Sun-Tech SVO-1 User manual

Operating Manual
Thank you for purchasing the SUNTEC products.
To ensure best results and use for a long time, it is
important that you read, understand and follow
these instructions in this manual carefully before
using.
This manual should be retained for future reference.
The following words and symbols, found in this
manual, alert you to hazards to the operator, service
personnel or the equipment. The words are defined
as follows; WARNING: This symbol refers to a
potential hazard which could result in serious injury
or death. CAUTION: This symbol refers to a potential
hazard or unsafe practice which may result in minor
or moderate injury or product or property damage.
Safety Precautions
However, indicated CAUTION may result in serious
condition by situation, it is important that you follow
the instruction in this manual carefully.
Ice Cream Sandwich Maker
SVO-1 SVO-2

！WARNINGWARNING
The products which
electric power is over
1.0kw must plag a
properly(grounded)
indlvidual receptacle.
It could result in fire
by ignition.
Do not cover the
product with a cloth
or plastic bag while
you are using it.
It could result in fire.
Ensure to unplug the
product while you
don't use it.
It could result in fire
or electric shock.
Do not touch the
product with wet
hands.
It could result in
electric shock.
Never clean the
product by sprinkling
water.
It could result in
electric shock or
product damage.
Do not use the
product outside in
the rain or wet area.
Use the product in a
light place.
It could result in
accident or burn if
you use it in a dark
room.
Do not use the
product near
flammable gas or
liquid.
It could result in
explosion or fire.
It could result in
electric shock.

！WARNINGWARNING
Never touch the plate
or around while the
product is working
because there are
very hot.
It could result in burn..
Beware of opening or
closing a lid while you
are using the product.
It could result in burn
or injury by closing a
lid.
Ensure to unplug and
get cold the product
when you move it.
It could result in
electric shock or
burn.
Must be plugged
directly into a
properly grounded.
(Never connect with
gas pipe)
It could result in
electric shock by
trouble or electric
leakage.
Do not overhaul,
repair or reconstruct
the product except
service personnel.
It could result in
ignition or injury by
unusual
performance.
Always clean the edge
of a plug when it is
dirty or dusty. It could result in fire.
！CAUTIONCAUTION
Nobody allows
touching the product
or code and keep
anyone away from
workshop except
workers.
It could result in injury
or burn.

！CAUTIONCAUTION
Always keep cleaning
the workshop.
It could result in
obstruction of safety
or efficient work.
Check the supply
cord regularly. If it is
damaged, it must be
replaced with a new
cord assembly
available from the
suppliers agent.
It could result in
electric shock or
ignition by short
circuit.
Place on a horizontal
and strong surface at
the desired location.
Set up with not
slipping down.
It could result in injury
or burn by the product
falls down.
Do not place near
water or oil.
It could result in
electrical shock, fire,
trouble or
transformation.
Stop to use the
product when it
appears smoke, smell
or other unusual
things.
Be sure to attach this
manual, if you hand
over the product.
It's necessary that new
user works safety and
uses correctly.
Contact with the sales
agent after turning off
the switch and pulling
out the plug for
ｐreventing trouble or
accident.
The connecting wire
should request
check and replace
from a maker or a
distributor
periodically.
It could result in
electric shock or
burn.

Parts DescriptionParts Description
Top Plate
Bottom Plate
Pilot Lamp
Switch/
Thermostat Timer
(hand-operated)
Description Ice Cream Sand Maker
Model SVO-1 SVO-2
Power 110/220V
110V 910W/220V 1090W 110V 1820W/220V 2180W
Measurements 255(W)×445(D)×190(H) 510(W)×445(D)×190(H)
Electricity
Consumption

Before First UseBefore First Use
・Place on a horizontal and strong surface at the desired location.
Set up with not slipping down.
・A minimum clearance of 5 cm is required between other equipments.
・Must be plugged directly into a properly grounded. Improper grounding
could result in electrical shock or accident. Never connect with gas pipe.
・Don't place near water or oil. It could result in electrical shock, fire,
accident or transformation.

SafetySafety
InstructionInstruction
1.Plug directly into a properly individual receptacle.
2.Set thermostat knb to scale 5. (When temperature
reaches set temperature, pilot lamp will be turned
off. It takes about 15-20min.)
3.After confirmed pilot lamp is turned off, put your
favorite ice-cream between breads for ice-sand,
close a lid.
4.Set timer 20-30 sec., after then, take it out.
※This plate is coated teflon, so-Never clean by hard
stuff.
※A life of Teflon plates depends on frequency or
conditions(the amount of sugar and oil) of using the
product, and these need re-coat Teflon at your cost.
・This product should not be cleaned with water.
It's very dangerous.
・Wipe off the product with a dry cloth and always
keep clean.
・If the plates don't work sufficiently, contact with
your agency. To change the plates is at your cost.
・A warranty should be retained carefully, it's writtn
a serial number of the product.
This warranty is valid only in Japan.
This warranty is invalid to use the product in other
countries.
・Should attach a warranty with the product when
you order the repair of the product under warranty.
・This manual should be retained carefully for future
reference.

2-8-12Mukojima, Sumida-ku, Tokyo
131-0033 Japan
Telephon No.81-3-6746-9797
Facsimile No.81-3-6746-9669
After Service After Service
This product is attached the warranty.
（Excluded Teflon plates）
■Limited Warranty
・Should read and retain the warranty
carefully.
This warranty is valid only in Japan.
This warranty is invalid to use the
product in other countries.
・The warranty runs for one year from
the date of purchasing.
■Request for Repair
・When the product doesn't work well,
contact with your agency and request
to check the product.
・If it's under warranty, should attach
the warranty with the product.
・When you order to repair, should
attach a memo which is written a
breakdown condition of the product.
SUNTEC CO., LTD
