Summit FF-1074W User manual

Two-Door Frost Free Refrigerator
Le Manuel de Deux Portes Dégivrent le
Réfrigérateur
El Manual de Dos Puertas Descongela el
Refrigeradore
User Manual (Features may vary by model)
Model # FF-874W, FF-1074W, FF-1274W
Guide de l’Utilisateur (Les caractéristiques Peuvent Varier par le Modéle)
Modéle # FF-874W, FF-1074W, FF-1274W
Manual del Usuario (Las caracteristicas Pueden Variar por el Modelo)
Para Modelo de # FF-874W, FF-1074W, FF-1274W

SAFETY PRECAUTIONS
Read all of the instructions before using this appliance. When using this
appliance, always exercise basic safety precautions, including the
following:
1) Use this appliance only for its intended purpose as described in this use
and care guide.
2) This refrigerator must be properly installed in accordance with the
installation instructions before it is used. See grounding instructions in the
installation section.
3) Never unplug your refrigerator by pulling on the power cord. Always
grasp the plug firmly and pull straight out from the outlet.
4) Repair or replace immediately, all electric service cords that have become
frayed or otherwise damaged. Do not use a cord that shows cracks or
abrasion damage along its length, the plug or the connector end.
5) Unplug your refrigerator before cleaning or before making any repairs.
Note: If for any reason this product requires service, we strongly
recommend that a certified technician performs the service.
6) Do not use any electrical device or any sharp instrument in defrosting your
refrigerator.
7) If your old refrigerator is not being used, we recommend that you remove
the doors and leave the shelves in place. This will reduce the possibility of
danger to children.
8) After your refrigerator is in operation, do not touch the cold surfaces in
the freezer compartment, particularly when hands are damp or wet. Skin
may adhere to these extremely cold surfaces.
9) Do not refreeze foods which have been thawed completely. The United
States Department of Agriculture in Home and Garden Bulletin No. 69
reads: “…You may safely refreeze frozen foods that have thawed if they
still contain ice crystals or if they are still cold-below 40˚F.“
“…Thawed ground meats, poultry, or fish that have any off-odor or
off-color should not be refrozen and should not be eaten. Thawed ice
cream should be discarded. If the odor or color of any food is poor or
questionable, discard it. The food may be dangerous to eat.“
“…Even partial thawing and re-freezing reduce the eating quality of
foods, particularly fruits, vegetables, and prepared foods. The eating
quality of red meats is affected less than that of many other foods. Use
refrozen foods as soon as possible, to save as much of its eating quality
as you can.“
1
EnglishEnglish

2
Thank you for using our Summit
product. This easy-to-use manual will
guide you in getting the best use of
your refrigerator.
Remember to record the model and
serial number. They are on a label in
back of the refrigerator.
Model number
Serial number
Date of purchase
Staple your receipt to your manual. You will need it to obtain
warranty service.
10) This refrigerator should not be recessed or built-in in an enclosed
cabinet. It is designed for freestanding installation only.
11) Do not operate your refrigerator in the presence of explosive fumes.
SAVE THESE INSTRUCTIONS
for future use
DANGER
Risk of child entrapment. Before you throw away your old
refrigerator or freezer, take off the doors. Leave the shelves
in place so that children may not easily climb inside.
EnglishEnglish

3
Table Of Contents
PAGE
Safety Precautions...........................................................................1
Parts And Features ..........................................................................4
Installing Your Refrigerator ...........................................................5
Unpacking Your Refrigerator...................................................................5
Adjusting Your Refrigerator.....................................................................5
Proper Air Circulation ............................................................................5
Electrical Requirements ...........................................................................6
Door Alignment .....................................................................................7
Reversing the Door Swing.......................................................................8
Refrigerator Features And Use .................................................. 10
General Features................................................................................. 10
Refrigerator Interior Shelves................................................................. 10
Crisper and Crisper Cover................................................................... 11
Food Storage Information .................................................................... 12
Normal Operating Sounds................................................................... 13
Proper Refrigerator Care and Cleaning ................................... 14
Cleaning and Maintenance.................................................................. 14
Light Bulb Replacement........................................................................ 15
Power Interruptions ............................................................................. 15
Vacation and Moving Care.................................................................. 15
Troubleshooting............................................................................. 16
Warranty Information.................................................................. 18
EnglishEnglish

Parts And Features
4
EnglishEnglish
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
1. Ice Cube Trays
2. Full-Width Freezer Door Shelves
3. Full-Width Door Shelf
4. Adjustable Front Leveling Legs
(not shown)
5. Clear Crisper
6. Clear Glass Crisper Cover
7. Adjustable Full-Width Wire Shelves
(number will vary by model)
8. Adjustable Mechanical
Temperature Control
9. Interior Light
10. Freezer Shelf
11. Gallon Storage Compartment
12. Can Storage (not on all models)
13. 1/2 Width Shelf Storage
Compartment (not on all models)
14. Half-Width Shelf, 2 Liter Bottle
Storage Compartment
15. Crisper Humidity Control
16. Air Flow Control
17. Condiments Storage Shelf
(not on all models)
(Features may vary per model)

Unpacking Your Refrigerator
1. Remove all packaging material. This includes the foam base and
all adhesive tape holding the refrigerator accessories inside an outside.
Slide out and remove plastic or foam guard used to secure the
compressor from shipping damage due to vibration and shock.
2. Inspect and remove any remains of packing, tape or printed materials
before powering on the refrigerator.
Adjusting Your Refrigerator
Leveling Your Refrigerator:
• Your refrigerator has two leveling legs which are located in the
front corners of your refrigerator. After properly placing your
refrigerator in its final position, you can level your refrigerator.
• Leveling legs can be adjusted by turning them counterclockwise to raise
your refrigerator or by turning them clockwise to lower your refrigerator.
The refrigerator door will close easier when the leveling legs are raised.
Proper Air Circulation
• To ensure that your refrigerator works at the maximum efficiency it was
designed for, you should install it in a location where there is proper air
circulation, plumbing and electrical connections.
• The following are recommended clearances around the
refrigerator:
Sides……………3/4" (19mm)
Top....................1" (25mm)
Back..................1" (25mm)
Installing Your Refrigerator
5
EnglishEnglish

6
EnglishEnglish
Electrical Requirement
• Make sure there is a suitable power outlet (115 volts, 15 amps outlet)
with proper grounding to power the refrigerator.
• Avoid the use of three-plug adapters or cutting off the third grounding
in order to accommodate a two-plug outlet. This is a dangerous practice
since it provides no effective grounding for the refrigerator and may
result in shock hazard.
Installation Limitations
• Do not install your refrigerator in any location not properly insulated or
heated, e.g. garage etc. Your refrigerator was not designed to operate
in temperature settings below 55˚ Fahrenheit.
• Select a suitable location for the refrigerator on a hard, even
surface away from direct sunlight or heat source, e.g. radiators,
baseboard heaters, cooking appliances etc. Any floor unevenness should
be corrected with the leveling legs located on the front bottom corners of
the refrigerator.
Use of Extension Cords
• Avoid the use of an extension cord because of potential safety
hazards under certain conditions. If it is necessary to use an extension
cord, use only a 3-wire extension cord that has a 3-blade grounding
plug and a 3-slot outlet that will accept the plug. The marked rating of
the extension cord must be equal to or greater than the electrical rating
of the appliance.

Freezer Door: (see fig. # 1)
1. Remove hinge cover screw.
2. Remove the top hinge cover.
3. Loosen the top hinge screws using a Phillips head screwdriver.
4. Adjust the door or put a spacer in between and then tighten the screws.
5. Replace the top hinge cover.
Door Alignment
7
Reversing the Door Swing
fig. # 1
Hinge
cover
Top hinge
EnglishEnglish
Left/right door opening method:
This product allows you to reverse the door opening from left to right and
back. You can select your preference of door opening by following the
procedure to make the change.
Dismantling: (see fig. # 1 and fig. # 2)
1. Affix refrigerator and freezer door by sticking adhesive tape on both
sides to hold doors in place.
2. As shown in fig. 1, dismantle the hinge cover on the upper part of
freezer door with a Phillips head screwdriver. Then remove the three
screws that hold the hinge. Take out the hinge by pulling it vertically,
and keep it in a safe place.
3. Remove the adhesive tape on freezer door, lift it and take off the door,
and carefully put it aside.
4. Dismantle two screws of the central hinge, lift it and take off the central
hinge, and keep them in a safe place. (see fig # 2)
5. Remove the adhesive tape on refrigerator door, lift it and take
refrigerator door, and carefully put it aside.
6. Remove the doorstoppers from the refrigerator and freezer doors.
7. Insert left side doorstopper (provided in your packing) on the left side
bottom hole of the refrigerator door and on the left side bottom hole of
the freezer door. Fasten with screws provided.

8
screw holes
doorstopper (right side)
middle pivot pin
central hinge
fig. # 2
EnglishEnglish
Reinstallation: (see fig. # 3 and fig. # 4)
1. Remove the lower pivot pin from the lower hinge by turning counter
clockwise. Move the pin to the opposite hole and tighten. (see below)
2. Tilt refrigerator on a 45-degree angle to have access to the
bottom front.
NOTE: Two People Required.
lower pivot pin
fig. # 3
bottom of unit
bottom hinge

3. Remove both left and right front feet from bottom.
4. Loosen the screws holding the bottom hinge
and remove it.
5. Align the holes in the bottom hinge to the corresponding holes on the
opposite side of the cabinet. Insert and tighten the screws. Reinstall both
front feet.
6. To install refrigerator door: Line up the left bottom hole of the
refrigerator compartment door over the bottom hinge pin. Move
door forward to make it straight and align with central hinge.
Install the central hinge again, and turn the hinge axle until it
completely enters the door body. Secure it with the screws provided.
(see fig. 4)
NOTE: Remove plugs from doorframe and install on other side.
7. To install freezer door: Lineup left bottom hole of the door over the
central hinge middle pin. Move door forward to make it straight
and align with freezer compartment. Place over left side the top hinge,
align holes with hole on the refrigerator top and tighten with the
screws provided.
9
doorstopper (left side)
middle pivot pin
central hinge
screw holes
fig. # 4
EnglishEnglish

10
Refrigerator Features And Use
The refrigerator shelves of your refrigerator were designed with you
in mind. Their varied adjustability allows you to satisfy your personal
storage needs.
To remove or adjust a full-width
slide-out shelf: (see fig. # 5)
1. Gently tilt the shelf up and slide forward until the shelf has been
completely removed.
2. To replace the shelf, select the desired setting and gently slide the
shelf back until it rests in the locking position.
General Features
Adjustable temperature dial:
Your refrigerator will automatically
maintain the temperature level you
select. The temperature control dial
has 7 settings plus off. 1 is the warmest.
7 is the coldest. Turning the dial to OFF
stops cooling in both the refrigeration
and freezer sections. At first, set the
dial to 4 and allow 24 hours to pass
before adjusting the temperature to
your needs.
To adjust the temperature range in the
cold setting, turn the temperature dial
in a clockwise direction. For normal
operating conditions, keep the dial
halfway between cold and coldest. For
your convenience, the factory presets the
control at normal operating conditions.
(Note: If the refrigerator has
been placed in a horizontal or
tilted position for any period
of time wait 24 hours before
plugging the unit in.)
Refrigerator Section
Interior Light:
Your refrigerator is equipped with an
interior light in the fresh food section for
you to easily locate your food.
Your freezer compartment is equipped
with adjustable airflow control. For
your convenience, airflow is preset by
the factory to the colder setting. There
is also an option to adjust the settings,
either to cold or to coldest.
Your refrigerator may be equipped with
slide control to raise or lower the
humidity levels or your crispers. This
feature will increase the storage life of
your fruits and vegetables. Simply adjust
the controls to the appropriate setting
for setting for items you are storing in
the crispers. Low settings allow moist air
to exit the crisper, for optimum storage
of fruit and/or vegetables that have
skins. High settings retains moist air in
the crisper, for optimum storage of fresh
vegetables.
Refrigerator Interior Shelves
(Shelves May vary by Model)
fig. # 5
EnglishEnglish

11
To remove and install the crisper: (see fig. # 6)
1. Grip the crisper firmly and slide out completely.
2. Replace the crisper by placing the crisper properly in position and
gently sliding it back into place.
Removing or replacing the crisper cover: (see fig. # 7)
1. Carefully grasp the crisper cover and slide out to remove.
2. To replace, slide the rear of the crisper cover into the right and left slots
above the crisper area and gently slide back into place.
Crisper and Crisper Cover
fig. # 6
fig. # 7
EnglishEnglish

12
Fresh Food
• When storing fresh food that is not prepackaged, be sure to wrap or
store food in airtight and moisture-proof material unless otherwise
noted. This will ensure proper shelf life and prevent the transfer of
odors and tastes.
• Wipe containers before storing to avoid needless spills.
• Eggs should be stored in an upright position in their original
carton to maximize shelf life.
• Fruit should be washed and dried, then stored in sealed plastic bags
before storing in the refrigerator.
• Vegetables with skins should be stored in plastic bags or
containers.
• Leafy vegetables should be washed and dried, then stored in
plastic bags or containers.
• Hot food should be allowed to cool before storing in the
refrigerator. This will prevent unnecessary energy use.
• Fresh seafood should be used the same day as purchased.
• When storing meats in the fresh food section, keep in the original
packaging or rewrap as necessary. Follow the suggestions below for
safe storage:
• Chicken 1-2 Days
• Ground Beef 1-2 Days
• Cold Cuts 3-5 Days
• Steaks/Roasts 3-5 Days
• Smoked/Cured Meats 7-10 Days
• All others 1-2 Days
If longer periods of storage are required, store immediately in the
freezer section.
Food Storage Information
EnglishEnglish

13
Frozen Food
• Proper freezer storage requires correct packaging. All foods must be
in packages that do not allow the flow of air or moisture in or out.
Improper storage will result in odor and taste transfer and will result in
the drying out of the improperly packaged food.
• Follow package or container instructions for proper storage.
• Packaging Recommendations:
Plastic containers with air tight lids
Heavy duty aluminum foil
Plastic wrap made from saran film
Self-sealing plastic bags
• Do not refreeze defrosted/thawed foods.
• It is recommended that the freezing date be marked on the
packaging.
• The fan circulating air inside the interior of your unit to maintain the
temperature you have selected.
• Boiling water, gurgling sounds or slight vibrations that are the result of
the refrigerant circulating through the cooling coils.
• The thermostat control will click when it cycles on and off.
Normal Operating Sounds You May Hear
EnglishEnglish

14
Warning: To avoid electric shock always unplug your
refrigerator before cleaning. Ignoring this warning
may result in death or injury.
Caution: Before using cleaning products, always read and
follow manufacturer’s instructions and warnings to
avoid personal injury or product damage.
General:
• Prepare a cleaning solution of 3-4 tablespoons of
baking soda mixed with warm water. Use sponge or
soft cloth, dampened with the cleaning
solution, to wipe down your refrigerator.
• Rinse with clean warm water and dry with a soft cloth.
• Do not use harsh chemicals, abrasives, ammonia,
chlorine bleach,concentrated detergents, solvents or
metal scouring pads. Some of these chemicals may
dissolve, damage and/or discolor your
refrigerator.
• Clean door gaskets every three months according to
general instructions. Gaskets must be kept clean and
pliable to ensure a proper seal.
• Petroleum jelly applied lightly on the hinge side of
gaskets will keep the gasket pliable and ensure a good
seal.
Proper Refrigerator Care
and Cleaning
Cleaning and Maintenance
Door Gaskets:
Refrigerators: FF-874W/FF-1074W/FF-1274W
We recommend that you clean the rear of the refrigerator at least twice a year.
Some operating environments may require more frequent cleaning.
• Slowly pull the refrigerator straight out away from the wall.
Note: Do not move the refrigerator sideways as this may cause damage to the
floor covering of your refrigerator.
• Unplug the refrigerator.
• Use a vacuum or a brush to clean coils.
• When cleaning has been completed, plug the cord back into the outlet and slide
the refrigerator straight back to its original position.
Note: When pushing it back, be sure not to roll over the power cord.
EnglishEnglish

15
1. Switch off power to refrigerator.
2. Remove the highest shelf.
3. Allow light bulb to cool before removing.
4. Pinch the plastic cover between fingers and
thumb and gently pull to the left.
5. Remove the bulb by screwing it counter-clockwise.
6. Always replace with appliance-type light bulb rated at 15 watts
or lesser wattage.
7. Do not exceed the 15 watts rating at any time.
8. To replace cover, insert rear clips in first and gently push front
clip in until the cover snaps into place.
• Occasionally there may be power interruptions due to
thunderstorms or other causes. Remove the power cord from AC outlet
when a power outage occurs. When power has been restored, replug
power cord to AC outlet. If outage is for a prolonged period, inspect
and discard spoiled or thawed food in freezer and refrigerator. Clean
refrigerator before reusing.
• For long vacations or absences, empty food from refrigerator and
freezer, move the temperature to the OFF position and clean the
refrigerator and door gaskets according to "General cleaning"
section. Prop doors open, so air can circulate inside.When moving
always move the refrigerator vertically. Do not move with the unit lying
down. Possible damage to the sealed system could occur.
Light Bulb Replacement
Power Interruptions
Vacation and Moving Care
EnglishEnglish

16
Refrigerator Does Not Operate
• Check if thermostat control is not in the “OFF” position.
• Check if refrigerator is plugged in.
• Check if there is power at the AC outlet, by checking the circuit breaker.
Food temperature appears too warm
• Frequent door openings.
• Allow time for recently added warm food to reach fresh food or
freezer temperature.
• Check gaskets for proper seal.
• Adjust temperature control to colder setting.
Food temperature is too cold
• If temperature control setting is too cold, adjust to a warmer
setting and allow several hours for temperature to adjust.
Refrigerator runs too frequently
• This may be normal to maintain constant temperature during
high temperature and humid days.
• Doors may have been opened frequently or for an extended
period of time.
• Check gasket for proper seal.
• Check to see if doors are completely closed.
Troubleshooting
EnglishEnglish

17
Moisture build-up on interior or exterior
of the refrigerator:
• This is normal during high humidity periods.
• Prolonged or frequent door openings.
• Check door gaskets for proper seal.
Refrigerator has an odor:
• Interior needs cleaning.
• Foods improperly wrapped or sealed are giving off odors.
Refrigerator light does not work:
• Check power supply.
• Tighten bulb in socket.
• Replace burned-out bulb.
Refrigerator/Freezer door does not shut properly:
• Level the refrigerator.
• Realign refrigerator/freezer door.
• Check for blockages e.g. food containers, crisper cover,
shelves, bins etc.
EnglishEnglish

18
Summit Limited Warranty
EnglishEnglish
Summit Appliances warrants this
product to be free from defects
in materials and workmanship for
a period of one year from the date
of original purchase or delivery with
an additional 5 years parts only on
the compressor. Any parts determined
to be defective will be replaced by
SUMMIT at no charge to you. Plastic
parts, liners and outer cabinets are
warranted to be manufactured to
commercially acceptable standards
and free from defects at the time
of delivery.
This limited warranty does not
apply to:
1. Improper installation
2. Customer misuse, negligence
or damage
3. Incorrect electrical current
4. Products with the serial number
altered or removed
5. Products sold or used outside the
fifty United States or the District
of Columbia
6. Commercial or Industrial Users
7. Damage to this product from
accidents, alterations, failure to
follow instructions, fire, floods,
earthquakes, war, civil disturbance
or Acts of God.
SUMMIT is not liable for consequential
or incidental damage.
SUMMIT APPLIANCE DIV.
FELIX STORCH, INC.
770 GARRISON AVENUE
BRONX, NY 10474
[phone]
FACTORY REGISTRATION CARD
THANK YOU FOR PURCHASING A QUALITY SUMMIT®APPLIANCE
Summit Model Number Serial
Customer’s Name Date of Delivery
Address Apt. No.
City State Zip
Dealer’s Name City State
Is this unit for: Private Home Apartment Office Other
Reasons for selecting this unit: Dealer Recommendation
Size Price Other

FrançaisFrançais
1
MESURES DE SECURITE
Lire l’ensemble des instructions avant d’utiliser l’appareil. Lors de l’utilisation
de cet appareil, prendre toutes les mesures de sécurité de base, y compris
les suivantes:
1) N’utiliser cet appareil que pour l’usage pour lequel il est prévu, tel qu’il
est indiqué dans le guide d’utilisation et d’entretien.
2) Ce réfrigérateur doit être correctement installé conformément aux
instructions d’installation avant d’être utilisé. Consulter les instructions de
mise à la terre du chapitre Installation.
3) Ne jamais tirer sur le cordon d’alimentation pour débrancher le
réfrigérateur. Toujours saisir fermement la fiche et la retirer
complètement de la prise.
4) Réparer ou remplacer immédiatement tout cordon électrique effiloché ou
endommagé d’une quelconque manière. Ne pas utiliser un cordon fissuré,
abrasé ou dont la prise ou le connecteur est endommagé.
5) Débrancher le réfrigérateur avant de le nettoyer ou d’effectuer des
réparations. Remarque: Si ce produit doit faire l’objet d’une
maintenance pour quelque raison que ce soit, il est vivement
recommandé de confier cette tâche à un technicien agréé.
6) Ne pas utiliser d’appareils électriques ou d’objets pointus pour dégivrer le
réfrigérateur.
7) Si vous n’avez plus l’usage de votre ancien réfrigérateur,
nous vous conseillons d’en retirer les portes et laissons les étagères
dans leur emplacement approprié. Ceci permet d’éviter tout danger
potentiel pour les enfants.
8) Une fois le réfrigérateur en fonctionnement, ne pas toucher les surfaces
froides du compartiment de congélation, en particulier avec des mains
mouillées ou humides. La peau risquerait d’adhérer à ces surfaces
extrêmement froides.
9) Ne pas recongeler les aliments qui ont été complètement décongelés. Le
bulletin Maisons et Jardins du Ministère de l’Agriculture des États-Unis n°
69 stipule que: “ ...Les aliments congelés peuvent être recongelés en toute
sécurité s’ils contiennent toujours des cristaux de glace ou si leur
température reste inférieure à 4,5°C“.
“ …Les viandes hachées, la volaille et le poisson présentant une odeur
désagréable ou une couleur suspecte ne doivent ni être recongelés, ni être
consommés. La crème glacée dégelée doit être jetée. Tout aliment
présentant une odeur ou couleur douteuse doit être jeté. L’ingestion d’un
aliment de ce type peut s’avérer dangereuse.”
