Sumo ST 520 Assembly instructions
9.45 x 12.2 x 1.57 in; 240 x 310 x 40 mm
SUMO ST520.
Always exercise care when operating and handling the SU O ST520.
SU O ST520 rugged xed-mount tablet
guidance on the hardware elements and features of the SUMO ST520. Please refer to your device
and startup proceed smoothly. The SU O ST520 is ready for use, out of the box, in its default
M
The SUMO ST520 offers Microsoft® Windows® XP Embedded or Professional operating systems.
The SUMO ST520 integrates a 12.1” TFT LCD display and AMD Mobile Sempron™ 1GHz processor,
ST520, a rugged xed-mount tablet designed to run
Technologies line of tablet devices- the SUMO
Thank you for acquiring the latest addition to SUMO
SUMO ST 520
ENGLISH
ENGLISH 4
signage dtri com
INTRODUCTION
applications that support specic business processes.
and enables real-time data access in harsh environments by combining wireless networking
with shock, vibration and water protection. The compact, yet robust device is IP65 and MIL-STD-
810F highway truck vibration exposures, supporting water-proof and dust-proof operation and
standards.
Each system features web browser, client/ server computing software, media player, accessories,
and applications support, enabling timely and cost-effective deployment of applications.
Please take a few moments to review the contents of this document to ensure that the setup
conguration when powered by the power source provided. The following discussion offers
provider for information pertaining to the software operating system or software applications.
Package Contents
•
A
• C/DC power adapter with power cord
Precautions
•
Never disassemble any portion of the enclosure, as this will void any product warranty on the•
Do not use any AC/DC adapter other than the one provided with the device or a replacement•
acquired from the manufacturer.
SPECIFICATIONS
Display 12.1” TFT LCD with resistive touch, outdoor-viewable option
Display Resolution 1024 x 768
Processor AMD Mobile Sempron™ 1GHz
Storage Up to 16GB ash memory module,
HDD (120GB), SSD (32GB/ 64GB) (optional)
Operating Systems Windows®XP Embedded; Windows®XP Professional
Display Enclosure Magnesium-aluminum alloy
Control Buttons One (1) mechanical switch power button,
one (1) power button, and nine (9) programmable buttons
Input/Output Ports One (1) COM port, one (1 ) Mic-in , one (1) Headphone out,
four (4) USB (2.0), Ethernet RJ45, two (2) DC-in jack (AC-DC/ DC-DC)
Network Interface Bluetooth Class2, Ethernet 10/100/1000 Base-T LAN,
Wireless 802.11a/b/g
Speaker One (1) built-in speaker
AC/DC adapter Input voltage 100 - 240V AC, 50/60 Hz
Output: 18.5V, 3.5A
DC / DC 12 - 36V DC input
Power Cords North America, EU, UK and China
Dimensions
(H x W x D)
Base Weight 6.6lbs (3 Kg) (with UPS battery, HDD);
5.5 lbs (2.5 Kg)/ (without UPS Battery, HDD)
Regulatory FCC Class B, CE, UL, RoHS compliant, C-Tick, MIL STD 810F, and IP65
Operating
Temperature 0oC - 40oC
Humidity 5% - 95% RH non-condensing
* Note: Specications are subject to change without notice.
Rugged Fixed-Mount
Tablet
BASIC OPERATION GUIDE
THE SUMO ST520
M
M
D
D
For more information, including pricing, availability and detailed features
SUMO Technologies Ltd, Manor Chambers, Marygate, YORK YO30 7BH
Tel: +44 (0) 1904 670670 Fax: +44 (0) 1904 670570
The front panel of the SUMO ST520 features power and programmable buttons.
M
Outdoor-viewable touch screen
The SU O ST520 has a number of optional congurations in both software and hardware.
The SUMO ST520 is designed to be secured to VESA-compliant mounting arms or stands. The
The SUMO ST520 has a comprehensive set of I/O ports. The following ports are located
there is ever a need to ship the SUMO ST520.
The SU O ST520 is packaged with recyclable materials and designed for maximum
ENGLISH 23ENGLISH
Packaging
•
protection in transportation and handling.
When possible, please save the packaging carton and protective inserts for re-use if•
I/O Panels
Lower I/O Panel
along the lower rear edge of the display unit.
Serial port1.
Audio-out jack2.
Microphone-in jack3.
Four (4) USB 2.0 ports4.
Enternet port5.
DC in jack6.
Fuse7.
DC power inlet8.
Power Switch9.
Front Panel Function Buttons
Programmable buttons:10.
Power button11.
Rear Mounting
VESA-compliant mounting holes at the rear of the device will mate with VESA mounts or
arms to meet the requirements of the deployment.
The tablet without the VESA-compliant1.
mounting arm
The display successfully mounted on a3.
VESA - compliant mounting arm.
Attach the VESA-compliant2.
mounting arm or stand to the
display using the same screws
removed in step 1.
8 9
1110
The nine (9) buttons are
intended to be user
programmable via software
in applicable operating
systems.
M
• ay be congured to perform different functions, depending on the software operating
system.
D
• epending on the OS, a brief, rm push will trigger software-enabled entry into Shutdown
or Standby modes. Push in similar manner to Restart or to exit Standby mode.
P
• ush and hold for over 4 seconds to forcefully shut down the device. This method
of powering off should only be used when proper shutdown through software is not
possible.
OPTIONS
These include:
1.
HDD or SSD storage2.
Back-up battery pack implemented as an uninterruptible power supply (UPS)3.
Waterproof keyboard and keyboard tray4.
U bracket5.
DC power cable6.
