Subcold SUPER 35 User manual

PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS BEFORE USE

1
Thank for purchasing our product and thank you for placing your confidence in us.
Please read this manual carefully before using. Follow the instructions and keep this handy for
future reference. Please follow the operating instructions and safety notices in the manual.
If any issues arise, do not fix it yourself or hand it to the after sales service center which has not
been authorized. Please contact the local authorized service center.
Name of the parts .................................................................................................. 2
Specifications and parameters............................................................................... 3
Safety warnings ...................................................................................................... 4
Installation instructions .......................................................................................... 5
Operation ………………............................................................................................... 6
Packing and moving................................................................................................. 6
Maintenance............................................................................................................ 7
Defrost...................................................................................................................... 7
Disconnecting the appliance.................................................................................... 7
User notifications.................................................................................................... 8
Troubleshooting tips................................................................................................ 8

2
1. Blank Plate for Hinge
2. Evaporator
3. Large Shelf
4. Small Shelf
5. Hinge Cover
6. Light Switch
7. Door seal
8. Door Handle
Name of the Parts for Spare Parts Orders :

3
MODEL
SUPER 35 SUPER 50 SUPER 65 SUPER 85
NET CAPACITY 35L 49L 60L 80L
RATED VOLTAGE
220-240V~
50Hz
220-240V~
50Hz
220-240V~
50Hz
220-240V~
50Hz
WATTAGE 85W 85W 85W 85W
REFRIGERANT
R600a R600a R600a R600a
ENERGY
CONSUMPTION
80KWh/ Annum 84kWh/ Annum 80kWh/ Annum 102kWh/ Annum
MAX LAMP POWER 10W10W10W10W
CLIMATE CLASS
N N N N
FOAMING GAS
Cyclopentane Cyclopentane Cyclopentane Cyclopentane
DIMENSION (MM)
405X440X552 440X500X525 474X450X640 474X435X844
PACKING (MM)
490X528X625 550X510X675 545X510X885
NET WEIGHT (KG)
15.6 17.1 17.5 23
GROSS WEIGHT (KG)
16.9 19.6 26
530X550X575
18.1

4
1. The circuitry for the refrigerator must be isolated. The area of cross section of wire must be larger than
0.75mm2. The power plug should have its own socket, the socket must be grounded as an adapter may
cause the socket to overheat.
2. The voltage and frequency of this product should be 220-240V;50Hz. Contact with a local maintenance
company or your retailer in case of electrical cord damage.
3. Always disconnect the power only by pulling the power plug out of the socket directly but not by the cord.
The socket power switch should be used before unplugging.
4. Do not damage the refrigerant circuit by overloading items inside causing damage to the evaportator.
5. Persons with low physical, sensory and mental capabilities (including children of below 8 years) are not
advised to use this appliance unless they are well supervised/instructed by a safety person. Children should
be supervised to ensure that they do not play with the appliance. Children should not play with the
appliance. Cleaning and user maintenance should not be made by children without supervision.
6. Keep a minimum of 5cm gap on all sides for best cooling performance and ensure sufficient
ventilation opening. This is freestanding design and a furniture door / cupboard use is not suitable for this
appliance.
7. Before you throw away your old refrigerator or freezer.
▪Take off the doors
▪Leave the shelves in place so that children may not easily climb inside
8. Do not store explosive devices / substances such as aerosol cans with a flammable propellant . This
appliance is intended to be used in household and similar applications such as :
▪Staff kitchen areas in shops, offices and other working environments;
▪Farm houses and by clients in hotels, motels and other residential type environments; bed and
breakfast type environments;
▪Catering and similar non-retail applications.
9. Do not use any electrical appliances inside the food storage compartments of the appliance, unless they
are of the type recommended by the manufacturer
10. All affected or faulty parts (including the lamp) must be changed be a certified technician
11. To avoid hazards, the supply cord must always be replaced by the manufacturer, its service agent or similarly
a certified/qualified persons when damaged.
To avoid the risk of fire, electrical shock or injury and to ensure
your personal safety when using this appliance the under listed
instructions/precautions are to be followed:
1. Do not expose to open flames, gas or other harmful substances
2. Don't splash water on the rear of the appliance, for it may cause malfunction or electric shock.
3. Don't store flammable materials such as ether, benzene, LP gas etc
4. It is better not place objects on the top of appliance which is magnetic, heavy, or filled with water.
5. The refrigerant of this product is R600a,which is inflammable. So, make sure not to damage the cooling
system during the transportation and installation.
6. DISPOSAL: For safe disposal contact a WEE waste removal company local to your area
Warning: this appliance must be fixed in accordance to the instructions provided to avoid hazard

5
1. The refrigerator should be located in a
completely flat surface , Leave 5~10 cm between
each side of the appliance and the wall
2. Choose a location which is not exposed to
sunlight , high temperature or humidity
3. Remove all adhesive transport tapes before
using.
4. The appliance can be adjusted by turning its two
feet on the front and bottom when it is
unstable. Turning clockwise / anti-clockwise to
level the appliance with a spirit level.
5. The location should be firm and flat. If it is not in
a level position it may cause noise / vibration:
1) The noise may be increased if the floor is not
firm.
2) Put a sheet under the appliance for better
heat emission if you need to locate it onto a
carpet.
6. Make sure the adjustable feet are tight to the
floor, and set the appliance to slope
backwards slightly for keeping the doors closed
tightly.
1. Allow some space between items inside for air circulation.
2. Food should be kept in sealed package to prevent them from getting dry
3. Hot food should be cooled down before placing into the appliance.
4. Reduce the frequency of door opening - it can efficiently lower the electricity consumption.
For disposal of the appliance:
To prevent possible harm to the environment or
human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable
reuse of material resources. And the disposal
should only be done through public collection or
drop off points.
For installation, servicing:
Appliance should be placed on a horizontal floor
and allow free ventilation.
For handling:
Always handle the appliance gently and with care
to avoid any damage. Do not drop

6
The temperature of refrigerator can be controlled manually by the thermostat knob. The higher the
number on the thermostat the colder the inside temperature will be.
1. Place this product in a cool area of the room and far away from any heat source for a maximum function.
2. Do not store hot food in the refrigerator, wait for it to cool before storage. This will prevent the compressor
from overworking
3. Ensure foods and other items placed in the refrigerator is wrapped properly or with a dry container to
prevent frost build-up inside the unit
4. Do not line the interior with an aluminum foil, wax paper etc.
5. Well organization and proper food labelling should be taken into consideration to reduce frequent door
openings to improve the efficiency of the appliance.
•Your unit has only one control knob for regulating the temperature in the compartment.
The temperature control knob can be found at the lower right side of the compartment
or on the rear of the product on the lower left side.
•Set the temperature knob to 5 for first use, the Temperature can be adjusted to suit
your need after 24hrs . “3” and “4”is recommended for normal home or office use.
•Turn the switch to “0” to turn the compressor off
NOTE:
•Turning the switch to “0”only stops the cooling cycle and not the shutting off the unit’s
power.
•When the unit is not plugged or turned off, wait for 3 to 5 minutes before restarting to
avoid the unit’s malfunctioning
1. Ensure you note the position of each accessory of the appliance when you
unpack it, repack the product and check it carefully before transportation.
2. Do not lift or pull the door or the door handle during lifting, carrying and
transportation.
3. When moving, the appliance can not be sloped over 45 degrees (the angle
to the vertical direction). Please avoid strong vibrations.

7
This appliance should be maintained and cleaned frequently. For your safety, ensure to unplug the socket from
the main power source before cleaning.
Heavy frost will influence the refrigeration of the appliance and increase the energy consumption. Thus,
defrosting is needed when the frost is as thick as 5mm. The process for manual defrost are listed as follows:
•Take all the items out of the appliance;
•Remove the shelf;
•Unplug the power cord;
•Open the doors and wait for thawing;
•Wipe the defrost water with a dry cloth.
❑Interior maintenance
Clean the interior of the appliance with clean water and non-haz cleaner and wipe it with dry with a cloth.
❑Maintenance of the door gasket
It is easy to cause damage if the door gaskets if not cleaned well. Ensure the gasket is cleaned sufficiently.
❑Outer maintenance
Wipe the dust off with a dry clean cloth.
In case of a power failure, the refrigerator can store items normally for several hours.
❑During power failure
If there is a power failure, do not put new items in the refrigerator and minimize the frequency of door opening.
❑During vacation
For a short vacation, ensure that all items in the fridge are removed before the vacation and close the door
firmly. if on a long vacation, the appliance can be disconnected from the power source; defrost, clean and wipe-
it dry, and leave the door open.
❑Not in use
Warning: Do not use any other equipment or method to assist the defrost process. It may cause damage to the
cooling system.
If the refrigerator will not be used for a long time, please unplug it from the outlet and clean the appliance. The
door should be kept open in order to prevent unpleasant smells
Attention: In a general working conditions, do not restart the power immediately, please leave at at least 5
minutes before powering back on.

8
❑Do not expose water to the refrigerator, as it will lead to oxidation which may cause malfunction or
damage.
❑Cleaning materials such as soap powder, abrasive cleaning powder, alkali cleansers, chemicals, thinners,
alcohol, acid petroleum and very hot water should not be used to clean the refrigerator as they may
damage the painted covers and plastics.
❑Heat or direct sunlight can cause damage to the interior plastic components and liner.
❑Ensure to check the following after maintenance:
•Is there any damage or loss of power ?
•Can the plug be put in the socket reliably and smoothly?
•Is the plug heating unconventionally?
You can easily solve some common problems in the unit which will save you the cost for a possible service
charge by technician. Try the suggested points below to see if you can solve the problem before
contacting the repair centre.
PROBLEMS POSSIBLE CAUSE
The refrigerator does not work
•It may not be connected to the power supply(plug,
power cut or fuse; Voltage may be too low.
•Circuit breaker tripped or blown fuse
•The control knob was set to “0”
The refrigerator does not work efficiently as
expected
•It may be caused by heavy frost, or by warm
temperature setting, or by frequent door openings.
Turns on and off frequently
•Room temperature is hot
•Door opens frequently
•Door not closed tightly
•The temperature control switch was not set right
•Door gasket not sealed properly
•Unit not having correct clearances
It makes an unusual noise
•It may be caused by an imbalance in the position
•The compressor keeps working for a long period
•The environment temperature may be high.
•The door may be opened frequently or even left
opened.
•The temperature control knob setting in 5 state
may increase the working time of compressor.

9
PROBLEMS POSSIBLE CAUSE
Unusual smell
•Food with strong odour should be packed tightly
before being put inside the appliance.
•Please check whether there is any deteriorated
items or whether the liners are left uncleaned for a
long time.
Water leaks from the bottom of the refrigerator •The drain tube is blocked. Please use a tool to
unblock the drain pipe. Empty and Clean Tray
Heavy frost occurs on the rear of the appliance
•Putting hot food into the appliance may cause this
problem. Or the setting high (5 for long time)
•it may be caused by the heavy environment
moisture / humidity
Door not closed properly
•Unit not on a level surface
•Door not installed properly or reversed
•The gasket is dirty or bent
•The shelves are out of position
❑Moisture may form dew on the outside of the product during high humidity. Please wipe the external
surface with a clean and dry cloth to clear this dew
❑The flow of refrigerant through the evaporator and compressor can cause some noises which is normal.
❑The sides of product having a warm temperature; it is as a result of the appliance working.
❑The frame of the appliance will be warm to prevent condensation
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or a
qualified technician in order to avoid hazard.
