LCD Screen 31.5-inch diagonal TFT Active Matrix
Resolution 1366 x 768
Aspect Ratio 16:9
Contrast Ratio 3000:1
H/V Viewing Angle 178oby 178o
Response Time 6.5 milliseconds
TV formats 1080i, 720p, 480i, 480p
Input Connectors:
RF
HDMI
Video Composite
Video Component
PC
Antenna/CATV (NTSC/ATSC/QAM)
HDMI Input x2
S-Video x1 and CompositeVideo x1, L/R Audio Inputs x1
YCbCr/YPbPr x2 and audio L/R channels x2
15-pin D-sub VGA plus Stereo Audio
Control Set RS232 Serial, Discrete IR Control, Concealed IRWindow
Audio Out SPDIF Audio, Analog Headphone Jack
Speakers 10-watt x 2 channels, water-resistant detachable speaker
module
Exterior Powder-coated aluminum
Input Power 100-240VAC, 50-60 Hz 2.5A Max
Operating Temp. -24oto 122oF. (-31oto 50oC.)*
Non-op. Temp.
(O-mode with
power applied)
-24oto 140oF. (-31oto 60oC.)
The non-operating temperature feature requires power to be
applied
Accessories Included Water-resistant remote control with lithium battery
Removable table top stand
TV Dimensions 32.07 in. W x 22.12 in. H (with speakers) 20.02 H w/o speakers)
x 6.29 in. D
Weight 37.5 lbs., 41.6 lbs w/speakers, 46 lbs w/ speakers and table
top stand
Shipping Dimensions 37.0 in. W x 31.0 in. H x 11.7 in. D
Shipping Weight 54 lbs.
Warranty One-year, in-factory, parts and labor
Optional Accessories
Specications
Side ViewFront View
SunBriteTV Model 3220HD
(All dimensions are in inches)
TV Dimensions are:
32.07 in. W x 22.12 in. H x 6.29 in. D
Height dimension with table top stand is 23.33 in.
Depth dimension with table top stand is 10.80 in.
TV with optional wall mount measures 9.008 in. when folded ush against the wall.
Model 3220HD
5069 Maureen Lane, Unit A lMoorpark, CA 93021
866.357.8688
www.sunbritetv.com
Designed with a durable All-weather Environmental Feature-Set, SunBriteTV televisions are
engineered for permanent outdoor installation:
• The extra bright 32-inch HD 1366 x 768 LCD screen is integrated into an all-weather exterior
thatprotectstheinternalcomponentsfromrain,dirt,insectsandscratches.
• Dual-fan Airow Systemkeepsthe unitcool and dryintemperatures upto 122 degreesF.
• Internal Thermostatically-Controlled Heater protects TV in temperatures as low as
-24 degrees F.
• Innovative Water-tight Cable Entry System with pass-through design keeps cables
dry and allows for easy hook-ups.
• Anti-Reective Window reduces glare, increases contrast and protects the LCD screen.
• TheDetachableSpeakerModule,controlbuttonsandremotecontrolarealsowater-resistant.
The Control Feature-Set maximizes system integration and programming security:
• RS232 and Discrete IR input connectors simplify control functions.
• The Concealed IR Emitter is located in the cable-entry compartment, thus
protecting it from the elements.
• Remote Control Lock-out prevents unauthorized users from changing the
programming.
• Sleep Mode automatically turns the TV to the O mode when the signal is removed,
and turns it back to On when the signal is restored.
SB-CM32A12 Ceiling mount with tilt. Includes adjustable extension column provides
3”-9”above unit to ceiling in 1”increments without disassembly, and 4”x 4”designer
ceiling plate. MeetsVESA standards.
SB-WM32 Articulating wall mount with tilt and swivel, and extends up to 11-7/8”from the wall.
MeetsVESA standards.
SB-DP2332X Deck/Planter pole (requires purchase of wall mount). Special order item.
SB-FMT32 RadioFMTM, transmits audio fromTV to FM radio
SB-DC322 OutdoorTV dust cover
*Temperature range is for operation in shaded location. Specications may be subject to change.
Patent pending. All rights reserved. (C) 2009 SunBriteTV® LLC Rev. 3220HD-0906
All-Weather Outdoor
LCD Television
