This service manual has been prepared to provide
SUBARU service personnel with the necessary infor-
mation and data for the correct maintenance and
repair of SUBARU vehicles.
This manual includes the procedures for maintenance,
disassembling, reassembling, inspection and adjust-
ment of components and diagnostics for guidance of
experienced mechanics.
Please peruse and utilize this manual fully to ensure
complete repair work for satisfying our customers by
keeping their vehicle in optimum condition. When
replacement of parts during repair work is needed, be
sure to use SUBARU genuine parts.
All information, illustration and specifications con-
tained in this manual are based on the latest product
information available at the time of publication
approval.
FUJI HEAVY INDUSTRIES LTD.
2001 LEGACY SERVICE MANUAL QUICK REFERENCE INDEX
SUPPLEMENT FOR 6 CYLINDER
ENGINE MODEL
G2281GE

2001 LEGACY SERVICE MANUAL QUICK REFERENCE INDEX
SUPPLEMENT FOR 6 CYLINDER
ENGINE MODEL
G2281GE

FOREWORD
FW
Page
1. Foreword .....................................................................................................2

1. Foreword SA01674
A: FOREWORD SA01674G21
These manuals are used when performing
maintenance, repair, or diagnosis of the Subaru
Legacy.
Applied model: BE***** and BH***** from 2001MY.
The additional manuals below are also available:
AUTOMATIC TRANSMISSION SERVICE
MANUAL (Pub. No. G0853ZE)
The manuals contain the latest information at the
time of publication. Changes in specifications,
methods, etc. may be made without notice.
FW-2
FOREWORD
Foreword

MEMO:
FW-3
Foreword FOREWORD

FW-4
Foreword FOREWORD

HOW TO USE THIS MANUALS
HU
Page
1. How to Use This Manuals...........................................................................2

1. How to Use This Manuals SA02675
A: HOW TO USE THIS MANUALS
SA02675F69
1. STRUCTURE SA02675F6901
Each section consists of SCT that are broken down
into SC that are divided into sections for each com-
ponent. The specification, maintenance and other
information for the components are included, and
diagnosis information has also been added where
necessary.
2. INDEX SA02675F6902
The first page has an index with tabs. And at the
end of each section is an alphabetical index.
3. COMPONENTS SA02675F6903
For each component, a composition drawing is
included.
4. SPECIFICATIONS SA02675F6904
If necessary, specifications are also included
5. INSPECTION SA02675F6905
Inspections are included to be carried out before
and after maintenance.
6. MAINTENANCE SA02675F6906
Maintenance instructions are provided for each
component. When multiple components comprise
one process, refer to the instructions for that pro-
cess for each component.
7. DIAGNOSIS SA02675F6907
Tables showing a step-by-step process make it
easy to conduct diagnosis.
8. SI UNITS SA02675F6909
Measurements in these manuals are according to
the SI units. Metric and yard/pound measurements
are also included.
HU-2
HOW TO USE THIS MANUALS
How to Use This Manuals

MEMO:
HU-3
How to Use This Manuals HOW TO USE THIS MANUALS

HU-4
How to Use This Manuals HOW TO USE THIS MANUALS

SPECIFICATIONS
SPC
Page
1. Legacy.........................................................................................................2
2. OUTBACK ...................................................................................................9

1. Legacy SA08704
A: DIMENSIONS SA08704G28
Model Sedan Wagon
AWD
Overall length mm (in) 4,605 (181.3) 4,680 (184.3)
Overall width mm (in) 1,695 (66.7) 1,695 (66.7)
Overall height (at CW) mm (in) 1,415 (55.7) 1,515 (59.6)
Compartment Length mm (in) 1,965 (77.4) 1,925 (75.8)
Width mm (in) 1,440 (56.7), 1,420 (55.9)*2 1,440 (56.7), 1,420 (55.9)*2
Height mm (in) 1,155 (45.5) 1,190 (46.9), 1,175 (46.3)*3
Wheelbase mm (in) 2,650 (104.3) 2,650 (104.3)
Tread Front mm (in) 1,460 (57.5) 1,460 (57.5), 1,465 (57.5)*1
Rear mm (in) 1,460 (57.5) 1,455 (57.3), 1,465 (57.5)*1
Minimum road
clearance
Without catalytic
converter
mm (in) 160 (6.3) 165 (6.5), 14.5 (5.7)*1
With catalytic
converter
mm (in) 155 (6.1) 155 (6.1), 140 (5.5)*1
Australia mm (in) 155 (6.1) 155 (6.1), 140 (5.5)*1
*1: With pneumatic suspension
*2: With leather seat
*3: With sunroof
B: ENGINE SA08704G29
Model Sedan/Wagon
AWD
2.0 L 2.5 L
Engine type Horizontally opposed, liquid cooled, 4-cylinder, 4-stroke gasoline engine
Valve arrangement Overhead camshaft type
Bore ×Stroke mm (in) 92 ×75 (3.62 ×2.95) 99.5 ×79.0 (3.917 ×3.110)
Displacement cm
3
(cu in) 1,994 (121.67) 2,457 (149.9)
Compression ratio 10.0
Firing order 1 —3—2—4
Idle speed at Park/Neutral
position
rpm 700±100
Maximum output kW (HP)/rpm 92 (123)/5,600 115 (154)/5,600
Maximum torque N·m (kgf-m, ft-lb)/rpm 184 (18.8, 136.0)/3,600 223 (22.7, 164.2)/3,600
SPC-2
LEGACY
Specifications

C: ELECTRICAL SA08704G30
Model Sedan/Wagon
AWD
2.0 L 2.5 L
Ignition timing at idling speed BTDC/rpm 10°±10°/700
Spark plug Type and manufacturer Without OBD NGK: BKR6E (without catalyst)
CHAMPION: RC10YC4 (with catalyst)
NGK: BKR5E-11 (with catalyst)
With OBD RC10YC4 .......... CHAMPION
Alternate RC8YC4 .......... CHAMPION
BKR6E-11 .......... NGK
K20PR-U11 .......... NIPPONDENSO
Generator 12V —90A
Battery Type and capacity
(5HR)
For Europe and
South America
MT: 12V —48AH (55D23L)
AT: 12V —52AH (65D23L)
MT: 12V —48AH (55D23L)
AT: 12V —52AH (75D23L)
Others 12V —27AH (34B19L)
D: TRANSMISSION SA08704G31
Model Sedan/Wagon
AWD
2.0 L 2.5 L
Transmission type 5MT*1 4AT*2 5MT*1 4AT*2
Clutch type DSPD TCC DSPD TCC
Gear ratio 1st 3.454 2.785 3.454 2.785
2nd 2.062 1.545 2.062 1.545
3rd 1.448 1.000 1.448 1.000
4th 1.088 0.694 1.088 0.694
5th 0.825 —0.825*3, 0.780*4 —
Reverse 3.333 2.272 3.333 2.272
Reduction gear
(Front drive)
1st reduction Type of gear —Helical —Helical
Gear ratio —1.000 —1.000
Final reduction Type of gear Hypoid Hypoid Hypoid Hypoid
Gear ratio 3.900 4.111 3.700*3, 4.111*4 4.111
Reduction gear
(Rear drive)
Transfer reduc-
tion
Type of gear Helical —Helical —
Gear ratio 1.000 —1.000 —
Final reduction Type of gear Hypoid Hypoid Hypoid Hypoid
Gear ratio 3.900 4.111 3.700*3, 4.111*4 4.111
5MT*1: 5 forward speeds with synchromesh and 1-reverse
4AT*2: Electronically controlled fully-automatic, 4-forward speeds and 1-reverse
DSPD: Dry Single Plate Diaphragm
TCC: Torque Converter Clutch
*3: Except Australia spec. vehicles
*4: Australia spec. vehicles
E: STEERING SA08704G32
Model Models with
185/70R14 tires
Models with
195/60R15 tires
Models with
205/50R16 tires
Type Rack and Pinion
Turns, lock to lock 3.2 3.1
Minimum turning circle m (ft) Curb to curb: 10.5±1.0 (34.5±3.3)
Wall to wall: 11.4±1.0 (37.4±3.3)
Curb to curb: 10.8±1.0 (35.4±3.3)
Wall to wall: 11.5±1.0 (37.7±3.3)
SPC-3
LEGACY Specifications

F: SUSPENSION SA08704G33
Model Conventional suspension Pneumatic suspension
Front Macpherson strut type, Independent, Coil spring Macpherson strut type, Independent, Pneumatic suspension
with height control
Rear Multi-link type, Independent, Coil spring Multi-link type, Independent, Pneumatic suspension with
height control
G: BRAKE SA08704G34
Model Australia spec. vehicles Except Australia spec. vehicles
LX Others
Service brake system Dual circuit hydraulic with vacuum suspended power unit
Front Ventilated disc brake
Rear Disc brake Drum brake Disc brake
Parking brake Mechanical on rear brakes
H: TIRE SA08704G35
Rim size 14 ×5
1
/
2
JJ 15 ×6JJ 16 ×6
1
/
2
JJ
Tire size 185/70R14 195/60R15 205/50R16
Type Steel belted radial, Tubeless
I: CAPACITY SA08704G36
Model Sedan/Wagon
AWD
2.0 L 2.5 L
5MT 4AT 5MT 4AT
Fuel tank (US gal, Imp gal) 64 (16.9, 14.1)
Engine oil Upper level (US qt, Imp qt) 4.0 (4.2, 3.5)
Lower level (US qt, Imp qt) 3.0 (3.2, 2.6)
Transmission gear oil (US qt, Imp qt) 3.5 (3.7, 3.1) —3.5 (3.7, 3.1) —
Automatic transmission fluid (US qt, Imp qt) —8.4 (8.9, 7.4) —9.3 (9.8, 8.2)
AT differential gear oil (US qt, Imp qt) —1.2 (1.3, 1.1) —1.2 (1.3, 1.1)
AWD rear differential gear oil (US qt, Imp qt) 0.8 (0.8, 0.6)
Power steering fluid (US qt, Imp qt) 0.7 (0.7, 0.6)
Engine coolant (US qt, Imp qt) 7.0 (7.4, 6.2) 6.9 (7.3, 6.1) 6.8 (7.2, 6.0) 6.7 (7.1, 5.9)
SPC-4
LEGACY
Specifications

J: WEIGHT SA08704G37
1. EUROPE SPEC. VEHICLE SA08704G3703
Model Sedan
AWD
2.0 L
LHD RHD
LX GL GL
5MT 5MT*2 4AT*2 5MT*3 4AT*4
Curb weight (C.W.) Front kgf (lb) 770 (1,698) 785 (1,731) 810 (1,786) 785 (1,731) 810 (1,786)
Rear kgf (lb) 585 (1,290) 605 (1,334) 605 (1,334) 605 (1,334) 605 (1,334)
Total kgf (lb) 1,355 (2,988) 1,390 (3,065) 1,415 (3,120) 1,390 (3,065) 1,415 (3,120)
Maximum permissible
axle weight (M.P.A.W.)
Front kgf (lb) 950 (2,095) 950 (2,095) 950 (2,095) 950 (2,095) 950 (2,095)
Rear kgf (lb) 950 (2,095) 950 (2,095) 950 (2,095) 950 (2,095) 950 (2,095)
Maximum permissible
weight (M.P.W.)
Total kgf (lb) 1,835 (4,046) 1,835 (4,046) 1,835 (4,046) 1,835 (4,046) 1,835 (4,046)
Model Sedan
AWD
2.5 L
LHD RHD
GX GX
5MT*5 4AT*5 5MT*3 4AT*3
Curb weight (C.W.) Front kgf (lb) 805 (1,775) 830 (1,830) 795 (1,753) 820 (1,808)
Rear kgf (lb) 605 (1,334) 610 (1,345) 605 (1,334) 610 (1,345)
Total kgf (lb) 1,410 (3,109) 1,440 (3,175) 1,400 (3,087) 1,430 (3,153)
Maximum permissible
axle weight (M.P.A.W.)
Front kgf (lb) 950 (2,095) 970 (2,139) 950 (2,095) 970 (2,139)
Rear kgf (lb) 975 (2,150) 975 (2,150) 975 (2,150) 975 (2,150)
Maximum permissible
weight (M.P.W.)
Total kgf (lb) 1,875 (4,134) 1,875 (4,134) 1,875 (4,134) 1,875 (4,134)
SPC-5
LEGACY Specifications

Model Wagon
AWD
2.0 L
LHD RHD
LX GL GL
5MT 5MT*2 4AT*2 5MT*3 4AT*3
Curb weight (C.W.) Front kgf (lb) 770 (1,698) 785 (1,731) 800 (1,764) 785 (1,731) 800 (1,764)
Rear kgf (lb) 630 (1,389) 650 (1,433) 650 (1,433) 650 (1,433) 650 (1,433)
Total kgf (lb) 1,400 (3,087) 1,435 (3,164) 1,450 (3,197) 1,435 (3,164) 1,450 (3,197)
Maximum permissible
axle weight (M.P.A.W.)
Front kgf (lb) 950 (2,095) 950 (2,095) 950 (2,095) 950 (2,095) 950 (2,095)
Rear kgf (lb) 1,030 (2,271) 1,030 (2,271) 1,030 (2,271) 1,030 (2,271) 1,030 (2,271)
Maximum permissible
weight (M.P.W.)
Total kgf (lb) 1,895 (4,178) 1,895 (4,178) 1,895 (4,178) 1,895 (4,178) 1,895 (4,178)
Model Wagon
AWD
2.5 L
LHD RHD
GX GX*1 GX GX*1
5MT*2 4AT*6 4AT*7 5MT*3 4AT*3 4AT*7
Curb weight (C.W.) Front kgf (lb) 790
(1,742)
820
(1,808)
845
(1,863)
790
(1,742)
805
(1,775)
845
(1,863)
Rear kgf (lb) 655
(1,444)
655
(1,444)
680
(1,499)
655
(1,444)
655
(1,444)
680
(1,499)
Total kgf (lb) 1,445
(3,186)
1,475
(3,252)
1,525
(3,363)
1,445
(3,186)
1,460
(3,219)
1,525
(3,363)
Maximum permissible
axle weight (M.P.A.W.)
Front kgf (lb) 960
(2,117)
980
(2,161)
980
(2,161)
960
(2,117)
980
(2,161)
980
(2,161)
Rear kgf (lb) 1,040
(2,293)
1,040
(2,293)
1,040
(2,293)
1,040
(2,293)
1,040
(2,293)
1,040
(2,293)
Maximum permissible
weight (M.P.W.)
Total kgf (lb) 1,945
(4,289)
1,945
(4,289)
1,970
(4,344)
1,945
(4,289)
1,945
(4,289)
1,970
(4,344)
*1: Pneumatic suspension equipped models
*2: Includes weight of side airbag
*3: Includes weight of audio and side airbag
*4: Includes weight of cruise control, audio and side airbag
*5: Includes weight of air conditioner and side airbag
*6: Includes weight of cruise control, cold weather pack, air conditioner and side airbag
*7: Includes weight of VDC, cruise control, audio, leather interior, cold weather pack, air conditioner, side airbag and sunroof
NOTE:
When any of the following optional parts are installed, add the weight to the curb weight.
Weight of
optional
parts
VDC Cruise
control
Air condi-
tioner
Sunroof Leather
interior
SRS
Airbag
(Side)
Cold
weather
pack
Audio Rear
spoiler
Sports
package
Front kgf
(lb)
6.5
(14.3)
2.1
(4.6)
13.9
(30.6)
10.9
(24.0)
1.8
(4.0)
2.9
(6.4)
0.2
(0.4)
1.8
(4.0)
−0.7
(−1.54)
−1.4
(−3.09)
Rear kgf
(lb)
0.1
(0.2)
0.3
(0.7)
−0.1
(−0.2)
16.4
(36.2)
3.1
(6.8)
3.0
(6.6)
0.2
(0.4)
0.7
(1.5)
3.2
(7.1)
−3.8
(−8.38)
Total kgf
(lb)
6.6
(14.6)
2.4
(5.3)
13.8
(30.4)
27.3
(60.2)
4.9
(10.8)
5.9
(13.0)
0.4
(0.9)
2.5
(5.5)
2.5
(5.5)
−5.2
(−11.47)
SPC-6
LEGACY
Specifications

2. AUSTRALIA SPEC. VEHICLE SA08704G3704
Model Sedan
AWD
2.0 L 2.5 L
GX RX
5MT*1 4AT*2 5MT*2 4AT*2
Unladen mass (U.M.) Front kgf (lb) 780 (1,720) 775 (1,709) 775 (1,709) 785 (1,731)
Rear kgf (lb) 585 (1,290) 585 (1,290) 595 (1,312) 595 (1,312)
Total kgf (lb) 1,365 (3,010) 1,360 (2,999) 1,370 (3,021) 1,380 (3,043)
Gross vehicle mass
(G.V.M. )
Front kgf (lb) 930 (2,051) 930 (2,051) 940 (2,073) 940 (2,073)
Rear kgf (lb) 970 (2,139) 970 (2,139) 980 (2,161) 980 (2,161)
Total kgf (lb) 1,900 (4,190) 1,900 (4,190) 1,920 (4,234) 1,920 (4,234)
Model Wagon
AWD
2.0 L 2.5 L
GX RX
5MT*1 4AT*2 5MT*2 4AT*2
Unladen mass (U.M.) Front kgf (lb) 775 (1,709) 775 (1,709) 765 (1,687) 780 (1,720)
Rear kgf (lb) 635 (1,400) 635 (1,400) 645 (1,422) 645 (1,422)
Total kgf (lb) 1,410 (3,109) 1,410 (3,109) 1,410 (3,109) 1,425 (3,142)
Gross vehicle mass
(G.V.M.)
Front kgf (lb) 930 (2,051) 930 (2,051) 950 (2,095) 950 (2,095)
Rear kgf (lb) 1,010 (2,227) 1,010 (2,227) 1,040 (2,293) 1,040 (2,293)
Total kgf (lb) 1,940 (4,278) 1,940 (4,278) 1,990 (4,388) 1,990 (4,388)
*1: Includes weight of cruise control, audio and air conditioner
*2: Includes weight of audio
NOTE:
When any of the following optional parts are installed, add the weight to the unladen mass.
Weight of
optional
parts
VDC Cruise
control
Air condi-
tioner
Sunroof Leather
interior
SRS
Airbag
(Side)
Cold
weather
pack
Audio Rear
spoiler
Sports
package
Front kgf
(lb)
6.5
(14.3)
2.1
(4.6)
13.9
(30.6)
10.9
(24.0)
1.8
(4.0)
2.9
(6.4)
0.2
(0.4)
1.8
(4.0)
−0.7
(−1.54)
−1.4
(−3.09)
Rear kgf
(lb)
0.1
(0.2)
0.3
(0.7)
−0.1
(−0.2)
16.4
(36.2)
3.1
(6.8)
3.0
(6.6)
0.2
(0.4)
0.7
(1.5)
3.2
(7.1)
−3.8
(−8.38)
Total kgf
(lb)
6.6
(14.6)
2.4
(5.3)
13.8
(30.4)
27.3
(60.2)
4.9
(10.8)
5.9
(13.0)
0.4
(0.9)
2.5
(5.5)
2.5
(5.5)
−5.2
(−11.47)
SPC-7
LEGACY Specifications

3. OTHERS SA08704G3705
Model Sedan
AWD
2.0 L 2.5 L
LHD RHD LHD
LX GL GL GX
5MT 5MT 4AT 4AT*1 5MT*1 4AT*1
Curb weight (C.W.) Front kgf (lb) 765
(1,687)
775
(1,709)
800
(1,764)
800
(1,764)
785
(1,731)
810
(1,786)
Rear kgf (lb) 590
(1,301)
610
(1,345)
610
(1,345)
605
(1,334)
610
(1,345)
615
(1,356)
Total kgf (lb) 1,355
(2,988)
1,385
(3,054)
1,410
(3,109)
1,405
(3,098)
1,395
(3,076)
1,425
(3,142)
Maximum permissible
axle weight (M.P.A.W.)
Front kgf (lb) 950
(2,095)
950
(2,095)
950
(2,095)
950
(2,095)
950
(2,095)
950
(2,095)
Rear kgf (lb) 950
(2,095)
950
(2,095)
950
(2,095)
950
(2,095)
975
(2,139)
975
(2,139)
Maximum permissible
weight (M.P.W.)
Total kgf (lb) 1,835
(4,046)
1,835
(4,046)
1,835
(4,046)
1,835
(4,046)
1,875
(4,134)
1,875
(4,134)
Model Wagon
AWD
2.0 L 2.5 L
LHD RHD LHD
LX GL GL GX
5MT 5MT 4AT 4AT*1 5MT*1 4AT*2
Curb weight (C.W.) Front kgf (lb) 765
(1,687)
775
(1,709)
790
(1,742)
790
(1,742)
780
(1,720)
805
(1,775)
Rear kgf (lb) 635
(1,400)
655
(1,444)
655
(1,444)
655
(1,444)
655
(1,444)
655
(1,444)
Total kgf (lb) 1,400
(3,087)
1,430
(3,153)
1,445
(3,186)
1,445
(3,186)
1,435
(3,164)
1,460
(3,219)
Maximum permissible
axle weight (M.P.A.W.)
Front kgf (lb) 950
(2,095)
950
(2,095)
950
(2,095)
950
(2,095)
960
(2,117)
960
(2,117)
Rear kgf (lb) 1,030
(2,271)
1,030
(2,271)
1,030
(2,271)
1,030
(2,271)
1,040
(2,293)
1,040
(2,293)
Maximum permissible
weight (M.P.W.)
Total kgf (lb) 1,895
(4,178)
1,895
(4,178)
1,895
(4,178)
1,895
(4,178)
1,945
(4,289)
1,945
(4,289)
*1: Includes weight of audio
*2: Includes weight of cruise control and air conditioner
NOTE:
When any of the following optional parts are installed, add the weight to the curb weight.
Weight of
optional
parts
VDC Cruise
control
Air condi-
tioner
Sunroof Leather
interior
SRS
Airbag
(Side)
Cold
weather
pack
Audio Rear
spoiler
Sports
package
Front kgf
(lb)
6.5
(14.3)
2.1
(4.6)
13.9
(30.6)
10.9
(24.0)
1.8
(4.0)
2.9
(6.4)
0.2
(0.4)
1.8
(4.0)
−0.7
(−1.54)
−1.4
(−3.09)
Rear kgf
(lb)
0.1
(0.2)
0.3
(0.7)
−0.1
(−0.2)
16.4
(36.2)
3.1
(6.8)
3.0
(6.6)
0.2
(0.4)
0.7
(1.5)
3.2
(7.1)
−3.8
(−8.38)
Total kgf
(lb)
6.6
(14.6)
2.4
(5.3)
13.8
(30.4)
27.3
(60.2)
4.9
(10.8)
5.9
(13.0)
0.4
(0.9)
2.5
(5.5)
2.5
(5.5)
−5.2
(−11.47)
SPC-8
LEGACY
Specifications

2. OUTBACK SA08705
A: DIMENSIONS SA08705G28
Model OUTBACK
AWD
Overall length mm (in) 4,720 (185.8)
Overall width mm (in) 1,745 (68.7)
Overall height (at CW) mm (in) 1,580 (62.2), 1,590 (62.6)*3
Compartment Length mm (in) 1,925 (75.8)
Width mm (in) 1,440 (56.7), 1,420 (55.9)*1
Height mm (in) 1,190 (46.9), 1,175 (46.3)*2
Wheelbase mm (in) 2,650 (104.3)
Tread Front mm (in) 1,470 (57.9)
Rear mm (in) 1,460 (57.5)*3 , 1,465 (57.7)
Minimum road
clearance
Without catalytic
converter
mm (in) 195 (7.7)
With catalytic
converter
mm (in) 190 (7.5)
Australia mm (in) 200 (7.9)
*1: With leather seat
*2: With sunroof
*3: Australia spec. vehicles
B: ENGINE SA08705G29
Model OUTBACK
AWD
2.5 L 3.0 L
Engine type Horizontally opposed, liquid cooled,
4-cylinder, 4-stroke gasoline engine
Horizontally opposed, liquid cooled,
6-cylinder, 4-stroke gasoline engine
Valve arrangement Overhead camshaft type
Bore ×Stroke mm (in) 99.5 ×79.0 (3.917 ×3.110) 89.2 ×80.0 (3.512 ×3.150)
Displacement cm
3
(cu in) 2,457 (149.9) 3,000 (183.06)
Compression ratio 10.0 10.7
Firing order 1 —3—2—41—6—3—2—5—4
Idle speed at Park/Neutral
position
rpm 700±100 600±100
Maximum output kW (HP)/rpm 115 (154)/5,600 154 (206)/6,000
Maximum torque N·m (kgf-m, ft-lb)/rpm 223 (22.7, 164.2)/3,600 282 (378)/4,400
SPC-9
OUTBACK Specifications

C: ELECTRICAL SA08705G30
Model OUTBACK
AWD
2.5 L 3.0 L
Ignition timing at idling
speed
BTDC/rpm 10°±10°/700 10°±8°/600
Spark plug Type and manufacturer RC10YC4 .......... CHAMPION PLFR6A .......... NGK
Alternate RC8YC4 .......... CHAMPION
BKR6E-11 .......... NGK
K20PR-U11 .......... NIPPONDENSO
Generator 12V —90A 12V —100A
Battery Type and capacity (5HR) For Europe and
South America
MT: 12V —48AH (55D23L)
AT: 12V —52AH (75D23L)
12V —52AH (75D23L)
Others 12V —27AH (34B19L)
D: TRANSMISSION SA08705G31
Model OUTBACK
AWD
2.5 L 3.0 L
Transmission type 5MT*1 4AT*2 4AT*2
Clutch type DSPD TCC TCC
Gear ratio 1st 3.454 2.785
2nd 2.062 1.545
3rd 1.448 1.000
4th 1.088 0.694
5th 0.825 —
Reverse 3.333 2.272
Auxiliary transmission gear ratio High 1.000 —
Low 1.196 —
Reduction gear
(Front drive)
1st Reduction Type of gear —Helical
Gear ratio —1.000
Final reduction Type of gear Hypoid Hypoid
Gear ratio 3.900*3, 4.111*4 4.444 4.111
Reduction gear
(Rear drive)
Transfer reduction Type of gear Helical —
Gear ratio 1.000 —
Final reduction Type of gear Hypoid Hypoid
Gear ratio 3.900*3, 4.111*4 4.444 4.111
5MT*1: 5 ×2 forward speeds with synchromesh and 1-reverse
4AT*2: Electronically controlled fully-automatic, 4-forward speeds and 1-reverse
DSPD: Dry Single Plate Diaphragm
TCC: Torque Converter Clutch
*3: Except Australia spec. vehicles
*4: Australia spec. vehicles
SPC-10
OUTBACK
Specifications
