediate Attention
Caution
Informational
Seatbelt warning
Front passenger
seatbelt warning
SRS airbag system
Security indicator light
Door open
Charge warning
Oil pressure warning
Power steering warning
Brake system
Hot coolant temperature /
Cold coolant temperature
High beam indicator light
AT OIL TEMP
(Automatic Transmission)
ABS warning
Low fuel
All-Wheel Drive
(Automatic Transmission)
Headlight leveler
(if equipped)
1353095_14a_Subaru_Forester_QRG_021913.indd 8 2/19/13 9:33 AM

Information display selection knobFuel gauge
9
Getting
Started
Instrument
Panel
Gauges Personalize Controls While
Operating
Safety/In Case
of Emergency
Additional
Information
Gauges
Trip meter and odometer Speedometer
Vehicle Dynamics
Control/Vehicle Dynamics
Control operation
Vehicle Dynamics Control OFF
CHECKENGINE/
Malfunction indicator
Tire pressure warning light
FrontpassengerairbagON
Front passenger airbag OFF
Incline start assist
Engine oil level warning light
Windshield washer
uid warning
Smart key system
(if equipped)
Turn signals
Front fog light indicator
light (if equipped)
Headlight indicator light
Cruise control
indicator light
Cruise control set
indicator light
Hill decent control
(if equipped)
1353095_14a_Subaru_Forester_QRG_021913.indd 9 2/19/13 9:33 AM

10
Personalize
Tilt and Telescopic
Steering Column
Push the lever down rmly to adjust the height
and lengthwise position of the column; rmly
push the lever back up to lock the column in
place. Do not adjust while driving.
Power Exterior Mirrors
Turntheknobtothe“L”sidetoadjustthe
left-handmirrorortothe“R”sidetoadjust
the right-hand mirror. Move the knob in the
direction you want to move the mirror. Then
return the knob to the neutral/center position.
1353095_14a_Subaru_Forester_QRG_021913.indd 10 2/19/13 9:33 AM

11
Getting
Started
Instrument
Panel
Gauges Personalize Controls While
Operating
Safety/In Case
of Emergency
Additional
Information
Personalize
Power Moonroof (if equipped)
With the moonroof in the fully closed position,
press the switch 1to fully open the moonroof.
Press the switch 2to close the moonroof. To
stop the moonroof in a midway position while
opening or closing, momentarily press the
switch to the 1side or 2side.
(EyeSight equipped
vehicles only)
1
2
1353095_14a_Subaru_Forester_QRG_021913.indd 11 2/19/13 9:34 AM

12
Bluetooth for AM/FM Stereo with Single
Disc CD Player and AM/FM Stereo HD
Radio® with Single Disc CD Player
Pairing Your Cell Phone
Press the phone off hook button and listen to phone prompts.
Press the talk button and name your phone.
Press the talk button and follow the phone prompts.
You may need to set the language before pairing your phone.
Phone off hook button
Phone on hook button
Talk button
1353095_14a_Subaru_Forester_QRG_021913.indd 12 2/19/13 9:34 AM

13
Getting
Started
Instrument
Panel
Gauges Personalize Controls While
Operating
Safety/In Case
of Emergency
Additional
Information
Pressthetalkbuttonandsay“Conrm.”
Put your phone into Bluetooth pairing mode and pair your phone to the
system using the pass-key provided. When phone is successfully paired you
willhear“Thephoneispairedandreadyforuse.”
Pass-key for pairing will be given audibly as well as be displayed on the
radio display.
Personalize
1353095_14a_Subaru_Forester_QRG_021913.indd 13 2/19/13 9:34 AM

14
Bluetooth for AM/FM Stereo HD Radio®
with Single Disc CD Player and
Navigation System
Pairing Your Cell Phone
PresstheAUDIObutton;thentouchthe“Info”softkeyonthetouchscreen.
Thentouch“Bluetooth.”
AUDIO button
1353095_14a_Subaru_Forester_QRG_021913.indd 14 2/19/13 9:34 AM

15
Getting
Started
Instrument
Panel
Gauges Personalize Controls While
Operating
Safety/In Case
of Emergency
Additional
Information
Nowtouch“RegisteredDevices.”
When the phone is successfully paired, the screen will show the phone’s
name on the list.
Touch“AddNew.”
Personalize
A pass-key pairing number will appear on the screen. Put your phone into
Bluetooth pairing, search or discoverable mode. Depending on the phone’s
make, model and software; the phone may connect automatically or the pass-key
number may need to be inputted on the phone. Pair your phone to the system.
1353095_14a_Subaru_Forester_QRG_021913.indd 15 2/19/13 9:34 AM

16
Controls
While the light switch is
on, rotate the dial downward
to dim the instrument panel
illumination. Rotate the
dial upward to make the
illumination brighter. When the
dial is fully rotated upward, the
instrument panel illumination
becomes fully bright.
Light Controls
Turns on instrument panel lights,
tail lights, parking lights and license
plate lights.
Turns on headlights,
instrument panel
illumination, parking
lights, tail lights and
license plate lights.
Turns on
fog lights
(if equipped).
Push up for right
turn signal.
Push down for
left turn signal.
1353095_14a_Subaru_Forester_QRG_021913.indd 16 2/19/13 9:34 AM
