Sun Bandit YC500-S User manual

Sun Bandit® Water Heater with YC-500S AC Micro-Grid Inverter(s)
Read and follow all installation, operation
and maintenance documents prior to installation.
Installation Guide
AC GROUND
ELECTRODE
CONDUCTOR
#6 BARE CU
STRAIGHT TO GROUND
ELECTRODE
(IE GROUND ROD)
JUNCTION
BOX
AC MICRO-GRID
30A DISCONNECT
FUSED AT 15A
Sun Bandit
® 200
Sun Bandit® 200 THREE-LINE
GROUND ELECTRODE
(IE GROUND ROD)
Sun Bandit®
HYBRID
WATER
HEATER
Sun Bandit®
MONITOR
01
30A 240V
GRID TIED
CIRCUIT
WIRE SIZING BY
ELECTRICIAN
2 #12 CU W
EQUIPMENT
GROUND
MAX 80FT
Version
170130
of 01
©2017 Sun Bandit®
All rights reserved. No portion of this document may be reproduced without the written consent of Sun Bandit®. Sun Bandit® is a registered trademark of Next Generation Energy®. Patents Pending.
This document, and the information it contains, including the principles of design, is the exclusive property of Sun Bandit® and is confidential. Accordingly, this information is submitted to you with the agreement that it is not to be reproduced, copied,
or loaned in part or in whole, nor is the information to be relayed to any other individual or company except as Sun Bandit® first authorizes in writing. Acceptance of this document constitutes agreement to these restrictions.
NOTE: ALL WORK TO BE PERFORMED BY
QUALIFIED ELECTRICIANS.ALL WORK TO BE
DONE PER AHJ AND UTILITY REQUIREMENTS.
ALL INSTALLATION CONDITIONS TO BE FIELD VERIFIED FOR APPROPRIATENESS.
TO BUILDING
ELECTRICAL
(NOT PROVIDED BY NGE®)
NOTE: Sun Bandit
®
AC
MICRO-GRID RESISTIVE
ELEMENT CONNECTIONS
AT TOP OF TANK



Sun Bandit® YC500-S
MICRO-GRID INVERTER
MASTER AND SUBORDINATE
DC INPUT (PER MODULE / CHANNEL)
RECOMMENDED PV MODULE POWER RANGE (STC): 180W-310W
MPPT VOLTAGE RANGE: 22V - 45V
OPERATION VOLTAGE RANGE: 16V - 45V
MAXIMUM INPUT VOLTAGE: 55V
STARTUP VOLTAGE: 22V
MAXIMUM INPUT CURRENT: 10.5A
MAXIMUM DC SHORT CIRCUIT CURRENT: 15A
TYP OF 4 CHANNELS
L1
L2
G
WHIP
#12 CU W
EQUIPMENT
GROUND
INVERTER OUTPUT
TO WHIP
CONNECTION
INVERTER OUTPUT
CABLE
2 #12 CU W
EQUIPMENT
GROUND
NOTE: BOND AND GROUND PANEL FRAMES
AND RACKING PER MANUFACTURER, NEC, AND
AHJ REQUIREMENTS
DC GROUND
ELECTRODE
CONDUCTOR
#6 BARE CU
STRAIGHT TO GROUND
ELECTRODE
(IE GROUND ROD)
TOP VIEW OF
WATER HEATER:
2 #12 CU W
EQUIPMENT
GROUND
MAX 20FT TOTAL

L
N
G






BLACK
Sun Bandit® YC500-S
MICRO-GRID INVERTER
AC MAX OUTPUT POWER: 450W
AC MAX OUTPUT CURRENT: 5A
MAX AC OUTPUT VOLTAGE: 150V
DC GROUND
ELECTRODE
CONDUCTOR
#6 BARE CU
STRAIGHT TO GROUND
ELECTRODE
(IE GROUND ROD)
Sun Bandit® YC500-S
MICRO-GRID INVERTER
AC MAX OUTPUT POWER: 450W
AC MAX OUTPUT CURRENT: 5A
MAX AC OUTPUT VOLTAGE: 150V
L
N
G
L
N
G
INVERTER
TO
INVERTER
CONNECTION
Channel 1
Channel 2
Channel 1
Channel 2
PROTECTIVE
END CAP
PROVIDED
2 #12
WITH #12 GROUND
AWM STYLE 2586
FACTORY SUPPLIED
MAX 6 FT TOTAL
2 #12
WITH #12 GROUND
AWM STYLE 2586
FACTORY SUPPLIED
MAX 6 FT TOTAL
NOTE: Always check with your Authority Having Jurisdiction about your proposed grounding methodology prior to installing the system
RED
GREEN
DC DC Ground Electrode Conductor:
A DC Ground Electrode Conductor (typically #6 bare CU) must be installed
and terminated at the marked location on the Sun Bandit AC Micro-Grid
Inverters. The DC Ground Electrode Conductor must be run unspliced or
irreversibly spliced from the marked grounding locations on the inverters to
the premises grounding electrode system (ie ground rod). PV Panel frames,
mounting rails, and other metal equipment are not to be used as part of
the DC Ground Electrode Conductor.
AC AC Ground Electrode Conductor and AC System Grounding:
Each Sun Bandit AC Micro-Grid circuit is a separately derived AC system
and requires a system bonding jumper between the neutral AC Micro-Grid
output conductor and ground. The system bonding jumper must be
installed in one and only one location at the first disconnecting
means on the AC side of the Sun Bandit Micro-Grid Inverters. From
this point an AC Ground Electrode Conductor (typically #6 bare CU) must
be run unspliced or irreversibly spliced to the premises grounding electrode
system (ie ground rod).
Solar PV
Module
Solar PV
Module
Solar PV
Module
Solar PV
Module
BLACK
WHITE
GREEN
BLACK
WHITE
GREEN
BLACK
RED
GREEN
BLACK
RED
GREEN
BLACK
RED
1
1
2

3
1
= LOCATION OF
UPPER / LOWER
RESISTIVE
ELEMENT
BLACK
WHITE
GREEN
L
N
G


4500W
GRID BACKUP
ELEMENT


GREEN
BLACK
WHITE
GREEN
2
= LOCATION OF
SINGLE
RESISTIVE
ELEMENT
3
= LOCATION OF
STANDARD
UTILITY
POWERED
RESISTIVE
ELEMENT
FRONT VIEW OF
WATER HEATER:
DC
AC
DC


NOTE: BOND AND GROUND PANEL FRAMES
AND RACKING PER MANUFACTURER, NEC, AND
AHJ REQUIREMENTS


www.sunbandit.us 877-NGE-4SUN (877-643-4786)
Sun Bandit® is a trademark-registered, patented product innovation of Next Generation Energy® © 2017 All Rights Reserved 5/2017

2
Pre-Installation Tips
Read and follow these precautions
before you begin:
The supplied Mix Valve must be installed on
all systems as shown!
Read all manuals and safety information that
pertain to your system prior to installation.
Fill Water Heater with water before making
any electrical connections to protect resistive
elements!
Modules produce voltage when exposed to
sunlight, be aware and avoid shock.
Always check with your Authority Having
Jurisdiction (AHJ) about your proposed
grounding methodology prior to installation.
Items Needed for Installation:
All systems require you to supply the following items:
1. Wire from junction box on roof to water heater in
mechanical room.
2. #6 bare copper grounding wire from AC Micro-Grid
Inverters to Ground Electrode and AC Disconnect
to Ground Electrode (separate parallel runs are
required).
Depending upon the system you’ve purchased,
you may also need the following items:
1. Modules and Racking.
2. AC Disconnect with fuse to match your system.
3. Junction box and ashing for connecting whip to
wires beneath the roof.
www.sunbandit.us 877-NGE-4SUN (877-643-4786)
Sun Bandit® is a trademark-registered, patented product innovation of Next Generation Energy® © 2017 All Rights Reserved 5/2017

3
Refer to all manufacturer’s installation manuals for important details, safety instructions and equipment warnings.
Steps:
1. Mix Valve & Plumbing
2. Connect Water Heater to Grid
3. AC Disconnect & Monitor
4. Adjust Thermostats
5. AC Micro-Grid Inverter(s) & Racking
6. DC Equipment Ground
7. AC Equipment Ground
8. AC Disconnect & Junction Box
9. Connect to Modules
10. Connect to Whip
11. Commission System
Installation Procedure
www.sunbandit.us 877-NGE-4SUN (877-643-4786)
Sun Bandit® is a trademark-registered, patented product innovation of Next Generation Energy® © 2017 All Rights Reserved 5/2017

4
Refer to the Water Heater installation manual for important details, safety instructions and warnings.
Note: Refer to the Water Heater
installation manual for heat trap and
expansion tank suggestions.
Plumb to the Hot/Cold
connections at the top of the
Mix Valve.
Install the supplied Mix Valve
to the top of the tank.
Fill the tank with water.
Step 1. Mix Valve & Plumbing
Fill Water Heater with water
before making any electrical
connections to protect resistive
elements!
The Mix Valve must be
installed as shown!
www.sunbandit.us 877-NGE-4SUN (877-643-4786)
Sun Bandit® is a trademark-registered, patented product innovation of Next Generation Energy® © 2017 All Rights Reserved 5/2017

5
Refer to the Water Heater installation manual for important details, safety instructions and warnings.
Step 2. Connect Water Heater to Grid
Connect Grid side to match your backup type (Electrical or Gas).
Fill Water Heater with water before
making electrical connections.
The water heater is ready to
be used as a normal water
heater until the solar side of
the system is connected.
Congratulations!
www.sunbandit.us 877-NGE-4SUN (877-643-4786)
Sun Bandit® is a trademark-registered, patented product innovation of Next Generation Energy® © 2017 All Rights Reserved 5/2017

6
Step 3. AC Disconnect & Monitor
Refer to the 3-line Electrical Diagram for your particular system.
Connect the Monitor of your primary circuit to the Upper/Lower junction box
of the Water Heater.
If your system is equipped with a secondary circuit, connect the Monitor to
the Single junction box of the Water Heater.
Connect the corresponding AC
Disconnect to the Monitor for each
circuit per your system diagram.
www.sunbandit.us 877-NGE-4SUN (877-643-4786)
Sun Bandit® is a trademark-registered, patented product innovation of Next Generation Energy® © 2017 All Rights Reserved 5/2017

7
Set All AC Micro-Grid
(Solar) thermostats to
Very Hot.
Set the Grid (Utility)
thermostat as low as possible to
maintain customer comfort. The
factory setting is usually effective.
Step 4. Adjust Thermostats Disconnect Fuse Block or shut off
AC Disconnect to avoid shock.
Remove all covers and foam
insulation to adjust the element
thermostats. Remove plastic shield to
verify all connections are tight.
Refer to the Water Heater Installation Manual for more details.
www.sunbandit.us 877-NGE-4SUN (877-643-4786)
Sun Bandit® is a trademark-registered, patented product innovation of Next Generation Energy® © 2017 All Rights Reserved 5/2017

8
Step 5. AC Micro-Grid Inverter(s) & Racking
Mount the Racking per your system
design specications and racking
manufacturer.
Mount the AC Micro-Grid Inverter(s) to the racking per your system design.
Space each AC Micro-Grid Inverter beneath a module within reach of the
corresponding pair of module connections and inverters (if present).
Identify and verify proper location of Master and Subordinate on 3-line.
Refer to the AC Micro-Grid Inverter Installation manual for warnings and details.
www.sunbandit.us 877-NGE-4SUN (877-643-4786)
Sun Bandit® is a trademark-registered, patented product innovation of Next Generation Energy® © 2017 All Rights Reserved 5/2017

9
Step 6. DC Equipment Ground
A DC Ground Electrode Conductor (typically #6 bare CU) must be installed
and terminated at a grounding lug on each Sun Bandit AC Micro-Grid Inverter.
It must be run unspliced or irreversibly spliced from the grounding lug on each
inverter to the premises grounding electrode system (ie; ground rod).
PV Module frames, mounting rails, and other metal equipment are not
to be used as part of the DC Ground Electrode Conductor.
Check with your Authority
Having Jurisdiction (AHJ)
to approve the building ground
electrode prior to installation.
Splice at the Grounding
Electrode (ie; ground rod).
(not to scale)
Refer to the 3-line Electrical Diagram for your particular system.
www.sunbandit.us 877-NGE-4SUN (877-643-4786)
Sun Bandit® is a trademark-registered, patented product innovation of Next Generation Energy® © 2017 All Rights Reserved 5/2017

10
Step 6. DC Equipment Ground (cont’d)
Run the bare #6 copper over the roof to the Ground Electrode (building
ground). Insulated, stranded #6 copper can be used as an alternative when
run in conduit or raceway.
Go through the junction box on the
roof as an alternative.
Refer to the 3-line Electrical Diagram for your particular system.
www.sunbandit.us 877-NGE-4SUN (877-643-4786)
Sun Bandit® is a trademark-registered, patented product innovation of Next Generation Energy® © 2017 All Rights Reserved 5/2017

11
Step 7. AC Equipment Ground
Each Sun Bandit AC Micro-Grid circuit is a separately derived AC system
and requires a system bonding jumper between the neutral AC Micro-Grid
output conductor and ground.
The system bonding jumper must be installed in one and only one location
at the rst disconnecting means on the AC side of the Sun Bandit Micro-
Grid Inverters.
Check with your Authority Having Jurisdiction (AHJ) to
approve the building ground electrode prior to installation.
From this point an AC Ground
Electrode Conductor (typically #6
bare CU) must be run unspliced or
irreversibly spliced to the premises
grounding electrode system (ie
ground rod).
Disconnect Fuse Block or shut off
AC Disconnect to avoid shock.
AC Fuse Block removed.
AC Disconnect showing
AC Ground Electrode
Conductor from terminal
block (bare #6).
Refer to the 3-line Electrical Diagram for your particular system.
www.sunbandit.us 877-NGE-4SUN (877-643-4786)
Sun Bandit® is a trademark-registered, patented product innovation of Next Generation Energy® © 2017 All Rights Reserved 5/2017

12
Run corresponding wires from the roof down to the AC Disconnect. Make connections to mating wires of the Whip
within a junction box and to the AC Disconnect using appropriate screw terminals.
Step 8. AC Disconnect & Junction Box
Refer to the 3-line Electrical Diagram for your particular system.
www.sunbandit.us 877-NGE-4SUN (877-643-4786)
Sun Bandit® is a trademark-registered, patented product innovation of Next Generation Energy® © 2017 All Rights Reserved 5/2017

13
Connect Modules to corresponding channels on the supplied AC Micro-Grid Inverter(s) per system design within the
3-line diagram. Mount the Modules per your system design and Module manufacturer specications.
Step 9. Connect to Modules
Refer to the 3-line Electrical Diagram for your particular system and
Racking Installation Manual for detailed information.
www.sunbandit.us 877-NGE-4SUN (877-643-4786)
Sun Bandit® is a trademark-registered, patented product innovation of Next Generation Energy® © 2017 All Rights Reserved 5/2017

14
Temporarily install fuse and fuse block at the AC Disconnect, then use a volt meter to measure resistance of the wiring
from the Whip through the roof to the Resistive Elements in the tank. The resistance between line and neutral should
be 18-20 ohms. The resistance between neutral and ground should be almost 0 ohms.
Check all connections until acceptable ranges are measured.
Connect the Whip from the Junction Box
to the Master AC Micro-Grid Inverter;
align and twist to lock the collar.
This is the nal connection you should
make in your system.
Your system is ready to Turn On!
Step 10. Connect to Whip Connect these wires last.
Remove fuse block before
proceeding to protect the
system. Assume these connectors
are live during daylight hours.
www.sunbandit.us 877-NGE-4SUN (877-643-4786)
Sun Bandit® is a trademark-registered, patented product innovation of Next Generation Energy® © 2017 All Rights Reserved 5/2017

15
Step 11. Commission System
The System is ready to Turn On.
With the appropriate sized fuse in the fuse block, insert the fuse block into the
AC Disconnect.
The Monitor’s display will light up
to show production; this may take
several minutes.
With fuse installed,
Insert fuse block into
AC Disconnect.
www.sunbandit.us 877-NGE-4SUN (877-643-4786)
Sun Bandit® is a trademark-registered, patented product innovation of Next Generation Energy® © 2017 All Rights Reserved 5/2017
