Subcold ECO 75 User manual

PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS BEFORE USE

1
Thank for purchasing our products and thank you for placing your confidence in us.
Please read this manual carefully before using. Follow instructions and keep it for future reference.
Please follow the operating instructions and safety notices in the manual.
If any trouble arise, do not fix it yourself or hand it to the after sales service center which has not
been authorized. Please contact the local authorized service center.
Description of Parts.................................................................................................. 2
Safety Warnings ...................................................................................................... 3
Installation Instructions .......................................................................................... 5
Operation ………………............................................................................................... 6
Packing and Moving................................................................................................. 6
Maintenance............................................................................................................ 7
Defrost...................................................................................................................... 7
Disconnecting the Appliance.................................................................................... 7
User Notifications.................................................................................................... 8
Troubleshooting Tips................................................................................................ 8
Specifications and Parameters............................................................................... 10

2
1. Ice Box Compartment
2. Drip Tray
3. Removable Shelf
4. Temperature Control Dial
5. Tall Bottle Storage
6. Can Dispenser
1. Ice Box Compartment
2. Drip Tray
3. Removable shelf
4. Temperature Control Dial
5. Tall bottle Storage
•This unit you purchased may be improved, which maybe not completely be consistent with the manual,
However the functions and operating methods will not change. Please pay attention to the
instruction manual for the best operation.
•When you switch on the Unit for the first time, remove the adhesive tapes of the inside of the unit.
Leave the fridge to settle for minimum 1hour after transportation.
•Be careful when handling the unit and do not drop, and ensure the fridge is always kept in the
upright position. Do not pull or push the components in case of damage.
•Adjust the temperature control dial to your preferred temperature and leave it empty for minimum 1
hour before loading any goods inside.
•Don’t open the door continually if it is in the normal working condition.

3
1. The circuitry for the refrigerator must be isolated. The area of cross section of wire must be larger than
0.75mm2. The power plug should have its own socket, the socket must be grounded as adapter may cause
the socket to overheat.
2. The voltage and frequency of this product should be 220-240V;50Hz. Contact with the local maintenance
station or retailer in case of electrical cord damage.
3. Always disconnect the power only by pulling the power plug out of the socket directly but not by the cord.
4. Do not damage the refrigerant circuit.
5. Persons with low physical, sensory and mental capabilities (including children of below 8 years) are not
advised to use this appliance unless they are well supervised/instructed by a safety person. Children should
be supervised to ensure that they do not play with the appliance. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
6. Keep enough space around the unit for ventilation, the appliance enclosure or the built in
structure should be clear of obstruction and have a minimum of 5-10cm gap on the rear, sides and 30cm
above.
7. Before you throw away your old refrigerator or freezer.
▪Take off the doors;
▪Leave the shelves in place so that children may not easily climb inside
8. Do not store in the appliance explosive devices / substances such as aerosol cans with a flammable
propellant . This appliance is intended to be used in household and similar applications such as :
▪Staff kitchen areas in shops, offices and other working environments;
▪Farm houses and by clients in hotels, motels and other residential type environments; bed and
breakfast type environments;
▪Catering and similar non-retail applications.
9. Do not use electrical appliance inside the food storage compartments of the appliance, unless they are of the
type recommended by the manufacture.
10. All affected or faulty parts must be changed be a certified technician
11. To avoid hazards, the supply cord must always be replaced by the manufacturer, its service agent or similarly
a certified/qualified persons when damaged.
For ensure your personal safety, please follow the points below:
Warning:
•This appliance must be fixed in accordance to the instructions provided to avoid hazard
•When positioning the appliance, ensure the supply cord is not trapped or damaged.
•Do not locate multiple portable socket outlets or portable power supplies at the rear of the appliance.

4
•Children should be supervised when using or operating the item
•To avoid contamination of food, please respect the following instructions:
•Opening the door for long periods can cause a significant increase of the temperature in the compartments
of the appliance.
•Clean regularly surfaces that can come in contact with food and accessible drainage systems.
•Store raw meat and fish in suitable containers in the refrigerator, so that it is not in contact with or drip onto
other food.
•Two-star frozen-food compartments are suitable for storing pre-frozen food, storing ice-cream and
making ice cubes or other water based frozen goods.
•One-, two- and three-star compartments are not suitable for the freezing of fresh food.
•If the refrigerating appliance is left empty for long periods, switch off, defrost, clean, dry, and leave the
door open to prevent mold developing within the appliance.
1. Do not expose to open flames, gas or other harmful substances
2. Don't splash water on the rear of the appliance, for it may cause malfunction or 2. electric shock.
3. Don't store inflammable materials such as ether, benzene, LP gas etc
4. It is better not place objects on the top of appliance which is magnetic, heavy, or filled with water.
5. The refrigerant of this product is R600a,which is inflammable. So, make sure not to damage the cooling
system during the transportation and installation.
6. DISPOSAL: For safe disposal contact a WEE waste removal company local to your area

5
1. The refrigerator should be located in a completely
flat surface , Leave 5~10 cm between each side of
the appliance and the wall, and leave 30 cm
between the top of the appliance.
2. Choose a location which is not exposed to
sunlight , high temperature or humidity
3. Remove all adhesive transport tapes before using.
4. The appliance can be adjusted by turning its two
legs in front the bottom when it is unstable.
Turning clockwise can raise up the machine.
5. The location should be firm and flat. If it is not in
a level position it may cause noise / vibration:
1) The noise may be increased if the floor is not
firm.
2) Put a sheet under the appliance for better
heat emission if you need to locate it onto a
carpet.
6) Make sure the adjustable legs are tight to the
floor, and set the appliance slope backwards
slightly for keeping the doors closed tightly.
1. There should always be some space between items inside for air circulation.
2. Food should be kept in sealed package to prevent them from getting dry or with odour
3. Hot food should be cooled down before placing into the appliance. Otherwise, interior temperature and
electronic consumption will increase.
4. Reduce the frequency of door opening - it can efficiently lower the electricity consumption.
For disposal of the appliance:
To prevent possible harm to the environment or
human health from uncontrolled waste disposal,
recycle it responsibly to promote the
sustainable reuse of the materials. And the
disposal should only be done through public
collection points / local WEEE recycling centres
For installation, servicing:
Appliance should be placed on a horizontal floor
and allow free ventilation.
For handling:
Always handle the appliance gently and with
care to avoid any damage.

6
1. Place this product in a cool area of the room and far away from any heat source for maximum efficiency.
2. Do not store hot food in the refrigerator, wait for it to cool before storage. This will prevent the
compressor from overworking
3. Ensure foods and other items placed in the refrigerator is wrapped properly or with a dry container to
prevent frost build-up inside the unit
4. Do not line the storage bin with an aluminum foil, wax paper or to improve the efficiency of the refrigerator
5. Well organization and proper food labeling should be taken into consideration to reduce frequent door
openings to improve the efficiency of the appliance.
1. Unpack , repack and transport
Please memorize the position of each accessory of the appliance when you
unpack it, and repack the product and check it carefully before transportation.
2. Do not lift or pull the door or the door handle during lifting, carrying and
transportation.
3. When moving, the appliance can not be sloped over 45 degrees (the angle
to the vertical direction). Please avoid strong vibrations.
The temperature of refrigerator can be controlled manually by the dial. However, the
number shown on the knob does not directly represent the temperature. Instead, the larger
the number is, the lower the interior temperature will be. 0 stands for off. Turn the knob to
state 4 when it is normal used, turn it to the state during 4-7 if a lower interior temperature is
required
1. The common temperature of the main compartment is from 2°C to 8°C.
2. The common temperature of the ice box compartment is from -2 to 2°C.
3. Raw food and cooked food need to stored in different containers. In order to prevent
bacterial contamination, raw vegetables and fruits should not be exposed to raw meat or fish. Vegetables
and fruits should be wrapped by film and stored seperately

7
This appliance should be maintained and cleaned frequently. For your safety, ensure to unplug the socket from
the main power source before cleaning.
Heavy frost will influence the refrigeration of the appliance and increase the energy consumption. Thus,
defrosting is needed when the frost is as thick as 5mm. The process for manual defrost are listed as follows:
•Take all the food out of the
compartment;
•Remove the shelf;
•Unplug the power cord;
•Open the doors and wait for thawing;
•Wipe the defrost water with a dry cloth.
❑Interior maintenance
Clean the interior of the appliance with clean water or a neutral non-haz cleaner. Clean warm water works best to
wipe the surfaces clean with a damp cloth
❑Maintenance of the door gasket
It is easy to cause damage to the door gaskets if it becomes dirty. Wipe the rubber door gasket seal with a warm
cloth to remove any dirt or stains
❑Outer maintenance
Keep the exterior clean with a piece of dry cloth ,clean it with neutral non-haz
cleaner if necessary.
In case of a power failure, the refrigerator can store food normally for several hours.
❑During power failure
If you experience a power failure, do not put additional food in the appliance and reduce the frequency of door
opening.
❑During vacation
Please remove food in fridge before a shot holiday. Close the door firmly. If you have a longer holiday, please
remove all the food and switch off the power. After defrosting, clean the appliance and wipe it dry, and leave
the door open to prevent unwanted smells
❑Not in use
Warning: Do not use any other equipment or method to assist the defrost process. It may cause
damage to the cooling system.
If the refrigerator has stopped being used for a long time, please unplug from the outlet and clean the appliance.
The door should be kept open in order to prevent unpleasant smell
Attention: In a general working conditions, do not restart the power immediately, please leave at at least 5
minutes before powering back on.

8
❑Do not expose water to the refrigerator, as it will lead to oxidation which may cause malfunction or
damage.
❑Cleaning materials such as soap powder, abrasive cleaning powder, alkali cleansers, chemicals, thinners,
alcohol, acid petroleum and very hot water should not be used to clean the refrigerator as they may
damage the painted covers and plastics.
❑Heat can damage the interior plastic components.
❑Ensure to check the following after maintenance:
•Is there any damage or loss of power ?
•Can the plug be put in the socket reliably and smoothly?
•Is the plug heating unconventionally?
You can easily solve some common problems in the unit which will save you the cost for a possible service charge
by technician. Try the suggested points below to see if you can solve the problem before calling a technician.
Warning: Please remove the gasket of the door before disposal. The disposal should be handled by a trained
personnel, as it may be harmful to the environment.
PROBLEMS POSSIBLE CAUSE
The refrigerator does not work
•It may not be connected to the power supply(plug,
power cut or fuse; Voltage is too low.
•Circuit breaker tripped or blown fuse
•The control knob was set to “0”
The refrigerator does not work efficiently as
expected
•It may be caused by heavy frost, or by warm
temperature setting, or by frequent door openings.
Turns on and off frequently
•Room temperature is hotter
•Door opens frequently
•Door not closed tightly
•The temperature control switch was not set right
•Door gasket not sealed properly
•Unit not having correct clearances
It makes an unusual noise
•It may be caused by an imbalance in the position
•The compressor keeps working for a long period
•The environment temperature may be high.
•The door may be opened frequently or even left
opened.
•The temperature control knob setting in (4-10)
state may increase the working time of compressor.

9
PROBLEMS POSSIBLE CAUSE
Unusual smell
•Food with strong odour should be packed tightly
before being put inside the appliance.
•Please check whether there is any deteriorated
items or whether the liners are left uncleaned for a
long time.
Water leaks from the bottom of the refrigerator •The drain tube is blocked. Please use a tool to
unblock the drain pipe
Heavy frost occurs on the rear of the appliance
•Putting hot food into the appliance may cause this
problem. Or
•it may be caused by the heavy environment
moisture / humidity
Door not closed properly
•Unit not on a level surface
•Door not installed properly or reversed
•The gasket is dirty or bent
•The shelves are out of position
❑Moisture may form dew on the outside of the product during high humidity. Please wipe the external
surface with a clean and dry cloth to clear this dew
❑The flow of refrigerant through the pipeline coil can cause some noises which is normal.
❑The sides of product having a warm temperature; it is as a result of the appliance working.
❑The frame of the appliance will be warm to prevent condensation
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or a
qualified technician in order to avoid hazard.

10
Model
ECO50 ECO 75
Climate Class
SN/N/ST/T SN/N/ST
Electric Shock Protection Type
| |
Net Capacity (L)
Freezer
\ /
Refrigerator
46 72
Rated
Voltage (V) 220-240 220-240
Frequency (Hz)
50 50
Current (A)
0.45 0.55
Noise Level [dB (A)] ≤ 42 ≤ 42
Energy consumption (
kW.h/24h) 0.29 0.30
Refrigerant
R600a/18g R600a/23g
Net Weight (KG)
16 16.5
Interior
temperature (
0
C)
Freezer \ \
Refrigerator 2-10 2-10
Dimension
(mm)
Width 440 486
Depth 480 500
Height 500 627
ECO 50
- 1 Piece
- 1 Piece
1. Refrigerator
2. Keys
3. Owner's manual - 1 copy
ECO 75
- 1 Piece
- 1 Piece
1. Refrigerator
2. Keys
3. Owner’s Manual - 1 Piece

www.subcold.com @subcoldltd
01506415564 (UKOffice Hours) @subcold_official
[e-mail]
